montpellier MWBI8014 User manual

Integrated Washing Machine
MWBI8014 -8kg - 1400rpm - A+++
Please read these instructions carefully before attempting to install or use this appliance.
We recommend that you keep these instructions in a safe place for future reference.
Installation and Operating Instructions
THE PERFECT BALANCE OF FUNCTION AND STYLE
LAUNDRY - DISHWASHING - COOKING - COOLING

Thank you for choosing this Montpellier Integrated Washing Machine.
Our Integrated Washing Machine has been designed to provide you with the best combination of style, reliability
and performance to give you years of trouble-free use.
You may be familiar with a similar product, but please take time to read these instructions carefully before installing
or using your Integrated Washing Machine to ensure you get the most from your purchase.
We recommend that you keep this manual in a safe place for future reference.
Your Integrated Washing Machine is covered by a comprehensive two year
Parts & Labour Guarantee. In the unlikely event that you experience a problem
with your Integrated Washing Machine, you can rest assured that you are fully
protected against the cost of repairs for the first 24 months . Please note that
any claim must be accompanied by the model reference number, serial number
and proof of purchase.
To activate your guarantee, you will need your product serial number. This can be
found on the rear of the machine.
There are two ways to register your Guarantee:
•Online: Visit the Support page on our website and complete the online Product
Registration form. www.montpellier-appliances.com
•By Post: Simply detach and ll in the form provided, attach a stamp and send
it in the post. Don’t forget to include your e-mail address so that we can send
conrmation through to you.
Welcome
Note: We are unable to take registrations over the phone.
ACROSS ALL OUR MODELS
YEAR
GUARANTEE
PA R T S & L A B O U R
www.montpellier-appliances.com

3
EN
Carefully read this manual for correct and
safe appliance use and for helpful tips on
efficient maintenance.
Only use the washing machine
after carefully reading these instructions.
We recommend
you always keep this
manual on hand and in good condition for
any future owners.
Please check that the appliance is
delivered with this instruction manual,
warranty certificate, service centre address
and energy efficiency label. Also check that
plugs, d
rain hose support hook and liquid
detergent or bleach tray (only on some
models) are included. We recommend you
keep all these components.
Each product is identified by a unique 16-
character code, also called the “serial
number”, printed on the sticker. T
his can
be found inside the door opening. This
code is a unique code for your product that
you will need to register the product
warranty, or if you need to contact the
Customer Service Centre.
This appliance is marked acc
ording to
the European directive 2012/19/EU
on Waste Electrical and Electronic
Equipment(WEEE).
WEEE contains both polluting substances (which
can cause negative consequences for the
environment) and basic components (which can
be re-used). It is importa
nt to have WEEE
subjected to specific treatments, in order to
remove and dispose properly all pollutants, and
recover and recycle all materials. Individuals can
play an important role in ensuring that WEEE
does not become an environmental issue; it is
essential to follow some basic rules:

WEEE should not be treated as household
waste;

WEEE should be handed over to the relevant
collection points managed by the municipality or
by registered companies. In many countries, for
large WEEE, home collection could be present.
In many countries, when you buy a new
appliance, the old one may be returned to the
retailer who has to collect it free of charge on a
one-to-
one basis, as long as the equipment is of
equivalent type and has the same functions as
thesupplied equipment.
1. GENERAL SAFETY RULES
2. INSTALLATION
3. PRACTICAL TIPS
4. MAINTENANCE AND CLEANING
5. QUICK USER GUIDE
6. CONTROLS AND PROGRAMS
7.
THROUBLESHOOTING AND WARRANTY
Environmental conditions
Contents

