MODSTER MINI CITO User manual

USER MANUAL / BETRIEBSANLEITUNG
MINI CITO

www
www.modster.at
2
User Manual MODSTER Mini Cito
Safety and caution .................................................................................................................................. 3-4
Troubleshooting ........................................................................................................................................... 4
Product instruciton .................................................................................................................................... 5
Instruction of common tools and installation the electronic part ............................ 5
Practice and maintenance .................................................................................................................... 6
Assemble exploded view .................................................................................................................. 7-15
Fittings view ............................................................................................................................................ 16-20
Table of contents

www
www.modster.at
3
User Manual
Safety and caution
MODSTER Mini Cito
- Never run the model on public roads or streets, as it could endanger trafc.
- Never run the model in crowded areas, near or toward people or animals,to prevent property damage and/or
personal injury.
- Never run the model near rivers, ponds or lakes as to prevent RC car from dropping into the water.
- Make sure that no one else is using the same frequency as yours in your running area. Using the same
frequency at the same time, whether it is driving,ying or sailing.can cause loss of control with RC model,
resulting in serious accidents.
- To avoid a runaway RC model or loss of control, always follow the procedure below:
1. Switch on transmitter.
2. Switch on RC model.
- Follow reverse procedure to shut down.
- Never touch or hinder rotating tire.
- Never run RC model in the rain or let run over puddles, as water
may cause trouble with RC model.
- Motor and battery get very hot after running. Take care when
handle them.
- Remove the batteries from model and transmitter when they are not in use.
Cautions when handing batteries:
- Do not dismantle the battery or charger and do not cut any battery cables.
This may cause short-circuit and/or damage to the product.
- Charge battery with compatible charger following proper procedure that is
called out in the lnstructions.
Do not modify charger or charge battery in improper way.
- Do not recharge battery that is still warm from use as it may damage
the battery. Allow the battery to cool off prior to recharging.
- Make sure to disconnect charger cables from RC model and electRC outlet
when not in use.
- Remove transmitter battery when not using it for a long time as it may
leak and damage transmitter when left for a long period.
- Never incinerate used batteries,as they can explode causing serious accidents.
- Never charge the battery unobserved!
- Never load the battery in the RC model
Safety precautions
Do not operate the model
on public roads, in
crowded places or near
infants, it may cause
accidents or injury.
As the front end of the
antenna may be
dangerous, do not aim it
toward faces.
As the product includes
small and sharp parts,
assemble and store this
product only in places out
of reach of children.
During the car running and after,
the motor will be hot. Please do
not touch it until it had time to
cool down.

www
www.modster.at
4
User Manual
Troubleshooting
MODSTER Mini Cito
Description
The car does not
operate at all
- Please observe the operation manual or packing explanation to install and use, and some parts
should be installed by adults.
- The product contains small part, it may cause swallow or choke.
- Never run a RC model in the seeper or rain, moisture areas, or it may cause the parts malfunction.
- Please throw the wrapper in time to avoid danger for the children.
- Regularly examine for damage to the charge, wire, plug, bodyshell or other parts. In the event of
any damage, it must not be used until the damage has been repaired.
- The charge, battery box and battery must insert with the appointed power source of product symbol
same.
- This product must only be used with the original charger.
- The product contains small parts that can be dangerous for children.
The car does not
follow your operation
and control distance
not enough long.
CAUTION
Cause
Transmitter or receiver is off.
Batteries are not placed
properly in the transmitter.
The drive battery is not
charged enough.
There is not enough power
in the transmitter or receiver
batteries.
Solution
Turn on both transmitter and receiver.
Place batteries in the transmitter
properly.
Charge the drive battery.
Replace the transmitter batteries
with new ones and charge the drive
battery.

www
www.modster.at
5
User Manual MODSTER Mini Cito
2.0mm
Proportinal RC Using Instruction
Introduce the common tools and assemble the electron parts
Turn left the steering wheel, the car will turn
left. Turning left angle can be adjusted by the
degree of wheel twisting.
Move angleMove angle
Move angle Move angle
Forward
Backward
Turret spanner
Side cutter
Crossed spanner
Hobby knife
Philips type screw (Large) Scissors Needle nose pliers
Instant
mucilage
glue
Philips type screw (Small)
Pull
Push
Turn right the steering wheel, the car will turn
right. Turning right angle can be adjusted by
the degree of wheel twisting.
Pull the throttle trigger backward, the car
will forward. Adjusting the angle of
throttle trigger can adjust forward speed
of the car. During the car forward, quickly
push the trigger forward to stop it.
Loosen the trigger to make it retrun
the neutral position when brake. Push
the throttle trigger forward, the car will
backward. Adjusting forward angle of
throttle trigger adjust backward speed
of the car.
Tools needed for assembly

