Monzana DBKH002 User manual

www.DEUBAXXL.co.uk
BDA-106479-002 / 02.06.2023
EN
Convector heater
Artikel-Nr: 106479
Modell-Nr: DBKH002
This product is only suitable for well-insulated
rooms or for occasional use.

2
www.DEUBAXXL.co.uk
Dear Customer,
Thank you for choosing our product. You have made the right choice by buying one of our brand
products. Our products are regularly inspected to ensure that they meet the desired high quality
standards and, of course, always comply with the stringent requirements of the European Union.
READ THE USER INSTRUCTIONS. IMPORTANT
INFORMATION. KEEP IN A SAFE PLACE FOR FUTURE USE!
Please read the instructions thoroughly and in their entirety before using the product for the first
time. Keep these instructions for future reference. Should you pass the product on in future, ensure
that you also include these instructions.
TABLE OF CONTENTS
1.0 SYMBOLS.............................................................................................................................................................................................. 2
2.0 SAFETY INSTRUCTIONS................................................................................................................................................................... 3
2.1 GENERAL SAFETY INSTRUCTIONS FOR USE ...................................................................................................................3
2.2 GENERAL SAFETY INSTRUCTIONS –ELECTRICAL SYSTEM ........................................................................................4
2.3 NOTES ABOUT THE LOCATION AND SPACING.............................................................................................................4
3.0 PROPER USE........................................................................................................................................................................................ 4
4.0 UNPACKING INSTRUCTIONS ........................................................................................................................................................ 5
5.0 USING THE APPLIANCE FOR THE FIRST TIME ......................................................................................................................... 5
6.0 OPERATION ......................................................................................................................................................................................... 5
7.0 MAINTENANCE AND CARE INSTRUCTIONS ............................................................................................................................ 6
8.0 TROUBLESHOOTING ........................................................................................................................................................................ 7
9.0 TECHNICAL DATA.............................................................................................................................................................................. 7
10.0 DISPOSAL........................................................................................................................................................................................... 7
11.0 DATA SHEET FOR CONVECTOR HEATER ................................................................................................................................ 8
1.0 SYMBOLS
CAUTION! POTENTIAL DANGER!
Observe the safety information and setup instructions to avoid the risk of injury or damage to the
product.
RISK OF SUFFOCATION!
Keep small parts and packaging material out of the reach of children!
PRODUCT MODIFICATION
Never make modifications to the product! Modifications will invalidate the warranty and the
product may become unsafe or, in the worst case scenario, dangerous.
WARNING –ELECTRICAL VOLTAGE!
Danger to life and health of persons due to electrical voltage.
WARNING
The appliance is not a toy and should not be handled by children.
WARNING –FIRE HAZARD!
Fire hazard and risk of burns.
INSTRUCTIONS
EN

3
www.DEUBAXXL.co.uk
WARNING –HOT SURFACES!
Risk of a hot surface. Risk of burns.
SAFETY INFORMATION ATTACHED TO THE APPLIANCE
DO NOT COVER!
Do not remove any safety signs or notices from the appliance. Keep the stickers and labels in a
legible condition.
2.0 SAFETY INSTRUCTIONS
2.1 GENERAL SAFETY INSTRUCTIONS FOR USE
•The product requires a power supply of 220-240V~50-60 Hz. Please check that the appropriate
power supply is available before use.
•To avoid danger in the event of damage to the appliance, please contact our Customer Service
team or send the appliance to one of our authorised service centres for repair; do not attempt
to replace parts without our authorisation.
•Do not leave the appliance unattended.
•Do not touch any hot surfaces. Some parts of this product can become very hot and cause
burns. Take particular caution when children and at-risk persons are present.
•Do not move the appliance when it is in operation. Wait until the device has cooled down
completely.
•WARNING: The heater must not be covered so that it does not overheat. It is not suitable for
drying laundry.
•Do not remove any warning labels or tags from the product.
•Do not insert objects through the protective grille.
•Do not use the heater if it has previously been dropped.
•Do not use the heater if it exhibits visible signs of damage.
•Do not use the heater if the feet are not correctly attached.
•Keep the power cable away from the heater’s hot body.
•Make sure that no one can trip over the mains cable.
•Do not use the heater in connection with a separate control timer, a separate remote control
system or other devices that automatically switch the device on. In such a case, there is a risk
of fire if the device is covered or has been incorrectly set up.
•This device may be used by children over the age of 8 and by individuals with reduced physical,
sensory or mental capabilities or a lack of experience and knowledge, provided that they are
supervised or have received instructions on the safe use of the appliance and understand the
risks involved.
•Children may not play with the appliance. Do not allow children to clean and maintain the
device without supervision.
•Keep children under 3 years of age away from the device if they are not constantly supervised.
•WARNING: This heater is not equipped with a device to control the room temperature. The
heater may not be used in small rooms occupied by people who cannot leave the room on
their own, unless constant monitoring is guaranteed.

