ASSEMBLY INSTRUCTIONS
Six Cube
Thank you for purchasing Six Cube. Please follow the
manufacturer’s assembly instructions in detail.
Phillips & Flathead screwdrivers required.
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
A
8 x
screw
B
4 x
screw
C
28 x
short dowel
D
8 x
long dowel
E
1 x
wrench
F
12 x
screw cover
G
2 x
screw
H
2 x
wall anchor
I
2 x
screw
J
2 x
wall plug WARNING: Any furniture that is not anchored to a wall has the
potential to tip over in certain circumstances, ie. if a child attempts
to climb on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall.
We supply a free safety wall anchor with all furniture sold and we
recommend these are used to prevent your product tipping. The
fixing device provided should fit most wall types, but please note
that dierent wall materials may require dierent fixing devices from
those supplied.

mocka.co.nz I mocka.com.au I
ASSEMBLY INSTRUCTIONS
Six Cube
1
5
4
4
4
4
3
2
1

mocka.co.nz I mocka.com.au I
ASSEMBLY INSTRUCTIONS
Six Cube
1 2
Attach 4 x panels (4) to panel (3) together as shown and secure with
8 x long dowels (D).
Attach panels (2) and (5) to panels (4) together as shown and secure with
16 x short dowels (C).
D
D
D
D
D
D
D
D
D
D
4
2
5
4
4
4
4C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
4
3
4
4
4
4

mocka.co.nz I mocka.com.au I
ASSEMBLY INSTRUCTIONS
Six Cube
3 4
Attach 2 x panels (1) to assembled frame and secure with 12 x short dowels (C),
8 x screws (A) and 4 x screws (B). Tighten with an Allen Key (E).
Attach 12 x screw covers (F) to assembled frame as shown.
B
B
B
B
A
A
A
A
A
A
A
F
F
F
F
F
F
F
F
F
F
F
F
A
E
C
C
C
C
C
C
C
C
C
C
C
C
1
1
1
5
2
3
1

mocka.co.nz I mocka.com.au I
ASSEMBLY INSTRUCTIONS
Six Cube
5
Once assembled lift furniture into place, do not drag. Use a drill to
create a small hole lining up with the top of the 2 x wall anchors (H) and 2 x
screws (G). Fasten to the wall using 2 x wall plugs (J) and 2 x screws (I). Ensure
unit is balanced and steady before use. You’re done, enjoy!
2
G
H
I
J