4
1. GENERAL SAFETY
RULES
This appliances is intended to
be used in household and
similar applications such as:
- Staff kitchen areas in shops, offices
and other working environments;
- Farm houses;
- By clients in hotels, motels and
otherresidential typeenvironments;
- Bedandbreakfasttypeenvironments.
A different use of this appliance
from household environment
or from typical housekeeping
functions, as commercial use by
expert or trained users, is excluded
even in the above applications. If
the appliance is used in a manner
inconsistent with this it may reduce
the life of the appliance and may
void the manufacturer’s warranty.
Any damage to the appliance or
other damage or loss arising
through use that is not consistent
with domestic or household use
(even if located in a domestic or
household environment) shall not
be accepted by the manufacturer to
the fullest extent permitted by law.
This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand the
hazards involved.
Children shall not play with the
appliance. Cleaning and user
maintenance shall not be made
bychildren without supervision.
Children should be supervised
to ensure that they do not play
with the appliance.
Children of less than 3 years
should be kept away unless
continuously supervised.
If the supply cord is damaged, it
must be replaced by the
manufacturer, its service agent
or similarly qualified persons in
order to avoid a hazard.
Only use the hose-sets
supplied with the appliance for
the water supply connection
(do not reuse old hose-sets).
 Water pressure must be between
0.05 MPa and 0.8 MPa.
Make sure carpets or rugs do
not obstruct the base or any of
the ventilation openings.
The OFF condition is reached
by placing the reference mark on
the programmes control/knob in
the vertical position. Any other
different position of such control
sets the machine in ON condition
(only for models with programmes
knob).

5
EN
After installation, the appliance
must be positioned so that the
plug is accessible.
The maximum load capacity of
dry clothes depends on the
model used (see control panel).
 To consult the product technical
specification please refer to the
manufacturer website.
Before cleaning or maintaining
the washing machine, unplug
the appliance and turn off the
water tap.
 Make sure the electrical system
is earthed . Otherwise, seek
qualified professional assistance.
Please do not use converters,
multiple sockets or extension
cords.
Make sure there is no water in
the drum before opening the
door.
Do not pull on the power cord
or appliance to unplug the
machine.
Do not expose the washing
machine to rain, direct sunlight
or other weather elements.
Protect from possible freezing.
When moving, do not lift the
washing machine by the knobs
or detergent drawer; during
transport, never rest the door on
the trolley. We recommend two
people lift the washing machine.
In the event of fault and/or
malfunction, turn off the
washing machine, close the
water tap and do not tamper
with the appliance.
Immediately contact the
Customer Service Centre and
only use original spare parts.
Failure to observe these
instruction may jeopardise
appliance safety.
By placing the
mark on this
product, we are confirming
compliance to all relevant
European safety, health and
environmental requirements which
are applicable in legislation for
this product.
Safety instructions
WARNING:
water may reach very high
temperatures during the
wash cycle.

6
2. INSTALLATION

Release the power chord and
drain hose from the securing
clip at the rear of the machine.
 Remove the 2 or 4
transportation
screws (A)
on the back and
remove the 2 or 4
flat washers,
rubber bungs and plastic sp
acer
tubes (B) as illustrated in figure 1 .
 If the washing machine is built-
in,
unscrew the 3 or 4
transportation
screws (A) and remove the 3
or
4
flat washers, rubber bungs and
plastic spacer tubes (B) .

During the removal of the screws
occasionally spac
er tubes fall
inside the product, these can be
remove by tilting the product forward
and recovering them from the floor
or inside the base ofthemachine.

Cover the open transportation
screw holes with the 2or
4
plastic caps included in the
instruction bag.
Place the corrugated plastic
sheet, found on top of the
appliance during the unpacking
process, into the base of the
appliance as shown in
figure 2
(according to the model,
consider version A, Bor C).
A
A
A
A
B
B
B
B
1
3
2
1
3
1
2
A
C
B
2
WARNING:
keep packaging materials
away from children.

7
EN

Position the template onto the
reverse of the furniture door. It
is possible to mount the hinges
and closure magnet on the right
or left-
hand side depending on
your requirements. Mark the
screw hole positions, then drill
out these positions.

Fix the hinges in place with the
4 screws provided (A).
Fix the magnet (B)
in place
using screw (C).
Mount the plate (D)
on the right
or left-
hand side, depending on
your installation requirements.
Place the plastic support
(E)
under the plate an
d fix it in
position with screw (F).
Snap mount cap (G)
in the
lower position.
A
D
E
G
F
BC
Instructions for mounting the
furniture door

8

Mount the furniture door to the
front of the washer using the
hinges. Place the spacers
under the hinges (I)
and then
fix in position with screw (H).