www
www.modster.at
6
User Manual MODSTER Mini Cito
Practise and Maintenance
Let‘s practice! Make RC car circuit at a wide and safe location using corner pylons
(seperately available), empty cans or such. Running fast at straight section and slow down at
curved section is a basic speed control technique useful when driving RC car.
When the car is not in use, you should
remove the battery from the car.
Completely remove sand, mud, dirt,
etc.
Metal outside should apply the rust
prevention oil.
Store the car and batteries seperately
when not in use.
Practise
Maintain

www
www.modster.at
7
User Manual MODSTER Mini Cito
Practise and Maintenance
1290
the right
Steering column
1300
Buffer spring seat
1296
Ball bearing
4*7*1.8
1294
6*2.7The flange
shaft sleeve
1296
Ball bearing
4*7*1.8
1296
Ball bearing
4*7*1.8
1291
Steering
column set
A949-43
Round
head
machinery
screw
M2.5*6*6
1268
Left swing arm
1268
Steering clutch upper
1268
Steering clutch under
1338
Ball head screw
4.9*10.6
1338
Ball head screw
4.9*10.6
1265
Fixed seat for Steerengine
1263
Steering gear
swing arm
1307
The Steerengine
A202-04
Ball head screw
4*9.5
L959-57
2.6*8PB
Cross round
head with self
tapping screw
A949-54
2.6*8KB
Cross countersunk head self tapping screw
Steering
components
1304
Steering link
1290
the left
Steering column
1279
Buffer spring
1259
Second floor components
Steerengine
assembly
Second floor components
Car shell pillar
Steering
compontents
287390
287390
287383
287359
287367
287387
287357
287362
287362
287362
287392
287392
287396
287392
287373
287362
287353

www
www.modster.at
8
User Manual MODSTER Mini Cito
1309 Front and rear
differential
components
0098
Include
screw
M3*3
1316
Shock absorber assembly
0117
3*8KM
Cross
countersunk
head
machine
tooth
screw
A959-B-15
Copper gear
1308
550
The carbon
brush
motor
Electrical
components
1303
The motor seat
1315
Universal drive shaft assembly
287399
287404
287398
287376
287395
287378
287381 287403

www
www.modster.at
9
User Manual MODSTER Mini Cito
17.0MM
1287
Steering gear
connect rod
2*26
23.10MM
Long rod 4.5*40 21.2MM
15.1MM
Short rod 4.5*36
Short rod 4.5*40
1270
After the tyres
1270
Rear wheel hub
75*51.5*20
Tyre sponge
1270
Rear tire
1269
Front tyre
1269
Front wheel hub
1269
Front tire
1287
Steering gear tie rod assembly
1287
Steering gear
pull ball
head
seat
1287
Steering
gear pull
ball head
seat
1288
Front upper tie rod assembly
The ball head block
The ball head block The ball head block
The ball head block
1289
Rear tie rod assembly
The ball head block The ball head block
1289
Steering tie rod assembly
66*50*20
Tyre sponge
12
13
287364
287363
287363
287387
287387 287387
287387
287389
287389
287388
287363
287364
287364
Rear tires

www
www.modster.at
10
User Manual MODSTER Mini Cito
14
15
17 18
1154
12TActive tooth
1154
12TActive tooth
0109
Cross pan head
mechanical
screw
2*8PM
0109
Cross pan
head
mechanical
screw
2*8PM
Right rear wheel
seat assembly
1337
4.9*13.6
The ball
screw 1337
4.9*13.6
The ball
screw
L959-57
2.6*8PB
Cross head
self - attack
screw
L959-57
2.6*8PB
Cross round
head tapping
screw
L959-57
2.6*8PB
Cross
round
head
tapping
screw
1252
The rear
seat left
1296
4*7*1.8 Ball
bearing
1296
4*7*1.8
Ball bearing
1338
4.9*10.6
The ball screw
1274
1.5*9.35O
ptical axis
1283
8*27.5
After the
shaft cup
1274
1.5*9.35
Optical axis
1296
4*7*1.8
Ball bearing
1296
4*7*1.8
Ball bearing
1283
8*27.5
The rear wheel
Shaft cup
1338
4.9*10.6
Ball head
screw
0094
Ball bearing
7*11*3
0094
Ball bearing
7*11*3
A949-49
M3 nut
A949-49
M3 nut
Central drive shaft assembly
1293
Central drive shaft
1260
Reduction gear
Left rear wheel seat
assembly
1266
Hexagon
wheel
seat
1266
Hexagon
wheel seat
1252
The rear
seat right
Front shock absorber
assembly
Rear shock absorber assembly
1302
Shock
absorber
plate 1302
Shock
absorber
plate
1258
Tail fin fastener
On the left
1258
Tail fin fastener
right
1254
Top cover of
rear wave box
1254
Front box top cover
L959--57
2.6*10PB
Cross round
head tapping
screw
287391
287354
287371
287392 287382
287385 287392
287370
287350
287367
287367
287367
287394
287380
287370
287394
287380
287367
287350
287348
287360 287360
287348 287392
287385
287371
287382
287392
287391
287352
287352

