Mocka Eliza Buffet User manual

Eliza Buffet
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
1
Wall Strap
x2
washer
Z
Y
wall
anchor
x1
X
safety
strap x1
WV
screw
x1
wall
screw
x1
WARNING: Any furniture that is not anchored to a wall has the potential to tip over in certain
circumstances, i.e. if a child attempts to climb up on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall. We supply a free safety wall anchor
with all furniture sold and we recommend these are used to prevent your product tipping. The fixing device
provided should fit most wall types, but please note that different wall materials may require different fixing
devices from those supplied.
bolt
x23
x8
AB C D E F G H J
KLM N O P Q
I
Hardware Supplied
dowel
x16
slocking crew
x40
screw
x24
slide
rail x3
slide
rail x3
slide
rail x3
slide
rail x3
nut x23
screw
x8
x8
wedge
x5
handle
x2
hinge
x8
shelf
plug
x24
screw bolt
x15
screw Allen
key
x1
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
Phillips & Flathead screwdrivers
long
S T
x2
hinge hinge
*We recommend using a Flathead screwdriver to tighten all locking nuts 100% before first use.
Please clear any loose wood from the locking nut holes before inserting the nut to ensure it locks 100%.
R
adjuster
x2

Eliza Buffet
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
2
12
Insert 8x bolts (C) into panel [1] as shown. Tighten with a screwdriver.
C
G
E
E
F
F
CL
E
G
CR
E
1
6
4
Attach 3x slide rails (F) and 3x slide rails (G) to panels [6] and [4] as
shown and secure with 18x screws (E). Tighten with a screwdriver.

Eliza Buffet
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
3
3 4
Attach panels [3], [4], [5] and [6] to panel [1] with 8x dowels (A) and
secure with 8x locking nuts (D). Tighten with a screwdriver.
Slide panels [7] and [8] down along the grooves between the panels [3], [4],
[5] and [6] to form the back of the unit as shown.
A
D
A
D
1
4
3
6
5
7
8
8
4
3
6
5

Eliza Buffet
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
4
65
Attach panel [2] to panels [3], [4], [5] and [6] with 8x dowels (A)
and secure with 8x long screws (B). Tighten with a screwdriver.
Attach 4x panels [9] and 2x support legs [19] to panel [2] and secure with
24x bolts (L). Tighten with an Allen Key (N). Insert the 2x adjusters (R)
into the middle support legs as shown.
A
B
2
L
9
2
4
3
6
5
R
19
R
N
L
9

Eliza Buffet
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
5
7 8
Attach 2x hinges (S) and 2x hinges (P) to panels [10] and [11] and
secure with 8x hinge screws (T). Attach 2x handles (O) to panels [10]
and [11] and secure with 4x screw (E). Tighten with a screwdriver.
Secure panels [10] and [11] to the main unit by attaching the other
end of the hinges (S) and (P) with 16x hinge screws (T) as shown.
NOTE: If the doors are uneven
or there is a gap in the middle,
loosen or tighten the screw on
the door hinge until they are
sitting flush.
T
T
S
S
T
T
P
P
E
O
E
O
10
11
10
11
T
S
S
T
T

Eliza Buffet
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
6
9 10 Drawers x3
Insert 8x shelf plugs (Q) into the end cavities of the cabinet as shown.
Insert the panels [12] and balance on top of the plugs.
Insert 5x bolts (C) into panel [13]. Tighten with a screwdriver.
Attach panels [14], [15] and [16] to panel [13] and secure with 5x
locking nuts (D). Tighten with a screwdriver.
13
12
12
Q
6
5
3
C
D
16
15
14
D
13

Eliza Buffet
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
7
11 Drawers x3 12 Drawers x3
Slide panel [17] along the grooves between the panels [14]
and [15] to form the base of the drawer. Attach panels [14],
[15], [16] and [18] as shown using 5x screws (M).
Tighten with a screwdriver.
Attach slide rail (I) and slide rail (H) to the underside of the side panel as shown.
Secure with 4x screws (E) and tighten with a screwdriver. Attach handle (O) to
panel [13] and secure with 2x screws (E). Tighten with a screwdriver.
EO
13
15
E
H
I
14
E
13
17
14
15
M
18
14
15

Eliza Buffet
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
8
13 14
Insert the assembled drawers into the corresponding compartments
as shown. Ensure the drawers slide easily along the rails.
Attach 8x wedges (J) into the corners of the back of the unit and secure
with 8x screws (K). Tighten with a screwdriver. Attach 1x safety strap (V)
to the top of the back side of the unit as shown using 1x washer (Z) and
1x screws (W). Tighten with a screwdriver.
V
W
Z
J
K
13
8
8
7
1
V
Z
W

Eliza Buffet
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
9
15 16
Once assembled lift furniture into place, do not drag. Use a drill to create a
small hole lining up with the top of the safety strap (V). Fasten to the wall
using 1x washer (Z) , 1x wall anchor (X) and 1x wall screw (Y).
Ensure unit is balanced and steady before use. You’re done, enjoy!
X
Y
Z
1
X
Y
Z

Eliza Buffet
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
9
15 16
Once assembled lift furniture into place, do not drag. Use a drill to create a
small hole lining up with the top of the safety strap (V). Fasten to the wall
using 1x washer (Z) , 1x wall anchor (X) and 1x wall screw (Y).
Ensure unit is balanced and steady before use. You’re done, enjoy!
