Mocka Inca Four Drawer User manual

Inca Four Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
1
Wall Strap
x2
washer
Z
Y
wall
anchor
x1
X
safety
strap x1
WV
screw
x1
wall
screw
x1
WARNING: Any furniture that is not anchored to a wall has the potential to tip over in certain
circumstances, i.e. if a child attempts to climb up on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall. We supply a free safety wall anchor
with all furniture sold and we recommend these are used to prevent your product tipping. The fixing device
provided should fit most wall types, but please note that different wall materials may require different fixing
devices from those supplied.
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
Phillips & Flathead screwdrivers
bolt
x34
x8
A B C D EFG H
JKL M
I
Hardware Supplied
dowel
x8
screw
x48
slide
rail x4
slide
rail x4
slide
rail x4
slide
rail x4
locking
nut x34
screw
x6
wedge
x8
screw bolt
x8
handle
x4
N
screw
x20
Allen
Key
x1
O P
small
screw
x6
Thank you for your purchase. Please follow the instructions for correct assembly.
While we took great effort to ensure these assembly instructions were correct at
the time of printing, sometimes updates are required post production. For the
most up to date versions please refer to the product page on our website.
mocka.com.au/mocka.co.nz

Inca Four Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
2
12
Insert 4x bolts (C) into panel [1] and tighten with a screwdriver.
C
Attach 4x slide rails (F) and 4x slide rails (G) to panels [3]
and [4] as shown and secure with 24x screws (E). Tighten
with a screwdriver.Insert 10x bolts (C) into panel [3] and [4]
and tighten with a screwdriver.
C
C
C
C
C
CC
C
E
EE
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
CC
C
C
C
F
F
F
F
F
G
G
G
G
G
CL
E
E
CR
1
3
4

Inca Four Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
3
3 4
Attach panels [5], [6] and [7] to panel [3] secure with 5x locking
nuts (D). Tighten with a screwdriver.
Attach panel [4] to panels [5], [6] and [7] secure with 5x locking
nuts (D). Tighten with a screwdriver.
D
DD
D
D
D
DD
D
5
5
6
6
7
7
3
3
4

Inca Four Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
4
65
Slide panel [8] down along the grooves between the panels [3]
and [4] as shown.
D
D
A
A
A
D
B
B
3
3
8
4
4
1
5
Attach panel [1] to the unit with 4x dowels (A) and secure with 4x locking
nuts (D). Tighten with a screwdriver.Attach panel [1] to panel [5] secure
with 2x screws (B). Tighten with a screwdriver.

Inca Four Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
5
7 8
Slide panel [8] down along the grooves between the panels [3]
and [4] to form the back of the unit as shown.Attach panel [2] to panels [3] and [4] with 4x dowels (A) and secure with
4x screws (B). Tighten with a screwdriver.
A
A
B
B
BB
B
A
3
3
2
4
4
8

Inca Four Drawer
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
6
910
Assembly Instructions
Attach panel [9] to panels [10] and [11] secure with 8x bolt (L). Tighten
with an Allen Key (P).
L
L
L
L
L
L
L
L
L
P
9
9
11
11
10
10
Attach panels [11] and [9] to panel [2], secure with 6x small screws (N).
Tighten with a screwdriver.
N
N
N
N
N
N
N
11
11
9
9
2

Insert 5x bolts (C) into panel [12] . Tighten with a screwdriver.
Inca Four Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
7
12 Drawers x411Drawers x4
C
C
C
C
C
12
OO
O
OO
13
14
16
15
Attach panels [13], [14] and [16] to panels [15] as shown using
5x screws (O). Tighten with a screwdriver.

Slide panels [17] down along the grooves between the side
panels [13] and [14] as shown.
Inca Four Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
8
14 Drawers x413 Drawers x4
Attach panels [12] to panels [13], [14] and [16] secure with 5x locking
nuts (D). Tighten with a screwdriver.
D
D
DD
D
13
14
17 12
13
14
16

Attach 1x handle (M) to panel [12] secure with 2x screws (E).
Tighten with a screwdriver.
Attach slide rail (I) and slide rail (H) to the underside of the side
panels as shown. Secure with 4x screws (E) and tighten with a
screwdriver.
Inca Four Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
9
16 Drawers x415 Drawers x4
E
E
H
I
14
13
M
E
E
EE
12

Insert the assembled drawers into the corresponding compartments
as shown. Ensure the drawers slide easily along the rails.
Inca Four Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
10
1817
Attach 8x wedges (J) into the corners of the back of the unit and
secure with 8x screws (K). Tighten with a screwdriver. Attach 1x
safety straps (V) to the top of the back side of the unit as shown
using 1x washers (Z) and 1x screw (W). Tighten with a screwdriver.
J
K
J
K
J
J
J
J
K
K
K
K
J
J
K
K
J
K
V
Z
W
V
W
Z

Once assembled lift furniture into place, do not drag. Use a drill to
create a small hole lining up with the top of the safety strap (V).
Fasten to the wall using 1x washer (Z), 1x wall anchor (X) and
1x wall screw (Y). Ensure unit is balanced and steady before use.
Inca Four Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
11
2019
You’re done, enjoy!
XZ
wall
anchor
screw
strap
washer
Y
