MODSTER M650 User manual

USER MANUAL / BETRIEBSANLEITUNG
E-SCOOTER

www
www.modster.at
2
User Manual MODSTER M650
Technical specifications ............................................................................................. 3
Introduction ...................................................................................................................... 4
Key .......................................................................................................................................... 4
Intended Use .................................................................................................................... 5
Package contents .......................................................................................................... 5
Important safety instructions ................................................................................ 6
Preparation ....................................................................................................................... 9
Display functions ............................................................................................................ 11
Using the battery ............................................................................................................ 13
First use ................................................................................................................................. 16
Maintenance and care ................................................................................................. 18
Warranty ............................................................................................................................. 23
Information on disposal ............................................................................................. 26
Declaration / certificate of conformity ............................................................ 26
Notes ....................................................................................................................................... 27
Table of contents

www
www.modster.at
3
User Manual
Technical specications
MODSTER M650
Material Aluminium
Product size 1270 x 480 x 970 mm
5°
Maximum load 100 kg
Motor 350 Watt
Maximum range approx. 20 km*
Product size folded 1270 x 330 x 660 mm
Display LCD
Battery 36 V / 7.5 Ah lithium battery
Maximum speed approx. 25 km/h*
Charger 220-240 V / 50-60 Hz
Wheel size 12“ pneumatic tyres at the front and rear
Vibration intensity
58 dB
Dead weight 17.4 kg
Charging time approx. 5 hours
Airborne noise emissions
Brakes Disk brake at the front and rear
Gradeability
0.09-0.13 mm/s

www
www.modster.at
4
User Manual
Introduction
Key
Thank you for purchasing the Modster M650!
Please read the instruction manual carefully before using the E-Scooter and
ensure that it is used properly and in accordance with the instructions.
Retain the instruction manual for future reference. Only give the
E-Scooter to third parties in conjunction with the instruction manual.
The manufacturer reserves the right to make changes to the product.
The instruction manual and illustrations within it may differ depending on the
model.
We hope you enjoy using the Modster M650!
MODSTER M650
Contains important information to avoid injuries.
Contains important information to prevent damage to the product.
When reading the manual, it points out important information and
instructions.
Explanation of symbols

www
www.modster.at
5
User Manual MODSTER M650
Intended use
Package contents
The Modster M650 E-Scooter is a vehicle (fun vehicle) designed for transporting
one person.
The Folding E-Scooter is exclusively for private use and is not suitable for
commercial use.
Only use the Folding E-Scooter as described in this instruction manual.
Any other use is considered improper and may result in material damage or even
injury to people.
The manufacturer or distributor accepts no liability for damage caused by
unintended or improper use.
*The saddle and luggage rack must be assembled before first use (page 8)
User manual
Luggage rack with rear light*
Saddle and seat post*
Folding E-Scooter
Charger Allen key

www
www.modster.at
6
User Manual MODSTER M650
Important safety information
• Please strictly comply with the safety regulations stated in the manual. The
producer or distributor cannot be held liable for any injury to persons, material
damage, accidents or legal disputes resulting from the violation of the safety re-
gulations. The liability is always limited to the purchase value of the E-Scooter.
• Please check your Folding E-Scooter before every journey (see the section on
„Maintenance and Care“ on page 17).
• Do not use the Folding E-Scooter if there is visible damage or a damaged
power cord or plug.
• Modifying the Folding E-Scooter is prohibited.
• Repairs may only be carried out by qualified personnel authorised by KSR
Group GmbH. Liability and warranty claims are excluded if repairs are carried out
independently or in the event of improper connections or incorrect
operation.
• Always wear a safety helmet, appropriate clothing, protectivegear and
flat-heeled shoes.
• Hold the handlebar with both hands while riding.
• Practise riding the Folding E-Scooter on open and level terraininitially.
• The Folding E-Scooter is not suitable for children under 12 years of age.
• Please carefully read all the instructions in this instruction manual. This should
help to minimise potential risks. Please note that even if you follow the
instructions completely, there will still be some remaining risk when using the
Folding E- Scooter. Always adjust your speed to the current situation to
minimise the risk of accidents and injuries.

www
www.modster.at
7
User Manual MODSTER M650
Important safety information
The Folding E-Scooter has been designed to transport one person with a
maximum weight of 100 kg.
• The Folding E-Scooter is suitable for use on flat, dry surfaces. Do not ride
through water, in rainy conditions, at night or when visibility conditions are poor.
• The Folding E-Scooter is not suitable for stunts – DO NOT ATTEMP to jump or
perform any dangerous manoeuvres.
• Do not leave the Folding E-Scooter outdoors. Please store it in a dry, dark
location.
• Make sure that all bolts are tight before each ride.
• Be careful not to touch any moving parts during the ride, in order to avoid
injuries.
• The Folding E-Scooter is a vehicle (leisure vehicle) designed for transporting one
person.
• According to the Road Traffic Act (StVO – valid only in Austria), every road user
must behave in such a way that no other road user is endangered, harmed, ha-
rassed or hindered. In order to be allowed to operate your Folding E-Scooter on
public roads, it must comply with the legal guidelines. Basically, the Folding
E-Scooter must be equipped with two independ- ently operating brakes, a bell, a
brightly lit headlamp that illuminates the lane ahead with white or
light-yellow, steady light, and must have a red taillight and reflector strips.
• Before starting to use your Folding E-Scooter, check the current legal
provisions for your region by contacting the relevant authorities.

