MK Diamond Products MK-100 SERIES User manual

03.2015
MK-100 TILE SAW
OWNER'S MANUAL
PARTS LIST &
OPERATING INSTRUCTIONS
www.mkdiamond.com
Caution: Read all safety and operating instructions
before using this equipment. This parts list MUST
accompany the equipment at all times.
Revision 106
Manual Part# 158192

38
1
2
3
4
5
6
7 8
9
11
12 13
14
26
19
20
21
22
23
25
16
17
18
24
10
27
15
MK-100 EXPLODED VIEW
MK-100 Tile Saw Part # 158189

39
MK-100 PARTS LIST
ITEM # DESCRIPTION PART # QTY.
1 WRENCH, TILE SAW NUT 15/16 134684 1
2 PAN, PLASTIC MK-101 150634 1
3 WASHER, FLAT, SAE, 3/8 150923 1
4 SCREW, HEX HD, 5/16-18X1 151743 2
5 WASHER, LOCK, SPLIT, 5/16 151747 2
6 WASHER, FLAT, SAE, 5/16 151754 2
7 SCREW, WING, 1/4-20X1/2 151888 1
8 WASHER, FLAT, SAE, 1/4 151915 1
9 WASHER, LOCK, SPLIT, 1/4 152591 1
10 CASTING, ACC BULLNOSE LRG-COMP 153201 1
11 MK-100 10X060X5/8 154380 1
12 CLAMP, HOSE, 1/4-1/2 FLOW 154394 1
13 SCREW, HEX HD, 1/4-20X1-1/4 157145 1
14 STOP, CUTTING HEAD 157728 1
15 ASSY, CUTTING HEAD, 100 158225 1
16 DRAIN PLUG, W/RING 159529 1
17 STRAP, 9" DRAIN PLUG 159530 1
18 RIP GUIDE, LARGE DIE CAST 159751 1
19 GUARD, SPLASH 160310 1
20 SHEET, WARNING LABLES, TILE SAW 166012 1
21 ADAPTER, 1/2 NPT X 1/4 BARB 168261 1
22 ASSY, FRAME & POST, 101 170476 1
23 HOSE, VINYL, 1/4X3/8 (6.0') 132951 1
24 PUMP, WATER 115V/60HZ UL/CSA 151271-VP 1
25 KNOB, TRI PLASTIC MK-660 1-1/2 156770-02 1
26 ASSY, DC TABLE, NO COVER, 101 158477-NC 1
27 KNOB, RUBBER, 1/4-20 X 3/4" LONG 159428-1 2
MK-100 Tile Saw Part # 158189

40
MK-100 EXPLODED VIEW
1
2
3
4
5
6
7
8
9
13
INCLUDED WITH ITEM 8
2 3
5
10
12
MK-100 Cutting Head Part # 158225

41
MK-100 PARTS LIST
ITEM # DESCRIPTION PART # QTY.
1 KEY, 3/16 SQ X 1-1/8 150344 1
2 WASHER, FLAT, SAE, 1/4 151915 4
3 SCREW, HEX HD, 1/4-20X3/4 152370 3
4 ASSY, BLADE GUARD, 101 152582 1
5 WASHER, LOCK, SPLIT, 1/4 152591 4
6 SCREW, HEX HD, TAP, 1/4-20X1 152676 1
7 SCREW, 5/16-18 X 3/8 SOCKET HEAD SET 157083 1
8 ASSY, SUB, CTTG HD 101 158191 1
9 BELT, 6J260 158194 1
10 PULLEY, 6J19 X 5/8 BORE 158199 1
11 CASTING, 101 BELT GUARD -COMP 158319-00 1
12 BRACKET, INNER BELTGUARD 158611 1
13 MTR, 1-1/2HP, 115V, 3400 RPM 168022G 1
MK-100 Cutting Head Part # 158225

42
MK-100 EXPLODED VIEW & PARTS LIST
1
2
3
4
5
6
ITEM # DESCRIPTION PART # QTY.
1 BAR, GUIDE PLATED MK-101 134759 1
2 SCREW, HEX HD, 5/16-18X1 151743 2
3 WASHER, LOCK, SPLIT, 5/16 151747 2
4 WASHER, FLAT, SAE, 5/16 151754 2
5 ASSY, WHEEL BRKT TSAW 151756 1
6 CASTING, TABLE MK-100 COMP 157660 1
Assy, Table Part # 158477-NC

43
MK-100 EXPLODED VIEW & PARTS LIST
1
2
3
4
5
6 10
9
8
7
ITEM # DESCRIPTION PART # QTY.
1 WASHER, LOCK, SPLIT, 3/8 150925 2
2 SHAFT, 10.63 PIVOT 153254 1
3 SCREW, SET, SOC, CUPT, 3/8-16X1/2 153710 1
4 PLATE, PRESSURE 155671 1
5 SCREW, 3/8-`16 X 2-1/2 HEX HEAD CAP 156030 2
6 CASTING, POST, DC, 101, MKRED-COMP 158438 1
7 POST COVER, PLASTIC 160157 1
8 SPACER, 5/8 X .385 X 1.4 160654 2
9 PLUG, PLASTIC, 1 SQ-14-20 GA 160727-1 2
10 FRAME, 10" TILE SAW, 18" RIP 168021 1
Assy, Table Part # 170476

