montpellier MWM71400W User manual

Please read these instructions carefully before attempting to install or use this appliance.
We recommend that you keep these instructions in a safe place for future reference.
Installation and Operating Instructions
THE PERFECT BALANCE OF FUNCTION AND STYLE
LAUNDRY - DISHWASHING - COOKING - COOLING
Freestanding Washing Machine
MWM71400W

Thank you for choosing this Montpellier appliance.
Our appliances have been designed to provide you with the best combination of style, reliability and performance to
give you years of trouble-free use.
You may be familiar with a similar product, but please take time to read these instructions carefully before installing
or using your appliance to ensure you get the most from your purchase.
We recommend that you keep this manual in a safe place for future
reference.
Your appliance is covered by a comprehensive two year Parts & Labour
Guarantee. In the unlikely event that you experience a problem with your
appliance, you can rest assured that you are fully protected against the cost of
repairs for the first 24 months . Please note that any claim must be
accompanied by the model reference number, serial number and proof of
purchase.
To activate your guarantee, you will need your product serial number. This can
be found inside your appliance.
NB: Please make sure that you keep a copy of your original sales invoice as this
will be needed if any service call is required.
There are three ways to register your Guarantee:
• Online: Visit the Support page on our website and complete the online
Product Registration form. www.montpellier-appliances.com
•By Post: Simply detach and fill in the form provided, attach a stamp and send
it in the post. Don't forget to include your e-mail address so that we can send
confirmation through to you.
By Phone: Contact our warranty registration department on 0808 1961388
Welcome
ACROSS ALL OUR MODELS
YEAR
GUARANTEE
PA R T S & L A B O U R
www.montpellier-appliances.com
•
Icon Type Meaning
WARNING Serious injury or death risk
RISK OF ELECTRIC SHOCK Dangerous voltage risk
FIRE Warning; Risk of fire / flammable materials
CAUTION Injury or property damage risk
IMPORTANT / NOTE Operating the system correctly
Thank you for choosing this product.
This User Manual contains important safety information and instructions on the operation and
maintenance of your appliance.
Please take the time to read this User Manual before using your appliance and keep this book for
future reference.
The design and specifications are subject to change without prior notice for product improvement.

CONTENTS
1.SAFETY INSTRUCTIONS ................................................................................................1
1.1 General Safety Warnings ...............................................................................................2
1.2 During Use ....................................................................................................................6
1.3 Packaging and Environment...........................................................................................7
1.4 Savings Information........................................................................................................7
2.TECHNICAL SPECIFICATIONS.......................................................................................8
2.1 General Appearance.......................................................................................................8
2.2 Technical Specifications .................................................................................................8
3.INSTALLATION.................................................................................................................9
3.1 Removing the Transit Bolts.............................................................................................9
3.2 Adjusting the Feet / Adjusting Adjustable Stays..............................................................9
3.3 Electrical Connection....................................................................................................10
3.4 Water Inlet Hose Connection........................................................................................10
3.5 Water Discharge Connection........................................................................ ................11
4.CONTROL PANEL OVERVIEW.......................................................................................11
4.1 Detergent Drawer ......................................................................................... ................12
4.2 Sections ...................................................................................................................12
4.3 Program Dial.................................................................................................................13
4.4 Electronic Display.........................................................................................................13
5.USING YOUR WASHING MACHINE..............................................................................14
5.1 Preparing Your Laundry................................................................................................14
5.2 Putting Laundry in the Machine....................................................................................14
5.3 Adding Detergent to the Machine .................................................................................15
5.4 Operating Your Machine ...............................................................................................15
5.5 Selecting a Programme................................................................................................15
5.6 Half-Load Detection System.........................................................................................16
5.7 Additional Functions ....................................................................................................16
5.8 Child Lock ...................................................................................................................17
5.9 Cancelling the Programme...........................................................................................17
5.10 Programme End .........................................................................................................17
6.PROGRAMME TABLE....................................................................................................18
6.1 Important Information....................................................................................................20
7. CLEANING AND MAINTENANCE .................................................................................21
7.1 Warning ...................................................................................................................21
7.2 Water Inlet Filters .........................................................................................................21
7.3 Pump Filter ...................................................................................................................22
7.4 Detergent Drawer .........................................................................................................22
8.FLUSH STOPPER / BODY / DRUM ...............................................................................23
9.TROUBLESHOOTING....................................................................................................24
10.AUTOMATIC FAULT WARNINGS AND WHAT TO DO ..............................................25
11. ENERGY LABEL/PIS ....................................................................................................26
12. HERE FOR YOU ...........................................................................................................28

