Mobatime EuroTime Center ETC 12 User manual

© MOBATIME BE-800337.22
INSTRUCTION MANUAL
EuroTime Center ETC
Master Clock

© MOBATIME 2 / 96 800337.22
Certification of the Producer
STANDARDS
The Euro Time Center ETC was developed and produced in accordance with the EU Guidelines:
2014 / 30 / EU EMC
2014 / 35 / EU LVD
2008 / 57 / EU Railway
2011 / 65 / EU RoHS
1907 / 2006 REACH
References to the Instruction Manual
1. The information in this Instruction Manual can be changed at any time without notice.
The current version is available for download on www.mobatime.com.
2. This Instruction Manual has been composed with the utmost care, in order to explain all details in
respect of the operation of the product. Should you, nevertheless, have questions or discover errors in
this Manual, please contact us.
3. We are not liable for any direct or indirect damages which could occur when using this Manual.
4. Please read the instructions carefully and only start setting-up the product, after you have correctly
understood all the information for the installation and operation.
5. The installation must only be carried out by skilled staff.
6. It is prohibited to reproduce, to store in a computer system or to transfer this publication in a way or
another, even part of it. The copyright remains with all the rights with BÜRK MOBATIME GmbH,
D-78026 VS-Schwenningen and MOSER-BAER AG – CH 3454 Sumiswald / SWITZERLAND.

© MOBATIME 3 / 96 800337.22
Overview
1Safety.........................................................................................................................6
2Maintenance..............................................................................................................9
3General Information: Introduction........................................................................10
4Installation ..............................................................................................................12
5Time Administration Concept ............................................................................... 13
6Menu-driven Operation..........................................................................................14
7Power Supply.......................................................................................................... 16
8External Time Sources...........................................................................................19
9Time + Date – Setting and Configuring the Master Clock Time.........................21
10Synchronization – Configuration of the External Time Reference....................23
11State – Reception Quality and Alarms..................................................................27
12Slave clock lines.....................................................................................................31
13Serial communication............................................................................................44
14Relays......................................................................................................................50
15Switch Program......................................................................................................51
16Device Supervision ................................................................................................59
17Data Manager – Configurations and Files............................................................60
18Miscellaneous.........................................................................................................64
19Maintenance............................................................................................................66
ANNEX
AConnection Diagrams ............................................................................................68
BDefault Configuration............................................................................................. 77
CTime Zone Table.....................................................................................................79
DAlarm List................................................................................................................81
EDefinitions of Protocols.........................................................................................82
FConnection of GPS 3000 and GPS 4500 Satellite Receiver................................88
GTechnical Data........................................................................................................89
GIndex........................................................................................................................92
HConnection Table (to be filled-in)..........................................................................94

