Molnlycke Avance Solo User manual

Using Avance®Solo
A few things to keep in mind if you are receiving
treatment with Avance®Solo negative pressure wound
therapy (NPWT) system.

Contents
Introduction to Negative Pressure Wound Therapy (NPWT)
Get acquainted with NPWT and Avance®Solo 04–05
Things to keep in mind while using Avance®Solo
Learn about what to do and what to avoid when
receiving treatment with Avance®Solo 06–07
How to care for your Avance®Solo
Information on how to clean and care for your medical
device and what the audible and visual signals mean 08–11
Note: You should immediately contact your healthcare professional if you
experience any problems. Thisincludes bleeding, elevated blood pressure
or issues with the device. For any questions, reach out to your caregiver:
Name:
Phone:
Email:

4
What is Negative Pressure Wound Therapy (NPWT)?
Negative Pressure Wound Therapy (NPWT) is a method of treating wounds using
suction. The dressing is airtight and the pump creates a subatmospheric pressure,
clearing the wound of fluids.
• It helps support healing in complex and slow to heal wounds1
• It improves wound bed preparation that supports healing1
• It helps reduce swelling and protects the wound from external contamination2
What are the different
parts of Avance®Solo?
5
You are receiving treatment with
Avance®Solo NPWT from Mölnlycke®.
This brochure will inform you on
how to use and care for the device.
Please read it carefully.
Avance Solo
Pump Avance Solo Canister 50 ml
Dressing tubing
Avance Solo Silicone Bordered Dressing
Fixation strips
Canister tubing
Avance®Solo NPWT System
Manufacturer
Mölnlycke Health Care AB
Gamlestadsvägen 3C, Box 13080, SE-402 52 Göteborg, Sweden www.molnlycke.com
PATIENT USER MANUAL

6 7
Things to keep in mind
while using Avance®Solo
Avance®Solo is a medical device and it is important that you properly care for it.
The information below is gathered from the patient user manual, for complete instructions,
warnings and precautions see the patient user manual, included in the product package.
How to handle your daily hygiene routines
You can take light showers while receiving treatment with Avance®Solo, but it is
important that you do not expose the dressing, device, canister or tubing to jets of water.
Follow the guide below on how to handle your device correctly during hygiene routines
to avoiding contamination.
Do not:
• Change dressings yourself
• Expose the dressing, device, canister or tubing to jets of water, cold or heat
(operational temperature 5–40 °C)
• Submerge the dressing, pump, canister or tubing into water
• Use on an aircraft. Remove batteries during air travel
• Disassemble or tamper with the device
• Let children or pets have access to the device
Important features:
• Make sure you are aware of the visual and audible alarms for leakage,
blockage and low battery given by Avance Solo Pump. See page 10 for a list
of signals and alarms
•
target pressure level, in the same manner as larger benchtop systems
•
a healthcare professional
Make sure to wear and place the device in
a way that avoids:
• Entrapment or strangulation (i.e. tubing spiraled around a body part)
• Knotting or blocking of tubing
• When using the belt clip ensure that it is positioned to either side of your waist.
If for comfort or convenience, you position it at the front, remove prior to sitting to
avoid the pump being pushed out of the belt clip
Follow these steps when taking a light shower:
Pause therapy by pressing down the
green start button, and release after two
(2) seconds.
Clamp the canister tubing and dressing
tubing by positioning the slide clamps
next to the green connectors and slide
across the tubes until secured.
Restart therapy by pressing down the
green start button, and release after two
(2) seconds, until the pump activates and
Disconnect the two halves of the green
connector, and place the part with the
pump safely away from the shower.
Ensure that the dressing tubing is not
submerged when taking a shower.
After showering reconnect the dressing
green connectors. Once connected,
release the two clamps.
12
34
56
Avance®Solo NPWT System
Manufacturer
Mölnlycke Health Care AB
Gamlestadsvägen3C, Box 13080, SE-402 52 Göteborg, Sweden www.molnlycke.com
4 Precautions
• The Avance Solo Pump has both visual and audible notifications and alarms. Carry or position the pump so that you will be
able to detect audible and visual notifications or alarms.
• Regularly monitor the canister mounted on the pump. If the canister appears full or the pump alarms for blockage, change
the canister according to instructions provided in this manual, see Section 7.3.
• When the Avance Solo Pump alarms due to a low battery, replace the batteries in the pump according to the instructions
provided in this manual, see Section 7.4. Only use the type and model of lithium batteries specified for this product by
Mölnlycke Health Care, see Section 13.