Slide the washer into an
opening of the size indicated in
the diagram opposite. A furniture
plinth may be run across the front
of the appliance, but its height will
be dictated by the height the
washer is set at.
The 4 adjustable feet allow t
he
height of the washer to be
adjusted from 820 mm to a
maximum of 840 mm. To adjust
the height, you should remove
the nuts fitted to each foot and
replace these with the 5 mm
nuts supplied. Raise the feet to
your desired height and then
fully tighten the
lock nut to the
base of the washer.
570
596
600
min.
600
HI
820min.
825 min.
We suggest mounting the
furniture door so that it opens
towards the left, which is the
same direction as the porthole
door. This will leave more
space when you are loading
washing into the appliance.

9
EN

Connect the water hose to the water
supply tap (fig. 3)
only using the hose
supplied with the appliance (do not
reuse old hose-sets).
SOME MODELS may include o
ne or
more of the following features:
HOT&COLD (fig. 4):
water mains connection settings with hot
and cold water for higher energy savings.
Connect the grey tube to the cold water
tap
and the red one to the hot water
tap. The machine can be connected
to
the cold water tap only: in this case, some
programs may start a few minutes later.
AQUASTOP (fig. 5):
a device located on the supply tube that
stops water flow if the tube deteriorates;
in this case, a red mark will appear in the
window “A” and th
e tube must be
replaced. To unscrew the nut, press the
one-way lock device "B".
AQUAPROTECT –
SUPPLY TUBE WITH
GUARD (fig. 6):
Should water leak from the primary
internal tube "A
", the transparent
containment sheath "B
" will contain water
to permit the
washing cycle to complete.
At the end of the cycle, contact the
Customer Service Centre to replace the
supply tube.

The washing machine should be installed
in its final position such that the water fill
hose is not kinked o
r trapped. The
corrugated drain hose should be inserted
into suitable drain pipe of between 50 cm
and 85 cm height above the floor using
the curved drain hose support. If an under
sink connection is used the drain hose
must be routed above the sink overfil
l
opening to prevent back siphoning. Care
must be taken to avoid kinking or trapping
the drain hose (fig. 7).
3
1
4
B
A
5
B
A
6
Hydraulic connections
Setting

10

Level the appliance using the feet as
illustrated in figure 8:
a.
turn the nut clockwise to release the
screw;
b. rotate the fo
ot to raise or lower it until it
touches to the floor;
b.
lock the foot, screwing in the nut, until it
tightens against to the bottom of the
washing machine.
Plug in the appliance.
The d
etergent draw is split into 3
compartments as illustrated in figure 9:
compartment "1": for prewash detergent;
compartment “ ”
: for special additives,
softeners, starch fragrances, etc.;
compartment "2": for washing detergent.
2
1
10
WARNING:
contact the Customer Service Centre
should the power cord need
replacement.
Detergent drawer
WARNING:
only use liquid products; the washing
machine is set to automatically dose
additives at each
cycle during the last
rinse.
WARNING:
some detergents are hard to remove.
In this case we recommend using the
specific container to be placed in the
drum (example in figure 10).

11
EN
3. PRACTICAL TIPS
WARNING: when sorting laundry, make
sure:
- have eliminated metallic objects such as
hair clips, pins, coins, from laundry;
- to have buttoned pillow cases, closed zips,
tied loose belts and long robe ribbons;
- to have removed rollers, hooks or clips
from curtains;
- to have carefully read clothing washing
labels;
- to have removed any persistent stains
using specific detergents.
When washing rugs, bedcovers or other
heavy clothing, we recommend you avoid
the spinning cycle.
To wash wool, make sure the item can be
machine washed and marked by the
“Pure virgin wool” symbol with the “Does
not mat” or “Machine washable” label.
A guide environmentally friendly and
economic use of your appliance.
Maximise The Load Size
Achieve the best use of energy, water,
detergent and time by using the
recommended maximum load size.
Save up to 50% energy by washing a full
load instead of 2 half loads.
Do you need to pre-wash?
For heavily soiled laundry only!
SAVE detergent, time, water and
between 5 to 15% energy consumption
by NOT selecting Prewash for slight to
normally soiled laundry.
Is a hot wash required?
Pretreat stains with stain remover or soak
dried in stains in water before washing to
reduce the necessity of a hot wash
programme.
Save up to 50% energy by using a 60°C
wash programme.
Following is a quick guide with tips and
recommendations on detergent use at the
various temperatures. In any case, always
read the instructions on the detergent for
correct use and doses.
Load tips
Helpful suggestions for the user
When washing heav
ily soiled whites,
we recommend using cotton
programs of 60°C
or above and a
normal washing powder (heavy duty)
that contains bleaching agents that at
medium/high temperatures provide
excellent results.
For washes between 40°C and 60°C
the type of deterge
nt used needs to be
appropriate for the type of fabric and
level of soiling.
Normal powders are suitable for “white”
or colour fast fabrics with high soiling,
while liquid detergents or “colour
protecting” powders are suitable for
coloured fabrics with lig
ht levels of
soiling.
For washing at temperatures below
40°C
we recommend the use of liquid
detergents or detergents specifically
labeled as suitable for low temperature
washing.
For washing
wool
or
silk
, only use
detergents specifically formulated for
these fabrics.