www
www.modster.at
8
User Manual MODSTER M650
Important safety information
• The Folding E-Scooter is equipped with a lithium ion battery. Please note that
in some countries there are separate regulations for transporting lithium ion bat-
teries.
• The best operating temperature for the battery is between 10° C and 30° C.
Above and below this temperature the power output will deteriorate, resulting
in a reduced range.
- Each range information, as well as information on maximum speeds and incli-
ne ability are heavily dependent on parameters such as the state of charge of the
battery, condition of the ground, inclines or declines during the driving route,
weight of the person driving, physical performance by diving, or if available, use
of the pedals, weather conditions, headwind and depending on other factors.
Our information relates to the optimal case.

www
www.modster.at
9
User Manual MODSTER M650
Preparation
Take the Folding E-Scooter out of its box, pull the locking le-
ver on the steering column forward and fold the handlebar up.
Then push the lever back again.
Open the quick release in the middle of the handlebar and turn
the handlebar to a position thats comfortable for you.
Open the quick realease on the seat post mount on the frame
ans insert the seat post. Adjust the seat height to a
comfortable position and then close the quick release.

www
www.modster.at
10
User Manual MODSTER M650
Preparation
Make sure that the front light, rear light and bell are working.
Check the battery capacity on the display before setting off.
• Regularly check the tyre pressure and fill the tyres with air as nee-
ded.
• The recommended tyre pressure is 2.8 bar per tyre.
Remove the 4 mounting screws for the luggage rack above the
rear mudguard. Adjust the luggage rack and fix it in place with
the screws you just removed.
Check the pressure of the tyres.

www
www.modster.at
11
User Manual MODSTER M650
Display functions
• Press briefly to increase the speed level.
• Press and hold to turn the front light on or off.
• Press briefly to decrease the speed level.
Button functions
The display has three buttons:
• Press and hold to turn the display on or off.
• Press briefly to choose between the following display options:
1. ODO shows the total distance covered
2. TRIP shows the distance travelled since the scooter
was last turned on
3. Battery voltage in Volts
4. PWM shows the pulse width modulation
5. Error code (display in the event of an error)

www
www.modster.at
12
User Manual MODSTER M650
Display functions
• Before starting your journey, make sure that the front and rear
lights work!
• The light must be switched on in the dark or in poor visibility!
*Guide values, with a user weighing approx. 75 kg and with a fully
charged battery on smooth, even road surfaces and under optimal
temperature conditions (see pages 12, 13 and 14)
Display Description
Speed
Charge level indicator
Battery voltage in volts
Total distance
Distance since being
turned
on
PWM
Speed level*:
ECO: 13 km/h
MID: 19 km/h
HIGH: 23 km/h

www
www.modster.at
13
User Manual MODSTER M650
Using the battery
1. The charging port is located at the rear end of the running board
as shown.
2. Open the protective cap over the charging port
3. Make sure the charging port and charger are dry.
4. Make sure that the Folding E-Scooter is turned off.
5. Connect the charging cable to the charging port.
6. Connect the charging device‘s mains plug to a suitable wall
socket (220 - 240 V / 50 - 60 Hz).
7. The charging light on the charger will light red when charging.
8. The battery is charged once the charging light changes from
red to green. You should stop charging at this point.
9. Disconnect the charger from the mains and the Folding
E-Scooter.
Charging the battery:

www
www.modster.at
14
User Manual MODSTER M650
Using the battery
• Never remove the battery from the Folding E-Scooter.
• Charge the battery every 2 months for at least 1 hour, even if the
Folding E-Scooter has not been in use, otherwise it will
lose capacity.
• Regular charging protects the battery from total discharge.
• Never heat the battery or throw it into an open fire.
• Never dispose of battery cells in the household waste.
• Never get moisture on the battery contacts.
• The optimal operating temperature for the battery is between
10° C and 30° C. Above and below this temperature, the power out-
put will deteriorate, resulting in a reduced range and power out-
put.
• The Folding E-Scooter may only be charged with the sup- plied
charger. Ensure the correct voltage supply (220 - 240 V / 50 - 60
Hz).
• The Folding E-Scooter must not be charged if the charging cable
is damaged. Please contact customer service.
• A battery‘s service life and performance depends on its age, care
and how often it has been used.
• For optimum battery life, charge and store the E-Scooter in a dry
and clean environment, preferably at a temperature between 7
and 15° C.
• The Folding E-Scooter takes approx. 5 hours to charge. If the char-
ger is permanently connected to the battery and power
supply, this will have a negative effect on the battery life.
• The Folding E-Scooter and the charger must not be covered
during charging.