© MOBATIME 4 / 96 800337.22
Table of Content
1 Safety...............................................................6
1.1 Safety instructions.................................. 6
1.2 Symbols and Signal Words used in this
Instruction Manual.................................. 6
1.3 Intended Use.......................................... 6
1.4 Observe operating safety! ...................... 7
1.5 Consider the installation site! ................. 7
1.6Please observe the electromagnetic
compatibility! ................................................. 7
1.7Pay attention to the instructions for the
connection of the power supply..................... 8
2 Maintenance....................................................9
2.1 Troubleshooting: Repairs ....................... 9
2.2 Cleaning ................................................. 9
2.3 Disposing................................................ 9
3General Information: Introduction........10
3.1 Scope of Delivery ................................. 10
3.2 Technical data...................................... 10
3.3 Device Designation in this Manual....... 11
3.4 Device Description ............................... 11
3.5 Device types......................................... 11
4Installation .............................................12
4.1 Connections ......................................... 12
4.2 Checklist for Start-up............................ 12
5Time Administration Concept..............13
6Menu-driven Operation......................... 14
6.1 Definitions............................................. 14
6.2 Keypad Lock......................................... 14
6.3 Menu Navigation .................................. 15
7 Power Supply......................................... 16
7.1 Connection Terminals .......................... 16
7.1.1 Mains Power Supply....................................... 16
7.1.2 External DC – Power Supply.......................... 17
7.1.3 Passive Running Reserve Battery.................. 17
7.1.4 Active Running Reserve Battery .................... 18
8External Time Sources.......................... 19
8.1 General................................................. 19
8.2 DCF – Radio Time Receiver ................ 19
8.3 MSF – Radio Time Receiver ................ 19
8.4 GNSS 3000 .......................................... 19
8.5 GPS / GNSS 4500................................ 19
8.6 Minute Impulses ................................... 19
8.7 Serial Time Telegram (RS 232 / RS
422) ...................................................... 20
9Time + Date – Setting and Configuring
the Master Clock Time.......................... 21
9.1 Manual Setting of Time and Date......... 21
9.1.1Time ............................................................... 21
9.1.2Date............................................................. 21
9.2 Time Zone ............................................ 21
9.3 Quartz Correction................................. 21
9.4 Time Correction.................................... 21
9.5 DCF Time Code Output ....................... 22
10Synchronization – Configuration of the
External Time Reference ...................... 23
10.1 Time Source......................................... 23
10.2 Interface ............................................... 23
10.3Baudrate Mode (only with CAS
synchronisation).......................................... 24
10.4Baudrate (only with CAS synchronisation) .. 24
10.5 Time Zone.............................................24
10.6 Synchronisation Only............................24
10.7 Alarm Timeout.......................................25
10.8System Address (only with CAS
synchronisation).......................................... 25
10.9 State (only with CAN synchronisation) .25
10.10IP address (only with CAN synchronisation)25
10.11Subnet mask (only with CAN
synchronisation).......................................... 25
10.12Gateway (only with CAN synchronisation) .. 25
10.13NTP server (only with CAN
synchronisation).......................................... 26
10.14DHCP (only with CAN synchronisation) ...... 26
11State – Reception Quality and Alarms.27
11.1 Reception Quality..................................27
11.1.1 Telegram Quality ............................................ 27
11.1.2 Signal Quality ................................................. 27
11.2Alarms......................................................... 28
11.2.1 Alarm overview............................................... 28
11.2.2 Alarm Display ................................................. 29
11.2.3 Reset stored alarms ....................................... 29
11.2.4 Alarm masking................................................ 29
11.2.5 Alarm contact ................................................. 30
12Slave clock lines....................................31
12.1 Line type / Terminals: ...........................31
12.2 Active Line Current Supervision ...........32
12.3 Current Allocation .................................33
12.4 Impulse Line..........................................34
12.4.1 Change of the Line State................................ 34
12.4.2 Line Time........................................................ 34
12.4.3 Line Date ........................................................ 35
12.4.4 Line Mode....................................................... 35
12.4.5 Time Zone ...................................................... 35
12.4.6 Impulse Length and Impulse Pause ............... 36
12.4.7 Catch-up Periodicity ....................................... 36
12.5 DCF Output...........................................37
12.5.1 Change of the Line State................................ 37
12.5.2Line Time and Date ........................................ 37
12.5.3Time Zone ...................................................... 37
12.5.4DCF Mode ...................................................... 38
12.6 Combined DCF-Impulse Output ...........39
12.6.1Description ..................................................... 39
12.6.2 Change of the Line State................................ 40
12.6.3Line Time........................................................ 41
12.6.4Line Date ........................................................ 41
12.6.5Time Zone ...................................................... 41
12.6.6Line Mode....................................................... 41
12.7 MOBALine.............................................42
12.7.1Description ..................................................... 42
12.7.2Change of the Line State................................ 42
12.7.3Line Time and Date ........................................ 42
12.7.4Line Mode....................................................... 42
12.7.5Time Zone ...................................................... 43
12.7.6Switch Program and World Time Function
disable/enable ................................................ 43
12.7.7Definition of the World Time Zones ................ 43
13Serial communication............................44
13.1 General Description ..............................44
13.2 Parameters / Operating modes.............46
13.2.1Line Time and Date ........................................ 46
13.2.2Line Mode....................................................... 46
13.2.3Time Zone........................................47
13.2.4 Communication Parameters........................... 48
13.2.5 Telegram Format............................................ 48

