Mounting Manual for PROFILINE round
Prior to any installation work the mains power has to be disconnected.
1. Notes to this mounting manual
 The information in this mounting manual can be changed at any time without previous notice.
 This mounting manual has been composed with utmost care, in order to explain all details in
respect of the operation of the product. Should you, nevertheless, have questions or discover
errors in this Manual, please contact us.
 We are not liable for direct or indirect damages, which could occur when using this manual.
 Please read the instructions carefully before setting-up of the product, only once you have
correctly understood all information for the installation and of the operation.
 The installation must only be carried out by a skilled person.
 It is prohibited to reproduce, to store in a computer system or to transfer this publication, even
parts of it. The copyright remains with all the rights at MOSER-BAER AG – CH 3454 Sumiswald /
Switzerland and BÜRK-MOBATIME GmbH, D-78026 VS-Schwenningen / Germany.
2. Handling instructions
 The clock must be transported upright in its original packaging and has to be stored dry.
 Clean the cover glass with wet (leather-) cloth.
 Never use solvents, aerosol or organic cleaning products.
 The housing can be cleaned with standard cleaning agents.
3 Open the clock
 Remove all four screws on one clock side from the case ring. Pull case ring with glass cover and
dial from the clock’s cabinet. Disconnect electrical terminals from clock movement.
 To avoid damaging fluorescent-tube, remove before mounting the clock.
4. Mounting types
single sided (E)
types
double-sided (WA, DA, SM, ZM)
type
PLv.dm.R1.www.xxx.y.00 PLv.dm.R2.www.xxx.y.zz
Legend: v = illumination (0 = without, 1 = fluorescent, 2 = LED warm-white)
dm = nominal diameter (50, 60, 80 cm)
www = movement code, refer the enclosed installation manual Pt. 5.
xxx = dial
y = cover glas (1 = mineral glas, 2 = impact protection)
zz = mounting type: 00 = wall mounting (E)
10 = wall mounting (WA), double-sided
20 = ceiling mounting (DA)
30 = lateral post mounting (SM)
40 = central post mounting (ZM)

© MOBATIME
4.1 Single sided wall mounting (mounting type zz = 00 (E))
197
20
200
50
8,4
CB
D
4.2 Double-sided mounting (wall mounting, mounting type zz = 10 (WA))
AB 248
150
120
260
220
Ø13
dm
[cm]
A
[mm]
B
[mm]
weight
approx. [kg]
50 581 210 27
60 694 210 38
80 902 315 52
Nominal-
[cm] A
[mm]
B
[mm]
C
[mm]
D
[mm]
weight
approx. [kg]
50 581 102 220 170 16
60 694 152 280 220 23
80 902 202 380 270 37
Cable entry
Cable entry
Dimensions in mm
dimensions in [mm]

© MOBATIME
4.3 Double-sided mounting (Ceiling suspension, mounting type zz = 20 (DA))
A
C
248
200
150
200
150
11,5
Ø
4.4 Double-sided mounting (lateral post mounting, mounting type zz = 30 (SM))
A
D248
Fastening to pole of diameter 80mm to 120mm is done by enclosed tightening strap.
dm
[cm]
A
[mm]
B
[mm]
weight
approx. [kg]
50 581 500 27
60 694 600 38
80 902 800 63
dm
[cm]
A
[mm]
B
[mm]
Weight
approx. [kg]
50 581 216 28
60 694 216 39
Dimensions in mm
Dimensions in mm

© MOBATIME TE-801134.01
4.5 Double-sided mounting (Central post mounting, mounting type zz = 40 (ZM))
A248
59300
70
Ø

5. Disposing
At the end of its lifecycle, do not dispose of your device in the regular household rubbish. Return your
device to your supplier who will dispose of it correctly.
dm
[cm]
A
[mm]
Weight
approx. [kg]
50 581 28
60 694 39
80 902 64
Cable entry
Inner-ø 60 [mm]
Dimensions in mm
