Monogram ZV900 User manual

INSTALLATION
INSTRUCTIONS
36” Glass Canopy
Chimney Vent Hood
ZV900
MONOGRAM.COM

249-80328 Rev. 4
Safety Information
READ AND SAVE THESE INSTRUCTIONS
BEFORE YOU BEGIN
Read these instructions completely and carefully.
■IMPORTANT — Save these instructions
for local inspector’s use.
■IMPORTANT — Observe all governing
codes and ordinances.
■Note to Installer — Be sure to leave these
instructions with the Consumer.
■Note to Consumer — Keep these instructions with
your Owner’s Manual for future reference.
■Skill Level — Installation of this appliance requires
basic mechanical and electrical skills.
■Completion Time — 1 to 3 Hours.
■Properinstallationistheresponsibilityoftheinstaller.
Productfailureduetoimproperinstallationisnot
covered under the warranty.
■ForMonogramlocalserviceinyourarea,visit
monogram.com.
■ForMonogramserviceinCanada,visitmonogram.ca
■ForMonogramPartsandAccessories,visit
monogram.com/use-and-care/parts.
CAUTION Due to the weight and size of these
vent hoods and to reduce the risk of personal injury
ordamagetotheproduct, TWO PEOPLE ARE
REQUIRED FOR PROPER INSTALLATION.
WARNING To reduce the risk of fire or electrical
shock,donotusethisrangehoodwithanyexternal
solid-statespeedcontroldevice.Anysuchalteration
from original factory wiring could result in damage to
the unit and/or create an electrical safety hazard.
TO REDUCE THE RISK OF FIRE, USE ONLY
METAL DUCTWORK.
WARNING TOREDUCETHERISKOFFIRE,
ELECTRICALSHOCKORINJURYTOPERSONS,
OBSERVETHEFOLLOWING:
A.Usethisunitonlyinthemannerintendedbythe
manufacturer.Ifyouhaveanyquestions,contact
the manufacturer.
B.Beforeservicingorcleaningtheunit,switchthe
power off at the service panel and lock the service
disconnecting means to prevent the power from
beingswitchedonaccidentally.Whentheservice
disconnectingmeanscannotbelocked,securely
fastenaprominentwarningdevice,suchasatag,
to the service panel.
■Forgeneralventilatinguseonly.Donotusetoexhaust
hazardousorexplosivematerialsorvapors.
■Structuralframing,installationworkandelectrical
wiring must be done by qualified person(s) in
accordance with all applicable codes and standards
including fire-rated construction.
■Sufficientairisneededforpropercombustionand
exhaustingofgasesthroughtheflue(chimney)offuel
burningequipmenttopreventbackdrafting.Follow
the heating equipment manufacturer’s guidelines
and safety standards such as those published by
theNationalFireProtectionAssociation(NFPA),and
theAmericanSocietyforHeating,Refrigerationand
AirConditioningEngineers(ASHRAE),andthelocal
codeauthorities.Whenapplicable,installanymakeup
(replacement) air system in accordance with local
buildingcoderequirements.VisitGEAppliances.com
for available makeup air solutions.
■Localcodesvary.Installationofelectricalconnections
and grounding must comply with applicable codes.
Intheabsenceoflocalcodes,theventshouldbe
installedinaccordancewithNationalElectricalCode
ANSI/NFPA70-1990orlatestedition.
CAUTION To reduce risk of fire and to properly
exhaustair,besuretoductairoutside—donotvent
exhaustairintospaceswithinwallsorceilingsorinto
attics,crawlspacesorgarages.

