Blackbird™ 4K 8x8 HDBaseT™ Matrix with 6 Receivers
P/N 39670
User's Manual

2
CONTENTS
SAFETY WARNINGS AND GUIDELINES...................................................................................................................................4
INTRODUCTION..........................................................................................................................................................................................5
FEATURES........................................................................................................................................................................................................6
CUSTOMER SERVICE ..............................................................................................................................................................................6
PACKAGE CONTENTS............................................................................................................................................................................ 7
PRODUCT OVERVIEW ...........................................................................................................................................................................8
Matrix Front Panel............................................................................................................................................................................................................................ 8
Matrix Rear Panel...............................................................................................................................................................................................................................9
Receiver....................................................................................................................................................................................................................................................10
IR Remote Control...........................................................................................................................................................................................................................12
SAMPLE CONNECTION DIAGRAM............................................................................................................................................ 13
IR PASS-THROUGH CONTROL ......................................................................................................................................................14
Controlling a Single Remote Display from the Matrix .....................................................................................................................................14
Controlling All Remote Displays from the Matrix ................................................................................................................................................15
Controlling a Single Source Device from a Receiver.........................................................................................................................................16
Controlling All Source Devices from All Receivers..............................................................................................................................................17
CONTROL.......................................................................................................................................................................................................18
Front Panel Buttons .......................................................................................................................................................................................................................18
IR Remote Control...........................................................................................................................................................................................................................19
WEB GUI CONTROL..............................................................................................................................................................................20
Login ......................................................................................................................................................................................................................................................... 20
Switching Tab......................................................................................................................................................................................................................................21
Audio Tab...............................................................................................................................................................................................................................................22
Configuration Tab...........................................................................................................................................................................................................................23
CEC Tab....................................................................................................................................................................................................................................................26
RS232 Tab...............................................................................................................................................................................................................................................28

3
Interface Tab .......................................................................................................................................................................................................................................30
Network Tab.........................................................................................................................................................................................................................................31
Access Tab ............................................................................................................................................................................................................................................32
WEB GUI UPGRADE...............................................................................................................................................................................33
RS-232 CONNECTION .........................................................................................................................................................................34
Controlling the Matrix with a PC Connected to the Matrix.......................................................................................................................34
Controlling the Matrix with a PC Connected to a Receiver.......................................................................................................................35
Controlling a Remote Third-Party Device with a PC Connected to the Matrix ........................................................................36
Control a Local Third-Party Device with a PC Connected to a Receiver ........................................................................................ 37
RS-232 CONTROL ...................................................................................................................................................................................38
RS-232 COMMANDS ........................................................................................................................................................................... 39
System Settings ...............................................................................................................................................................................................................................39
Signal Switching ............................................................................................................................................................................................................................. 46
Audio Settings.................................................................................................................................................................................................................................. 49
EDID Management........................................................................................................................................................................................................................ 50
HDCP Management.......................................................................................................................................................................................................................53
Third-Party Device Control .....................................................................................................................................................................................................55
CEC Control......................................................................................................................................................................................................................................... 58
FIRMWARE UPGRADE.........................................................................................................................................................................61
TROUBLESHOOTING............................................................................................................................................................................62
TECHNICAL SUPPORT.........................................................................................................................................................................63
SPECIFICATIONS.....................................................................................................................................................................................63
Matrix........................................................................................................................................................................................................................................................63
Receivers ................................................................................................................................................................................................................................................65
REGULATORY COMPLIANCE ........................................................................................................................................................66
Notice for FCC .................................................................................................................................................................................................................................. 66
Notice for Industry Canada ....................................................................................................................................................................................................67

4
SAFETY WARNINGS AND GUIDELINES
Please read this entire manual before using this device, paying extra attention to these
safety warnings and guidelines. Please keep this manual in a safe place for future reference.
•This device is intended for indoor use only.
•Do not expose this device to water or moisture of any kind. Do not place drinks or
other containers with moisture on or near the device. If moisture does get in or on
the device, immediately unplug it from the power outlet and allow it to fully dry
before reapplying power.
•Do not touch the device, the power cord, or any other connected cables with wet
hands.
•Do not expose this device to excessively high temperatures. Do not place it in, on,
or near a heat source, such as a fireplace, stove, radiator, etc. Do not leave it in
direct sunlight.
•Use only in a well-ventilated area. Do not use in close, confined spaces.
•Prior to operation, check the unit and power cord for physical damage. Do not use if
physical damage has occurred.
•Before plugging the unit into a power outlet, ensure that the outlet provides the
same type and level of power required by the device.
•Unplug this device from the power source when not in use.
•Take care to prevent damage to the power cord. Do not allow it to become
crimped, pinched, walked on, or become tangled with other cords. Ensure that the
power cord does not present a tripping hazard.
•Never unplug the unit by pulling on the power cord. Always grasp the connector
head or adapter body.
•Ensure that power is turned off and disconnected before making any electrical
connections.
•Remove the batteries from the controller if it will go unused for a lengthy period of
time.

