Mocka Nixon Three Drawer User manual

A B C D E FG
HJI
Hardware Supplied
dowel
x14
bolt
x25
locking
nut x25
screw
x24
screw
x10
*We recommend using a Flathead screwdriver to
tighten all locking nuts 100% before first use. Please
clear any loose wood from the locking nut holes before
inserting the nut to ensure it locks 100%.
screw
x16
bolt
x4
WARNING: Any furniture that is not anchored to a wall has the
potential to tip over in certain circumstances, i.e. if a child attempts to
climb up on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall.
We supply a free safety wall anchor with all furniture sold and we
recommend these are used to prevent your product tipping. The
fixing device provided should fit most wall types, but please note that
different wall materials may require different fixing devices from
those supplied.
screw
x1
Wall Strap
Y
Z
safety
strap x1
slide
rail x6
L & R slide
rail x6
nut
x4 x1
allen key
Phillips & Flathead screwdrivers required
KML
wedge
x8
screw
x4
screw
x8
N
Nixon Three Drawer
ASSEMBLY INSTRUCTIONS
1
mocka.co.nz | mocka.com.au
Thank you for your purchase.
Please follow the instructions below for correct assembly.

12
Insert 4x bolts (A) and 4x dowels (C) into the back of panel [1]. Attach 3x slide rails (H) to each panel [2] and [3] and secure with 6x
small screws (G). Tighten with a screwdriver. Insert 3x bolts (A) and 3x
dowels (C) into each panel [2] and [3] as shown.
1
A
A
A
A
back
A
A
A
A
C
C
G
G
G
H
H
H
3
C
C
G
G
G
H
H
H
2
A
C
AC
C
C
C
C
Nixon Three Drawer
ASSEMBLY INSTRUCTIONS
2
mocka.co.nz | mocka.com.au

12
Insert 4x bolts (A) and 4x dowels (C) into the back of panel [1]. Attach 3x slide rails (H) to each panel [2] and [3] and secure with 6x
small screws (G). Tighten with a screwdriver. Insert 3x bolts (A) and 3x
dowels (C) into each panel [2] and [3] as shown.
1
A
A
A
A
back
A
A
A
A
C
C
G
G
G
H
H
H
3
C
C
G
G
G
H
H
H
2
A
C
AC
C
C
C
C
34
Attach leg panels [10], [11], [12] and [13] together using 4x bolts (I) and
secure with 4x nuts (J). Tighten with the allen key (N).
Secure panels [5], [8] and [9] to side panels [3] and [2] with 6x locking
nuts (B). Tighten with a flathead screwdriver.
10
13
12
11
J
J
I
I
I
9
8
5
3
2
B
B
B
B
B
B
I
N
B
Nixon Three Drawer
ASSEMBLY INSTRUCTIONS
3
mocka.co.nz | mocka.com.au

56
Slide panels [6] and [7] along the grooves between panels [2] and [3] to
form the back of the unit.
Attach panel [1] as shown, and secure with 4x locking nuts (B). Tighten
with a screwdriver.
7
65
3
2
3
2
1
B
B
B
Nixon Three Drawer
ASSEMBLY INSTRUCTIONS
4
mocka.co.nz | mocka.com.au

Jolt Wardrobe
ASSEMBLY INSTRUCTIONS
5
mocka.co.nz | mocka.com.au
56
Slide panels [6] and [7] along the grooves between panels [2] and [3] to
form the back of the unit.
Attach panel [1] as shown, and secure with 4x locking nuts (B). Tighten
with a screwdriver.
7
65
3
2
3
2
1
B
B
B
78
Attach panel [4] to the main unit using 4x dowels (C) and secure with
4x screws (K). Tighten with the allen key (N).
Attach the leg panels to panel [4] and secure with 10x screws (E).
Tighten with a screwdriver.
4
3
2
1
C
K
K
K
K
C
C
C
E
E
EE
E
E
E
E
E4
3
2
N
Nixon Three Drawer
ASSEMBLY INSTRUCTIONS
5
mocka.co.nz | mocka.com.au

910
Insert 5x bolts (A) into panel [14]. Secure side panels [16] and [17] with
4x locking nuts (B). Tighten with a screwdriver. Slide panel [18] down
between the grooves of side panels [16] and [17].
Attach panel [19] behind panel [18] using 1x locking nut (B). Attach panel
[15] to panels [16], [17] and [19] using 5x screws (D) as shown. Attach
1x slide rail (F) onto each panel [16] and [17] and secure with 2x screws
(G) for each. Tighten all with a screwdriver.
14
AA
AA
14 14
14
17
16
17
16
17
16
16
16
17
18
18
15 15
19
19
B
D
D
GF
G
F
Drawers x3 A
B
D
Nixon Three Drawer
ASSEMBLY INSTRUCTIONS
6
mocka.co.nz | mocka.com.au

910
Insert 5x bolts (A) into panel [14]. Secure side panels [16] and [17] with
4x locking nuts (B). Tighten with a screwdriver. Slide panel [18] down
between the grooves of side panels [16] and [17].
Attach panel [19] behind panel [18] using 1x locking nut (B). Attach panel
[15] to panels [16], [17] and [19] using 5x screws (D) as shown. Attach
1x slide rail (F) onto each panel [16] and [17] and secure with 2x screws
(G) for each. Tighten all with a screwdriver.
14
AA
AA
14 14
14
17
16
17
16
17
16
16
16
17
18
18
15 15
19
19
B
D
D
GF
G
F
Drawers x3 A
B
D
11 12
Insert the completed drawers, ensuring they slide smoothly along the
rails.
Attach 8x wedges (L) to each corner of the back panel as shown, and
secure using 8x screws (M). Tighten with a screwdriver.
M
L
L
L
L
L
L
L
L
L
Nixon Three Drawer
ASSEMBLY INSTRUCTIONS
7
mocka.co.nz | mocka.com.au

13 14
Once assembled lift furniture into place, do not drag. Attach the other
end of the safety strap (Z) to the wall with 1x screw (D) and tighten with
a screwdriver. You’re done, enjoy!
Wall Strap
Attach the safety strap (Z) to the underside of the back edge of the top
of the unit using 1x screw (Y). Tighten with a screwdriver.
Z
Y
Z
Y
Z
D
Z
D
Nixon Three Drawer
ASSEMBLY INSTRUCTIONS
8
mocka.co.nz | mocka.com.au