12
4. MAINTENANCE AND
CLEANING
To clean the washing machine exterior, use
a damp cloth, avoiding abrasives, alcohol
and/or solvents. To maintain a good wash
performance we recommend that the soap
drawer and pump filters are regularly
cleaned. A monthly service wash, using a
proprietary cleaner is also recommended.
We recommend you clean the drawer to
avoid accumulating detergent and
additive residue.
To do this, extract the drawer using slight
force, clean it with running water and
reinsert it in its housing.
Ensure the siphon cap is correctly
refitted.
The washing machine comes with a
special filter able to trap large residue,
such as buttons or coins, which could
clog the drain.
Only available on certain models: pull out
the corrugated hose, remove the stopper
and drain the water into a container.
Ensure all the water has been emptied
from the drum.
Before unscrewing the filter, we
recommend you place an absorbent cloth
under it to keep the floor dry. A small
amount of water will come out of the filter
as you remove it - this is normal.
Turn the filter counter-clockwise to the
limit stop.
Remove and clean the filter; when
finished, replace it turning it clockwise.
The filter handle will be locked when it is
not possible to turn any further and the
handle is horizontal. Smearing a small
amount of liquid soap on the filter seal will
help refitting.
Repeat the previous steps in reverse
order to reassemble all parts.
Should the washing machine be stored in
an unheated room for a long period of
time, drain all water from tubes.
Unplug the washing machine.
Detach the tube from the drainage
system and clip on the rear of the
machine and lower it, fully draining water
into a bowl.
Secure the drain tube with the drainage
system and clip on the rear of the
machine when finished.
Keep the door glass and gasket clean.
Drawer cleaning
Filter cleaning
Suggestions for moves or
prolonged disuse
The manufacturers warranty only
covers faults within the product of a
mechanical or electrical nature. Faults
caused by handling, installation or
miss use are
not covered and may
incur a charge for any repair visit to
resolve.

13
5. QUICK USER GUIDE
This washing machine automatically adjusts
the level of the water to the type and
quantity of washing. This system gives a
reduction in energy consumption and a
saving in washing times.
Turn on the washing machine and select
the required program.
Adjust the washing temperature if
necessary and press the required "option"
buttons.
Press the START/PAUSE button to start
washing.
Should power go out when the washing
machine is running, a special memory
saves the settings and, when power
returns, the machine resumes the cycle
from where it left off.
At the end of the programme, the
message "End" will appear on the display
or, on some models, all wash stage
indicator lights will turn on.
6. CONTROLS AND
PROGRAMS
A
D C E F G B
H
LI MNO P
A
Programme selector with OFF
position
B
START/PAUSE button
C
DELAY START button
D
OPTIONS button
E
RAPID / STAIN LEVEL button
F
TEMPERATURE SELECTION
button
G
SPIN SPEED button
F+G
KEY LOCK
H
Di
gital display
I
OPTIONS indicator lights
L
DOOR LOCKED indicator light
M
KG DETECTOR indicator light
N
KEY LOCK indicator light
O
TEMPERATURE SELECTION
indicator lights
P
SPIN SPEED indicator lights
Program selection
Wait until the DOOR LOCKED light has
gone out before opening the door.
Turn off the washing machine.
For any type of wash, see the program
table and follow the operating sequence
as indicated.
Technical data
Water pressure:
min 0.05 Mpa / max 0.8 Mpa
(0.05 MPa dispenses approximately 1 litre
of water in 10 seconds)
Spin r.p.m. 1400rpm
Power input / Power current fuse amp /
Supply voltage: See rating plate.