• Ensure that the battery lid on the Avance Solo Pump is closed during therapy.
• If you see signs of possible infection such as pain, reddening, odor, or sensitization of the wound area or sudden change of
wound fluid volume or color, immediately contact a healthcare professional.
• Inform your healthcare professional if you are hypersensitive to the product’s materials, see Section 10.
• The Avance Solo Canister is provided sterile. Do not use the canister if the inner packaging of the canister is damaged.
• Do not place the Avance Solo Pump with canister in water or other liquids. If the pump is wet, disconnect the pump and
canister and contact your healthcare professional.
• Do not expose the Avance Solo Border Dressing to extensive contact with water. If the dressing is disconnected from the pump,
place the dressing tubing so that water does not enter the connector of the dressing tubing.
• Do not take the pump apart.
• Do not modify pump, canister, tubing or dressing as any modification may significantly compromise the ability of Avance Solo
NPWT System to deliver therapy.
• The Avance Solo Pump is not intended for use aboard aircraft. During air travel pause the pump and remove the batteries.
Make sure that the dressing is not left without applied suction longer than the time determined by your healthcare
professional.
5 Description of Avance Solo NPWT System
Avance Solo NPWT System consists of Avance Solo Pump, Avance Solo Canister 50ml and Avance Solo Border Dressing with
fixation strips for a close seal. Your healthcare professional may have applied Avance Solo Foam under the dressing if you have
a cavity wound.
Avance Solo Pump
1. Push button for start and paus
2. Speaker
LIGHT INDICATORS
3. Blockage
4. Leakage
5. Low battery
A. Connectors — connecting dressing and canister
B. Clamps — blocking fluid leakage from tubings
when disconnecting dressing from canister
C. Canister tubing
D. Dressing tubing
The dressing is applied on the wound and the dressing tubing is then connected to the canister tubing via the green connectors.
The canister is attached to the pump. When the pump is started a negative pressure will be created, providing suction to the
wound. Fluid from the wound will be transported and absorbed in the dressing. Any excess fluid will be transported from the
dressing and collected in the canister. If the canister becomes full, you or your health care specialist will be able to change
PATIENT USER MANUAL
www.molnlycke.com/symbols
Do not reuse
MRI unsafe
ETL Listed Marking
Follow instructions for use
Do not use if package is damaged
The device is sterilized using ethylene
oxide
Caution, see instructions for use
Keep dry
Keep away from rain
Temperature limitation
Humidity limitation
Atmospheric pressure limitation
Keep away from sunlight
Keep away from heat
Ingress Protection
Applied part type BF
System lasts up to 14 days
Separate collection of Waste Electrical and
Electronic Equipment (WEEE)
Manufacturer
Medical Device
Only use the type and model of lithium
batteries specified for this product by
Mölnlycke Health Care, see section 13.
Use by date / Expiry date
Batch code
Catalogue number
Leakage
Blockage
Avance®Solo NPWT System
Manufacturer
Mölnlycke Health Care AB
Gamlestadsvägen3C, Box 13080, SE-402 52 Göteborg, Sweden www.molnlycke.com
4 Precautions
• The Avance Solo Pump has both visual and audible notifications and alarms. Carry or position the pump so that you will be
able to detect audible and visual notifications or alarms.
• Regularly monitor the canister mounted on the pump. If the canister appears full or the pump alarms for blockage, change
the canister according to instructions provided in this manual, see Section 7.3.
• When the Avance Solo Pump alarms due to a low battery, replace the batteries in the pump according to the instructions
provided in this manual, see Section 7.4. Only use the type and model of lithium batteries specified for this product by
Mölnlycke Health Care, see Section 13.
• Ensure that the battery lid on the Avance Solo Pump is closed during therapy.
• If you see signs of possible infection such as pain, reddening, odor, or sensitization of the wound area or sudden change of
wound fluid volume or color, immediately contact a healthcare professional.
• Inform your healthcare professional if you are hypersensitive to the product’s materials, see Section 10.
• The Avance Solo Canister is provided sterile. Do not use the canister if the inner packaging of the canister is damaged.
• Do not place the Avance Solo Pump with canister in water or other liquids. If the pump is wet, disconnect the pump and
canister and contact your healthcare professional.
• Do not expose the Avance Solo Border Dressing to extensive contact with water. If the dressing is disconnected from the pump,
place the dressing tubing so that water does not enter the connector of the dressing tubing.
• Do not take the pump apart.