44
1
2
3
4
Blade Guard
Part# 152582
ITEM # DESCRIPTION PART # QTY.
1 SCREW, 5/16 - 18 X 1/2 SOCKET HD SET 152607 3
2 ELBOW, 1/2MNPT X 1/4 BARB, 90 DEG 154652 1
3 TUBE, WATER 155389 2
4 CASTING, 101 BLD GUARD-DC-COMP 162481 1
ITEM # DESCRIPTION PART # QTY.
1 WHEEL, ROLLER 151799 1
2 NUT, HEX, 1/4-20 151893 1
3 SCREW, HEX HEAD 1/4-20 X 1-12" 151914 1
4 WASHER, 1/4 SAE FLAT 151915 1
5 BRACKET, ROLLER WHEEL 154021 1
MK-100 EXPLODED VIEW & PARTS LIST
Roller Wheel Assembly Part # 151756

45
Table Assembly
Part# 158191
1
2
3
4
22
5
7
8
9
21
10
11
12
13
14
15
16
17
18
19
20
23
1
10
ITEM # DESCRIPTION PART # QTY.
1 NUT, HEX, 5/16 - 18 101196 5
2 FLANGE, OUTER, 2 - 3/8 135830 1
3 NUT, HEX, 5/8-18 135848 1
4 BEARING, BALL, 17X40X12MM 137711 2
5 KEY, 3/16 SQ X 1-1/8 150344 1
6 WASHER, FLAT, SAE, 3/8 150923 1
7 SCREW, HEX HD, 5/16-18X1 151743 4
8 NUT, WING, NYLK, 5/16-18 151746 1
9 WASHER, LOCK, SPLIT, 5/16 151747 4
10 WASHER, FLAT, SAE, 5/16 151754 5
11 STRAP, 1 INCH, MOTOR ADJ. 152673 1
12 BUMPER, RUBBER, 1/2 DIA 152674 1
13 BOLT, 3/8-16 X 3-1/2 HEX HEAD TAP 153147 1
14 SCREW, 5/16-18 X 3/8 SOCKET HEAD SET 157083 1
15 PULLEY, 6J19 X 5/8 BORE 158199 1
16 BUTTON, SHAFT LOCK 158200 1
17 SPRING, BLADE SHAFT LOCK 158201 1
18 RING, 1/4 E-STYLE RETAINING 158202 1
19 SHAFT, BLADE 158222 1
20 CASTING, 10” CTTG HEAD - COMP 158224 1
21 SCREW, HEX HD, TAP, 5/16-18X3 162473 1
22 FLANGE, Ø 2-3/8 INNER 162758 1
23 SPACER, 9/16X5/16X1.5, PLAS 170824 1
MK-100 EXPLODED VIEW & PARTS LIST

46
MK-100 TILE SAW THEORY
Types of Cutting
There are two basic types of cutting-Dry or Wet. The choice of which type of blade to use
depends on:
• The requirements of the job
• The machine/tool utilizing the Diamond Blade
• The preference of the operator
In the case of DRY cutting, the overwhelming popularity and quantity of hand-held saws and the
exible nature of MK Diamond blades to professionally handle most ceramic, masonry, stone and
concrete materials, make the DRY cutting blade a very attractive tool. When using a DRY blade,
the user must be aware of distinct operating practices to ensure optimum performance. DRY cutting
blades require sufcient airow about the blade to prevent overheating of the steel core. This is best
accomplished by shallow, intermittent cuts of the material with periods of “free-spinning” (for several
seconds) between each cut, to maximize the cooling process.
For WET cutting applications, MK has the exact blade to compliment both the material to be cut and
the wet cutting machine to be used. During cutting operations, liberal amounts of water act as a
coolant to support the cutting effectiveness and longevity of the WET blade. Additionally, using water
adds to the overall safety of cutting operations by keeping the dust signature down.
KNOW ALL YOU CAN ABOUT THE MATERIAL YOU WISH TO CUT
Diamond blades do not really cut; they grind the material through friction. Diamond crystals, often
visible at the leading edge and sides of the rim/segment, remove material by scratching out par-
ticles of hard, dense materials, or by knocking out larger particles of loosely bonded abrasive mate-
rial. This process eventually cracks or fractures the diamond particle, breaking it down into smaller
pieces. As a result, a diamond blade for cutting soft, abrasive material must have a hard metal
matrix composition to resist this erosion long enough for the exposed diamonds to be properly uti-
lized. Conversely, a blade for cutting a hard, non-abrasive material must have a soft bond to ensure
that it will erode and expose the diamonds embedded in the matrix. These simple principles are the
foundation of “controlled bond erosion”
THEORY OF DIAMOND BLADES