www
www.modster.at
15
User Manual MODSTER M650
Using the battery
• Depending on the charge state, lithium batteries have a freezing
point of approx. -20° C to -25° C. If a battery cell freezes, it will be
irretrievably destroyed and the whole battery will need to be
replaced. A lithium battery loses capacity at low temperatures just
like conventional batteries.
• Compared to other battery models, Lithium Ion batteries have
a very low self-discharge and a very low memory effect, but they
must be periodically charged.
• Please note that a over-discharged battery is irreparably
destroyed and must to be replaced for a fee. The battery should
never be completely discharged during operation.
-never charge unattended

www
www.modster.at
16
User Manual MODSTER M650
First use
Before you begin:
Wear a safety helmet and protectors
for your own safety.
• Fold in the kickstand before riding, otherwise there may be
a risk of accidents and injuries.
On/off button on the rear light
Kickstand
• Wear comfortable leisure or sports clothing and flat shoes
while riding.
• Before riding for the first time, make sure you have plenty
of space and ensure that there are no obstacles in the way.
• Fold the handlebar up and check the tyre pressure (see
section on „Preparation“ on page 8).
• Please check your Folding E-Scooter before every journey
(see the section on „Maintenance and Care“ on page 17).
• Switch on the Folding E-Scooter (see section on „Display
functions“ on page 10).
• Turn on the rear light.

www
www.modster.at
17
User Manual MODSTER M650
First use
First steps
Always turn the
Rear wheel brake
Throttle twistgrip
Front wheel brake
• Use the throttle twist grip to accelerate.
• You can use the front and rear brakes to brake.
• You can choose between three speed levels (see section on
„Display functions“ on page 10).
• Folding E-Scooter and the rear light off after riding.
• Charge the Folding E-Scooter.
• To fold in, pull the locking lever on the handlebar.
• Please note the information on storage (see section on
„Using the battery“ on pages 12, 13 and 14)

www
www.modster.at
18
User Manual MODSTER M650
Maintenance and care
• Before each ride, please make sure that all screws or self-locking fas-
teners and quick release clamps are tightened and that the the hand-
lebar‘s locking lever is well engaged.
• Make sure the tyre pressure is correct (see page 9)!
• Only use a soft, damp cloth for cleaning the Folding E-Scooter. Dirt
that cannot be removed this way can be removed with plastic polish.
Follow the manufacturer‘s instructions in this respect.
• Never use alcohol, cleaner‘s naphtha, acetone or other corrosive and
volatile chemical solvents that are corrosive to surfaces. These
substances can damage the bike‘s appearance and its exterior or
interior structure.
• Never clean the Folding E-Scooter with a strong jet of water or
high-pressure cleaner.
• Make sure the Folding E-Scooter is switched off and the charging so-
cket cover is closed before cleaning, otherwise you may be exposed to
the risk of electric shock or damage the Folding E-Scooter.

www
www.modster.at
19
User Manual MODSTER M650
Maintenance and care
• Store your Folding E-Scooter in a dry and cool place.
• A well-maintained battery can still provide good performance even
after many kilometres. Charge the battery after each ride and avoid
operating the battery on „empty“. Please note that the performance of
the battery decreases continuously at low temperatures (see
section on „Using the battery“ on
pages 12, 13 and 14).
• Do not store the scooter outdoors. Exposing the Folding E-Scooter to
sunlight or to hot or cold environments will accelerate ageing of the
plastic surfaces, in particular, and reduce the battery life.
• Do not forget to turn off the Folding E-Scooter after each ride and to
charge the battery. The cells will be irreparably damaged if the bat-
tery is over-discharged. Damage resulting from incorrect use is not
covered by the warranty. Removing or opening the battery is not per-
mitted.

www
www.modster.at
20
User Manual MODSTER M650
Maintenance and care
Adjusting the brake callipers:
• Check regularly to see whether the brake callipers of the two disc
brakes are properly adjusted.
• You will need the Allen key and a rubber band to adjust the brake
callipers:
1. Slightly loosen the two brake calliper mounting bolts until you can
move the brake calliper.
2. Then fix the brake lever with the rubber band to centre the brake
calliper.
3. Tighten both brake calliper mounting bolts again. After removing
the rubber band, check whether the wheel can be moved easily.
• The adjustment procedure is the same for both the front and rear
brakes.
Brake calliper mounting bolts