• Do not modify pump, canister, tubing or dressing as any modification may significantly compromise the ability of Avance Solo
NPWT System to deliver therapy.
• The Avance Solo Pump is not intended for use aboard aircraft. During air travel pause the pump and remove the batteries.
Make sure that the dressing is not left without applied suction longer than the time determined by your healthcare
professional.
5 Description of Avance Solo NPWT System
Avance Solo NPWT System consists of Avance Solo Pump, Avance Solo Canister 50ml and Avance Solo Border Dressing with
fixation strips for a close seal. Your healthcare professional may have applied Avance Solo Foam under the dressing if you have
a cavity wound.
Avance Solo Pump
1. Push button for start and paus
2. Speaker
LIGHT INDICATORS
3. Blockage
4. Leakage
5. Low battery
PATIENT USER MANUAL
www.molnlycke.com/symbols
Do not reuse
MRI unsafe
Follow instructions for use
Do not use if package is damaged
The device is sterilized using ethylene
oxide
Caution, see instructions for use
Temperature limitation
Humidity limitation
Atmospheric pressure limitation
Applied part type BF
Manufacturer
Medical Device
Only use the type and model of lithium
batteries specified for this product by
Mölnlycke Health Care, see section 13.
Avance®Solo NPWT System
Manufacturer
Mölnlycke Health Care AB
Gamlestadsvägen3C, Box 13080, SE-402 52 Göteborg, Sweden www.molnlycke.com
4 Precautions
• The Avance Solo Pump has both visual and audible notifications and alarms. Carry or position the pump so that you will be
able to detect audible and visual notifications or alarms.
• Regularly monitor the canister mounted on the pump. If the canister appears full or the pump alarms for blockage, change
the canister according to instructions provided in this manual, see Section 7.3.
• When the Avance Solo Pump alarms due to a low battery, replace the batteries in the pump according to the instructions
provided in this manual, see Section 7.4. Only use the type and model of lithium batteries specified for this product by
Mölnlycke Health Care, see Section 13.
• Ensure that the battery lid on the Avance Solo Pump is closed during therapy.
• If you see signs of possible infection such as pain, reddening, odor, or sensitization of the wound area or sudden change of
wound fluid volume or color, immediately contact a healthcare professional.
• Inform your healthcare professional if you are hypersensitive to the product’s materials, see Section 10.
• The Avance Solo Canister is provided sterile. Do not use the canister if the inner packaging of the canister is damaged.
• Do not place the Avance Solo Pump with canister in water or other liquids. If the pump is wet, disconnect the pump and
canister and contact your healthcare professional.
• Do not expose the Avance Solo Border Dressing to extensive contact with water. If the dressing is disconnected from the pump,
place the dressing tubing so that water does not enter the connector of the dressing tubing.
• Do not take the pump apart.
• Do not modify pump, canister, tubing or dressing as any modification may significantly compromise the ability of Avance Solo
NPWT System to deliver therapy.
• The Avance Solo Pump is not intended for use aboard aircraft. During air travel pause the pump and remove the batteries.
Make sure that the dressing is not left without applied suction longer than the time determined by your healthcare
professional.
5 Description of Avance Solo NPWT System
Avance Solo NPWT System consists of Avance Solo Pump, Avance Solo Canister 50ml and Avance Solo Border Dressing with
fixation strips for a close seal. Your healthcare professional may have applied Avance Solo Foam under the dressing if you have
a cavity wound.
Avance Solo Pump
1. Push button for start and paus
PATIENT USER MANUAL
www.molnlycke.com/symbols
Do not reuse Do not use if package is damaged
The device is sterilized using ethylene
oxide Medical Device
Solo NPWT System
Mölnlycke Health Care AB
Gamlestadsvägen 3C, Box 13080, SE-402 52 Göteborg, Sweden www.molnlycke.com
4 Precautions
• The Avance Solo Pump has both visual and audible notifications and alarms. Carry or position the pump so that you will be
able to detect audible and visual notifications or alarms.
• Regularly monitor the canister mounted on the pump. If the canister appears full or the pump alarms for blockage, change
the canister according to instructions provided in this manual, see Section 7.3.
• When the Avance Solo Pump alarms due to a low battery, replace the batteries in the pump according to the instructions
provided in this manual, see Section 7.4. Only use the type and model of lithium batteries specified for this product by
Mölnlycke Health Care, see Section 13.
• Ensure that the battery lid on the Avance Solo Pump is closed during therapy.
• If you see signs of possible infection such as pain, reddening, odor, or sensitization of the wound area or sudden change of
wound fluid volume or color, immediately contact a healthcare professional.