14
EN
Press the START/PAUSE button to start
the selected cycle.
Once a programme is selected the
programme selector remains stationary on
the selected programme till cycle ends.
Switch off the washing machine by
turning the selector to OFF.
Press to start the selected cycle.
ADD OR REMOVE ITEMS AFTER THE
PROGRAMMES HAS STARTED (PAUSE)
Press and hold the START/PAUSE
button for about 2 seconds (some
indicator light and the time remaining
indicator will flash, showing that the
machine has been paused).
Wait 2 minutes until the safety device
unlocks the door.
After you have added or removed items,
close the door and press the
START/PAUSE button (the programme
will start from where it left off).
CANCELLING THE PROGRAMME
To cancel the programme, set the
selector to the OFF position.
This button allows you to pre-programme
the wash cycle to delay the start of the
cycle for up to 24 hours.
To delay the start use the following
procedure:
- Select the required programme.
- Press the delay start button once to
activate it (h00 appears on the display)
and then press it again to set a 1 hour
delay (h01 appears on the display). The
pre-set delay increases by 1 hour each
Opening the door
A special safety device prevents the
door from being opened
immediately
after the end of the cycle.
Wait for 2 minutes after the wash
cycle has finished and the "Door
Security" light has gone out before
opening the door.
PROGRAMME selector with OFF
position
When the programme selector is turned
the display lights
up to show the settings
for the programme selected.
For energy saving, at the end of the
cycle or with an inactivity period, the
display level contrast will decrease.
N.B.: To switch the machine off, turn
the programme selector to the OFF
position.
Th
e programme selector must be
returned to the OFF position at the end
of each cycle or when starting a
subsequent wash cycle prior to the next
programme being selected and started.
START/PAUSE button
Close the door BEFORE selecting the
button START/PAUSE.
When the START/PAUSE button has
been pressed, the appliance can take
few seconds before it starts working.
Before you open the door, please
check water level is below the door
opening to avoid flooding.
DELAY START button

15
time the button is pressed, until h24
appears on the display, at which point
pressing the button again will reset the
delay start to zero.
- Confirm by pressing the START/PAUSE
button. The delay countdown will begin
and when it has finished the programme
will start automatically.
It is possible to cancel the delay start by
turning the programme selector to OFF.
If there is any break in the power supply
while the machine is operating, a special
memory stores the selected programme
and, when the power is restored, it
continues where it left OFF.
This button allows you to choose between
three different options:
- EXTRA RINSE
This option allows you to add one rinse at
the end of the washing cycle and is useful
for people with delicate and sensitive
skin, for which a small amount of
detergent residue can cause irritations or
allergies.
It is advisable to also use this function for
the children clothes and for the washing
of heavily soiled items, which requires a
lot of detergent to be used, or for the
washing of toweling items whose fibres
mostly have the tendency to hold the
detergent.
- HYGIENE +
Activated when you set 60°C of
temperature. This option allows deep
cleaning of your clothes by maintaining the
same temperature for the whole wash.
- EASY IRON
This function allows you to minimizes
creases as much as possible, eliminating
the intermediate spins or reducing the
intensity of the last one.
This button allows you to choose between
two different options, depending on the
selected programme.
- RAPID
The button becomes active when
you select the RAPID (14/30/44 Min.)
programme on the knob and allows you to
select one of three durations indicated.
- STAIN LEVEL button
Once the programme has been selected
the wash time set for that programme will
be automatically shown.
This option allows you to choose between
3 levels of wash intensity modifying the
length of the programme, depending on
how much the fabrics are soiled (can only
be used on some programmes as shown
in the table of programmes).
This button allows you to change the
temperature of the wash cycles.
It is not possible to raise the temperature
over the maximum allowed for the
programme, in order to protect the
fabrics.
If you want carry out a cold wash all the
indicators must be off.
The option buttons should be
selected
before pressing the START/PAUSE
button.
OPTIONS button
If an option is selected that is not
compatible with the selected
programme then the option indicator
light first flashes and then goes off.
RAPID / STAIN LEVEL button
TEMPERATURE SELECTIO
N
button