EN - 1
1. SAFETY INSTRUCTIONS
Operating voltage / frequency (V/Hz) (220-240)
V~/50Hz
Total current (A) 10
Water pressure (Mpa) Maximum 1 Mpa /
Minimum 0. 1Mpa
Total power (W) 2100
Maximum washing capacity
(dry laundry) (kg) 7.0
•Do not install your machine on a carpet or any surface
that would prevent the ventilation of its base.
•The appliance is not intended for use by people
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
•Children of less than 3 years should be kept away unless
continuously supervised.
•Call the nearest authorized service centre if you find any
damage to the power supply cable.
•Use only the new water inlet hose coming with your
machine when making water inlet connections to your
machine. Never use old, used or damaged water inlet
hoses.
•Children should not play with the appliance.
•Cleaning and user maintenance should not be made by
children without supervision.

EN - 2
Read this user manual carefully.
Your machine is for domestic use only.
Using it for commercial purposes will cause
your warranty to be cancelled.
1.1 General Safety Warnings
•Thenecessaryambienttemperatureforoperationof
yourWashingMachineis15-25°C.
•Wherethetemperatureisbelow0°C,hosesmay splitor
theelectroniccardmaynotoperatecorrectly.
•Pleaseensurethatgarmentsloadedintoyour Washing
Machinearefreefromforeignobjectssuch asnails,
needles,lightersandcoins.
•It is recommended that for your first wash,
you select the 90˚ Cotton programme without laundry
and half fill compartment II of the detergent drawer with
a suitable detergent.
•Residuemaybuildupondetergentandsofteners
exposedtoairforalongperiodoftime.Onlyput
softenerordetergentinthedraweratthebeginning of
each wash.
•UnplugyourWashingMachineandswitchoffthe water
supplyiftheWashingMachineisleftunused foralong
time.Wealsorecommendthatyouleave thedooropen
topreventbuildupofhumidityinside theWashing
Machine.
•Some water may be left in your Washing Machine as a
result of quality checks during production. This will not
affect the operation of your Washing Machine.

EN - 3
• Thepackagingofthemachinecouldbehazardous
tochildren.Donotallowchildrentoplaywiththe
packagingorsmallpartsfromtheWashing
Machine.
• Keepthepackagingmaterialsinaplacewhere
childrencannotreachthem,ordisposeofthem
appropriately.
• Usepre-washprogramsonlyforverydirtylaundry.
Neveropenthedetergentdrawerwhilethemachine
is running.
•In the event of a breakdown, unplug the machine
from the mains supply and turn the water supply off.
Do not attempt to carry out any repairs. Always
contact an authorised service agent.
•Do not exceed the maximum load for the washing
programme you have chosen.
Never force the door open when your Washing
Machine is running.
•Washing laundry containing flour may damage your
machine.
•Please follow the manufacturers’ instructions
regarding the use of fabric conditioner or any similar
products that you intend to use in your Washing
Machine.
•Make sure that the door of your Washing Machine is
not restricted and can be opened fully.
•Install your machine in a location that can be fully
ventilated and preferably has constant air
circulation.

EN - 4
Read these warnings. Follow the advice given
to protect yourself and others from risks and fatal
injuries.
RISK OF BURNS
Do not touch the drain hose or any discharged water
while your Washing Machine is running. The high
temperatures involved pose a burn risk.
RISK OF DEATH FROM ELECTRICAL
CURRENT
•DonotconnectyourWashingMachinetothemains
electricitysupplyusinganextensionlead.
•Donotinsertadamagedplugintoasocket.
•Never remove the plug from the socket by
pullingthecord.Alwaysholdtheplug.
•Nevertouchthepowercord/plugwithwet
handsasthiscouldcauseashortcircuitor electric
shock.
•DonottouchyourWashingMachineifyour
hands or feet are wet.
•Adamagedpowercord/plugcancausefireor
giveyouanelectricshock.Whendamagedit mustbe
replaced,thisshouldonlybedoneby qualified
personnel.
Risk of flooding(when placing the drain hose in a sink)
•Checkthespeedofwaterflowbeforeplacingthe drain
hoseinasink.
•Take necessary measures to prevent the hose from
slipping.
•Waterflowmaydislodgethehoseifitisnotproperly
secured. Make sure the plug in your sink does not block
the plug hole.