• Inform your healthcare professional if you are hypersensitive to the product’s materials, see Section 10.
• The Avance Solo Canister is provided sterile. Do not use the canister if the inner packaging of the canister is damaged.
• Do not place the Avance Solo Pump with canister in water or other liquids. If the pump is wet, disconnect the pump and
canister and contact your healthcare professional.
• Do not expose the Avance Solo Border Dressing to extensive contact with water. If the dressing is disconnected from the pump,
place the dressing tubing so that water does not enter the connector of the dressing tubing.
• Do not take the pump apart.
• Do not modify pump, canister, tubing or dressing as any modification may significantly compromise the ability of Avance Solo
NPWT System to deliver therapy.
• The Avance Solo Pump is not intended for use aboard aircraft. During air travel pause the pump and remove the batteries.
Make sure that the dressing is not left without applied suction longer than the time determined by your healthcare
PATIENT USER MANUAL

8 9
How to care for
your Avance®Solo
Changing the batteries
You must change the two (2) batteries if there is a low battery alarm, or after 7 days.
Only use AA 1,5V GP15LF lithium batteries.
Changing the canister
You can see if the canister should be changed through the transparent window on the
back of the canister, if there’s a pump blocking alarm. If you are to change the canister,
follow the steps below. Always try out changing the canister together with a healthcare
professional when receiving Avance®Solo.
Slide the tubing clamps up close to the
green connectors and push both clamps
across the tubing to ensure there is no
Release tubing at the back of the pump.
Press hard onthe side-mounted plastic tabs
and pull while gently rocking to disconnect
the canister. Connect the new canister.
You should expect the canister to be a
maintaining an effective seal.
Recouple the two green connectors,
release the clamps on the tubes and
restart the pump by pressing down the green
start button, release after two (2) seconds.
Monitor that the negative pressure is active,
the dressing should be contracted and firm
to the touch. Dispose of the used canister
as directed by your healthcare professional.
12
3 4
Pause the pump by pressing down the
green start button, and release after two
(2) seconds. The pump will emit two
Cleaning the device
Occasional cleaning of the pump can be
performed by wiping with a damp cloth
or with a non-abrasive detergent. Do not
put the pump under running water.
To replace the batteries, perform the
following steps:
• If the pump is still active, pause the
pump by pressing down the green
start button, and release after
two (2) seconds
• Open the battery compartment by
sliding the lid
• Remove the batteries
• Insert new batteries, ensuring that
the positive terminal (marked +) and
negative terminal (marked-) of each
battery matches the +/- label in the
battery compartment
• Close the battery compartment lid
• Restart the pump by pressing down
the green start button, release after
two (2) seconds. Make sure that
the negative pressure is active, the
dressing should be contracted and
• The Avance Solo Pump has both visual and audible notifications and alarms. Carry or position the pump so that you will be
able to detect audible and visual notifications or alarms.
• Regularly monitor the canister mounted on the pump. If the canister appears full or the pump alarms for blockage, change
the canister according to instructions provided in this manual, see Section 7.3.
• When the Avance Solo Pump alarms due to a low battery, replace the batteries in the pump according to the instructions
provided in this manual, see Section 7.4. Only use the type and model of lithium batteries specified for this product by
Mölnlycke Health Care, see Section 13.
• Ensure that the battery lid on the Avance Solo Pump is closed during therapy.
• If you see signs of possible infection such as pain, reddening, odor, or sensitization of the wound area or sudden change of
wound fluid volume or color, immediately contact a healthcare professional.
• Inform your healthcare professional if you are hypersensitive to the product’s materials, see Section 10.
• The Avance Solo Canister is provided sterile. Do not use the canister if the inner packaging of the canister is damaged.
• Do not place the Avance Solo Pump with canister in water or other liquids. If the pump is wet, disconnect the pump and
canister and contact your healthcare professional.
• Do not expose the Avance Solo Border Dressing to extensive contact with water. If the dressing is disconnected from the pump,
place the dressing tubing so that water does not enter the connector of the dressing tubing.
• Do not modify pump, canister, tubing or dressing as any modification may significantly compromise the ability of Avance Solo
NPWT System to deliver therapy.
• The Avance Solo Pump is not intended for use aboard aircraft. During air travel pause the pump and remove the batteries.