© MOBATIME 5 / 96 800337.22
13.2.6 Telegram Send Offset .................................... 48
13.2.7 Period ............................................................. 49
14Relays.....................................................50
14.1 Switching States................................... 50
14.2 Channel Assignment ............................ 50
15Switch Program..................................... 51
15.1 General Description.............................. 51
15.2 Simplified channel relay operation ....... 52
15.3 Week Programs.................................... 53
15.3.1 Description ..................................................... 53
15.3.2 Insert a New Line Entry .................................. 54
15.3.3 Edit a Line Entry............................................. 54
15.3.4 Delete a Line Entry......................................... 54
15.4 Channel Programs ............................... 54
15.4.1 Description ..................................................... 54
15.4.2 Insert a New Line Entry .................................. 55
15.4.3 Edit a Line Entry............................................. 56
15.4.4 Delete a Line Entry......................................... 56
15.5 Channel Monitor ................................... 56
15.5.1 Description ..................................................... 56
15.6 Control Inputs ....................................... 57
15.7 Example of a Switch Program.............. 58
16Device Supervision...............................59
17Data Manager – Configurations and
Files........................................................60
17.1Administration of the Configuration Data..... 60
17.2 File Download in General..................... 60
17.3 System Software .................................. 61
17.4 Switch Program .................................... 61
17.4.1Download Switch Program from a PC............ 61
17.4.2Delete Switch Program................................... 61
17.4.3Read Switch Program from ETC (upload)..... 62
17.5 Season Table ....................................... 62
17.5.1Download Season Table from a PC ............... 62
17.6 Default Configuration............................ 62
17.7 User Configuration ............................... 62
17.7.1Save ............................................................... 63
17.7.2Restore........................................................... 63
17.8 Remote Download ................................63
18Miscellaneous ........................................64
18.1 Language ..............................................64
18.2 Display ..................................................64
18.2.1Contrast.......................................................... 64
18.2.2Backlight......................................................... 64
18.3 Versions ................................................64
18.3.1 System Software ............................................ 64
18.3.2 Core Print PCB............................................... 65
18.3.3 Basis Print PCB.............................................. 65
18.3.4 Season table .................................................. 65
18.4 Power supply ........................................65
19Maintenance...........................................66
19.1 Troubleshooting ....................................66
19.2 Reset with Hotkey-Combination ...........67
ANNEX
AConnection Diagrams............................68
BDefault Configuration............................77
CTime Zone Table.....................................79
DD Alarm List............................................81
EDefinitions of Protocols ........................82
E.2NMEA 0183 – Protocol................................ 82
E.3IF482 – Telegram........................................ 83
E.4DIEM – Telegram........................................ 84
E.5SINEC – Telegram...................................... 85
E.6H7001 – Telegram ...................................... 86
E.7BUS485 – Telegram.................................... 87
FConnection of GPS 3000 and GPS 4500
Satellite Receiver...................................88
GTechnical Data........................................89
HIndex........................................................92
IConnection Table (to be filled-in).........94

© MOBATIME 6 / 96 800337.22
1 Safety
1.1 Safety instructions
Read this chapter and the entire instruction manual carefully and follow all instructions
listed. This is your assurance for dependable operations and a long life of the device.
Keep this instruction manual in a safe place to have it handy every time you need it.
1.2 Symbols and Signal Words used in this Instruction Manual
Danger!
Please observe this safety message to avoid electrical shock!
There is danger to life!
Warning!
Please observe this safety message to avoid bodily harm and injuries!
Caution!
Please observe this safety message to avoid damages to property and
devices!
Notice!
Additional information for the use of the device.
Important information in the Manual!
This information must be followed!
1.3 Intended Use
The Euro Time Center, in this manual identified as ETC,is a master clock for the use
in small to medium clock systems. It can read the time from DCF or GPS (e.g. from
GPS 4500).
The ETC can operate as a master clock for a self-setting MOBALine clock line (with
switching function for clock lighting, switching program, and world time function) or it
can drive a line of impulse clocks. The ETC 24 has 2 such lines. The ETC 12 can only
drive impulse clocks.
For additional functions, see the device descriptions in Chapter 3.4.
!
!

