Blackbird™ 4K 4x2 HDMI® Matrix
P/N 15376
User's Manual

2
CONTENTS
SAFETY WARNINGS AND GUIDELINES ......................................................................3
INTRODUCTION.............................................................................................................................. 5
FEATURES............................................................................................................................................ 5
CUSTOMER SERVICE.................................................................................................................. 6
PACKAGE CONTENTS ............................................................................................................... 6
PRODUCT OVERVIEW................................................................................................................7
Front Panel.................................................................................................................................7
Rear Panel.................................................................................................................................. 8
Remote Control.................................................................................................................... 9
SAMPLE CONNECTION DIAGRAM ..............................................................................10
TECHNICAL SUPPORT.............................................................................................................. 11
SPECIFICATIONS........................................................................................................................... 11
REGULATORY COMPLIANCE.............................................................................................13
Notice for FCC ......................................................................................................................13
Notice for Industry Canada......................................................................................14

3
SAFETY WARNINGS AND GUIDELINES
Please read this entire manual before using this device, paying
extra attention to these safety warnings and guidelines. Please
keep this manual in a safe place for future reference.
This device is intended for indoor use only.
Do not expose this device to water or moisture of any
kind. Do not place drinks or other containers with
moisture on or near the device. If moisture does get in or
on the device, immediately unplug it from the power
outlet and allow it to fully dry before reapplying power.
Do not touch the device, the power cord, or any other
connected cables with wet hands.
Do not subject the product to extreme force, shock, or
fluctuations in temperature or humidity.
Do not expose this device to excessively high
temperatures. Do not place it in, on, or near heat sources,
such as a fireplace, stove, radiator, etc. Do not leave it in
direct sunlight.
Prior to operation, check the unit and power cord for
physical damage. Do not use if physical damage has
occurred.

4
Before plugging the unit into a power outlet, ensure that
the outlet provides the same type and level of power
required by the device.
Unplug this device from the power source when not in
use.
Take care to prevent damage to the power cord. Do not
allow it to become crimped, pinched, walked on, or
become tangled with other cords. Ensure that the power
cord does not present a tripping hazard.
Never unplug the unit by pulling on the power cord.
Always grasp the connector head or adapter body.
Ensure that power is turned off and disconnected before
making any electrical connections.
Remove the batteries from the controller if it will go
unused for a lengthy period of time.
Clean using a soft, dry cloth only. Do not use chemical
cleaners, solvents, or detergents. For stubborn deposits,
moisten the cloth with warm water.
This device has no user serviceable parts. Do not attempt
to open, service, or modify this device.

5
INTRODUCTION
This Blackbird™ 4K 4x2 HDMI® Matrix allows you to select any of
four HDMI video sources to either or both of two HDMI displays.
It supports the HDMI 2.0a and HDCP™ 2.2 standards, as well as
being DVI 1.0 compliant. It supports video resolutions up to
4K@60Hz 4:2:0, including 1080p@60Hz and 3D video. It can
extract the HDMI audio from either output and outputs both
multichannel S/PDIF digital optical and 2-channel analog audio. It
features three EDID® control options and can be controlled using
the front panel buttons, as well as the included IR remote control.
FEATURES
Complies with the HDMI® 2.0a, HDCP™ 2.2, and DVI 1.0
standards
Supports HDMI resolutions up to 4K@60Hz 4:2:0,
including 1080p@60Hz and 3D video
Supports multichannel digital optical and stereo analog
audio extraction from either output
Includes three EDID® control options
Can be controlled using the front panel buttons and the
included IR remote control

6
CUSTOMER SERVICE
The Monoprice Customer Service department is dedicated to
ensuring that your ordering, purchasing, and delivery experience
is second to none. If you have any problem with your order,
please give us an opportunity to make it right. You can contact a
Monoprice Customer Service representative through the Live
Chat link on our website www.monoprice.com or via email at
[e-mail]. Check the website for support times
and links.
PACKAGE CONTENTS
Please take an inventory of the package contents to ensure you
have all the items listed below. If anything is missing or damaged,
please contact Monoprice Customer Service for a replacement.
1x Blackbird™ 4K 4x2 HDMI matrix
1x IR remote control
1x AC power adapter
2x Rack mount brackets
1x User's manual

7
PRODUCT OVERVIEW
Front Panel
1. IR: Aim the remote control towards the IR receiver
window.
2. OUT A: Press the button to cycle forward through the
available inputs for output A. The LEDs will indicate which
of the four inputs is selected.
3. OUT B: Press the button to cycle forward through the
available inputs for output B. The LEDs will indicate which
of the four inputs is selected.
4. AUDIO: Press the button select which output's audio is
extracted to the digital optical and analog audio outputs.
The LEDs will illuminate to indicate which output is
selected.
5. EDID: Use the switch to select one of the three EDID®
control options is used.