4
www.DEUBAXXL.co.uk
•Children aged 3 up to 8 may only switch the device on / off if it was placed in the intended
normal operational position, and they were safely supervised or instructed on how to use the
device and understand the dangers.
•Children between 3 and 8 years old may not plug in, control and clean or maintain the device.
2.2 GENERAL SAFETY INSTRUCTIONS –ELECTRICAL SYSTEM
•CAUTION! Read all safety information and instructions. Failure to follow the safety information
and instructions may cause electric shock, fire and / or serious injury.
•Ensure that water cannot get inside the appliance. Never immerse the appliance in water or
other liquids. Never expose it to rain.
•Do not use the appliance if the mains plug, mains cable or any other part of the appliance is
defective or damaged.
•Do not remove the mains plug from the socket by pulling on the mains cable.
•Never insert or remove the mains plug with wet hands.
•Do not use any electrical appliances in potentially explosive environments, e.g. in the presence
of flammable liquids, gases or dust. Electrical appliances produce sparks that can ignite dust or
exhaust fumes.
•Check the fuse protection of the mains. The fuse must be 16A.
•Do not use the heater together with other devices on a power strip.
•The plugs of electrical appliances must be compatible with the socket. Never change the plug.
Do not use any adaptor plugs with earthed electrical appliances. Original plugs and matching
sockets reduce the risk of electric shock.
•Use the cable only for its intended purpose. Never use the cable to carry, pull or unplug the
electrical appliance. Keep the cable away from heat, oil, sharp edges and moving parts.
Damaged or entangled cables increase the risk of electric shock.
2.3 NOTES ABOUT THE LOCATION AND SPACING
•Always ensure that the heater is placed on a firm level surface.
•Do not place the heater on a rug with a very high pile.
•Only use indoors.
•WARNING: Do not use this heater in the immediate vicinity of a bathtub, a shower or a
swimming pool.
•To reduce the risk of a fire, keep textiles, curtains or other flammable material at least 1 m away.
•Do not place the heater near flammable materials. Keep a minimum distance of 50 mm from
walls, furniture, etc.
•The heater must always be in the upright position
•WARNING: Do not place the heater right below a wall outlet.
3.0 PROPER USE
The heater is only designed for heating indoor air. The heater can be set up freely. A note about
the Renewable Energy Law: This product is suitable for well-insulated rooms or for occasional use.
The heater may not be used in damp rooms.
Use the product only for the purpose it is intended for. The manufacturer accepts no liability for
damage caused by improper use. Any modification to the product may negatively impact safety,
cause hazards and invalidate the warranty.
Only suitable for domestic use; not for commercial use.