© MOBATIME 7 / 96 800337.22
ETC xx (wall mounting version):
The wall mounting version of the ETC should be mounted with the enclosed DIN rail or
on an existing DIN rail into a closed cabinet. Operate the device only in installed
condition. Access to the device only for skilled persons allowed.
ETC xxR (rack version)
The device is designed for 19" racks and intended to be installed in a 19" cabinet.
Operate the device only in installed condition.
1.4 Observe operating safety!
Never open the housing of the device! This could cause an electric short or even a fire,
which would damage your device. Do not modify your device!
When the device is powered on, it never must be opened or accessed by the hands or
any objects through existing openings at the device.
The device is not intended for use by persons (including children) with limited physical,
sensory, or mental capacities or a lack of experience and/or knowledge.
Keep packaging such as plastic films away from children. There is the risk of
suffocation if misused.
1.5 Consider the installation site!
To avoid any operating problems, keep the device away from moisture and avoid dust,
heat, and direct sunlight. Do not use the device outdoors.
By operating the device, the heat sinks attached to the sides get warm.
Make sure there is enough air circulation for the heat to dissipate.
The device shuts off when overheated. After it has regained its normal operating
temperature, it will restart automatically. The settings are saved.
Danger! Make sure
that you wait before using the device after any transport until the device has
reached the ambient air temperature. Great fluctuations in temperature or
humidity may lead to moisture within the device caused by condensation, which
can cause a short.
1.6 Please observe the electromagnetic compatibility!
This device complies with the requirements of the EMC and the Low-voltage Directive.
!
Caution!
!
Caution!
!
Caution!

© MOBATIME 8 / 96 800337.22
1.7 Pay attention to the instructions for the connection of the power supply
The connections are described in appendix "A Connection Diagrams".
Danger! Absolutely pay attention:
Mounting, installation, commissioning and repairs of electrical devices must only be
carried out by a licensed electrician. While the national installation regulations must
be adhered.
For the mains power input a 3 wire mains power cable (2P + PE) with a cross
section of at least 0.75 mm2has to be used.
For each power supply connection ( Mains ) / ( DC In ) / ( Bat + ) two fuses of 10A
(13A) slow has to be provided (in both lines).
The used fuses for the DC- and battery supply have to be approved for DC.
Each power supply connection ( Mains ) / ( DC In ) / ( Bat + ) needs to be realized
with an all-pole disconnection device, which is installed near to the device
mentioned in this manual, which is clearly labeled and good accessible.
Before working on a device or on the electrical installations the corresponding
circuits have to be switched off and secured against uncontrolled power on.
In case more than one supply voltage is used, including battery power supply, all of
them have to be disconnected before starting any maintenance work.

© MOBATIME 9 / 96 800337.22
2 Maintenance
2.1 Troubleshooting: Repairs
Please read carefully chapter "19 Maintenance" if your device does not work properly.
If you cannot rectify the problems, contact your supplier from whom you have
purchased the device.
Any repairs must be carried out at the manufacturer’s plant.
Disconnect the power supply immediately and contact your supplier, if …
liquid has entered your device
the device does not properly work and you cannot rectify this problem yourself.
2.2 Cleaning
Please make sure that the device remains clean especially in the area of the
connections, the control elements, and the display elements.
Clean your device with a damp cloth only.
Do not use solvents, caustic, or gaseous cleaning substances.
2.3 Disposing
Device
At the end of its lifecycle, do not dispose of your device in the regular household
rubbish. Return your device to your supplier who will dispose of it correctly.
Batteries
The user is legally obliged (battery regulation) to return used batteries and
accumulators. Disposing used batteries in the household waste is prohibited!
Batteries/ accumulators containing hazardous substances are marked with the
crossed-out bin. The symbol indicates, that this product is forbidden to be disposed in
the household waste. Below the chemical shortcuts for the contained hazardous
substances of this product are mentioned:
Ag2O= Silver oxide, Cd = Cadmium, Hg = Mercury, Li = Lithium, Li-Ion = Li-ion, NiCD
= Nickel-cadmium, NiMH = Nickel-metal-hybrid, Pb = Lead, ZnMnO2= tin-manganese
dioxide.
You can return used batteries / accumulators free of charge to any collecting
point of your local authority or stores, where batteries / accumulators are sold.
Consequently you comply with your legal obligations and contribute to environmental
protection!
Packaging
Your device is packaged to protect it from damages during transport.
Packaging is made of materials that can be disposed of in an environmentally friendly
manner and properly recycled.