5
•Clean using a soft, dry cloth only. Do not use chemical cleaners, solvents, or
detergents. For stubborn deposits, moisten the cloth with warm water.
•This device has no user serviceable parts. Do not attempt to open, service, or
modify this device.
INTRODUCTION
This Blackbird™ 4K 8x8 HDBaseT™ Matrix features 8 HDMI® inputs, 2 HDMI outputs, 6
HDBaseT outputs, and 4 digital optical S/PDIF audio outputs. It supports video resolutions
up to 4K@60Hz with YCbCr 4:4:4 and can transmit 4K video to distances up to 131 feet (40
meters) and 1080p video to distances up to 229 feet (70 meters) over a single Cat5e/6
Ethernet cable. Audio extracted from the HDMI inputs, HDBaseT outputs, and Audio Return
Channel (ARC) output from the HDBaseT receivers can be output using the 4 digital optical
S/PDIF audio connectors. It supports bidirectional IR extension and features front panel
buttons, IR remote control, RS-232, and Web GUI control options. It supports the Power
over Cable (PoC) feature, which allows the receivers to draw their power from the matrix
over the Ethernet cable. It includes smart EDID® management using the 4-pin DIP switch on
the rear panel.

6
FEATURES
•Supports HDMI® resolutions up to 4K@60Hz with YCbCr 4:4:4 HDR, including
1080p@60Hz and 3D video
•Fully compliant with the HDMI 2.0 and HDCP™ 2.2 specifications
•Can transmit 4K signals to distances up to 131 feet (40 meters) and 1080p signals to
distances up to 229 feet (70 meters) over a single Cat5e/6 Ethernet cable
•Features 6 HDBaseT™ outputs and includes 6 receivers
•Supports the 24V Power over Cable (PoC) feature, allowing the receivers to draw
their power from the matrix over the Ethernet cable
•Includes two HDMI outputs for connecting local displays
•Audio from the HDMI inputs, HDBaseT and HDMI outputs, and Audio Return
Channel (ARC) audio from the receivers can be output to 4 digital optical S/PDIF
audio outputs
•Includes smart EDID® management using the 4-pin DIP switch on the rear panel
•Can be controlled using the front panel controls, the included IR remote control, or
with a computer using an RS-232 or Ethernet connection
CUSTOMER SERVICE
The Monoprice Customer Service department is dedicated to ensuring that your ordering,
purchasing, and delivery experience is second to none. If you have any problem with your
order, please give us an opportunity to make it right. You can contact a Monoprice
Customer Service representative through the Live Chat link on our website
www.monoprice.com or via email at sup[email protected]. Check the website for
support times and links.

7
PACKAGE CONTENTS
Please take an inventory of the package contents to ensure you have all the items listed
below. If anything is missing or damaged, please contact Monoprice Customer Service for a
replacement.
1x Blackbird™ 4K 8x8 HDBaseT™ matrix
6x HDBaseT receivers
2x Mounting ears with 6 screws for the matrix
12x Mounting ears with 24 screws for the receivers
4x Plastic feet for the matrix
24 Plastic feet for the receivers
1x IR remote control
6x IR receivers
8x IR transmitters
1x RS-232 cable (3-pin to DB-9)
6x 3-pin terminal blocks
1x AC power adapter
1x User's manual

8
PRODUCT OVERVIEW
Matrix Front Panel
1. POWER LED: The LED indicator illuminates red when power is applied.
2. OUTPUTS: Eight buttons with LED indicators for selecting the outputs.
3. INPUTS: Eight buttons with LED indicators for selecting the inputs.
4. MENU: Four buttons for performing various menu related functions.
•ENTER: Press the button to accept the changes.
•LOCK: Press the button to lock or unlock the other buttons on the front panel.
•ALL: Press the button to select all inputs for EDID® management or all outputs
for switching.
•CLEAR: Press the button to cancel pending changes.
5. PRESET RECALL: Momentarily press one of the 4 buttons to select a previously
saved preset. The LED to the left of the button illuminates to indicate that the
preset is active. Press and hold one of the 4 buttons to save the current input
selections for each output channel to a preset.