Make sure that the dressing is not left without applied suction longer than the time determined by your healthcare
5 Description of Avance Solo NPWT System
Avance Solo NPWT System consists of Avance Solo Pump, Avance Solo Canister 50ml and Avance Solo Border Dressing with
fixation strips for a close seal. Your healthcare professional may have applied Avance Solo Foam under the dressing if you have
1. Push button for start and paus
Avance Solo Canister 50ml
Avance Solo Border Dressing
with Fixation strips
Avance Solo Foam
— connecting dressing and canister
— blocking fluid leakage from tubings
when disconnecting dressing from canister
The dressing is applied on the wound and the dressing tubing is then connected to the canister tubing via the green connectors.
The canister is attached to the pump. When the pump is started a negative pressure will be created, providing suction to the
wound. Fluid from the wound will be transported and absorbed in the dressing. Any excess fluid will be transported from the
dressing and collected in the canister. If the canister becomes full, you or your health care specialist will be able to change the
To replace the canister, perform the following steps
1. If the pump is active, pause the pump by pressing down the green push button, and release after two (2) seconds.
2. Clamp the canister tubing and dressing tubing by positioning the slide clamps next to the green connectors and slide across
the tubings until secured. Blocking the tubings minimizes fluid leakage when you disconnect the canister from the dressing.
3. Disconnect the canister tubing from the dressing tubing by squeezing the connector from both sides and pull apart.
4. Remove the canister by pushing the spring buttons on both sides and pull.
5. Attach a new canister to the pump by pushing the canister until it clicks on both sides.
6. Be sure to attach the canister tubing onto the back of the pump.
7. To continue therapy, connect the canister tubing to the dressing tubing.
8. Make sure that the clamps on the canister and dressing tubings are released. Restart the pump by pressing down the green
push button, and release after two (2) seconds.
9. Monitor that the negative pressure is active, the dressing should be contracted and firm to the touch.
7.4 How do I know when to change batteries?
The Avance Solo Pump is battery powered and will require you or responsible healthcare
professional to change batteries, normally after 7 days or when the pump alarms for Low battery.
When the battery power is reaching its end, the pump will indicate the following:
When 24 hours of battery power remain, the indicator light for LOW BATTERY flashes once every
five (5) seconds.
When less than 4 hours of battery power remain, the indicator light for LOW BATTERY flashes once
every second and the pump repeatedly alarms with a beep.
To replace batteries, perform the following steps
Only use the type and model of lithium batteries specified for this product by Mölnlycke Health Care, see section 13.
2 3
2s2s
1
4 5 6
7
2s2s
8 9
• The Avance Solo Pump has both visual and audible notifications and alarms. Carry or position the pump so that you will be
• Regularly monitor the canister mounted on the pump. If the canister appears full or the pump alarms for blockage, change
the canister according to instructions provided in this manual, see Section 7.3.
• When the Avance Solo Pump alarms due to a low battery, replace the batteries in the pump according to the instructions
provided in this manual, see Section 7.4. Only use the type and model of lithium batteries specified for this product by
• Ensure that the battery lid on the Avance Solo Pump is closed during therapy.
• If you see signs of possible infection such as pain, reddening, odor, or sensitization of the wound area or sudden change of
wound fluid volume or color, immediately contact a healthcare professional.
• Inform your healthcare professional if you are hypersensitive to the product’s materials, see Section 10.
• The Avance Solo Canister is provided sterile. Do not use the canister if the inner packaging of the canister is damaged.
• Do not place the Avance Solo Pump with canister in water or other liquids. If the pump is wet, disconnect the pump and
• Do not expose the Avance Solo Border Dressing to extensive contact with water. If the dressing is disconnected from the pump,
place the dressing tubing so that water does not enter the connector of the dressing tubing.
• Do not modify pump, canister, tubing or dressing as any modification may significantly compromise the ability of Avance Solo
• The Avance Solo Pump is not intended for use aboard aircraft. During air travel pause the pump and remove the batteries.
Make sure that the dressing is not left without applied suction longer than the time determined by your healthcare
Avance Solo NPWT System consists of Avance Solo Pump, Avance Solo Canister 50ml and Avance Solo Border Dressing with
fixation strips for a close seal. Your healthcare professional may have applied Avance Solo Foam under the dressing if you have
Avance Solo Canister 50ml
Avance Solo Border Dressing
with Fixation strips
To replace the canister, perform the following steps
1. If the pump is active, pause the pump by pressing down the green push button, and release after two (2) seconds.
2. Clamp the canister tubing and dressing tubing by positioning the slide clamps next to the green connectors and slide across
the tubings until secured. Blocking the tubings minimizes fluid leakage when you disconnect the canister from the dressing.