16
EN
By pressing this button, it is possible to
reduce the maximum speed, and if you
wish, the spin cycle can be cancelled.
If the label does not indicate specific
information, it is possible to use the
maximum spin expected in the program.
To reactivate the spin cycle press the
button until you reach the spin speed you
would like to set.
It is possible to modify the spin speed
without pausing the machine.
Pressing simultaneously the buttons
TEMPERATURE SELECTION and SPIN
SPEED for about 3 seconds, the
machine allows you to lock the keys. In
this way, you can avoid making
accidental or unwanted changes if a
button on the display is pressed
accidently during a cycle.
The key lock can be simply cancelled by
pressing the two buttons simultaneously
again or turning off the appliance.
The display’s indicator system allows you to
be constantly informed about the status of
the machine.
1
5
2 3 4 6 7
1) OPTIONS INDICATOR LIGHTS
The indicator lights show the options that
can be selected by the relevant button.
2) CYCLE DURATION
When a programme is selected the
display automatically shows the cycle
duration, which can vary, depending on
the options selected.
During the initial filling phase of the cycle
the machine calculates the actual cycle
time needed based on the load size,
content and options selected. The real
time of the wash will then be displayed.
This time can recaulculate during the
wash depending on detergent levels and
load balancing.
3) DOOR LOCKED INDICATOR LIGHT
The indicator light is illuminated when the
door is fully closed.
SPIN SPEED button
To prevent damage to the fabrics, it is
not possible to increase the speed
over the maximum allowed for the
programme.
An over dosing of detergent can
cause excessive foaming. If the
appliance detects the presence of
excessi
ve foam, it may exclude the
spinning phase or extend the duration
of the program and increase water
consumption.
The machine is fitted with a special
electronic device, which prevents the
spin cycle should the load be
unbalanced. This reduces the noise
an
d vibration in the machine and so
prolongs the life of your machine.
KEY LOCK
Digital Display
Close the door BEFORE selecting the
START/PAUSE button.

17
When START/PAUSE is pressed on
the machine with the door closed, the
indicator will flash momentarily and then
illuminate.
A special safety device prevents the door
from being opened immediately after the
end of the cycle. Wait for 2 minutes after
the wash cycle has finished and the
DOOR LOCKED light has gone out before
opening the door. At the end of the cycle
turn the programme selector to OFF .
4) Kg LOAD INDICATOR LIGHT (function
active only on Cotton and Synthetics
programmes)
During the first minutes of the cycle, the
"Kg LOAD" indicator will remain on while
the intelligent sensor will weigh the
laundry and adjust the cycle time, water
and electricity consumption accordingly.
 Through every wash phase "Kg LOAD"
allows to monitor information on the wash
load in the drum and in the first minutes of
the wash it:
- adjusts the amount of water required;
- determines the length of the wash cycle;
- controls rinsing according to the type of
fabric selected to be washed it;
- adjusts the rhythm of drum rotation for
the type of fabric being washed;
- recognises the presence of too much
soap suds, and if necessary, adjust the
amount of rinse water.
- adjusts the spin speed according to the
load, thus avoiding any imbalance.
5) KEY LOCK INDICATOR LIGHT
The indicator light show that the keys are
locked.
6) WASH TEMPERATURE INDICATOR
LIGHTS
This show the washing temperature of the
selected programme that can be changed
(where allowed) by the relevant button.
If you want carry out a cold wash all the
indicators must be off.
7) SPIN SPEED INDICATOR LIGHTS
This show the spin speed of the selected
programme, you can reduce or omit by the
relevant button.
If
the door
is not
properly closed
,
the light will continue to flash
for
about 7 seconds, after w
hich the
start command
will be automatically
cancelled. In this case, close
the
door in the proper way and
press
the
START/PAUSE button.