49-80328 Rev. 4 3
Design Information
CONTENTS
Design Information
ProductDimensionsandClearances............................ 3
Installation Options........................................................ 3
InstallationPreparation
AdvancePlanning,Ductwork,Framing ......................... 4
PowerSupply ................................................................ 4
DuctFittings .................................................................. 5
Tools and Materials Required ....................................... 6
RemovethePackaging ................................................. 6
Determine Installation Height ........................................ 7
WallMountInstallationHeights..................................... 7
Check Installation Hardware ......................................... 8
Installation—Vented to the Outside
Ductwork,WiringLocations........................................... 9
Step1,InstallFramingforHoodSupport...................... 9
Step2,InstallMountingBracket ................................. 10
Step3,InstallDuctBracket......................................... 10
Step4,PreparetheHood ........................................... 11
Step5,MounttheHood .............................................. 12
Step6,LeveltheHood................................................ 12
Step7,ConnectDuctwork .......................................... 12
Step8,ConnectElectrical........................................... 13
Step9,InstallDuctCovers.......................................... 14
Step10,InstallFilters.................................................. 14
Step11,FinalizeInstallation ....................................... 14
Installation—Recirculating
Ductwork,WiringLocations......................................... 15
Step1,InstallFramingforHoodSupport.................... 15
Step2,InstallMountingBracket ................................. 16
Step3,InstallDuctBracket......................................... 16
Step4,PreparetheHood ........................................... 17
Step5,MounttheHood .............................................. 17
Step6,LeveltheHood................................................ 17
Step7,SizeandCutDuctPiece................................. 18
Step8,ConnectElectrical........................................... 18
Step9,InstallDuctCovers.......................................... 19
Step10,InstallFilters.................................................. 19
Step11,FinalizeInstallation ....................................... 19
PRODUCT DIMENSIONS AND
CLEARANCES
Theventhoodmustbeinstalled24”min.,and30≤
max.abovethecookingsurface.Thehoodinstallation
height above the cooking surface depends upon
ceiling height.
The telescopic duct cover conceals the ductwork
running from the top of the hood to the ceiling. The
suppliedductcoverissizedtoreach8’to9’-5”ceiling
heights.
TheZX90010accessoryisavailableforceiling
heightsof9’-6”to10’-5”.
INSTALLATION OPTIONS
NOTE: Installation height should be measured from
the cooking surface to the outer glass sides.
This hood may be installed onto a wall and vented
totheoutdoors,oritcanbeinstalledforrecirculating
operation.Allnecessarypartsforrecirculating
operationaresuppliedwiththehood.Nokitsrequired.
This hood can be installed over any Monogram
electric cooktop or gas cooktop. It cannot be
installedoveraMonogramProfessionalcooktop
or range.
*Height
to
Ceiling
21 7/16"
3 1/4"
35 7/8"
*TheSuppliedDuctCoverFits8'to9'-5" Ceiling Heights.
For9'-6"to10'-5"ceilings,orderZX90010.
*Height
to
Ceiling
20 7/16”
357/8”
3 1/4”
24” Min.
30”Max.
1”=2.5cm;1’=0.3m

449-80328 Rev. 4
Installation Preparation
ADVANCE PLANNING
■Determinetheexactlocationoftheventhood.
■Plantherouteforventingexhausttotheoutdoors.
■Usetheshortestandstraightestductroutepossible.
Forsatisfactoryperformance,ductrunshould
notexceed100ft.equivalentlengthforanyduct
configurations.
■Referto“DuctFittings”charttocomputethe
maximumpermissiblelengthforductrunstothe
outdoors.
■Whenapplicable,installanymakeup(replacement)
air system in accordance with local building
code requirements. Visit GEAppliances.com for
available makeup air solutions.
CAUTION To reduce risk of fire and to properly
exhaustair,besuretoductairoutside—donotvent
exhaustairintospaceswithinwallsorceilingsorinto
attics,crawlspacesorgarages.
■Usemetalductworkonly.Thesehoodsmustuse
8” round duct.
■Installawallcapwithdamperorroofcapatthe
exterioropening.Orderthewallorroofcapandany
transition needed in advance.
Wall Framing for Adequate Support
■Thisventhoodisheavy.Adequatestructural
support must be provided in all types of
installations. The hood must be secured to vertical
studsinthewall,ortoahorizontalsupport.
■Theventhoodshouldbeonsitebeforefinalframing
and wall finishing. This will help to accurately locate
the duct work and electrical service.
■Installationwillbeeasieriftheventhoodisinstalled
before the cooktop and countertop are installed.
Decorative Duct Covers
This hood is shipped with a decorative duct cover for
ceilingheightsof7’-11”to9’-5”.ZX90010ductcover
accessoryisavailabletoreach9’-6”to10’-5”ceiling
heights. The accessory should be ordered with the
hood and be on site before installation begins.
POWER SUPPLY
IMPORTANT - (Please read carefully)
WARNING FORPERSONALSAFETY,THIS
APPLIANCEMUSTBEPROPERLYGROUNDED.
Remove house fuse or open circuit breaker before
beginning installation.
Donotuseanextensioncordoradapterplugwith
thisappliance.FollowNationalelectricalcodesor
prevailing local codes and ordinances.
Electrical supply
Theseventhoodsmustbesuppliedwith120V,60Hz,
andconnectedtoanindividual,properlygrounded
branchcircuit,andprotectedbya15or20ampcircuit
breaker or time delay fuse.
■Wiringmustbe2wirewithground.
■Iftheelectricalsupplydoesnotmeettheabove
requirements,callalicensedelectricianbefore
proceeding.
■Routehousewiringasclosetotheinstallation
location as possible on the back wall or ceiling.
■Connectthewiringtothehousewiringin
accordance with local codes.
Grounding instructions
The grounding conductor must be connected to
agroundmetal,permanentwiringsystem,oran
equipment-grounding terminal or lead on the hood.
WARNING The improper connection of the
equipment-grounding conductor can result in a risk
of electric shock. Check with a qualified electrician or
service representative if you are in doubt whether the
appliance is properly grounded.
CAUTION
AutomaticallyOperatedDevice–
To reduce the risk of injury disconnect from power supply
before servicing. This unit is equipped with an integral
disconnecting switch located inside the blower housing.
1”=2.5cm;1’=0.3m