www
www.modster.at
11
User Manual MODSTER Mini Cito
19
20
1338
4.9*10.6
The ball screw
1338
4.9*10.6
The ball screw
0102
2.5*10PM
Cross round head machine tooth screw
0102
2.5*10PM
Cross round
head machine
tooth screw
0102
2.5*10PM
Cross round
head machine
tooth screw
0102
2.5*10PM
Cross round
head machine
tooth screw
1296
4*7*1.8
Ball bearing
1296
4*7*1.8
Ball
bearing
1296
4*7*1.8
Ball
bearing
1274
1.5*9.35
Optical axis
1274
1.5*9.35
Optical axis
1296
4*7*1.8
Ball bearing
1295
6*5.2 The flange shaft sleeve
1295
The
flange
shaft
sleeve
6*5.2
Front right steering seat assembly
1253
C-seat right
1315
Universal Drive S
haft Assembly
1315
Universal Drive S
haft Assembly
1251
The front
wheel seat
right
1266
Hexagon
wheel seat
1266
Hexagon
wheel seat
1251
ront
wheel
seat
left
1253
C-seat left
Front turn left to seat assembly
287372
287371
287349
287347
287382
287360 287392
287372
287403
287371
287349
287372
287372
287347
287382
287392
287392
287360
287392
287403

www
www.modster.at
12
User Manual MODSTER Mini Cito
22
21
1323
2.6*5KB
Cross countersunk
head self tapping
screw
1249
Vehicle bottom
1323
2.6*5KB Cross countersunk head self
tapping screw
L959-54
2.6*8KBCross
countersunk
head self tapping
screw
L959-54
2.6*8KB
Cross countersunk head self tapping
screw
1323
2.6*5KB
Cross
countersunk
head self
tapping
screw
1261
Battery
compartment
partition-A
1255
Bottom edge left
1255
Bottom rail right
1262
Bottom of
reduction gear
box
1287
Steering gear tie rod assembly
1307
Steering gear components
Motor assembly
1261
Battery
compartment
partition-B
0114
2.5*8KM
Countersunk hear screw
287355
287355
287369
287377
287377
287377
287397
287387
287356
287369
287345

www
www.modster.at
13
User Manual MODSTER Mini Cito
23
24
Front turn left to seat assembly
1305
Front swing arm reinforcement plate
1277
2*26 Optical axis
1453
M2*4PWM5 Round
head Machine screw
1257
Before
the
crash a
1281
The dog bone
2.5*66.7
A949-49
M3 nut
0256
3*12PM
Cross round head
machine tooth screw
L959-57
2.6*8PB Self tapping screw with round head
L959-57
2.6*8PB Self tapping screw
with round head
L959-57
2.6*8PB
Self
tapping
screw
with
round
head
0553
2*6PB
Self tapping screw
with
round
head
1309
Front and rear differential
components
1309
Front and rear differential components
1267
Rear
swing arm
sleeve D
1453
2*4*PWM5
Aross round
head self
tapping screw
0553
2*6PB
Self tapping
screw
with
round
head
1316
Shock absorber
assembly
0256
3*12PM
Cross round head
machine tooth
screw
1389
3*20PM Cross round head
machine tooth
screw
A949-49
M3 nut
1389
3*20PM
Cross round head machine
tooth screw
1276
2.5*40
Optical axis
1276
2*26
Optical
axis
1254
Front shock absorber assembly
Rear wave
box assembly
1256
Ball head
support
L959-57
2.6*8PB
Cross countersunk head self
tapping screw
L959-57
2.6*8PB
Cross countersunk head
self tapping screw
L959-57
2.6*8PB
Cross
countersunk
head self tapping
screw
1257
Rear
wave box
compression
1306
Rear
swing arm
reinforcement
plate
1267
Rear
swing
arm
sleeve C
Left rear wheel
seat assembly
1289
Rear tie rod assembly
1306
Rear swing arm
reinforcement plate in
front
Rear shock absorber assembly
1316
Shock absorber
assembly
Front wave
box assembly
1305
After the
front
swing
arm
reinforcement
piece
1267
Forearm
sleeve A
1289
Front upper
tie rod assembly
1250
Before the
swing arm
1267
Before the swing arm
Shaft
sleeve
B
1256
Ball head support 1257
Anti - tilting
bar press
287367
287399
287399
287367
287389
287389
287384
287367
287350
287399
287367
287346
287389
287361
287367
287404
287373
287361
287361
287404
287380
287361
287656
226025
287655
287351
287655