8
When set to AUTO, the matrix will poll both outputs
and will transmit the lower of the two EDID® options to
all four source devices.
When set to COPY, the matrix will transmit the EDID
information of the display connected to output A to all
four source devices. If the EDID cannot be copied, it
will send the default 1080p@60Hz video resolution to
all four source devices.
When set to STD, the matrix will send the standard
4K@30Hz resolution to all four source devices.
6. SERVICE: For use by the manufacturer only.
Rear Panel
1. HDMI INPUT: Four HDMI® ports for connecting the HDMI
source devices.
2. HDMI OUTPUT: Two HDMI ports for connecting HDMI
displays.

9
3. AUDIO OUT: S/PDIF digital optical and 3.5mm TRS analog
audio outputs for connecting an external amplifier or
powered speakers for playback of the extracted audio.
4. DC 5V: DC barrel connector for connecting the included
AC power adapter.
Remote Control
1. OUTPUT A: Press one of the IN#
buttons to directly select the
numbered input for OUT A. Press
the ◄button to select the
previous input or press the ►
button to select the next input.
The corresponding LED in the OUT
Asection on the front panel will
illuminate to indicate the selected
input.
2. OUTPUT B: Press one of the IN# buttons to directly select
the numbered input for OUT B. Press the ◄button to
select the previous input or press the ►button to select
the next input. The corresponding LED in the OUT B
section on the front panel will illuminate to indicate the
selected input.

10
3. AUDIO: Press the Aor Bbutton to extract the audio from
OUT A or OUT B. The corresponding LED in the AUDIO
section on the front panel will illuminate to indicate the
selected output.
SAMPLE CONNECTION DIAGRAM

11
TECHNICAL SUPPORT
Monoprice is pleased to provide free, live, online technical
support to assist you with any questions you may have about
installation, setup, troubleshooting, or product recommendations.
If you ever need assistance with your new product, please come
online to talk to one of our friendly and knowledgeable Tech
Support Associates. Technical support is available through the
online chat button on our website www.monoprice.com or
through email by sending a message to t[email protected]m.
Check the website for support times and links.
SPECIFICATIONS
Model
15376
Inputs
4x HDMI®
Video Outputs
2x HDMI
Audio Outputs
1x S/PDIF multichannel digital
optical,
1x 3.5mm TRS stereo analog
HDMI Version
2.0a
HDCP™ Version
2.2 and 1.4

12
Video Bandwidth
297Mbps/channel
891Mbps total
Maximum Video Resolution
4K@60Hz 4:2:0
Supported Color Spaces
RGB/YCbCr 4:2:0, YCbCr
4:4:4, YCbCr 4:2:2
Supported Color Depths
8-bit, 10-bit, 12-bit
Input Power
5 VDC, 1A
AC Adapter Input Power
100 ~ 240 VAC, 50/60 Hz
Maximum Power
Consumption
2 watts
Operating Temperature
+32 ~ +104°F (0 ~ +40°C)
Storage Temperature
-4 ~ +140°F (-20 ~ +60°C)
Operating Humidity
20 ~ 90% RH, noncondensing
Dimensions
7.9" x 3.1" x 0.6"
(200 x 80 x 16 mm)
Weight
11.6 oz. (328g)
Regulatory Compliance
CE, FCC, UL

13
REGULATORY COMPLIANCE
Notice for FCC
This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Modifying the equipment without Monoprice's authorization may
result in the equipment no longer complying with FCC
requirements for Class A digital devices. In that event, your right
to use the equipment may be limited by FCC regulations, and you
may be required to correct any interference to radio or television
communications at your own expense.
This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a commercial installation. This
equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. Operation of this equipment in a residential area

14
is likely to cause harmful interference, in which case the user will
be required to correct the interference at his own expense.
Notice for Industry Canada
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme
NMB-003 du Canada.
Blackbird™ is a trademark of Monoprice Inc.
HDMI®, the HDMI Logo, and High-Definition Multimedia Interface
are trademarks or registered trademarks of HDMI Licensing LLC in
the United States and other countries.
HDCP™ is a trademark of Digital Content Protection LLC.
EDID® is a registered trademark of the Video Electronics
Standards Association.
