Mocka Sadie Bedside Table User manual

mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008
ASSEMBLY I N S TRUCTION S
Sadie
Bedside Table
Thank you for your purchase.
Please follow the instructions below for correct assembly
WARNING: Any furniture that is not anchored to a wall has
the potential to tip over in certain circumstances, i.e. if a
child attempts to climb up on the furniture or in the event
of an earthquake. Accordingly, we recommend that all
furniture is anchored to a wall. We supply a free safety
wall anchor with all furniture sold and we recommend
these are used to prevent your product tipping. The fixing
device provided should fit most wall types, but please
note that dierent wall materials may require dierent
fixing devices from those supplied.
Phillips screwdriver and hammer required
For quicker assembly, we recommend the use of a power drill on a low-speed setting.
*We recommend using a Flathead screwdriver to tighten all locking nuts 100% before first use.
Please clear any loose wood from the locking nut holes before inserting the nut to ensure it locks 100%.
x2
washer
Z
wall
Y
screw
wall
x1
X
anchor
safety
W
strap x1
V
Wall Strap
Hardware Supplied
x1
screw
x1
A B C D E F
dowel
x16 x8
screwbolt
x44
locking
nut x44
small
screw x24 x8
long screw
JI
slide
rail x2
slide
rail x2
L1
L2 J1
J2
G H
wedge
x4 x4
screw
K
plastic
glides x6 x1
allen key
L
1

Sadie
mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008
ASSEMBLY I N S TRUCTION S
21
Bedside Table
2
Insert 4x bolts (A) into panel [4] and [5]. Insert 4x dowels (C) to panel [5] and [4]. Attach panel [6] to panel [4]
and [5] using 4x screws (F).Tighten with a screwdriver.
AA
AA
F
F
C
F
F
C
C
5
5
6
4
4

Sadie
Bedside Table
mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008
ASSEMBLY I N S TRUCTION S
Attach 2x slide rails (L1) to panel [2] using 6x screws (D). Attach 2x slide
rails (L2) to panel [3] using 6x screws (D). Tighten with a screwdriver.
Insert 4x bolts (A) into panel [2] and 4x bolts (A) into panel [3].
3 4
Attach left panel (7) to panel [3], then attach panel [7] and panel [9] to
panel [3]. Secure with 6x locking nuts (B) and tighten with a screwdriver.
AA
AA
AA
A
D
DD
D
D
D
D
D
D
D
D
D
2
3
A
5
3
7
9
BB
BB
BB
L1
L2
L2
L1
L2
D

mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008
ASSEMBLY I N S TRUCTION S
Sadie
Bedside Table
5 6
Attach right panel [7] to panel [2]. Then attach panel [7] and panel [9] to
panel [2]. Secure with 6x locking nuts (B) and tighten with a screwdriver.
Insert 12x bolts (A) to top panel [1].
1
A
A
A
A
A
A
A
AA
A
A
A
2
4
7
9
BB
BB
B

Sadie
Bedside Table
mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008
ASSEMBLY I N S TRUCTION S
Attach 2x panels [8] to panel [1]. Secure with 4x locking
nuts (B) and tighten with a screwdriver.
Insert 8x dowels (C) into top panel [1]. Attach top panel [1] to
panels [2], [4], [5] and [3]. Secure with 8x locking nuts (B) and
tighten with the allen key (L).
78
1
8
8
B
B
B
B
5
4
CC
CC
C
C
C
C
B
L
2
3
1

Sadie
Bedside Table
mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008
ASSEMBLY I N S TRUCTION S
Slide panel [11] down along the grooves of panels [3] and [2]. Insert 4x dowels (C) into panel [2] and [3]. Attach panel [10] to
panels [2] and [3] using 4x screws (F).Tighten with a screwdriver.
109
22
33
10
11
C
F
C
C
F
F
F

11
Sadie
Bedside Table
mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008
ASSEMBLY I N S TRUCTION S
Insert 8x bolts (A) into panel [10]. Insert 2x bolts (A) into each panel [13]. Attach panels [12] and [13]
together using 4x locking nuts (B). Tighten with a screwdriver.
12
K
K
K
K
K
K
A
A
13
13
12
12
B
13 x2
B
B
B
A
A
A
A
A
A
A
A
10

13
Sadie
Bedside Table
mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008
ASSEMBLY I N S TRUCTION S
Attach panels [13] and [12] to panel [10] using 8x locking nuts (B).
Tighten with a screwdriver.
Attach 4x wedges (G) to back of the unit as shown using 4x screws (H).
Tighten with a screwdriver. Attach 1x safety strap (V) to the panel [1]
using 1x washer (Z) and 1x screw (W) as shown.
14
G
G
G
H
H
H
G
H
G
H
V
ZW
screw
strap
washer
10
13
13
12
12
B
B
B
B

15
Sadie
Bedside Table
mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008
ASSEMBLY I N S TRUCTION S
Insert 4x bolts (A) into panel [14]. Insert 4x bolts (A) into panel [15]
Attach panels [20] and [21] to panel [14] using 4x locking nuts (B).
Attach panels [16] and [17] to panel [15] using 4x locking nuts (B).
Tighten with a screwdriver. Slide down panels [19] to form the base
of the drawers.
Attach back panel [18] to the side panels[16]and [17] using 4x screws (E).
Attach back panel [22] to the side panels [20] and [21] using 4x screws (E).
Attach 1x slide rail (J1) and 1x slide rail (J2) to the sides of each drawer and
secure with 6x screws (D) as shown. Tighten with a screwdriver.
16
AA
AA
14
14
14
14
15
15
15
15
21
19
20
D
D
D
D
D
D
J1
J2
B
B
B
B
E
E
E
E
22
J1
21
20
AA
AA
17
19
16
B
B
B
B
D
D
D
D
D
D
J1
J2
E
E
E
E
18
J1
17
16

17
Sadie
Bedside Table
mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008
ASSEMBLY I N S TRUCTION S
Insert the drawers into the unit as shown. Ensure the drawers
slide smoothly and easily along the rails.
Lift the furniture into the desired location, do not drag. Fasten to wall
using 1x wall plug (X), 1x washer (Z) and 1x screw (Y). You’re done, enjoy!
18
14
15
X
Y
Z
wall
plug
screw
strap
washer