18
EN
PROGRAMME
(MAX.) *
1)
21
(see control panel)
(MAX.) 2
1
Whites
2)
6 7 8 9 90°
Cottons +
Prewash
2)
6 7 8 9 60°
Cottons **
2)
6 7 8 9 60°
Eco 20° 6 7 8 9 20°
Mixed
2)
3 3,5 4 4,5 60°
Delicates 2 2,5 2,5 2,5 40°
Rinse - - - - -
Spin - - - - -
Drain - - - - -
14'
1 1 1,5 1,5 30°
Rapid
3) 30' 2 2,5 2,5 2,5 30°
44'
3 3,5 3,5 3,5 40°
Dark Colours 3 3,5 4 4,5 40°
Shirts
2)
3 3,5 4 4,5 30°
Silk 1 1 2 2 30°
Wool 1 1 2 2 40°
Hand Wash 1 1 2 2 30°
Table of programmes

19
Please read these notes:
*
Maximum load capacity of dry clothes,
according to the model used (see control
panel).
1)
When a programme is selected,
on the display is shown the
display shows the recommended
wash temperature that can be
reduced (where allowed) by the
relevant button.
2)
For the programmes shown you
can adjust the duration and
intensity of the wash using the
STAIN LEVEL button.
3)
Selecting the RAPID program on
the knob, it will be possible to
select with the RAPID button, one
of the three rapid programs
available among 14’, 30’ and 44’.
** STANDARD COTTON PROGRAMMES
ACCORDING TO (EU) No 1015/2010 and
No 1061/2010.
COTTON PROGRAMME WITH A
TEMPERATURE OF 60°C.
COTTON PROGRAMME WITH A
TEMPERATURE OF 40°C.
These programmes are suitable to
clean normally soiled cotton laundry and
they are the most efficient programmes
in terms of combined energy and water
consumptions for washin
g cotton
laundry.
These programmes have been
developed to be compliant with the
temperature on the wash label on the
garments and the actual water
temperature may slightly differ from the
declared temperature of the cycle.

20
EN
To clean different types of fabrics and
various levels of dirt, the washing machine
has specific programs to meet every need
of washing (see table of programmes).
Whites
An intensive wash.
The final spin at
maximum speed gives more efficient
removal.
Cotton + Prewash
This programme has been designed to
remove the stronger stains from cotton
white clothes. The prewash guarantees the
tough dirt removal. Add into compartment
"1"
a quantity of detergent equal to 20% of
that used for main wash.
Cottons
This program is suitable to clean normally soiled
cotton laundry and it is the most efficient program
in terms of combined energy and water
consumptionsforwashingcottonlaundry.
Eco 20°
This innovative programme, allows you to wash
different fabrics
and colours together, such as
cottons, synthetics and mixed fabrics at only
20°C and provides an excellent cleaning
performance. Consumption on this program is
about 40% of a conventional 40°C. cottons
wash.
Mixed
The washing and rinsing optimise the s
peed
and rhythm of the drum action and water
levels. The gentle spin, ensures a reduced
formation of creases in the fabric.
Delicates
This program has reduced periods of drum
rotation during the cycle and is particularly
suitable or washing delicate fabrics
. The
wash cycle and rinses are carried out with a
high level of water to ensure the best
performance.
Rinse
This program performs 3 rinses with an
intermediate spin (which can be reduced or
excluded by using the appropriate button). It
is used for
rinsing any type of fabric, for
example after a wash carried out by hand.
Spin
The programme carries out a maximum
spin. It is possible to delete or reduce the
spin with the SPIN SPEED button.
Drain
This programme drains out the water.
Rapid (14/30/44 Min.)
Washing cycle suggested for low loads and
slightly dirty. With this program it is
recommended to reduce the quantity of
detergent normally used, in order to avoid
unnecessary waste. Selecting the RAPID
program and acting on the button you can
choose one of three programs available.
Dark Colours
Program designed to mix all dark garments and to
avoid the lossof colour and the formation of creases.
We recommendtheuseofliquid detergent.
Shirts
The washing cycle is optimized to reduce the
creatio
n of creases, keeping an excellent washing
performance. It is also possible to further reduce
the spin speed, toensure an easier ironing.
Silk
Dedicated program for silk fabrics that can
be wash with a washing machine washable.
The rotations of the drum
are delicate, the
temperature does not exceed 30°C and the
program ends with a gentle spin.
Wool
This program performs a wash cycle
dedicated to the wool fabrics that can be
washed in a washing machine, or the
articles to be washed by hand.
Hand Wash
Pr
ogram for hand wash only clothes, the
program ends with 3 rinses and a slowspin.
Programmes selection