3. Disconnect the canister tubing from the dressing tubing by squeezing the connector from both sides and pull apart.
4. Remove the canister by pushing the spring buttons on both sides and pull.
5. Attach a new canister to the pump by pushing the canister until it clicks on both sides.
6. Be sure to attach the canister tubing onto the back of the pump.
7. To continue therapy, connect the canister tubing to the dressing tubing.
8. Make sure that the clamps on the canister and dressing tubings are released. Restart the pump by pressing down the green
push button, and release after two (2) seconds.
9. Monitor that the negative pressure is active, the dressing should be contracted and firm to the touch.
2 3
2s2s
1
456
7
2s2s
8 9
AUDIBLE AND VISUAL DISPLAY
The LEAKAGE indicator
light flashes once every
second.
The pump repeatedly
alarms with a beep and
will then pause.
POSSIBLE CAUSE
An air leakage has been
detected.
HOW TO TROUBLESHOOT
To correct a leak:
Press around the dressing
border and the strips
to improve contact with
the skin.
Check that the canister
is attached to the pump,
that the canister tubing is
11 Other information
If any serious incident has occurred in relation to Avance Solo NPWT System, it should be reported to Mölnlycke Health Care.
12 Troubleshooting
During therapy with Avance Solo NPWT System, it is important that you are aware of the audible and visual alarms and
notifications displayed by the pump. This section explains the audible and visual alarms and notifications and gives guidance o
how to troubleshoot and when to contact a healthcare professional.
• The Avance Solo Pump has both visual and audible notifications and alarms. Carry or position the pump so that you will be
• Regularly monitor the canister mounted on the pump. If the canister appears full or the pump alarms for blockage, change
• When the Avance Solo Pump alarms due to a low battery, replace the batteries in the pump according to the instructions
provided in this manual, see Section 7.4. Only use the type and model of lithium batteries specified for this product by
• If you see signs of possible infection such as pain, reddening, odor, or sensitization of the wound area or sudden change of
• Inform your healthcare professional if you are hypersensitive to the product’s materials, see Section 10.
• The Avance Solo Canister is provided sterile. Do not use the canister if the inner packaging of the canister is damaged.
• Do not place the Avance Solo Pump with canister in water or other liquids. If the pump is wet, disconnect the pump and
• Do not expose the Avance Solo Border Dressing to extensive contact with water. If the dressing is disconnected from the pump,
• Do not modify pump, canister, tubing or dressing as any modification may significantly compromise the ability of Avance Solo
• The Avance Solo Pump is not intended for use aboard aircraft. During air travel pause the pump and remove the batteries.
Make sure that the dressing is not left without applied suction longer than the time determined by your healthcare
Avance Solo NPWT System consists of Avance Solo Pump, Avance Solo Canister 50ml and Avance Solo Border Dressing with
fixation strips for a close seal. Your healthcare professional may have applied Avance Solo Foam under the dressing if you have
To replace the canister, perform the following steps
1. If the pump is active, pause the pump by pressing down the green push button, and release after two (2) seconds.
2. Clamp the canister tubing and dressing tubing by positioning the slide clamps next to the green connectors and slide across
the tubings until secured. Blocking the tubings minimizes fluid leakage when you disconnect the canister from the dressing.
3. Disconnect the canister tubing from the dressing tubing by squeezing the connector from both sides and pull apart.
4. Remove the canister by pushing the spring buttons on both sides and pull.
5. Attach a new canister to the pump by pushing the canister until it clicks on both sides.
6. Be sure to attach the canister tubing onto the back of the pump.
2 3
2s2s
1
4 5 6
7 8 9
AUDIBLE AND VISUAL DISPLAY
The LEAKAGE indicator
light flashes once every
second.
The pump repeatedly
alarms with a beep and
will then pause.
The BLOCKAGE indicator
light flashes once every
second.
The pump repeatedly
alarms with a beep and
will then pause.
POSSIBLE CAUSE
An air leakage has been
detected.
The canister is full or
there is a blockage in the
tubings.
11 Other information
If any serious incident has occurred in relation to Avance Solo NPWT System, it should be reported to Mölnlycke Health Care.
12 Troubleshooting
During therapy with Avance Solo NPWT System, it is important that you are aware of the audible and visual alarms and
notifications displayed by the pump. This section explains the audible and visual alarms and notifications and gives guidance o
how to troubleshoot and when to contact a healthcare professional.
