Installation and Operating Instructions
DMU 140
Movement for MOBALine, RS485 time code, DCF, MSF and GPS
receiver for outdoor clocks up to Ø 140 cm.
Please read these instructions carefully before installation.

© MOBATIME 2 / 16 800514.05
Certification of the Producer
STANDARDS
The clock movement DMU 140 has been developed and produced in accordance with the EU Standards
89 / 336 / EU
References to the Instruction Manual
1. The information in this Instruction Manual can be changed at any time without previous notice.
2. This Instruction Manual has been composed with utmost care, in order to explain all details in respect
of the operation of the product. Should you, nevertheless, have questions or discover errors in this
Manual, please contact us.
3. We do not answer for direct or indirect damages, which could occur, when using this Manual.
4. Please read the instructions carefully and start the setting-up of the product, only once you have cor-
rectly understood all information for the installation and of the operation.
5. The installation must only be carried out by skilled staff.
6. It is prohibited to reproduce, to store in a computer system or to transfer this publication in a way or
another, even part of it. The copyright remains with all the rights with BÜRK MOBATIME GmbH,
D-78026 VS-Schwenningen and MOSER-BAER AG – CH 3454 Sumiswald / SWITZERLAND.

© MOBATIME 3 / 16 800514.05
Contents
1. Dimensions, definitions ..............................................................................................................4
2. Installation guidelines .................................................................................................................5
2.1 Installation of DMU 140 clock movements ..............................................................................5
2.2 Installation of hands and commissioning.................................................................................5
2.2.1 Hand installation ...............................................................................................................................5
2.2.2 Commissioning and checking hand position ....................................................................................5
2.3 View and wiring ......................................................................................................................6
2.4 Setting the synchronization mode and commissioning............................................................6
2.4.1 Power supply voltage........................................................................................................................6
2.4.2 Receiver wiring .................................................................................................................................7
2.4.3 Connection to main clocks................................................................................................................7
2.4.4 RS-485 terminating resistor ..............................................................................................................7
2.4.5 DIP switches .....................................................................................................................................8
2.4.6 Synchronization ................................................................................................................................8
2.4.7 Cascading wiring option....................................................................................................................8
3. Function description ...................................................................................................................9
4. Standard Time Zone Table ........................................................................................................10
5. Technical data:...........................................................................................................................12
5.1 Plug wiring............................................................................................................................13
5.1.1 RS-485............................................................................................................................................13
5.1.2 DCF In/Out......................................................................................................................................13

© MOBATIME 4 / 16 800514.05
1. Dimensions, definitions
Caution. The DMU 140 is suitable for indoor and outdoor clocks to a max. Ø 140 cm.
The hands must be covered by a glass face. The movements cannot be used for a
facade clock with unprotected hands.
Fig. 1
73 112
11
93
20M x1
50,5
45
5ø
11,5ø
47.6
40ø
59,5

© MOBATIME 5 / 16 800514.05
2. Installation guidelines
2.1 Installation of DMU 140 clock movements
The dial must be adequately rugged. The installation drill hole must have
a diameter of 20 mm.
The movements must be mounted vertically.
Fig. 2 shows the position of the components.
The washer nut (2) M20 x 1 is to be tightened carefully with a special
spanner accessory and torque wrench using a torque of 4.5 Nm +/- 0.2
Nm.
Caution:
Do not turn the movements any further after the washer nut (2) has been
tightened in place.
2.2 Installation of hands and commissioning
2.2.1 Hand installation
The hour and minute hand axles are positioned at 12:00 ex works. They
must be inserted on the axles and pressed down to the stop (X). They must
then be tightened in place without twisting the axles. See Fig. 3.
The 12:00 position must be checked in each movements after installing the
hands (chapter 2.2.2)
2.2.2 Commissioning and checking hand position
Set DIP switch 1 to ON (12:00 position, Fig. 5)
Connect MOBALine or DC power. The clock will turn to the 12:00 position.
Are the hands exactly at the 12:00 position?
If not then carefully loosen, adjust and retighten them (do
not twist the axle).
Recheck the 12:00 position (by briefly interrupting the
power supply)
If it's correct, continue with chapter 2.4 Mode Settings
Fig. 2
1 Clock movements
2 Washer nut
3 Rubber washer
4 Clock face
Fig. 3
1
2
3
4
2
20
X