© MOBATIME 10 / 96 800337.22
3 General Information: Introduction
3.1 Scope of Delivery
Please check your delivery for completeness and notify your supplier within 14 days upon
receipt of the shipment, if it is incomplete.
The package you received contains:
ETC 12 / 14 / 24 (wall-mounted version)
Mounting set for wall mounting consisting of:
- 1 DIN rail
- 2 screws
- 2 plastic dowel
All types ETC 12R / 14R / 24R (rack versions)
Mounting set for rack mounting consisting of:
- 4 pcs nuts for 19" housing
- 4 screws M6 for the nuts
- 4 plastic discs for screws M6
2 pcs mounting tools with spring terminals
Only ETC 12R (rack versions)
Connector set
- spring terminal 3-pole gray for power supply
- spring terminal 6-pole orange
- spring terminal 5-pole orange
- spring terminal 2-pole orange
- 2 spring terminal 3-pole orange
Only ETC 14R (rack versions)
Connector set
- spring terminal 3-pole gray for power supply
- spring terminal 10-pole orange
- spring terminal 5-pole orange
- spring terminal 2-pole orange
- 4 spring terminal 3-pole orange
Only ETC 24R (rack versions)
Connector set
- spring terminal 3-pole gray for power supply
- spring terminal 12-pole orange
- spring terminal 8-pole orange
- spring terminal 4-pole orange
- 4 spring terminal 3-pole orange
3.2 Technical data
See Appendix H Technical Data.

© MOBATIME 11 / 96 800337.22
3.3 Device Designation in this Manual
This instruction manual is for the master clocks ETC 12, ETC 14, ETC 24 (wall-mounted
versions) and ETC 12R, ETC 14R, ETC 24R (rack versions). Below both models will be
referred to as ETC and only for the special features of the individual models the complete
designation is used.
3.4 Device Description
The EuroTime Center ETC operates conventional clock systems with impulse controlled
slave clocks as well as modern, self-setting MOBALine installations. Easy and intuitive
operation control due to ETC's intelligible user interface. ETC's power relays control light,
heating, signalling-bells and other devices by weekly periodic and/or date related
programs. Absolute precision of ETC's internal clock can be achieved by synchronisation
to an external time-reference such as DCF 77 or GPS.
3.5 Device types
There are three different models of the EuroTime Center ETC available. Each of them is
available in a plastic housing for wall mounting or in a 19” wide metal cabinet for rack
mounting.
Model: Main Features: Product No.:
ETC 12 1 slave clock line (impulse / DCF), 2 switching
contacts 201 671
ETC 14 1 slave clock line (impulse / DCF / MOBALine), 4
switching contacts 201 672
ETC 24 2 slave clock lines (impulse / DCF / MOBALine),
4 switching contacts 201 673
ETC 12R 1 slave clock line (impulse / DCF), 2 switching
contacts, 19” rack housing 201 674
ETC 14R 1 slave clock line (impulse / DCF / MOBALine), 4
switching contacts, 19” rack housing 201 675
ETC 24R 2 slave clock lines (impulse / DCF / MOBALine),
4 switching contacts, 19” rack housing 201 676
This manual covers all functions of all the different clock types. The exact features of the
ETC models are listed in appendix A. If necessary short notes, pictures or examples are
added to the manual to explain special options or features of the clock types.

