Mocka Vibe Coffee Table User manual

WARNING: Any furniture that is not anchored to a wall has the potential to tip
over in certain circumstances, i.e. if a child attempts to climb up on the furniture
or in the event of an earthquake. Accordingly, we recommend that all furniture
is anchored to a wall. We supply a free safety wall anchor with all furniture sold
and we recommend these are used to prevent your product tipping. The fixing
device provided should fit most wall types, but please note that different wall
materials may require different fixing devices from those supplied.
A B C D EF G
H
Hardware Supplied
dowel
x12
screw
x12
bolt
x18
locking
nut x18
small
screw x20
long
screw x14
*We recommend using a Flathead screwdriver to tighten all locking nuts 100% before first use.
Please clear any loose wood from the locking nut holes before inserting the nut to ensure it locks 100%.
Phillips & Flathead screwdrivers required
IJ
Vibe/Olsen Coffee Table
1
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
CL runner
tracks x2
CR runner
tracks x2
DL
runners x2
DR
runners x2
K
allen key
x1
L
cover
x2

12
Insert 6x bolts (A) into panels [1] and tighten with a screwdriver.
Vibe/Olsen Coffee Table
2
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Assembly Instructions
Attach 1x CL runner track (G) and 1x CR runner tracks (H) to panel
[3] with 6x screws (F). Attach 1x CL runner track (G) and 1x CR
runner tracks (H) to panel [4] with 6x screws (F). Insert 4x bolts
(A) into the panels [3] and [4]. Tighten with a screwdriver.
1
A
A
A
A
A
A
4
A
A
3
AA
F
F
F
F
F
F
F
F
F
F
F
F
G
H
G
H
F
H
CR
F
G
CL

Attach panels [3] and [4] to panel [6] and secure with 4x locking nuts (B).
Tighten with a screwdriver.
34
Attach panels [3] , [4] and [5] to panel [1] with 6x dowels (C) and
secure with 6x locking nuts (B). Tighten with a screwdriver. Seal
the holes with 2 x covers (L).
Vibe/Olsen Coffee Table
3
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Assembly Instructions
B
B
B
B
3
4
3
4
1
5
6
B
B
B
B
B
C
C
C
C
C
C
B
B
L
L

Attach the bottom panel [2] to the unit with 6x dowels (C) and secure
with 6x long screws (D). Tighten with a screwdriver.
56
Attach 4x legs [7] to the panel [2] with 12x screws (E). Tighten with
an Allen key (K).
Vibe/Olsen Coffee Table
Assembly Instructions
4
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
3
2
2
7
7
7
7
D
D
D
D
D
D
C
C
C
C
4
5
E
E
E
E
E
K

Slide the completed drawers into the unit, ensuring they slide smoothly
and easily.
Jolt Wardrobe
ASSEMBLY INSTRUCTIONS
5
mocka.co.nz | mocka.com.au
78
Attach side panels [9] and [10] to panel [8] and secure with
4x locking nuts (B). Tighten with a screwdriver.
Vibe/Olsen Coffee Table
Assembly Instructions
5
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Insert 4x bolts (A) into panel [8] and tighten with a screwdriver.
A
A
A
A
8
Drawers x2 Drawers x2
B
B
B
B
8
9
10
B

Jolt Wardrobe
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
9
Slide panel [11] down along the grooves between the side panels
[9] and [10] to form the base of the drawer.
Vibe/Olsen Coffee Table
Assembly Instructions
6
D
D
D
D
8
912
10
Attach panel [12] to the side panels using 4x screws (D). Tighten with
a screwdriver.
Drawers x2 Drawers x2
8
9
11
10
10

F
F
F
F
I
J
9
10
Jolt Wardrobe
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
11
Attach DL runner (I) to the side panel [9] and DR runner (J) to the side
panel [10]. Secure with 4x screw (F) and tighten with a screwdriver.
Complete the other drawer.
Vibe/Olsen Coffee Table
Assembly Instructions
7
12
Slide the completed drawers into the unit, ensuring they slide
smoothly and easily. Once assembled lift furniture into place,
do not drag. You’re done, enjoy!
3
1
Drawers x2
