ML Accessories FL8ABK Instruction Manual

INSTALLATION & MAINTENANCE MANUAL
FL8ABK / FL8AW / FL16ABK / FL16AW

These instructions should be read carefully and retained after installation by the end user for
future reference and maintenance.
These instructions should be used to aid installation of the following products:
FL8ABK / FL8AW / FL16ABK / FL16AW
GENERAL INSTRUCTIONS
•This product must be installed in accordance with the latest edition of the IEE Wiring Regulations (BS7671)
and current Building Regulations. If in any doubt, consult a qualified electrician
• Please isolate mains prior to installation or maintenance
• Check the total load on the circuit (including when this luminaire is fitted) does not exceed the rating of the
circuit cable, fuse or circuit breaker
• Please note the IP (Ingress Protection) rating of this product when deciding the location for installation
• This product is Class II double insulated
• This product is IP55 rated
SAFETY
INSTALLATION
• Provide power to the required point of installation (refer to BS7671 for correct cabling methods). Suitable IP
rated junction boxes should be used where required
• Remove the rear panel with the aid of a flat-head screwdriver (see Fig. 1)

INSTALLATION & MAINTENANCE MANUAL
These instructions should be read carefully and retained after installation by the end user for future reference
and maintenance.
These instructions should be used to aid installation of the following products:
FL8ABK / FL8AW / FL16ABK / FL16AW
SAFETY
•This product must be installed in accordance with the latest edition of the IEE Wiring Regulations
(BS7671) and current Building Regulations. If in any doubt, consult a qualified electrician
•Please isolate mains prior to installation or maintenance
•Check the total load on the circuit (including when this luminaire is fitted) does not exceed the rating of
the circuit cable, fuse or circuit breaker
•Please note the IP (Ingress Protection) rating of this product when deciding the location for installation
•This product is Class II double insulated
•This product is IP55 rated
INSTALLATION
•Provide power to the required point of installation (refer to BS7671 for correct cabling methods).
Suitable IP rated junction boxes should be used where required
•Remove the rear panel with the aid of a flat-head screwdriver (see Fig. 1)
Fig. 1
•Mark the location of the fixing holes and drill the holes ensuring not to infringe with any gas/water pipes
or electrical cables
•Feed the mains cable through the rubber grommet to retain IP rating, and secure the baseplate to the
surface
•Connect the luminaire to the mains supply ensuring the correct polarity is observed: L - Live (brown), N
- Neutral (blue). The earth terminal is non-functional and only provided for convenience (see Fig. 2)
Fig. 2
•Reattach the luminaire to the rear panel (see Fig. 3)
INSTALLATION & MAINTENANCE MANUAL
These instructions should be read carefully and retained after installation by the end user for future reference
and maintenance.
These instructions should be used to aid installation of the following products:
FL8ABK / FL8AW / FL16ABK / FL16AW
SAFETY
•This product must be installed in accordance with the latest edition of the IEE Wiring Regulations
(BS7671) and current Building Regulations. If in any doubt, consult a qualified electrician
•Please isolate mains prior to installation or maintenance
•Check the total load on the circuit (including when this luminaire is fitted) does not exceed the rating of
the circuit cable, fuse or circuit breaker
•Please note the IP (Ingress Protection) rating of this product when deciding the location for installation
•This product is Class II double insulated
•This product is IP55 rated
INSTALLATION
•Provide power to the required point of installation (refer to BS7671 for correct cabling methods).
Suitable IP rated junction boxes should be used where required
•Remove the rear panel with the aid of a flat-head screwdriver (see Fig. 1)
Fig. 1
•Mark the location of the fixing holes and drill the holes ensuring not to infringe with any gas/water pipes
or electrical cables
•Feed the mains cable through the rubber grommet to retain IP rating, and secure the baseplate to the
surface
•Connect the luminaire to the mains supply ensuring the correct polarity is observed: L - Live (brown), N
- Neutral (blue). The earth terminal is non-functional and only provided for convenience (see Fig. 2)
Fig. 2
•Reattach the luminaire to the rear panel (see Fig. 3)
Fig. 1
Fig. 2
• Mark the location of the fixing holes and drill the holes ensuring not to infringe with any gas/water pipes or
electrical cables
• Feed the mains cable through the rubber grommet to retain IP rating, and secure the baseplate to the
surface
• Connect the luminaire to the mains supply ensuring the correct polarity is observed: L - Live (brown), N -
Neutral (blue). The earth terminal is non-functional and only provided for convenience (see Fig. 2)
• Reattach the luminaire to the rear panel (see Fig. 3)