© MOBATIME 12 / 96 800337.22
4 Installation
4.1 Connections
The connections of the mains power are specified in chapter 7.
Further connections are specified in Appendix "A Connection Diagrams”.
Only connect the designated devices to the various inputs and outputs.
4.2 Checklist for Start-up
The following list should be of assistance for a safe and fast start-up.
□Application specific wiring of the inputs and outputs (Annexe A)
□Connect supply and switch on (Chapter 7, Annexe A)
□Read notes of operation (Chapter 6)
□Set the required menu language (Chapter 18.1)
□Set time zone of the master clock display (Chapter 9.2)
□When available, configure external time reference (Chapter 10.1) and check the
reception quality (Chapter 11.1)
□If there is no external time reference, set local time and date manually (Chapter 9.1)
□Configure outputs according to the requirements (Chapter 12)
□Once the configuration of the ETC is completed, save the current settings in the flash
memory (Chapter 17.7.1)

© MOBATIME 13 / 96 800337.22
5 Time Administration Concept
The internal master clock as well as the battery assisted real-time clock run with UTC (Universal
Time Coordinate). The synchronisation inputs and time outputs as well as the time shown on
the display are linked via a time zone entry with the master clock time, i.e. all inputs and outputs
can be individually allocated to a specific time zone.
External
Time Source
UTC
Master
Clock
Slave Clock Line(s) (DCF 77)
Time Code output
Time Zone Entry
(C)
LC Display
(D)
(A)
(B)
Switch Program
Time Zone Entry Time Zone Entry
Time Zone Entry
Serial Interface(s)
(E)
Time Zone Entry
Configurable time zones:
(A) Chapter 9.2
(B) Chapter 10.5
(C) Chapter 13.2.3
(D) Chapter 12.4.5 / 12.5.3 / 12.7.5
(E) Chapter 9.5

© MOBATIME 14 / 96 800337.22
6 Menu-driven Operation
6.1 Definitions
modify
thu
home *
0
123
456
789
sun
mon
fri
mon-
fri
tue
sat
mon-
sun
wed
home
modify home
home
Navigation keys
Status menu, back
Main menu, alter, select, OK
Cursor up/left
Cursor down/right
Return to main view
Modify key
Selecting an entry from a list, indicated by an arrow ()
Numeric keys
6.2 Keypad Lock
Simultaneous actuation of keys + in the main view locks the keypad to prevent
further inputs. Simultaneous actuation of the keys 1+ cancels the lock.
The display shows <<< LOCKED >>>.
home
mod
0 ... 9
0
10:36:59 Monday
24.07.2000 Summer
<<<<<< LOCKED >>>>>>

© MOBATIME 15 / 96 800337.22
6.3 Menu Navigation
This example explains how to navigate through the menu of the ETC and how to change
a configuration value. The individual menu items are marked by a schematic diagram of
the menu tree.
MENU
Synchronisation
T
ime source:
In the following example, the time source is to be set at DCF.
Press the key (MENU) to enter the main
menu.
The ‘Time + Date’ line then flashes, using the
cursor key move down by one menu item.
The ‘Synchronisation’ line now flashes, using the
navigation key (SELECT) select this menu
item.
The ‘Time source’ entry now flashes, press the
navigation key (CHANGE).
Select via the modify key , indicated by an
arrow above the key . Confirm the selection with
the navigation key (OK).
DCF is now configured as the time source. The
associated time zone is automatically set at 02
(CET).
Return to the main menu with the key.
mod
home
10:36:59 Monday
24.07.2000 Summer
STATE MENU
Time + Date
Synchronisation
Slave clock lines
BACK SELECT
Time + Date
Synchronisation
BACK SELECT
Time source: none
Configuration
BACK EDIT
Time source:
n
one
Configuration
CANCEL OK
Time source: DCF
Configuration
BACK EDIT

© MOBATIME 16 / 96 800337.22
7 Power Supply
7.1 Connection Terminals
There are two ways to feed the ETC. Either you connect the clock to mains power (ETC
14/24: 90 – 240 VAC, ETC 12: 230 VAC +/- 10%, 50/60 Hz) or to an external power
supply (24 VDC, 30 VA). See also annexe A.
7.1.1 Mains Power Supply
ETC 12R ETC 12
ETC 14R / ETC 24R ETC 14 / ETC 24
Caution: The ETC was designed for Protection class I. This requires a proper earth
connection, if the ETC is mains powered. Otherwise the ETC or the external
device could be damaged.
N
N
!