5
www.DEUBAXXL.co.uk
4.0 UNPACKING INSTRUCTIONS
Open the box and remove the product.
After unpacking, please check the product for damage and to ensure it is complete. Subsequent
complaints cannot be accepted.
Ensure that the heating elements and other parts of the radiant heater do not have any residual
packaging or other contamination.
5.0 USING THE APPLIANCE FOR THE FIRST TIME
Prior to commissioning, the base must be mounted. Otherwise the heater may not be used.
Mounting the feet to the heater
Before using the heater, the feet must be attached (the feet
are stored separately in the box). These are secured to the
base using the 4 self-tapping screws supplied. Ensure that
these are correctly inserted into the end pieces on the bottom
of the side panel.
Note:
When the heater is switched on for the first time or if it is being
switched on after a long period of not being in use, it is normal
for the heater to omit a certain odour and fumes. These will
disappear when the heater has been in operation for a short
time.
It is common for the heater to make noises when used for the first time.
6.0 OPERATION
Model DBHK002 - Convector heater with thermostat and timer
Control panel
1. Rocker switch
heating level 1
2. Rocker switch
heating level 2
3. Thermostat
4. Slide switch
5. Arrow (time)
6. Segments
•Select a suitable location. Observe the safety information listed above.
•Plug the heater mains plug into a suitable socket.
•Turn the thermostat knob clockwise to the maximum setting position.
•Switch on the heating elements using the rocker switched attached to the side panel. The switch
will illuminate once the heating elements are switched on. Both switches must be switched on
for maximum heating output.

6
www.DEUBAXXL.co.uk
•Once the desired room temperature is reached, the thermostat knob must be slowly turned
counter-clockwise until a “click” noise indicates the thermostat has been switched off. The
switch illumination turns off. The thermostat will now maintain the room temperature by turning
on and off automatically.
•This model is also equipped with a 24-hour timer. This timer has a total of 48 segments for the
entire day, which corresponds to 30 minutes per segment. The timer can be used to set the
time and duration within a 24-hour cycle during which the heater is to be switched on.
Timer operation
In the middle area, the timer has a slide switch with 3 positions. In the middle position (marked by
a clock symbol), the timer will switch the heating elements on or off according to the preset timer
segments (how to set the timer is described below). The position marked with an “I” bypasses the
timer. The timer will continue to run, but the heater is continuously powered. This means that the
heating elements are run for the entire time, if desired. In the “O” position, the timer continues to
run, but the heater is not powered.
Setting the timer
Make sure that the timer’s slide switch is in the middle position with the clock symbol.
To set the current time, turn the outer ring clockwise until the arrow matches the current time. If,
for example, the current time is 8:00 p.m., the outer ring should be turned until the number 20
matches the arrow.
Set the heater’s operating time by pulling the corresponding segments on the outer ring. After
setting the heater, the heater will operate every day at the set time with the programmed setting.
Note: The heater’s mains plug must be connected to the grid the entire time and the rocker
switches must be switched on. Moreover, the thermostat must be set accordingly to ensure that
the device switches on.
If you want the heater to work the entire time, the slide switch must be in the “I” position. If it is
necessary to change to the timer mode later, the slide switch must be pushed into the middle
position with the clock symbol.
Note: It must be noted that the heater can switch on in unobserved situations while in timer mode.
Overheating protection
1. An additional built-in safety thermostat protects the heater from overheating and switches it
off automatically. The service lamp then goes off. After a short cool-down phase (about 15
minute), the heater is ready for use again.
2. If this should repeat, first check whether the thermostat switch is correctly set or whether
objects are preventing heating operation.
7.0 MAINTENANCE AND CARE INSTRUCTIONS
Always switch off the appliance and disconnect the mains plug before carrying out maintenance
or inspection work.
Check all the parts for signs of wear. Do not continue to use the product if you find any defects.
Only have parts replaced with original spare parts by a specialist in accordance with the
manufacturer’s specifications. A lack of care and maintenance can damage the appliance.
Dangerous situations can arise. To ensure electrical safety, the appliance must not be treated with
or even immersed in liquids. Regular maintenance helps to ensure the safety of the product and
increases its service life.
WARNING: Allow the heater to cool down completely before cleaning or storage!