EN - 5
Danger of Fire
•Donotstoreinflammableliquidsnearyourmachine.
•Thesulphurcontentofpaintremoversmaycause
corrosion.Neverusepaintremovingmaterialsin your
machine.
•Neveruseproductsthatcontainsolventsinyour
machine.
•Pleaseensurethatgarmentsloadedintoyour Washing
Machinearefreefromforeignobjectssuch asnails,
needles,lightersandcoins.
Risk of falling and injury
•DonotclimbonyourWashingMachine.
•Makesurehosesandcablesdonotcauseatrip
hazard.
•DonotturnyourWashingMachineupsidedownor on
itsside.
•DonotliftyourWashingMachineusingthedooror
detergent drawer.
The machine must be carried by at least 2
people.
Child safety
• Donotleavechildrenunattendednearthemachine.
Childrenmightlockthemselvesinthemachine
resultinginriskofdeath.
• Donotallowchildrentotouchtheglassdoorduring
operation.Thesurfacebecomesextremelyhotand
maycausedamagetoskin.
• Keeppackagingmaterialawayfromchildren.
• Poisoningandirritationmayoccurifdetergent and
cleaning materials are consumed or come into contact
with the skin and eyes. Keep cleaning materials out of
the reach of children.

EN - 6
1.2 During Use
• Keeppetsawayfromyourmachine.
• Pleasecheckthepackagingofyourmachinebefore
installationandtheoutersurfaceofthemachine once
thepackaginghasbeenremoved.Donot operatethe
machineifitappearsdamagedorifthe packaginghas
beenopened.
•Yourmachinemustonlybeinstalledbyan authorised
serviceagent.Installationbyanyone otherthanan
authorisedagentmaycauseyour warrantytobevoid.
•This appliance can be used by children aged
8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be done by children without supervision.
• Onlyuseyourmachineforlaundrythatislabelledas
suitableformachine washingbythemanufacturer.
•Before operating the washing machine, remove the 4
transit bolts and rubber spacers from
the rear of the machine. If the bolts are not removed
they may cause heavy vibration, noise and malfunction
of the machine and cause the guarantee to be void.
•Your warranty does not cover damage caused by
externalfactorssuchasfire,floodingandother sources
of damage.
•Please do not throw away this user manual; keep it for
future reference and pass it onto the next owner.
NOTE: Specificationsforthemachinemayvary
depending on the product purchased.

EN - 7
1.3 Packaging and Environment
Removal of packaging materials
Packaging materials protect your machine from any
damage that might occur during transportation. The
packaging materials are environmentally friendly as
they are recyclable. Use of recycled material reduces
raw material consumption and decreases waste
production.
1.4 Savings Information
Some important information to get the most
efficient use out of your machine:
•Donotexceedthemaximumloadforthewashing
programmeyouhavechosen.Thiswillallowyour
machinetoruninenergysavingmode.
•Donotusethepre-washfeatureforlightlysoiled
laundry.Thiswillhelpyousaveontheamountof
electricityandwaterconsumed.
CE Declaration of conformity
WedeclarethatourproductsmeettheapplicableEuropeanDirectives,Decisionsand
Regulationsandtherequirementslistedinthestandardsreferenced.
Disposal of your old machine
Thesymbolontheproductoronitspackagingindicatesthatthisproduct
maynotbetreatedashouseholdwaste.Insteaditshallbehandedoverto
theapplicablecollectionpointfortherecyclingofelectricalandelectronic
equipment.Byensuringthisproductisdisposedofcorrectly,youwillhelp
preventpotentialnegativeconsequencesfortheenvironmentandhuman
health,whichcouldotherwisebecausedbyinappropriatewastehandlingof
thisproduct.Formoredetailedinformationaboutrecyclingofthisproduct,
pleasecontactyourlocalcityoffice,yourhouseholdwastedisposalserviceortheshop
where you purchased the product.