49-80328 Rev. 4 5
Installation Preparation
DUCT FITTINGS
This Hood Must Use an 8” Round
Duct. It Can Transition to a
3-1/4” x 12” Duct.
Usethischarttocomputemaximumpermissiblelengths
for duct runs to outdoors.
NOTE:Donotexceedmaximumpermissibleequivalent
lengths!
Maximum duct length: 100 foot for range hoods.
Flexible ducting
Ifflexiblemetalductingisused,alltheequivalentfeet
valuesinthetableshouldbedoubled.Theflexiblemetal
ductshouldbestraightandsmoothandextendedas
much as possible.
DoNOTuseflexibleplasticducting.
NOTE:Anyhomeventilationsystem,suchasa
ventilationhood,mayinterrupttheproperflowof
combustionairandexhaustrequiredbyfireplaces,gas
furnaces,gaswaterheatersandothernaturallyvented
systems. To minimize the chance of interruption of such
naturallyventedsystems,followtheheatingequipment
manufacturer’s guidelines and safety standards such
asthosepublishedbyNFPAandASHRAE.When
applicable,installanymakeup(replacement)airsystem
in accordance with local building code requirements. Visit
GEAppliances.com for available makeup air solutions.
Duct Piece Dimensions
Equivalent
Length*
Quantity
Used
Total
Equivalent
Length
Round,
straight
1 ft. (per foot
length)
3-1/4”x12”
straight
1 ft. (per foot
length)
90°elbow 17ft.
45°elbow 10ft.
3-1/4”x12”
90°elbow
43 ft.
3-1/4”x12”
45°elbow
26 ft.
3-1/4”x12”
90°flat
elbow
102ft.
8” round to
3-1/4”x12”
transition
2 ft.
3-1/4”x12”
to 8” round
transition
5 ft.
8” round to
3-1/4”x12”
transition90°
elbow
6 ft.
3-1/4”x12”
to 8” round
transition90°
elbow
13 ft.
Round wall
cap with
damper
32 ft.
3-1/4”x12”
wall cap with
damper
75ft.
Round roof
cap
44 ft.
*Actuallengthofstraightductplusductfitting
equivalent. Equivalent length of duct pieces
arebasedonactualtestsconductedbyGE
AppliancesEvaluationEngineeringandreflect
requirements for good venting performance
with any ventilation hood.
Total Duct Run
1”=2.5cm;1’=0.3m