7
www.DEUBAXXL.co.uk
Cleaning
It is bets to clean the ventilation grilles at the bottom and bottom using a soft brush. If necessary,
wipe the housing with a soft dry cloth. If heavily soiled, please use a slightly dampened cloth. Do
not use cleaners or detergents containing solvents; substances such as bleach can damage the
product.
Storage
If the heater is not used for a longer period of time, it should be stored protected from dust and
in a clean dry location.
8.0 TROUBLESHOOTING
Problem
Possible cause
Solution
The device is not
working
No power supply
Check the fuse, power cable and mains
plug
Device defective
Contact Customer Service
Fuse trips when
switching on or
after a short
operation duration
The load on the circuit is too
high.
Do not operate any larger consumers
(kettle, coffee machines, etc.) on the
same circuit simultaneously
The device switches
off automatically
The overheating protection
has tripped
After a short cool-down phase (about 15
minute), the heater is ready for use
again.
9.0 TECHNICAL DATA
Item number
106479
Model
DBKH002
Timer
Yes, 24 hours divided into 48 30-minute segments
Rated voltage
220-240V ~50-60Hz
Power consumption
1800-2000W
Protection class
I
Heating levels
3 levels, 750W, 1250W, 2000W
10.0 DISPOSAL
At the end of your item’s long service life, please dispose of the valuable raw materials properly
so that proper recycling can take place. If you are not sure how best to proceed, the local waste
disposal companies or recycling centres will be happy to help.
CORRECT DISPOSAL OF THIS PRODUCT
Never dispose of electronic appliances as household waste! Take defective or discarded appliances
to recycling centres.
Within the EU, this symbol indicates that this product must not be disposed of as household waste.
Old appliances contain valuable recyclable materials that should be recycled so that there is no
harm to the environment or human health as a result of uncontrolled waste disposal. Please,
therefore, dispose of old appliances through suitable collection systems or return the appliance
for disposal at the place where you bought it. They will then send the appliance for recycling.

8
www.DEUBAXXL.co.uk
11.0 DATA SHEET FOR CONVECTOR HEATER
Model identification(s): DBKH002 TIMER / Item no.: 106479
Item
Symbol
Value
Day
Item
Day
Thermal output
Type of heat supply, only for electric storage heating
(please choose)
Nominal heat output
Pnom
1.8 - 2.0
kW
Manual heat load control, with integrated
thermostat
[No]
Minimum heat output
(guide value)
Pmin
0.75
kW
Manual heat load control with temperature
feedback for indoor and/or outdoor use
[No]
Maximum continuous
thermal output
Pmax,c
2.0
kW
Electric heat load control with temperature
feedback for indoor and/or outdoor use
[No]
Electric auxiliary consumption
Fan-supported heat output
[No]
With normal heat
output
elmax
N/A.
kW
Type of heat output / room temperature control (please
select)
At minimum heat
output
elmin
N/A.
kW
Single-stage heat output and no room
temperature control
[No]
In standby mode
elSB
0
kW
Two- or single-stage heat output, no room
temperature control
[No]
With room temperature control via mechanical
thermostat
[Yes]
With electronic room temperature control
[No]
Electronic room temperature control plus day
timer
[No]
Electronic room temperature control plus week
timer
[No]
Other control options (multiple selections possible)
Room temperature control, with presence
detection
[No]
Room temperature control, with open window
detection
[No]
With remote control option
[No]
With adaptive control of heating start
[No]
With operating time limitation
[Yes]
With black ball sensor
[No]
Contact data
Deuba GmbH & Co. KG / Zum Wiesenhof 84 –66663 Merzig, Germany

9
www.DEUBAXXL.co.uk

10
www.DEUBAXXL.co.uk

11
www.DEUBAXXL.co.uk

www.deubaservice.de
SERVICEPORTAL
EN
For any kind of service, complaints and technical support, you can
confidently turn to our trained staff.
Hergestellt für:
Made for:
Deuba GmbH & Co. KG
Zum Wiesenhof 84
66663 Merzig, Germany
Deuba LTD
Wyatt Way, Thetford
Norfolk, IP24 1HB
Copyright by
Alle Rechte vorbehalten. Ohne schriftliche Zustimmung der Deuba
GmbH & Co. KG darf dieses Handbuch, auch nicht auszugsweise, in
irgendeiner Form reproduziert werden oder unter Verwendung
elektronischer, mechanischer oder chemischer Verfahren
vervielfältigt oder verarbeitet werden. Änderungen im Sinne des
technischen Fortschritts können jederzeit ohne Ankündigungen
vorgenommen werden. Das Handbuch wird regelmäßig korrigiert.
Für technische und drucktechnische Fehler und ihre Folgen
übernehmen wir keine Haftung.
Stand 2022/08 Rev5