9
Matrix Rear Panel
1. INPUTS: Eight HDMI® inputs for connecting the video source devices.
2. OUTPUTS:
•1-6 HDBT: Six RJ45 Ethernet jacks for connecting the included receivers using
Cat5e/6 Ethernet cables (not included).
•7-8 HDMI: Two HDMI output ports for connecting local displays.
3. IR OUT:
•1-8: Eight 3.5mm jacks for connecting the included IR transmitters for IR pass-
through control of the individual video source devices.
•ALL OUT: One 3.5mm jack for connecting one of the included IR transmitters for
IR pass-through control of all video source devices.
4. IR IN:
•1-6: Six 3.5mm jacks for connecting the included IR receivers to receive IR signals
for transmission to the corresponding HDBaseT™ receivers.
•ALL IN: One 3.5mm jack for connecting one of the included IR receivers to
receive IR signals for transmission to all HDBaseT receivers.
5. AUDIO MATRIX OUTPUTS/ARC: Four digital optical S/PDIF connectors for
connecting external amplifiers for separate amplification of audio de-embedded
from the HDMI inputs, HDBaseT and HDMI outputs, and Audio Return Channel (ARC)
audio from the HDBaseT receivers. By default, the four outputs use audio de-
embedded from HDBaseT receivers 1-4. The source for the audio de-embedding can
be set using the built-in Web GUI or using RS-232 commands.

10
6. CONTROL:
•TCP/IP: RJ45 Ethernet jack for connecting to an existing Ethernet network using
a Cat5e/6 Ethernet cable (not included) for computer control using the built-in
Web GUI.
•RS232: 3-pin terminal block for connecting the included RS-232 cable for
computer control using RS-232 commands or to connect to a third-party device
for RS-232 control.
•IR EYE: 3.5mm jack for connecting one of the included IR receivers to control the
matrix using the included IR remote control.
•FW: USB Type-A port for connecting a USB flash drive for performing firmware
updates.
7. DC 12V: Connector for attaching the included AC power adapter.
Receiver
1. POWER LED: The LED illuminates red when power is applied.
2. ARC Mode: Use a paper clip or other sharp, thin device to press the recessed button
to enable or disable Audio Return Channel (ARC) audio. When ARC mode is enabled,
the LED illuminates blue. When ARC audio is selected as the audio source for one of
the digital optical S/PDIF outputs on the matrix, ARC mode is automatically enabled.
3. ARC Audio In: Digital optical S/PDIF input for connecting the ARC audio source (e.g.,
TV) using a digital optical S/PDIF audio cable (not included).
4. FW: Micro USB port for connecting a USB flash drive to perform firmware updates.
5. HDMI Out: HDMI® port for connecting an HDMI display using an HDMI cable (not
included).

11
6. Audio Breakout: Digital optical S/PDIF connector for connecting an external
amplifier using a digital optical S/PDIF cable (not included) for amplification of
audio de-embedded from the input. Note that if ARC mode is enabled, this output is
disabled.
7. IR In: 3.5mm jack for connecting one of the included IR receivers for IR pass-through
control of the video source devices.
8. IR Out: 3.5mm jack for connecting one of the included IR transmitters for IR pass-
through control of the connected display.
9. RS232: 3-pin terminal block for connecting the included RS-232 cable for computer
control of the matrix using RS-232 commands or to connect to a third-party device
for RS-232 control.
10. HDBT In: RJ45 jack for connecting the Ethernet cable from the matrix. The HDCP LED
illuminates green when the video contains HDCP™ content. The LINK LED
illuminates orange when there is a valid HDBaseT™ link with the matrix.
11. DC 12V: DC barrel connector for connecting an AC power adapter (not included).
Note that the receivers can be power using the Power over Cable (PoC) feature, so
no AC power adapters for the receivers are included.

12
IR Remote Control
1. STANDBY: Press the STANDBY button to turn the matrix on
or to put it into standby mode.
2. INPUTS: Eight numbered buttons corresponding to the eight
inputs.
3. OUTPUTS: Eight numbered buttons corresponding to the
eight outputs.
4. MENU:
•ALL: The ALL button can be used to select all INPUTS for
EDID® management or all OUTPUTS for switching.
•EDID: The EDID button is used to set the EDID for one or
more INPUTS to the EDID capabilities of the selected
OUTPUT.
•CLEAR: The CLEAR button is used to cancel a change in
progress.
•ENTER: The ENTER button is used to accept the change.

13
SAMPLE CONNECTION DIAGRAM

14
IR PASS-THROUGH CONTROL
This matrix features bidirectional IR control and includes 6 IR receivers and 8 IR
transmitters. The receivers and transmitters can be installed in a variety of ways for several
control options. The following diagrams illustrate the various control methods.
Controlling a Single Remote Display from the Matrix
Perform the following steps to connect for control of one of the remote displays from the
matrix location.
1. Plug one of the included IR transmitters to the IR Out jack on the receiver, then
position the emitter so that it can transmit to the IR eye on the display.
2. Plug one of the included IR receivers to the IR IN jack on the matrix that
corresponds to the receiver, then position it so that it can receive IR signals from
the remote display's IR remote control.