© MOBATIME 17 / 96 800337.22
7.1.2 External DC – Power Supply
In case of external power supply from a direct current source it has to be connected to
the ETC like shown in the following connection drawing.
ETC 24R ETC 14R
ETC 12R ETC 12/14/24
7.1.3 Passive Running Reserve Battery
All ETC-models have a passive running reserve. The fitted lithium battery saves all data
and operates the internal RTC (Real Time Clock). After a power failure, the master clock
time is again at the precise time. The lithium battery is already fitted and connected upon
delivery. Where a master clock has not been in use for over 2 years, the lithium battery
should be replaced. When the master clock is connected, the lithium battery has a
service life of at least 15 years.
External DC power supply ETC 12R
24 VDC
1 A
-
+
External DC power supply ETC 14R
24 VDC
1.5 A
-
+
External DC power supply ETC 24R
24 VDC
1.5 A
-
+
ETC 12: 1 A
ETC 14/24: 1.5 A
External DC power supply ETC 12/14/24
24 VDC
-
+

© MOBATIME 18 / 96 800337.22
7.1.4 Active Running Reserve Battery
A running reserve battery (type BP ETC R 24 V / 2.3 Ah) can be connected to the ETC
to provide all functions during mains power failure. The battery is fully controlled by the
ETC which means that it is charged by the ETC and protected against total discharge.
The battery is disconnected at approximately 90 % of the nominal voltage. The ETC will
then switch to passive running reserve.
Caution: A running reserve battery connected to the ETC will only be activated once
the mains supply has been switched on again. This also applies to charged
batteries.
ETC 12R ETC 14R
+
ETC 24R ETC 12/14/24
+
+
+
!

© MOBATIME 19 / 96 800337.22
8 External Time Sources
8.1 General
It is possible to connect the ETC to several kinds of time reference. This chapter gives a
short description of the time sources. The configuration of the corresponding
synchronisation mode will be described in chapter 10.
8.2 DCF – Radio Time Receiver
The connection of a DCF time signal receiver allows the synchronisation from the long
wave time signal emitter DCF-77 in Mainflingen (near Frankfurt a.M.), Germany.
The transmission of a time telegram spreads over one minute. After five successive
correctly received telegrams the ETC takes over the time information, that means that
the synchronisation can last up to 5 minutes at faultless reception.
At good reception the LED in the receiver (DCF 4500) must flash in second rhythm. The
signal quality will be increased each second of 1 up to the max. value of 100. For each
correctly received time telegram, the value of the telegram quality will be increased of 10
up to the max. value of 100.
Available DCF time signal receivers: DCF 4500
The connection of some time signal receivers is not polarity dependent. For further
information please consult the corresponding documentation for the receiver.
8.3 MSF – Radio Time Receiver
The connection of a MSF time signal receiver allows the synchronisation from the long
wave time signal emitter MSF-60 in Rugby, England.
Available MSF time signal receivers: MSF 4500
For more information see chapter 8.2.
8.4 GNSS 3000
The GNSS 3000 time signal receiver is sending a DCF time code with UTC time. Time
source has to be set to GPS 4500 (time zone 00 [UTC] is predefined, see Chapter 10.1
und 10.5).
The connection diagrams are illustrated in annexe G.
8.5 GPS / GNSS 4500
The GPS / GNSS 4500 time signal receiver is sending a DCF time code with UTC time.
Time source has to be set to GPS 4500 (time zone 00 [UTC] is predefined, see Chapter
10.1).
The connection diagrams are illustrated in annexe G.
8.6 Minute Impulses
The opto-coupler interface (Art. No. 118922) allows the synchronisation with polarised
minute impulses of 24 V or 48 V. The setting of date and time must be made manually.
The seasonal time change-over will be executed automatically.
The opto-coupler interface has to be connected to the terminals DCF in +/-, see also
annexe A.

© MOBATIME 20 / 96 800337.22
8.7 Serial Time Telegram (RS 232 / RS 422)
The IF 482 telegram is a serial ASCII standard time telegram, which sends the time and
date information through the serial interface RS 232 or RS 422. The detailed specification
can be found in annexe F.