649-80328 Rev. 4
Installation Preparation
TOOLS AND MATERIALS REQUIRED
(NOT SUPPLIED)
■Tape measure
■Knife
■Spirit level
■Wirecutter/stripper
■Wirenuts
■Electric drill with 5/16” and 3/8” bits
■Phillipsandflatbladescrewdrivers
■Hammer
■Pliers
■Safety glasses
■Duct tape
■Tape to mount template
■Glovestoprotectagainstsharpedges
■120V60Hz.15or20Amp,2wirewith
groundProperlygroundedbranchcircuit
■Strain relief for junction cover
■8”roundmetalduct,lengthtosuit
installation
■Saw,jigsaworreciprocatingsaw
Gloves
Knife
Wirecutter/
stripper
Flatblade
screwdriver
Hammer
8"roundmetal
duct,lengthtosuit
installation
Measuring tape
Electric drill
with 5/16”
and 3/8” Bits
12” long
Phillips
head
screwdriver
Safety glasses
Spirit level
Pliers
Duct tape
Masking tape
Wirenuts
Strain relief
Saw,jigsawor
reciprocating
saw
REMOVE THE PACKAGING
CAUTION LIFTTHEHOODOUTOFTHEBOX
BYTHECENTERMETALPORTION.DONOTLIFTBY
THEGLASSSIDES.
CAUTION Wearglovestoprotectagainst
sharp edges.
■Graspthehoodbythemetalinsertinthecenterand
liftstraightupandoutofthebox.
■Removeandproperlydiscardtheplasticwrapping.
■Removepartsbox,ductcoversandotherpackaging.
1”=2.5cm;1’=0.3m

49-80328 Rev. 4 7
Installation Preparation
DETERMINE INSTALLATION HEIGHT
■Telescopicductcoversareprovidedtoconceal
the ductwork running to the ceiling.
■Thishoodcanbeinstalledforrecirculating
operation.Nokitsrequired.
Theventhoodmustbeinstalled24”min.and30”
max.abovethecookingsurface.Thehoodinstallation
height,fromthecookingsurfacetothebottomofthe
hood,dependsuponceilingheight.
ACCESSORIES:
■OrderZX90010accessoryforZV900wallmount
hoodtoreachceilingheightsbetween9’-6”and
10’-5”.Thisaccessorycontainsone40”longduct
cover.
24” Min.
30”Max.
36” Min.
NOTE: Measure
installation height from
the cooking surface to
the outer glass portion of
the hood.
Wall Mount ZV900
Installation Heights
Actual Ceiling
Height
*Possible VENTED
Installation Height
*Possible
RECIRCULATING
Installation Height
7’-11” 24” to 26” 24” to 26”
8’-0” 24”to27” 24”to27”
8’-1” 24” to 28” 24” to 28”
8’-2” 24”to29” 24”to29”
8’-3” 24”to30” 24”to30”
8’-4” 24”to30” 24”to30”
8’-5” 24”to30” 24”to30”
8’-6” 24”to30” 24”to30”
8’-7” 24”to30” 24”to30”
8’-8” 24”to30” 24”to30”
8’-9” 24”to30” 24”to30”
8’-10” 24”to30” 25”to30”
8’-11” 24”to30” 26”to30”
9’-0” 25”to30” 24”to30”
9’-1” 26”to30” 24”to30”
9’-2” 27”to30” 24”to30”
9’-3” 28”to30” 24”to30”
9’-4” 29”to30” 24”to30”
9’-5” 30” 25”to30”
9’-6” 24”to30” 24”to30”
9’-7” 24”to30” 24”to30”
9’-8” 24”to30” 24”to30”
9’-9” 24”to30” 24”to30
9’-10” 24”to30” 24”to30”
9’-11” 24”to30” 24”to30”
10’ 24”to30” 24”to30”
10’-1” 24”to30” 24”to30”
10’-2” 25”to30” 24”to30”
10’-3” 26”to30” 25”to30”
10’-4” 27”to30” 26”to30”
10’-5” 28”to30” 27”to30”
*Based on 36” countertop height.
SUPPLIEDACCESSORY ZX90010
1”=2.5cm;1’=0.3m

849-80328 Rev. 4
Installation Preparation
CHECK INSTALLATION HARDWARE
Locatethehardwareaccessoryboxpackedwiththehoodandcheckcontents.
29-7/8"
11-1/2"
12"
27-3/4"
Mounting bracket
1 charcoal filter for
recirculating installation
2-piece decorative duct
cover (dimension shown
for reference only)
Airdeflector
for recirculating
installation only
Duct bracket
14-5/8≤
to top of
bracket
C
L
t
ALIGN BOTT OM EDGE
WITH PENCIL LINE,
INDICA TING BOTT OM
OF THE HOOD
Drill 2 (two) 3/16≤ pilot holes through studs or rear wall support
REAR WALL
MOUNTING TEMPLA TE
49-80405 04-06 JR
Wallmounttemplate
HARDWARE
PACKAGE
Locate and count
screws
3 wood
screws
3 wall
fasteners
3 wall bracket
screws
12 hood
attachment
screws
27-3/4”
12-7/8”
23-7/8”
11-1/2”
Stainless steel filter
2 thumb
screws
1”=2.5cm;1’=0.3m