To replace the canister, perform the following steps
1. If the pump is active, pause the pump by pressing down the green push button, and release after two (2) seconds.
2. Clamp the canister tubing and dressing tubing by positioning the slide clamps next to the green connectors and slide across
the tubings until secured. Blocking the tubings minimizes fluid leakage when you disconnect the canister from the dressing.
3. Disconnect the canister tubing from the dressing tubing by squeezing the connector from both sides and pull apart.
2 3
2s2s
1
4 5 6
AUDIBLE AND VISUAL DISPLAY
The LEAKAGE indicator
light flashes once every
second.
The pump repeatedly
alarms with a beep and
will then pause.
The BLOCKAGE indicator
light flashes once every
second.
The pump repeatedly
alarms with a beep and
will then pause.
The LOW BATTERY
indicator light flashes
once every five (5)
seconds.
When less than 4 hours of
battery power remain the
11 Other information
If any serious incident has occurred in relation to Avance Solo NPWT System, it should be reported to Mölnlycke Health Care.
12 Troubleshooting
During therapy with Avance Solo NPWT System, it is important that you are aware of the audible and visual alarms and
notifications displayed by the pump. This section explains the audible and visual alarms and notifications and gives guidance o
how to troubleshoot and when to contact a healthcare professional.

10 11
Alarms and trouble shooting
Audible and visual display description Possible cause How to troubleshoot
The LEAKAGE
The pump repeatedly alarms with a beep and will then pause.
An air leakage has been
detected.
To correct a leak:
Press around the dressing border and the strips to
improve contact with the skin.
Check that the canister is attached to the pump, that the
canister tubing is attached to the canister, and that the
dressing tubing is connected to the canister tubing.
Press the green start button to restart the pump.
If the leakage is not resolved, the pump will again alarm
for leakage and then pause therapy. If this happens,
contact your healthcare professional.
The BLOCKAGE
The pump repeatedly alarms with a beep and will then pause.
The canister is full or
there is a blockage in
the tubings.
To correct a blockage:
Ensure that the tubing is not clamped or kinked. If the
canister is full, change the canister according to instructions
on page 8 in this document, or in the user manual
(included in the product package) under section 7.3.
Press the green start button to restart the pump.
If blockage is not resolved, the pump will again alarm
for blockage and then pause therapy. If this happens,
contact your healthcare professional.
The LOW BATTERY
When less than 4 hours ofbattery power remain the LOW BATTERY
alarms with a beep.
The batteries are low. To change batteries:
Change the batteries according to instructions on page
9 in this document, or in the user manual (included in
the product package) under section 7.4. Only use the
product by Mölnlycke Health Care. Press the green start
button to restart the pump.
and the pump repeatedly alarms with a beep.
Alarm for INTERNAL
FAILURE and the pump
cannot be started.
Contact yourhealthcare professional or
Mölnlycke.
AUDIBLE AND VISUAL DISPLAY
The LEAKAGE indicator
light flashes once every
second.
The pump repeatedly
alarms with a beep and
will then pause.
The BLOCKAGE indicator
light flashes once every
second.
The pump repeatedly
alarms with a beep and
will then pause.
The LOW BATTERY
indicator light flashes
once every five (5)
seconds.
When less than 4 hours of
battery power remain the
LOW BATTERY indicator
light flashes once every
second and the pump
repeatedly alarms with
a beep.
All indicator lights flash at
the same time, once every
second, and the pump
repeatedly alarms with
a beep.
POSSIBLE CAUSE
An air leakage has been
detected.
The canister is full or
there is a blockage in the
tubings.
The batteries are low. Alarm for INTERNAL
FAILURE and the pump
cannot be started.
HOW TO TROUBLESHOOT
To correct a leak:
Press around the dressing
border and the strips
to improve contact with
the skin.
Check that the canister
is attached to the pump,
that the canister tubing is
attached to the canister,
and that the dressing
tubing is connected to the
canister tubing.
Press the green push
button to restart the
pump.
If the leakage is not
resolved, the pump will
again alarm for leakage
and then pause therapy.
If this happens, contact
your healthcare
professional.
To correct a blockage:
Ensure that the tubing is
not clamped or kinked.
If the canister is full,
change the canister
according to instructions
in section 7.3.
Press the green push
button to restart the
pump.
If blockage is not resolved,
the pump will again alarm
for blockage and then
pause therapy.
If this happens, contact
your healthcare
professional.
To change batteries:
Change the batteries
according to instructions
in section 7.4.
Only use the type and
model of lithium batteries
specified for this product
by Mölnlycke Health Care,
see section 13.