47
ITEM NUMBER DESCRIPTION
1. MK-200, 10 x 5/8 Arbor
2.
MK-215, 10 x 5/8 Arbor
3.
MK-315, 10 x 5/8 Arbor
4. Dual 45°Flat Angle Guide
45°Bullnose Miter
90°Protractor
Dressing Stone
Ground Fault Circuit Interrupter
5.
6.
7.
8.
9.
10.
Folding Stand
Folding Stand with Casters
137166 Premium grade Diamond Blade for
smooth, chip-free cutting on tile.
128074 Supreme grade diamond blade for hard
materials
153252 Supreme super hi-rim diamond blade
134577-MK
153201-MK
134569-MK
152792
152610
168244
169243
MK-10O TILE SAW ACCESSORIES

48
MK-100 TILE SAW ORDERING & RETURN
ORDERING INFORMATION
You may order MK Diamond products through your local MK Diamond distributor or, you may order
direct from MK Diamond.
When ordering direct from MK Diamond, please have the following information ready before calling:
• The Model Number of the saw
• The Serial Number of the saw
• Where the saw was purchased and when
• The Part Number for the part(s) being ordered
• The Part Description for the part(s) being ordered
NOTE: There is a $25.00 minimum order when ordering direct from MK Diamond. A $6.00 charge will
be added to orders having a net billing value under $50.00. All purchases must be made using VISA,
MasterCard or American Express.
All parts may be ordered by calling toll free to – 800 421-5830 or 310 539-5221 and asking for
Customer Service. For technical questions, call – 800 474-5594.
RETURN MATERIALS POLICY
To expedite the service relative to the return of a product purchased through MK Diamond, please
observe the following:
NOTE: When returning all items, they must have been purchased within the previous twelve (12)
months.
• Have the Model Number of the saw
• Have the Serial Number of the saw
• Have the location of where the saw was purchased
• Have the date when the saw was purchased
• Contact Customer Service for approval to return the item(s)
• Obtain a Returned Goods Number (RGA) authorizing the return
• Follow the packaging instructions in the following section
• Ensure your item(s) are prepaid to the destination
For returned items, call toll free to – 800 421-5830 or 310 539-5221 and ask for Customer Service.
For technical questions, call – 800 474-5594 or 310 257-2845.
PACKAGING INSTRUCTIONS
• Remove the Cutting Head and Support Angle Assembly
• Dry the saw before shipping
• When packing, include the following: Saw, Diamond Blade, Blade Guard and Support Angle
Assembly and Adjustable Cutting Guide (Other Accessories are not required)
• Package the unit in its original container or one of comparable size (do not ship the unit partially
exposed)
• Ensure all parts are secured in the packaging to prevent moving
AUTHORIzED SERVICE CENTERS
For quicker repair time, you may contact MK Diamond Customer Service, toll free, at 800 421-5830
or 310 539-5221 for the Authorized Service Center closest too you or visit our web site at
www.mkdiamond.com. For technical questions, call – 800 474-5594.

49
MK-100 TILE SAW CONTACT & WARRANTY
CONTACT:
Please contact MK Diamond Products, Inc. Customer Service Department with any questions you
might have regarding distributors, parts or service.
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]
Customer Service Hours: Monday through Friday, 6AM-4PM PST
MK Diamond Products, Inc.
1315 Storm Parkway
Torrance, CA 90501
© COPYRIGHT 2014, MK DIAMOND PRODUCTS, INC. ALL RIGHTS RESERVED.
The MK Diamond logo is a registered trademark of MK Diamond Products, Inc. and may not be used,
reproduced, or altered without written permission. All other trademarks are the property of their re-
spective owners and used with permission.
MK Diamond may have patents, patent applications, trade marks, copyrights of other intellectual
property right covering this product in this document.
This manual MUST accompany the equipment at all times. This manual is considered a permanent
part of the equipment and should remain with the unit if resold.
The information and specications included in this publication were in effect at the time of approval for
printing.
MK DIAMOND PRODUCTS, INC. will guarantee every machine they build, to be free from defects in
material and workmanship for (1) one year from date of purchase. The obligation of MK DIAMOND
PRODUCTS, INC. under this warranty is limited to the repair or replacement of any parts which,
under normal use, prove to be defective in material or workmanship. The parts involved or the unit
in question should be returned to MK DIAMOND PRODUCTS, INC. or to a point designated by us,
transportation prepaid.
This warranty does not obligate us to bear the cost of labor or transportation charges in connection
with replacement or repair of defective parts. Likewise, it shall NOT apply to any unit which has been
subjected to misuse, neglect or accident. This warranty does NOT apply to any machine which has
been repaired or altered outside our factory.
This warranty does NOT obligate MK DIAMOND PRODUCTS, INC., with respect to items not of our
manufacture, such as engines, motors, hydraulics, etc., which are subject to their own guarantees and
warranties.
We shall in no event be liable for consequential damages or contingent liabilities arising out of failure
of any equipment or parts to operate properly.
MK DIAMOND PRODUCTS, INC. LIMITED WARRANTY

50
NOTES

51
NOTES

MK Diamond Products, Inc.
1315 Storm Parkway
Torrance, CA 90501
Toll-Free: [phone]
Phone: [phone]
Fax: [phone]
www.mkdiamond.com
MK-100 TILE SAW
OWNER'S MANUAL & OPERATING INSTRUCTIONS