49-80328 Rev. 4 9
Installation Instructions
DUCTWORK, WIRING LOCATIONS
Determinetheexactlocationoftheventhood.
■Locatethetemplatepackedwiththeliterature.
–Measure36”fromthefloortothetopofthe
cookingsurface.Addhoodinstallationheight
determinedonpage7.Markthatlocation.
–Use a level to draw a straight pencil line on the wall.
–Tapethetemplateinpositionalongthe
penciled line. CHECK TO BE SURE THE
TEMPLATEISLEVEL.
Ceiling ducting:
Ifductworkwillventstraightuptotheceiling:
■Usealeveltodrawalinestraightup,fromthe
centerline on the template to the ceiling.
■Measure5-1/2”fromthebackwalltothecenterline
of an 8-1/2” hole on the ceiling.
NOTE:Ifdrywallisnotpresent,adddrywallthickness
to the 5-1/2” dimension.
Wall Ducting:
Ifductworkwillventtotherear:
■Usealeveltodrawalinestraightupfromthe
centerline on the template.
■Measureatleast26”abovethepencillinethat
indicatesthebottominstallationheight,tothe
centerline of an 8-1/2” dia. duct hole. (Hole may be
elongated for duct elbow.)
HOUSE WIRING LOCATION:
■Thejunctionboxislocatedonthetopleftsideof
the hood.
■Wiringshouldenterthebackwallatleast22”above
thebottomofthehood,andwithin6”oftheleftside
of the centerline.
5-1/2” centerline to wall
8-1/2” dia. hole
FORCEILINGVENTDUCTING
Centerline 26” above the
marked bottom pencil line
for installation height.
FORWALLVENTDUCT
Ceiling
1INSTALL FRAMING FOR HOOD
SUPPORT
IMPORTANT — Framingmustbecapableof
supporting100lbs.
Ifdrywallispresent,markthescrewholelocationsfor
the top mounting brackets. Remove the template.
■Cutawayenoughdrywalltoexpose2verticalstuds
at the bracket location indicated on the template.
■Installahorizontalsupportatleast1”x6”between
two wall studs at the bottom mounting bracket
installation location. The horizontal support must
be flush with the room side of the studs. Use cleats
behind both sides of the support to secure to wall
studs.
■Reinstalldrywall.
Centerline of
installation
space
View from
rear cleats
1”x6”min.
mounting
support
8-1/2” min. opening for ductwork
INSTALLATION—VENTED TO THE OUTSIDE
1”=2.5cm;1’=0.3m

10 49-80328 Rev. 4
Installation Instructions
2INSTALL MOUNTING BRACKET
This vent hood must be secured to the horizontal
support or wall studs.
■Withthetemplatetapedinplace,useapunchto
mark mounting bracket screw locations.
■Drill3/16”pilotholesin2ofthepunchedlocations
in the lower bracket.
■Removethetemplate.
■Usewoodscrewstosecurethemountingbracketto
the wall. The screws must engage wall studs or the
installed horizontal mounting support.
■Checktobesurethatthebracketislevel.
3INSTALL DUCT BRACKET
The duct bracket should be installed against the back
wall and flush with the ceiling. This bracket will hold
the duct cover in place at the top.
Secure the bracket to the wall:
■Alignthemarkedcenterlineonthebracketwiththe
centerline on the wall.
■Mark2screwholelocationsinthewall.
■Drill3/16”pilotholesinthemarkedlocations.
■Ifpilotholesdonotenterstuds,enlargetheholes
to 3/8” and install wall fastener anchors.
■Drivescrews,byhand,intothefastenerstoallow
anchorstoexpand.Removethescrews.
■Securethebrackettothewallwithwoodscrews
and/or fasteners.
14-5/8≤
to top of
bracket
C
L
t
ALIGN BOTT OM EDGE
WITH PENCIL LINE,
INDICA TING BOTT OM
OF THE HOOD
Drill 2 (two) 3/16≤ pilot holes through studs or rear wall support
REAR WALL
MOUNTING TEMPLA TE
49-80405 04-06 JR
INSTALLATION—VENTED TO THE OUTSIDE
1”=2.5cm;1’=0.3m