15
Controlling All Remote Displays from the Matrix
Perform the following steps to connect for control of all of the remote displays from the
matrix location.
1. Plug one of the included IR transmitters to the IR Out jack on each connected
receiver, then position the emitters so they can transmit to the IR eyes on each
display.
2. Plug one of the included IR receivers into the IR IN ALL IN jack on the matrix, then
position it where it can receive IR signals from the remote displays' IR remote
controls.

16
Controlling a Single Source Device from a Receiver
Perform the following steps to connect for control of a single video source device from the
receiver location.
1. Plug one of the included IR transmitters into the IR OUT jack on the matrix that
corresponds to the source device to be controlled, then position it where it can
transmit to the IR eye on the source device.
2. Plug one of the included IR receivers into the IR In jack on one of the receivers, then
position it where it can receive signals from the source device's IR remote control.

17
Controlling All Source Devices from All Receivers
Perform the following steps to connect for control of all video source devices from the
receiver locations.
1. Plug one of the included IR transmitters into the IR OUT ALL OUT jack on the matrix,
then position it where it can transmit to the IR eyes on the source devices.
2. Plug one of the included IR receivers into the IR In jack on one or more of the
receivers, then position them where they can receive signals from the source
devices' IR remote controls.

18
CONTROL
Front Panel Buttons
The matrix can be controlled using the buttons on the front panel. Whenever a command is
accepted, the LEDs of all buttons pressed will blink three times, then turn off. If the ENTER
or CLEAR button is not pressed after initiating a change, the LEDs will turn off after eight
seconds.
•To switch an input to one or more outputs, press one of the INPUTS buttons, then
press one or more OUTPUTS buttons or the ALL button for all outputs, and finally
press the ENTER button to execute the change.
•To see which input is assigned to a given output, press and hold the OUTPUTS
button you want to query. The LED of the assigned input illuminates blue. The LEDs
turn off when you release the OUTPUTS button.
•Press and hold the LOCK button for about 3 seconds to lock or unlock the other
front panel buttons. The LED next to the LOCK button illuminates blue when the
front panel buttons are locked.
•Press and hold one of the PRESET buttons to save the current switching layout to
the corresponding preset. Momentarily press one of the PRESET buttons to load the
corresponding preset. The LED next to the selected PRESET button illuminates blue
to indicate that it is selected.
Note: The matrix supports nine presets, but only the first four presets can be
accessed using the front panel controls and only the first six can be managed in the
Web GUI. The other three presets can be managed using RS-232 control.
•Press the ENTER button to execute any pending commands.
•Press the CANCEL button to clear any pending commands.

19
IR Remote Control
•Press the STANDBY button to turn the matrix on or to put it
into standby mode.
•To switch the selected input for one or more of the outputs,
first press the number button in the INPUTS section
corresponding to the desired input, then press one or more
number buttons in the OUTPUTS section or the ALL button in
the MENU section for all outputs, and finally press the ENTER
button in the MENU section to execute the change.
•To set the EDID® for one or more source devices to the EDID
capabilities of a specific output, press the EDID button, then
press one or more number buttons in the INPUTS section
corresponding to the desired input(s) or the ALL button in
the MENU section for all inputs, then press a number button
corresponding to the OUTPUT with the desired EDID settings,
and finally press the ENTER button in the MENU section to
execute the change.
•At any time prior to pressing the ENTER button to execute
the change, you can press the CANCEL button in the MENU section to cancel the
pending change.
Following are some examples:
•To send input 3 to output 2, first press the INPUTS 3 button, then press the
OUTPUTS 2 button, and finally press the ENTER button to execute the change.
•To send input 4 to all outputs, first press the INPUTS 4 button, then press the ALL
button, and finally press the ENTER button to execute the change.
•To send the EDID from output 4 to all inputs, first press the EDID button, then press
the ALL button to select all inputs, press the OUTPUTS 4 button, and finally press
the ENTER button to execute the change.

20
WEB GUI CONTROL
The matrix features a built-in Web GUI and the ability to be controlled from a computer
connected to the network. To use the Web GUI, you must first connect the matrix to an
existing Ethernet network using a Cat5e or Cat6 Ethernet cable (not included). The default
IP settings of the matrix are as follows:
IP Address: 192.168.0.178
Subnet Mask: 255.255.255.0
Gateway: 192.168.0.1
Login
To access the Web GUI, open an internet browser on your computer, then type
192.168.0.178 into the address bar and hit enter. You will see the following login screen.
The default User Name and Password are:
User Name: admin
Password: admin
Type the User Name and Password into the appropriate fields, then click the Login button.
