moon COMET-X PRO Instruction Manual

Double click
DAY FLASH
(DOUBLE BLAST)
FL1
FL2
FL3
Mode3
Mode2
Mode1
Install
Release
click
Press
HOW TO MOUNT THE LIGHT
1. Choose the strap to fit in the bar.
2. Make sure the strap is clicked in place of the hook.
3. Hold the light on the handle bar/seat post.
4. Wrapping rubber strap around bar and stretching strap around hook to secure.
5. Slide the light forward onto bracket until it clicks into place.
6. Press down release lever to remove.
Pull
Install
RS-G RS-H
35-52 mm20-35 mm
20-26 mm
26-35 mm
26-35 mm
35-52 mm
7. Adjust the horizontal beam angle when mounted on the handle bar
loosen the screw knob and spin the light left to right for your preferred
angle, then tighten the screw knob to secure the light in place.
1. Slide tail light forward onto belt clip until it clicks into place.
2. Press down release lever to remove.
Install
Press
click
Release
Method 1 Method 2
1. Double click the power button to toggle between the steady and
flashing modes.(With mode memory, the light will resume previous
mode upon next usage.)
LIGHT OPERATION
2. Press and hold the power button about 1 second to switch off.
(With mode memory, the light will resume previous mode upon next
usage.)
Low battery status
* Steady blue
Auto safe mode
* Flashing blue
Indicators
Power button
Contents:
*COMET-X PRO
*RB-22 (Universal bracket)
*2 O-rings for mounting:
RS-G (fits 20-35mm diameters)
RS-H (fits 35-52mm diameters)
*BK-21 (Belt clip)
*RB-21 (Saddle rail bracket)
*USB-WP (Water resistant USB cable)
Optional accessories:
*RB-19 (Rear rack mount bracket)
*RB-23 (Helmet bracket)
*USB-RM-1200 (USB remote control 1200mmL)
*1 pc (30 chips) COB high brightness red LED
*CNC Aluminium heat sink casing
*Auto safe mode
*Mode memory function
*Rechargeable lithium polymer battery (3.7V 500 mAh)
*7 modes: Mode1 / Mode2 / Mode3 /
FL1 / FL 2 / FL 3 / DAY FLASH (DOUBLE BLAST)
*Quick release universal bracket RB-22
(fits all round bars and AERO style bars)
*Low battery, charging and fully charged indicator
*Automatic fully charged cut-off system
*Side visibility
*Water resistant (IPX 4)
HOW TO MOUNT THE LIGHT
click
USER GUIDELINE
Thank you for choosing MOON light!
*For using this product safely and conveniently and keeping it
well-preserved, please read this manual carefully before using.
Please save this manual for future reference.
*Due to the improvement of the product, the product you bought may
not be exactly in accordance with the introduction of this manual. We
apologize for that.
SPECIFICATION
CONTENTS INCLUDED
INSTALL
INSTALL
INSTALL
ADJUST
ADJUST
ADJUST
ADJUST
RELEASE
clockwise
anticlockwise
1. Loosen the screws in the saddle bracket with the Allen key.
2. Clamp the bracket onto the saddle rail.
3. Align the screw holes, using the Allen key to tighten the bracket.
4. Slide light forward onto bracket until it clicks into place.
5. Press down release lever to remove.
6. Twist the light body to adjust the vertical angle.
1.
2.
3.
4.
Method 1
Method 2
®
Wrapping
Release
Adjust

Run Time Recharge
time
(Auto safe)
around
1 hr
Mode Lumens
15 5:30
2:10
1:30
15:20
7:30
19:00
25
40
80
20
* The time of recharging depends on which method (wall charger or computer) is being used.
Mode3
Mode2
Mode1
DAY FLASH
(DOUBLE BLAST)
FL1
FL2
FL3
40
9:4040
Weight: 28 g
Double click 2 hrs
Charging indicator
* Flashing Blue - charging
* Steady Blue - charged
HOW TO CHARGE BATTERY
Attention: If you do not use the battery for a long time, be sure to fully
recharge every 3 months. Please store the battery in a cool and dry
place. Recharge battery after each long usage.
Indicators
Power button
2. When the signal “ ” flashes, it means that is in very low power
stage, then the safe mode will be on and cannot be changing mode
accordingly. The light may have an hour left for usage. (Depending on
which mode the light was on before entering safe mode, it would
affect the run time of safe mode before battery is completely drained.)
1. When the signal “ ” turns on, it means the battery is low. You
should charge your light.