Press the green push
button to restart the
pump.
Contact your healthcare
professional or
Mölnlycke Health Care.
11 Other information
If any serious incident has occurred in relation to Avance Solo NPWT System, it should be reported to Mölnlycke Health Care.
12 Troubleshooting
During therapy with Avance Solo NPWT System, it is important that you are aware of the audible and visual alarms and
notifications displayed by the pump. This section explains the audible and visual alarms and notifications and gives guidance on
how to troubleshoot and when to contact a healthcare professional.
What do the signals from Avance®Solo mean?
The device uses various signals to alert you if it is working or if you need
to take action. Please make sure that you are able to hear and understand the
various signals.
indicator
light flashes once every
The pump repeatedly
alarms with a beep and
The BLOCKAGE indicator
light flashes once every
second.
The pump repeatedly
alarms with a beep and
will then pause.
The LOW BATTERY
indicator light flashes
once every five (5)
seconds.
When less than 4 hours of
battery power remain the
LOW BATTERY indicator
light flashes once every
second and the pump
repeatedly alarms with
a beep.
All indicator lights flash at
the same time, once every
second, and the pump
repeatedly alarms with
a beep.
An air leakage has been The canister is full or
there is a blockage in the
tubings.
The batteries are low. Alarm for INTERNAL
FAILURE and the pump
cannot be started.
Press around the dressing
border and the strips
to improve contact with
Check that the canister
is attached to the pump,
that the canister tubing is
To correct a blockage:
Ensure that the tubing is
not clamped or kinked.
If the canister is full,
change the canister
according to instructions
in section 7.3.
Press the green push
To change batteries:
Change the batteries
according to instructions
in section 7.4.
Only use the type and
model of lithium batteries
specified for this product
by Mölnlycke Health Care,
Contact your healthcare
professional or
Mölnlycke Health Care.
If any serious incident has occurred in relation to Avance Solo NPWT System, it should be reported to Mölnlycke Health Care.
During therapy with Avance Solo NPWT System, it is important that you are aware of the audible and visual alarms and
notifications displayed by the pump. This section explains the audible and visual alarms and notifications and gives guidance on
how to troubleshoot and when to contact a healthcare professional.
indicator
light flashes once every
The pump repeatedly
alarms with a beep and
The LOW BATTERY
indicator light flashes
once every five (5)
seconds.
When less than 4 hours of
battery power remain the
LOW BATTERY indicator
light flashes once every
second and the pump
repeatedly alarms with
a beep.
All indicator lights flash at
the same time, once every
second, and the pump
repeatedly alarms with
a beep.
The canister is full or
there is a blockage in the
The batteries are low. Alarm for INTERNAL
FAILURE and the pump
cannot be started.
If any serious incident has occurred in relation to Avance Solo NPWT System, it should be reported to Mölnlycke Health Care.
During therapy with Avance Solo NPWT System, it is important that you are aware of the audible and visual alarms and
notifications displayed by the pump. This section explains the audible and visual alarms and notifications and gives guidance on
how to troubleshoot and when to contact a healthcare professional.
indicator light flashes
When less than 4 hours of
battery power remain the
All indicator lights flash at
the same time, once every
second, and the pump
repeatedly alarms with
a beep.
If any serious incident has occurred in relation to Avance Solo NPWT System, it should be reported to Mölnlycke Health Care.
During therapy with Avance Solo NPWT System, it is important that you are aware of the audible and visual alarms and
notifications displayed by the pump. This section explains the audible and visual alarms and notifications and gives guidance on

Find out more at www.molnlycke.co.uk/patientselfcare
Mölnlycke, Unity House, Medlock Street, Oldham, OL1 3HS. Tel [phone].
The Mölnlycke, Avance and Safetac, trademarks, names and logotypes are registered globally to one or more of the
Mölnlycke Health Care group of companies. © 2020 Mölnlycke Health Care AB. All rights reserved. UKWC0971
References: 1. Apelqvist, J., Willy, C., Fagerdahl, A.M. et al. Negative Pressure Wound Therapy – overview, challenges and perspectives.
J Wound Care 2017; 26: 3, Suppl 3, S1–S113. 2. Willy C, Agarwal A, Andersen CA, Santis GD, Gabriel A, Grauhan O, Guerra OM, Lipsky
BA, Malas MB, Mathiesen LL, Singh DP, Reddy VS. Closed incision negative pressure therapy: international multidisciplinary consensus
recommendations. Int Wound J 2016; doi: 10.1111/iwj.12612.