49-80328 Rev. 4 11
Installation Instructions
4PREPARE THE HOOD
■Placethehoodonapaddedsurface.
■Positionthemotorhousingatthebackofthehood.
Electricalconnectorsshouldfacethefront,withrear
mounting hooks at the back.
■Slipthebottomflangeofthemotorhousingintothe
side slots at the top rear opening.
■
Carefully lay the hood on its back.
■Fastenthehoodtothemotorhousingfromthebottom,
using 6 screws.
■Jointwocableconnectorsatthefrontofthehood.
Rear
mounting
hooks
Engage flange on
motor housing into
slots
Rear view
Bottom view
Rear side
Frontside
To Lights
To
Control
Panel
INSTALLATION—VENTED TO THE OUTSIDE
1”=2.5cm;1’=0.3m

12 49-80328 Rev. 4
Installation Instructions
5MOUNT THE HOOD
WARNING 2 people are required to lift and
position the hood onto the mounting bracket.
■Liftthehoodontothemountingbracket.
■Positionaspiritlevelatthebottomofthehoodto
check side to side leveling.
7CONNECT DUCTWORK
■Installductwork,makingconnectionsinthedirection
of airflow as illustrated.
■Pushductovertheexhaustoutletanddamper.
■Securejointsinductworkwithsheetmetalscrews.
■Wrapallductjointsandtheflangeconnectionswith
duct tape for an airtight seal.
CAUTION
Do not use sheet metal screws at the
hood flange connection. Doing so will prevent proper
damper operation. Seal connection with tape only.
6LEVEL THE HOOD
This hood has built-in levelers on the mounting hooks
ateachside.UsealongPhillipsscrewdriverfromthe
front to access the levelers.
■Usethetopscrewholeinthelevelertoraiseor
lower the hood on that side.
■Usethebottomscrewholetopullthehoodtight
against the wall surface.
■Markholelocationatthebottomofthehood.
■Removethehood.Ifthebottomscrewholedoes
notenterastud,enlargetheholeto3/8”andinstall
wall fastener anchors.
■Placethehoodbackontothemountingbracket,
check level again and install the wall fastener.
Levelers
Screw hole
Duct tape
over seam
and screw Screw
Airflow
INSTALLATION—VENTED TO THE OUTSIDE
1”=2.5cm;1’=0.3m

49-80328 Rev. 4 13
Installation Instructions
8CONNECT ELECTRICAL
Verify that power is turned off at the source.
WARNING If house wiring is not 2-wire with a
groundwire,agroundmustbeprovidedbytheinstaller.
Whenhousewiringisaluminum,besuretouseU.L.
approvedanti-oxidantcompoundandaluminum-to-
copper connectors.
■Removejunctionboxcoverandknockoutonthe
left side.
■Securethehousewiringtothejunctionboxwith
a strain relief.
■Connectwhiteleadstobranchcircuitwhitelead.
■Connectblackleadstobranchcircuitblacklead.
■Connectgreen/yellowleadstobranchcircuitgreen
lead or bare ground lead.
■Secureallconnectionswithwirenutsoneach
electrical connector.
■Pushwiresintojunctionboxandreplacecover.
Be sure wires are not pinched.
■SecureJ-Boxcoverwithoriginalscrew.
Knockout
J-Boxcover
House wiring
J-Boxcover
INSTALLATION—VENTED TO THE OUTSIDE
1”=2.5cm;1’=0.3m

14 49-80328 Rev. 4
Installation Instructions
9INSTALL DUCT COVERS
■Placethedecorativeduct
covers on top of the hood.
NOTE: The inside (upper) duct
piece has holes on one end.
The holes are intended for use
when the hood is installed for
recirculating purposes. Slide the
inside end into the outer piece;
the vent holes should not be
visible in this installation.
The inside duct piece must slip into the folded ends of
the outer section.
■Extendtheinnerductupwardtotheceilingbracket.
■Secureductcovertoceilingbracketwith2screws.
10 INSTALL FILTERS
IMPORTANT: ChecktobesurethatthemainON/
OFFswitchnexttothemotorisintheONposition.
■Removeprotectivefilmonthefilters.
■Tipthefilterintotheleftorrightsideoftheopening.
Lift the filter to the opposite side and into the filter
lock.
■Toremovethefilter,pullthefilterlockdownward.
11 FINALIZE INSTALLATION
■Checktobesurealltapeandpackagingmaterials
have been removed.
■RefertotheOwner’sManualforoperating
instructions.
Mounting
screws
Duct cover support
bracket
Upper
duct cover
Lower duct
cover seat
Duct cover
support bracket
Lower duct
cover
FilterLock
INSTALLATION—VENTED TO THE OUTSIDE
1”=2.5cm;1’=0.3m