SENSOR SETTINGS
An initial verification of the detection area can be carried out by turning the TIME dial to the TEST setting (see
Fig. 4). In test mode the sensor is initially activated for approximately 1 minute, then for three seconds every
time motion is detected.
Fig. 3
•See below for sensor settings
•Switch on and check for correct operation
SENSOR SETTINGS
An initial verification of the detection area can be carried out by turning the TIME dial to the TEST setting (see
Fig. 4). In test mode the sensor is initially activated for approximately 1 minute, then for three seconds every
time motion is detected.
Fig. 4
Once the detection area is verified, the sensor duration can be set via the TIME dial - from a minimum of 10
seconds to a maximum of 15 minutes. The lux setting can be adjusted via the LUX dial - from a minimum of 5
lux (indicated by the moon icon) to daylight (indicated by the sun icon). When set to daylight, the sensor will
activate when movement is detected regardless of the ambient light level.
The field of detection can be adjusted left or right by rotating the ring around the PIR (see Fig. 5). Positions A,
B, or C can be set, or any position in between.
Fig. 5
Specific zones within the detection area can be blocked if required by using the blanking inserts provided (see
Fig. 6). Each section of blanking insert covers a zone of a 300angle.
Fig. 3
• See below for sensor settings
• Switch on and check for correct operation
Fig. 3
•See below for sensor settings
•Switch on and check for correct operation
SENSOR SETTINGS
An initial verification of the detection area can be carried out by turning the TIME dial to the TEST setting (see
Fig. 4). In test mode the sensor is initially activated for approximately 1 minute, then for three seconds every
time motion is detected.
Fig. 4
Once the detection area is verified, the sensor duration can be set via the TIME dial - from a minimum of 10
seconds to a maximum of 15 minutes. The lux setting can be adjusted via the LUX dial - from a minimum of 5
lux (indicated by the moon icon) to daylight (indicated by the sun icon). When set to daylight, the sensor will
activate when movement is detected regardless of the ambient light level.
The field of detection can be adjusted left or right by rotating the ring around the PIR (see Fig. 5). Positions A,
B, or C can be set, or any position in between.
Fig. 5
Specific zones within the detection area can be blocked if required by using the blanking inserts provided (see
Fig. 6). Each section of blanking insert covers a zone of a 300angle.
Fig. 4

Once the detection area is verified, the sensor duration can be set via the TIME dial - from a minimum of 10
seconds to a maximum of 15 minutes. The lux setting can be adjusted via the LUX dial - from a minimum of
5 lux (indicated by the moon icon) to daylight (indicated by the sun icon). When set to daylight, the sensor will
activate when movement is detected regardless of the ambient light level.
The field of detection can be adjusted left or right by rotating the ring around the PIR (see Fig. 5). Positions A,
B, or C can be set, or any position in between.
Fig. 3
•See below for sensor settings
•Switch on and check for correct operation
SENSOR SETTINGS
An initial verification of the detection area can be carried out by turning the TIME dial to the TEST setting (see
Fig. 4). In test mode the sensor is initially activated for approximately 1 minute, then for three seconds every
time motion is detected.
Fig. 4
Once the detection area is verified, the sensor duration can be set via the TIME dial - from a minimum of 10
seconds to a maximum of 15 minutes. The lux setting can be adjusted via the LUX dial - from a minimum of 5
lux (indicated by the moon icon) to daylight (indicated by the sun icon). When set to daylight, the sensor will
activate when movement is detected regardless of the ambient light level.
The field of detection can be adjusted left or right by rotating the ring around the PIR (see Fig. 5). Positions A,
B, or C can be set, or any position in between.
Fig. 5
Specific zones within the detection area can be blocked if required by using the blanking inserts provided (see
Fig. 6). Each section of blanking insert covers a zone of a 300angle.
Fig. 5

WARRANTY
This product has a warranty of 3 years from date of purchase. Failure to install this product in accordance with
the current edition of the IEE Wiring Regulations (BS7671), improper use, or removal of the batch code will
invalidate the warranty. If this product should fail within its warranty period, it should be returned to the place
of purchase for a free of charge replacement. ML Accessories does not accept responsibility for any installation
costs associated with the replacement product. Your statutory rights are not affected. ML Accessories reserve
the right to alter product specification without prior notice.
GENERAL
The light source of this luminaire is not replaceable; when the light source reaches its end of life the whole
luminaire should be replaced.
Clean the external surfaces with a damp cloth using a mild solution of detergent and warm water only, do not
use aggressive cleaning products or solvents which may damage the product.
Do not use any source of high-pressure washers to maintain or clean this luminaire.
This product is non-dimmable.
This product should be recycled in the correct manner when it reaches the end of its life. Check local authorities
for where facilities exist.
WARNING
This product must be disconnected from the circuit if subjected to any high voltage or insulation resistance
testing. Irreparable damage will occur if this instruction is not followed.
This product is not suitable for installation in or near a coastal or marine environment

Fig. 6
WARNING
This product must be disconnected from the circuit if subjected to any high voltage or insulation resistance
testing. Irreparable damage will occur if this instruction is not followed.
This product is not suitable for installation in or near a coastal or marine environment.
GENERAL
The light source of this luminaire is not replaceable; when the light source reaches its end of life the whole
luminaire should be replaced.
Clean the external surfaces with a damp cloth using a mild solution of detergent and warm water only, do not
use aggressive cleaning products or solvents which may damage the product.
Do not use any source of high-pressure washers to maintain or clean this luminaire.
This product is non-dimmable.
This product should be recycled in the correct manner when it reaches the end of its life. Check local authorities
for where facilities exist.
WARRANTY
This product has a warranty of 3 years from date of purchase. Failure to install this product in accordance with
the current edition of the IEE Wiring Regulations (BS7671), improper use, or removal of the batch code will
invalidate the warranty. If this product should fail within its warranty period, it should be returned to the place of
purchase for a free of charge replacement. ML Accessories does not accept responsibility for any installation
costs associated with the replacement product. Your statutory rights are not affected. ML Accessories reserve
the right to alter product specification without prior notice.