© MOBATIME 6 / 16 800514.05
2.3 View and wiring
2.4 Setting the synchronization mode and commissioning
2.4.1 Power supply voltage
This is via MOBALine or 10-30 V DC. To ensure DCF/MSF reception is as trouble-free as
possible, functional earthing is essential.
Power supply via mains power module External 24 V power supply
DC IN
+Vin
GND
N
L
13
brown
red
Fig. 4
DC IN
+Vin
GND
Fig. 5 Fig. 6
DIP switch
Mobaline
connector
Mobaline A Mobaline B
DC-In
connector
+Vin
GND
RS-485
connector
RS485
/RS485
GND485
DCF
connector
+Vout GND DCF in GND DCFout+ DCFout-
Synchronization
LED
Power-OK
LED
DCF LED
On time
Step 12:00 Position Continuous
Hands:
ON
1 2 3 4 5 6 7 8 9 10 11 12
Time zone entry/
Address:
Minute Hand:
Synchronisation:
reserved
0 0 0 DCF77 1 0 0 MSF60 0 1 0 GPS (DCF UTC) 1 1 0 Mobaline 0 0 1 RS485/IF482
significance 32
significance 16
significance 8
significance 4
significance 2
significance 1
Synchronization: DCF RS485
MSF
GPS
significance 16
significance 8
significance 4
significance 2
significance 1
reserved
Time zone
entry
Address

© MOBATIME 7 / 16 800514.05
2.4.2 Receiver wiring
The signal is shown by DCF-LED
Correct synchronization is shown by the synchronization LED.
DCF receiver GPS receiver
2.4.3 Connection to main clocks
Correct synchronization is shown by the synchronization LED.
MOBALine RS-485
2.4.4 RS-485 terminating resistor
The termination resistor must be activated in clock movements at the end of a RS-485 line.
Open the clock movements cover cautiously to do so. The jumper is on the pc-board with DIP
switches. Replug the X8 jumpers X8 to activate the terminating resistor.
DCF77
DCF
GND
DCF in
white
brown
GPS 4500
white
brown
yellow
green
art. no. 201821
DCF
+Vout
GND
DCF in
GND
Fig. 7 Fig. 8
RS485
RS485
/RS485
GND485
Connect the shield on
one side of the cable
to earth
Mobaline A Mobaline B
Fig. 11
202508.01
Termination enabled
Termination disabled
(default)
Fig. 10
Fig. 9

© MOBATIME 8 / 16 800514.05
2.4.5 DIP switches
2.4.6 Synchronization
Set the DIP switches 3,4,5 as the synchronization mode dictates.
Set time zone and RS-485 address using the DIP switches 6 -11.
This setting is not needed in some synchronization modes.
DCF reception is shown by a regularly blinking of the DCF LED.
Correct synchronization is shown by the Synchronization LED.
After a brief period (see chapter 5) the clock will start running to current line time.
Example of calculating time zone and address setting:
Time zone Address
DIP switch 11 Off Value 1 0
DIP switch 10 On Value 2 2 Value 1 1
DIP switch 9 On Value 4 4 Value 2 2
DIP switch 8 Off Value 8 0 Value 4 0
DIP switch 7 On Value 16 16 Value 8 8
DIP switch 6 Off Value 32 0 Value 16 0
Total 22 Total 11
= Time zone
22
= Address
11
2.4.7 Cascading wiring option
The DCF time code can be connected to the next movement via DCF-out. Synchronization in cas-
caded movements must be set to GPS (DCF UTC).
ON
1 2 3 4 5 6 7 8 9 10 11 12
Fig. 12
Fig. 13
DCFDCF
GND
DCF in
DCF out+
DCF out-
DCF77
GND
DCF in
white
brown
On time
Step
12:00 Position
Continuous
Hands:
ON
1 2 3 4 5 6 7 8 9 10 11 12
Time zone entry/
Address:
Minute Hand:
Synchronisation:
reserved
0 0 0 DCF77 1 0 0 MSF60 0 1 0 GPS (DCF UTC) 1 1 0 Mobaline 0 0 1 RS485/IF482
significance 32
significance 16
significance 8
significance 4
significance 2
significance 1
Synchronization: DCF RS485
MSF
GPS
significance 16
significance 8
significance 4
significance 2
significance 1
reserved
Time zone
entry
Address

