Mobotix Mx-S-NAS2A-8 User manual

Quick Guide – MOBOTIX NAS & MOVE/ONVIF Cameras
Setting up MOBOTIX NAS/MxManagementCenter
Using MOVE/ONVIF Cameras

2
General Information (1)
Minimum requirements for software versions
•MOBOTIX NAS: Mx-NAS2-4A-4.3.4.0807, Mx-NAS8A-4.3.4.0807, ContainerStation 1.8.3.207,
MOBOTIX NAS QVRProServer 1.2.1.0 (see MOBOTIX NAS Quick Install)
•MOBOTIX MOVE: SD1A àMB20181025RS, BC1A/VD1A àMB20181025RP
•MxManagementCenter: 2.2+
IMPORTANT: We recommend updating all system components to the latest software releases. Please
download the latest releases of MxMC, MOBOTIX NAS, and MOBOTIX MOVE cameras from the MOBOTIX
website www.mobotix.com:
•Support > Download Center > Software Downloads
This document is valid for the following MOBOTIX NAS models
Product Name
Item Number
Product Label
MOBOTIX NAS 2
-Bay/8 Channels
Mx
-S-NAS2a-8
251
-G
MOBOTIX NAS 4
-Bay/16 Channels
Mx
-S-NAS4A-16
451
-G
MOBOTIX NAS 8
-Bay/32 Channels
Mx
-S-NAS8A-32
873U
-G

3
General Information (2)
A Note on Licensing
MxManagementCenter can show MOBOTIX IoT and MOVE cameras “as is”, i.e., without any further
licensing. For bandwidth-optimized usage and professional applications, it is highly recommended to use
H.264 (requires a license for MxManagementCenter).
For more information on licensing models, please read the Compact Guide MxMC 2.0 from the MOBOTIX
website www.mobotix.com:
•Support > Download Center > Documentation > Brochures & Guides
•Only one Starter License per MxMC required to enable H.264
Video Tutorials are available from the MOBOTIX website www.mobotix.com:
•Support > Download Center > Documentation > Video Tutorials
The MOBOTIX NAS HDD Compatibility List is available from the MOBOTIX website www.mobotix.com:
•Support > Download Center > Documentation > White Lists
Password Security!
•NEVER use the default access privileges! Always make sure that you have changed the default
passwords to strong passwords (numbers, lower/upper case letters, special characters)!
•The default user of the MOBOTIX NAS is “admin” and the password is “admin”.
•The default user of the MOBOTIX Cameras is “admin” and the password is “meinsm”.

4
Motivation
The objective of this document is to set up a MOBOTIX NAS as a storage device for MOBOTIX Move-Kameras
bzw. ONVIF-Kameras.
The MOBOTIX NAS QVRProServer recording software is required for recording from MOBOTIX Move-Kameras
bzw. ONVIF-Kameras on the NAS. For most efficient configuration of camera settings, use the Advanced
Configuration feature of MxManagementCenter.
MOBOTIX IoT cameras can
bridge network failures using
their internal SD card

5
Step 1 –Add ONVIF S Cameras to MxManagementCenter
1. Start MxManagementCenter.
2. Start the Welcome Wizard by clicking on File > Welcome in the menu bar.
3. Click on Add Devices. Then select the desired ONVIF S-compliant cameras you’d like to add to MxMC.
Note: It can take up to ten minutes to find an ONVIF camera. As an alternative, you can manually add the
cameras to the list by clicking the “+” icon in the control bar.
4. Enter the access privileges. You need access privileges of a user with ONVIF administration level access. For
MOBOTIX MOVE cameras, the admin user in the camera’s web interface is also the ONVIF admin. For other
camera brands (e.g., Axis), the roles for web interface admin and ONVIF admin are separate.
IMPORTANT: MOBOTIX MOVE cameras require
the following firmware version (or newer) :
-SD1A àMB20181025RS
-BC1A/VD1A àMB20181025RP

6
Step 2 –Adjust the Image Settings for Live and Recording
1
2
3
A Note on Image & Codec Settings:
•MxMC defines the settings for Live and Recording.
•The HiRes profile MxHiQuality belongs to the Recording settings of the NAS.
•H.264 Codec requires a Starter License for MxManagementCenter.
Open lock icon to enter edit mode,
then...
1. Right-click one or more selected
MOVE/ONVIF cameras.
2. Open Connection Settings.
3. Select your image and codec settings.

7
Step 3 –Check the Integration Key
A note on the Integration Key
•The key will be automatically set while adding the camera.
•The key is required for adding the camera in the MOBOTIX NAS.
If the integration key is not shown below, please try the follow steps:
•Remove camera from the system and add it again!
•Reset the camera to factory defaults and add the camera again.
•Check if the cameras is officially registered as an ONVIF S client at
https://www.onvif.org/conformant-products/
•Make sure model is conforming (using exact model name).
•Check if the camera firmware release is conforming.

8
Step 4: Adding NAS in MxManagementCenter (1)
•Open the Components View of
MxMC
•In tab File Servers add a MOBOTIX
NAS (ONVIF)

9
Step 4: Adding NAS in MxManagementCenter (2)
•From the Download Links section,
download and install the Device Finder app
•Also Download the Container App and the
Recorder App
•Optional: Download the latest NAS
firmware (see also step 9)

10
Step 5: Device Finder
•Select your MOBOTIX NAS
•Note the IP-Adresse of the NAS
•If your MOBOTIX NAS has not yet been
initialized, start the Intelligent Installation
Guide.
1
2

11
Step 6: Initially configure the NAS (1) - Set the access data
•If necessary, change the NAS-Name
•Set a password
•Click on Next
1

12
Step 6: Initially configure the NAS (2) – Optionally configure hard disks
•Choose Configure Disk Now
•Configure the available disks according to
your requirements
•Click on Next
1
Be sure to configure the data carriers!
Otherwise, errors may occur during the installation of apps.

13
Step 7: Setting up the NAS in the MxManagementCenter
•Enter the access data for your NAS
under File Server Settings
1
2
•Click Configure NAS

14
Step 8: Login to NAS Web Interface
•Log in to the web
interface of the NAS 1

15
Step 9: optionally update firmware (1)
•Open the Control Panel

16
Step 9: optionally update firmware (2)
•Click on Firmware Update

17
Step 9: optionally update firmware (3)
•Select the firmware (see step 4)
•Click on Update System
•Follow the instructions on the screen

18
Step 10: Install Apps on NAS (1) -Recording software
•Open the App Center.

19
Step 10: Install App on NAS (2) - Recording Software
1. Click Install Manually.
2. Install the following apps (you downloaded them in
step 4):
•Container Station App
•QVR Pro App
2
1

20
Step 11: Initial setup of QVR Pro (1)
•Open the QVR Pro