49-80328 Rev. 4 15
DUCTWORK, WIRING LOCATIONS
Determinetheexactlocationoftheventhood.
■Locatethetemplatepackedwiththeliterature.
■Measure36”fromthefloortothetopofthecooking
surface.Addhoodinstallationheightdeterminedon
page7.Markthatlocation.
■Usealeveltodrawastraightpencillineonthewall.
■Tapethetemplateinpositionalongthepenciled
line.CHECKTOBESURETHETEMPLATEIS
LEVEL.
■Usealeveltodrawalinestraightup,fromthe
centerline on the template to the ceiling.
HOUSE WIRING LOCATION:
■Thejunctionboxislocatedonthetopleftsideof
the hood.
■Wiringshouldenterthebackwallatleast22”
abovethebottomofthehood,andwithin6”ofthe
centerline.
1INSTALL FRAMING FOR HOOD
SUPPORT
IMPORTANT — Framingmustbecapableof
supporting100lbs.
Ifdrywallispresent,markthescrewholelocationsfor
the top mounting brackets. Remove the template.
■Cutawayenoughdrywalltoexpose2verticalstuds
at the bracket location indicated on the template.
■Installahorizontalsupportatleast1”x6”between
two wall studs at the bottom mounting bracket
installation location. The horizontal support must
be flush with the room side of the studs. Use cleats
behind both sides of the support to secure to wall
studs.
■Reinstalldrywall.
Centerline of
installation
space
View from
rear cleats
1”x6”min.
mounting
support
Installation Instructions
Ceiling
INSTALLATION—RECIRCULATING
1”=2.5cm;1’=0.3m

16 49-80328 Rev. 4
2INSTALL MOUNTING BRACKET
This vent hood must be secured to the horizontal
support or wall studs.
■Withthetemplatetapedinplace,useapunchto
mark mounting bracket screw locations.
■Drill3/16”pilotholesin2ofthepunchedlocations
in the lower bracket.
■Removethetemplate.
■Usewoodscrewstosecurethemountingbracketto
the wall. The screws must engage wall studs or the
installed horizontal mounting support.
■Checktobesurethatthebracketislevel.
3INSTALL DUCT BRACKET
The duct bracket should be installed against the back
wall and flush with the ceiling. This bracket will hold
the duct cover in place at the top.
Secure the bracket to the wall:
■Alignthemarkedcenterlineonthebracketwiththe
centerline on the wall.
■Mark2screwholelocationsinthewall.
■Drill3/16”pilotholesinthemarkedlocations.
■Ifpilotholesdonotenterstuds,enlargetheholes
to 3/8” and install wall fastener anchors.
■Drivescrews,byhand,intothefastenerstoallow
anchorstoexpand.Removethescrews.
■Securethebrackettothewallwithwoodscrews
and/or fasteners.
14-5/8≤
to top of
bracket
C
L
t
ALIGN BOTT OM EDGE
WITH PENCIL LINE,
INDICA TING BOTT OM
OF THE HOOD
Drill 2 (two) 3/16≤ pilot holes through studs or rear wall support
REAR WALL
MOUNTING TEMPLA TE
49-80405 04-06 JR
Installation Instructions
INSTALLATION—RECIRCULATING
1”=2.5cm;1’=0.3m