© MOBATIME 9 / 16 800514.05
3. Function description
Self-setting movement for hour and minute hands. For self-setting clocks indoors and outdoors (under
glass covers) with a face diameter of up to 140 cm with or without lighting.
MOBALine, DCF77, MFS60 time code or controlled by MB-485-protocol via RS-485 with automatic
time take over.
Synchronization from a master clock or with DCF, MSF or GPS receiver.
DC power supply to a GPS receiver.
Operating mode, synchronization, time zone and RS-485 address selectable by DIP switch.
Self-setting, 12:00 position monitored by sensors with correction facility.
Two motors with forwards and backwards capabilities for rapid adjustment.
Power-saving mode with MOBALine - only one motor in use, with priority given to the minute motor.
Lack of MOBALine or RS-485 time signal during 24 hours is shown by resetting the hands to 12:00
o'clock position.
Lack of DCF77 or MSF 60 time signal during 7 days (7 x 24 h) is shown by resetting the hands to
12:00 o'clock position.
Immediate adjustment to the correct time after power interruptions of up to 10 h based on internal
quartz clock (battery-less time keeping).
DIP switch 2 is used to select the minute hand function mode, continuous or in minute steps.
MOBALine ignores this switch. The running mode is selected via the line mode of the master clock,
with half-minute steps becoming minute steps.
Output of a synthetic DCF77 code, when movement is synchronized with DCF77 or MSF 60 (UTC).
Status LED for power supply, DCF impulses and synchronization.

© MOBATIME 10 / 16 800514.05
4. Standard Time Zone Table
Time zone entries in the standard season table (version 9.0).
Time
zone
City / State UTC
Offset
DST
Change
Standard → DST DST → Standard
00 UTC (GMT),
Monrovia, Casablanca
0 No
01 London,
Dublin, Edinburgh, Lisbon
0 Yes Last Sun. Mar. (01:00) Last Sun. Oct. (02:00)
02 Brussels, Amsterdam,
Berlin, Bern, Copenhagen,
Madrid, Oslo, Paris,
Rome, Stockholm, Vienna,
Belgrade, Bratislava, Bu-
dapest, Liubliana, Prague,
Sarajevo, Sofia, Vilnius,
Warsaw, Zagreb
+1 Yes Last Sun. Mar. (02:00) Last Sun. Oct. (03:00)
03 Athens,
Istanbul, Minsk, Helsinki,
Riga, Tallinn, Kaliningrad
+2 Yes Last Sun. Mar. (03:00) Last Sun. Oct. (04:00)
04 Bucharest, Romania +2 Yes Last Sun. Mar. (03:00) Last Sun. Oct. (04:00)
05 Cairo, Pretoria, Harare +2 No
06 Dhaka +6 Yes Wed. 31. Mar. (22:59)
(2010)
Sun. 31. Oct. (23:59) (2010)
07 Tel Aviv +2 Yes Last Fri. Mar. (02:00) 2nd Sun. Oct. (02:00) (2010)
08 Kuwait City +3 No
09 Moscow,
St. Petersburg, Volgograd
+3 Yes Last Sun. Mar. (02:00) Last Sun. Oct. (03:00)
10 Tehran +3.5 Yes Sun. 21. Mar. (00:00) (2010) Tue. 21. Sep. (00:00) (2010)
11 Abu Dhabi,
Muscat, Tbilisi
+4 No
12 Kabul +4.5 No
13 Yekaterinburg, Russia +5 Yes Last Sun. Mar. (02:00) Last Sun. Oct. (03:00)
14 Tashkent +5 No
15 Mumbai, Calcutta, Ma-
dras,
New Delhi, Colombo
+5.5 No
16 Astana, Thimphu +6 No
17 Bangkok, Hanoi, Jakarta +7 No
18 Beijing,
Chongqing, Hong kong,
Singapore, Taipei, Urumqi
+8 No
19 Tokyo,
Osaka, Sapporo, Seoul
+9 No
20 Yakutsk, Russia +9 Yes Last Sun. Mar. (02:00) Last Sun. Oct. (03:00)
21 South Australia: Adelaide +9.5 Yes 1st Sun. Oct (02:00) 1st Sun. Apr. (03:00)
22 Northern Territory: Darwin +9.5 No
23 Queensland: Brisbane,
Guam, Port Moresby
+10 No
24 NSW, Victoria: Sydney,
Canberra, Melbourne
+10 Yes 1st Sun. Oct. (02.00) 1st Sun. Apr. (03:00)
25 Tasmania: Hobart +10 Yes 1st Sun. Oct. (02:00) 1st Sun. Apr. (03:00)
26 Vladivostok +10 Yes Last Sun. Mar. (02:00) Last Sun. Oct. (03:00)
27 Solomon Is. ,
New Caledonia
+11 No