AUTO SAFE MODE
Steady-Blue
Flashing-Blue
!
*Do not charge over 5V the battery will result in damage.
*Keep away from flammable objects while charging as this may lead
to fire or battery explosion.
*Do not smoke while charging as the battery may release hydrogen gas.
Always charge your battery in a well-ventilated space.
*Never connect or disconnect the plug or cord with wet hands whilst
charging. Do not connect or disconnect the plug or cord when they are
wet, it may lead to electric shock.
CAUTION
1. Problem: The light is not on
Solution: Check if the battery still has power
Check if the power button is pressed hard
SIMPLE PROBLEMS ANALYSIS AND SOLUTION
1. Find the charging place at the back of the light.
2. Lift the rubber cover and you’ll see the charging port.
3. Plug the USB cable to your computer USB port.
4. Plug the charger cable to the light charger port.
5. The charging indicator shows slow flashing blue when the
light is charging, after fully charged it changes to steady.
6. It is normal that the battery may get high temperatures during
charging (up to 104°F/40°C), as the chemical in battery is in
reaction. If the battery is not drained completely before charging, it
may also get warm.
7. Several factors can influence the battery’s durability: type of cell
strain, the maintenance routine, the temperature and number of
charges etc.
Normally speaking, the higher the battery capacity, the longer the
burn time.
8. The battery capacity may become ineffective about 80% of its
value after 300-500 charge/discharge cycles. The battery may have
3 years life span under good care.
9. The battery voltage and capacity decrease apparently at low
temperatures, especially near or below ice point. The capacity
decreases 5%-10% at freezing (burn time decreases 50%). At
-20°C,the capacity decreases 30% (burn time decreases 70%). The
battery performance will return normal when the temperate gets up
to 70°F/20°C.
The battery will lose around 1% of its capacity per day when you
store the battery at normal room temperature. Battery temperate
should never exceed 104°F/40°C, it will lose about 5% of its
capacity per day.
10. If you do not use the battery for a long time, be sure to fully
recharge every 3 months. Please store the battery in a cool and dry
place.
HOW TO CLEAN AND CARE THE LIGHT
!
MOON warrants to the original purchaser of this product that the
product is free from defects in material and workmanship for a period of
one year. This warranty does not apply to damage due to heat, physical
damage resulting from abuse, neglect, improper repair, improper fit, or
alterations of the fixture. This warranty is in lieu of all other agreements
and warranties, general or specific, express or implied and no
representative or person is authorized to assume liability on behalf of
MOON in connection with the sale and use of this product.
MOON reserves the right to request the return of any product submitted
for warranty consideration. All customers should contact the local dealer
or regional distributor for warranty service.
To make a claim, first call local dealer or regional distributor. Some
issues may be resolved upon the initial call. If return of the product is
necessary, please refer to the following instructions:
*We recommend that items be sent by a traceable method (such as
FedEx or UPS). MOON is not responsible for lost or misdirected
packages.
*Please include your full contact information (name, address, phone
number, and email [if applicable]), and a description of the issue.
*Address items to: local dealer or regional distributor
What is not covered: MOON Lights are covered by a ONE YEAR
LIMITED WARRANTY from the date of purchase. This covers the lights
and cables only. It does not cover the battery or battery internals.
Batteries are covered by 120 days warranty.
For more information please contact us at [email protected].
http://www.moon-sport.com
*The specifications and design are subject to change without notice.
COMET-X PRO RUN TIME
*Make sure to clean the dust and dirt on the light with soft damp cloth
after every ride.
*Water resistant is for rain water only. Do not submerge the battery or
the whole light into water when cleaning.
CAUTION: When riding at night, please follow the guidelines below:
*Carrying a flash light is recommended.
*Use caution when handing, the light may get hot.
*Unplug the light if not in use.
*Unplug connector by the plug, never by the cable.
*Provide sufficient airflow to the light for cooling during use.
*Do not control any part of the system under water.
*Do not look directly at light.
*Do not leave the light on and unattended.
*Keep the light away from fire and combustible materials.
*Do not store head unit when hot or straightway after use.
*Unplug the light, charger and cable once the battery is fully charged.
*This light is for bicycle use only.
WA-MOON-COMET-X PRO
Emax (LUX) Distance (M)
COMET-X PRO
1M
2M
10M
15.5
4.8
0.15
1.6 M
3.2M
16 M
40 LUMENS
77°
SPOT ANGLE
270°
TOTAL ANGLE