www
www.modster.at
14
User Manual MODSTER Mini Cito
25
26
0114
2.5*8KM
Cross countersunk head screw
A949-43
2.5*6PWM6
Cross round
head machine
tooth
screw
1311
Receiver
panel
assembly
A949-43
2.5*6PWM6
Cross round head
machine tooth
screw A949-38
2.6*6PB
Self tapping screw
with round head
L959-54
2.6*8KB
Cross countersunk head self
tapping screw
L959-54
2.6*8KB
Cross countersunk head self
tapping screw
1264
Motor seat presser
1262
Reduction gear cover
Central drive shaft assembly
A949-38
2.6*6PB
Self tapping screw
with round head
287356
287358
287369
287375
287373
287373
287400
287375
287369

www
www.modster.at
15
User Manual MODSTER Mini Cito
28
27
1270
After the tyres
A949-54
R pin
1452
M3 locknut
L959-57
2.6*8PB
Self tapping screw with round head
1269
Front tyre
1335
The tail
1335
Car shell
---1258
The tail presses
287364
287363
287367
287369
118508
287652
287652
287352
Rear tires

www
www.modster.at
16
User Manual MODSTER Mini Cito
Sale parts view
2.5* 8KM screw
assembly
V2-133001
Remote controller Front and rear arms
3*8KM screw assembly
2*6KM screw assembly
Front seat assembly
12 * 3.2 * 0.2 gasket
set assembly
USB charging line
2*6PB screw assembly
Rear seat assembly
12 * 3.2 * 0.2 gasket
set assembly 3*12PM screw assembly
ST2*7PB screw
assembly
car body assembly
Type C Block
Component
287402
0114
287346
287378
0553
287653
287348
0422
287376
287347
287372
287365
0256
287345
287349

www
www.modster.at
17
User Manual MODSTER Mini Cito
Sale parts view
287350
Wave Box Component
Final-end rmware
component
Speed gear upper and
lower cover assembly
Hexagonal seat
assembly
Back tire assembly
Second oor panel
components
Tiller arm assembly
Front and rear arm
sleeve
Ball head support
assembly
Slow down large tooth
assembly
Motor seat press
component
Switcht to clutch
component
Anti-collision
accessories components
Battery partition
assembly
Steering seat press
assembly
Front tire assembly
287356
287352
287360
287364
1256
287358
287354
287362
287357
287353
287361
287351
287359
287355
287363

www
www.modster.at
18
User Manual MODSTER Mini Cito
Buffer spring assembly
Front Wheel Cup
Component
Short pull assembly
Dog bone assembly
Cross shaft assembly
Long pull bar assembly
Universal drive shaft
assembly
Universal cup spring
assembly
Steering column
assembly
Rear Wheel Cup
Component
Steering gear lever
assembly
Steering column
sleeve component
287386
287383
287388
1286
287403
287390
1285
287384
287389
287387
287385
287362
Sale parts view

www
www.modster.at
19
User Manual MODSTER Mini Cito
Sale parts view
287392
Ball bearing assembly
Front swing arm
reinforcement module
Differential
Shock absorbers
Shock absorber
assembly
Backswing arm
reinforcement module
Receiver board
assembly
ST2.6*5KB screw
assembly
Motor Block
Component
Rudder assembly
Car shell components
Steering connecting
rod assembly
Motor components
Coaxial component
1305
287399
287404
287397
287395
287652
1306
287394
287400
287377
287398
287396
287403

www
www.modster.at
20
User Manual MODSTER Mini Cito
Sale parts view
287370
4.9*13.6Ball Head screw
assembly
ST2.6*6PWB6 screw
assembly
ST2.6*6PB screw
assembly
Battery assembly
4.9*10.6Ball Head screw
assembly
M3*5 Inner hexagonal
screw assembly
2.5*6PWM6 screw
assembly
ST2.6*8KB screw
assembly
M3 Loose nut assembly
ST2.6*8PB screw
assembly
ST2*8KB screw
assembly
Ball bearings 7*11*3
groups
Motor teeth 27T group
ST2.6*10PB screw
assembly
287375
287374
A959-B-23
M3 ange nut
118508
287380
287367
287371
287373
287379
287369
3 * 20pm Cross round
head machine screw
226025
287368
287381
287393
287366