49-80328 Rev. 4 17
Installation Instructions
INSTALLATION—RECIRCULATING
4PREPARE THE HOOD
■Placethehoodonapaddedsurface.
■Positionthemotorhousingatthebackofthehood.
Electricalconnectorsshouldfacethefront,withrear
mounting hooks at the back.
■Slipthebottomflangeofthemotorhousingintothe
side slots at the top rear opening.
■Carefullylaythehoodonitsback.
■Fastenthehoodtothemotorhousingfromthe
bottom,using6screws.
■Jointwocableconnectorsatthefrontofthehood.
Rear
mounting
hooks
Engage flange on
motor housing into slots
Rear view
Bottom view
Rear side
Frontside
To Lights
To
Control
Panel
5MOUNT THE HOOD
WARNING 2 people are required to lift and
position the hood onto the mounting bracket.
■Liftthehoodontothemountingbracket.
■Positionaspiritlevelatthebottomofthehoodto
check side to side leveling.
6LEVEL THE HOOD
This hood has built-in levelers on the mounting hooks
ateachside.UsealongPhillipsscrewdriverfromthe
front to access the levelers.
■Usethetopscrewholeinthelevelertoraiseor
lower the hood on that side.
■Usethebottomscrewholetopullthehoodtight
against the wall surface.
■Markholelocationatthebottomofthehood.
■Removethehood.Ifthebottomscrewholedoes
notenterastud,enlargetheholeto3/8”andinstall
wall fastener anchors.
■Placethehoodbackontothemountingbracket,
check level again and install the wall fastener.
Levelers
Screw hole
1”=2.5cm;1’=0.3m

18 49-80328 Rev. 4
Installation Instructions
INSTALLATION—RECIRCULATING
7SIZE AND CUT DUCT PIECE
■Holdupperairdeflectorwithductconnectoragainst
the ceiling.
■Measurefromthebottomoftheairdeflectortothe
top of the hood as shown. Reduce that dimension
by 1” to facilitate installation. The duct will cover and
overlap the deflector and the hood outlets.
■Cuttheductpiecetosizeandslip
onto the bottom of the deflector.
■Placetheassembleddeflector
andductovertheexhaustoutlet.
■Holdtheassemblyagainstthe
duct bracket.
■Drive4screwsintothebottomof
the deflector and into the bracket.
■Useducttapetosealductto
thedeflectorandattheexhaust
outlet.
Measure
length
Duct
length
Deflector
8CONNECT ELECTRICAL
Verify that power is turned off at the source.
WARNING If house wiring is not 2-wire with
agroundwire,agroundmustbeprovidedbythe
installer.Whenhousewiringisaluminum,besure
touseU.L.approvedanti-oxidantcompoundand
aluminum-to-copper connectors.
■Remove
junctionbox
cover and
knockout on
the left side.
■Securethe
house wiring
to the junction
boxwitha
strain relief.
■Connectwhiteleadstobranchcircuitwhitelead.
■Connectblackleadstobranchcircuitblacklead.
■Connectgreen/yellowleadstobranchcircuitgreen
lead or bare ground lead.
■Secureallconnectionswithwirenutsoneach
electrical connector.
■Pushwiresintojunctionboxandreplacecover.Be
sure wires are not pinched.
■SecureJ-Boxcoverwithoriginalscrew.
Knockout
J-Boxcover
House wiring
J-Boxcover
1”=2.5cm;1’=0.3m

49-80328 Rev. 4 19
9INSTALL DUCT COVERS
■Placethedecorativeduct
covers on top of the hood.
NOTE: The inside piece has
holes on one end intended for
use when the hood is installed for
recirculating purposes. Be sure
the vented end is at the top; the
vent holes will be visible in this
installation.
The inside duct piece must slip
into the folded ends of the outer
section.
■Extendtheinnerductupwardtotheceilingbracket.
■Secureductcovertoceilingbracketwith2screws.
10 INSTALL FILTERS
IMPORTANT: ChecktobesurethatthemainON/
OFFswitchnexttothemotorisintheONposition.
Charcoal filter
■Installtheblackcharcoalfilterintothecenter
opening. Secure the filter with thumbscrews on
each side.
Metal filter
■Tipthefilterintotheleftorrightsideoftheopening.
Lift the filter to the opposite side and into the filter
lock.
11 FINALIZE INSTALLATION
■Removealltapeandpackingmaterial.
■RefertotheOwner’sManualforoperating
instructions.
Installation Instructions
INSTALLATION—RECIRCULATING
Mounting
screw holes
Vent holes
Duct cover support
bracket
Upper
duct cover
Lower
duct cover
Lower duct
cover seat
Duct cover
support bracket
FilterLock
1”=2.5cm;1’=0.3m

NOTE:Whileperforminginstallationsdescribedinthisbook,
safety glasses or goggles should be worn.
ForMonogram®localserviceinyourarea,visit
monogram.com.
NOTE:Productimprovementisacontinuingendeavorat
MonogramAppliances.Therefore,materials,appearance
and specifications are subject to change without notice.
49-80328 Rev. 4
10-19 GEA
Printed in Mexico
