moon Mask Instruction Manual

*5 high performance Nichia LEDs
*Quick release rubber strap mount (fits 22-31.8mm handlebars)
*Built-in lithium polymer battery
*USB rechargeable
*4 lighting modes
*Low battery, charging and fully charged indicator
*Automatic fully charged cut-off system
*Highly side visibility
*Cover can be exchanged
*Water resistant
FEATURES
WARNING : Charge the battery with the supplied USB cable only.
Using any other USB cable to charge the battery will result in
damage.Unplug the headlight once it is fully charged.
BATTERY CHARGING – CONTINUED
1.Lift the rubber cover at the back of the light to reveal the battery
charging port.
2.Connect the USB charging cable to your computer's USB
port.(Computer USB charging only)
3.Plug the charger cable to the light charger port.
4.The charging indicator shows slow flashing blue when the light is
charging, after fully charged it changes to steady.
SYSTEM CONTENTS
1.Press the power button to scroll through the light modes.
2. Press and hold the on / off button around 1 second to turn off.
Off – STANDARD
- HIGH - STROBE
- FLASHING
The low battery indicator is located at the back of the light. The
charging indicator shows slow flashing blue when the light is
charging,after fully charged, it changes to steady.
1.Install the light onto seat post/handlebar by wrapping rubber strap
around post/bar and stretching strap around hook to secure.
2.Twist the light body to adjust the horizontal angle.
RUN TIME
MOUNTING THE HEADLIGHT
HEADLIGHT OPERATION
BATTERY CHARGING
POWER BUTTON
To exchange cover use finger
click the cover off.
LOW BATTERY
INDICATOR
(RED LED)
RUBBER COVER
CHARGING PORT
CHARGING
INDICATOR
(BLUE LED)
CHARGING
INDICATOR
(BLUE LED)
CONTENTS:
* Mask
* Rubber strap bracket
* USB cable
5. It is normal that the battery may get high temperatures during
charging (up to 104°F/40°C), as the chemical in battery is in
reaction. If the battery is not drained completely before charging, it
may also get warm.
6. Several factors can influence the battery’s durability: type of cell
strain, the maintenance routine, the temperature and etc.
Normally speaking, the higher the battery capacity, the longer the
burn time.
7. The battery capacity may become ineffective about 80% of its
value after 300-500 charge/discharge cycles. The battery may have
3 years life span under good care.
8. The battery voltage and capacity decrease apparently at low
temperatures, especially near or below ice point. The capacity
decreases 5%-10% at freezing (burn time decreases 50%). At
-20°C,the capacity decreases 30% (burn time decreases 70%). The
battery performance will return normal when the temperate gets up
to 70°F/20°C.
The battery will lose around 1% of its capacity per day when you
store the battery at normal room temperature. Battery temperate
should never exceed 104°F/40°C, it will lose about 5% of its
capacity per day.
9. If you donot use the battery for a long time, be sure to make it a
fully recharge every 3 months before storing again. Please keep the
battery in cool and dry place when storing.
TROUBLESHOOTING
The headlight will not turn on.
*Make sure the power button was firmly pressed.
*Make sure the battery is fully charged.
Mode Lumen Runtime
Standard
High
35 Up to 6 hours
Up to 3 hours70
Strobe Up to 8.5 hours50
Flashing Up to 8.5 hours50
Weight
charge
time
36.8 g 2 hours
* Charge time dependent on wall charger or computer
USER GUIDELINE
®
CAUTION: Night riding is more dangerous than day riding.
Exercise caution when riding at night and follow the
guidelines listed below:
*Only use the provided Moon USB cable when charging.
*Unplug the USB cable when fully charged.
*Do not modify or substitute any parts with Non- MOON parts.
*Do not disassemble the headlight.
*Do not look directly at light.
*Do not operate or submerge any parts of the system under water.
*Do not charge over 5 V the battery will result in damaged.
*Do not operate the light when charging.
*Keep headlight away from fire and combustible materials.
*This light is for bicycle use only.
CAUTION
The Mask is designed to be used on bikes in some of the most
extreme outdoor conditions. Over time, dust and dirt may
hinder the connections on your battery and headlight. To
prevent this from happening, ensure that the headlight is
cleaned after every ride.
Wipe the headlight down with a damp cloth. Do not submerge
the headlight in water. Remove all dirt around or on the plugs
or jacks on the headlight.
The 5 high performance Nichia LEDs have extensive life so
bulb replacement is not required.
WARRANTY
!
MOON warrants to the original purchaser of this product that the
product is free from defects in material and workmanship for a
period of one year. This warranty does not apply to damage due to
heat, physical damage resulting from abuse, neglect, improper
repair, improper fit, or alterations of the fixture. This warranty is in
lieu of all other agreements and warranties, general or specific,
express or implied and no representative or person is authorized to
assume liability on behalf of MOON in connection with the sale and
use of this product.
MOON reserves the right to request the return of any product
submitted for warranty consideration. All customers should contact
the local dealer or regional distributor for warranty service.
To make a claim, first call local dealer or regional distributor. Some
issues may be resolved upon the initial call. If return of the product
is necessary, please refer to the following instructions:
*We recommend that items be sent by a traceable method (such
as FedEx or UPS). MOON is not responsible for lost or misdirected
packages.
*Please include your full contact information (name, address,
phone number, and email [if applicable]), and a description of the
issue.
*Address items to: local dealer or regional distributor
What is not covered: MOON Lights are covered by a ONE YEAR
LIMITED WARRANTY from the date of purchase. This covers the
lights and cables only. It does not cover the battery or battery
internals.
Batteries are covered by 120 days warranty.
For more information please contact us at [email protected].
Emax (LUX) Distance (M)
70 LUMENS
MASK Spot angle 15 ° Total Angle 48 °
1M
2M
10M
250
32 1.5 lux
2.8
0.27 M
0.54 M
Side light
2.7 M
8.75 M
®
WA-Moon-MASK EN

Besonderheiten
WARNUNG:
– STANDARD
-
-
.
(BL LED)
(BL LED)
*
*
*
*
*
*
*
*
*
*
5.
6.
Generell
7. Die Batteriekapazität könnte rund 80% ineffektiver werden nach
300 bis 500 Ladegängen. Die Batterie hat eine dreijährige
Lebensdauer unter guten Konditionen.
8.
9.
Modus Lumen Laufzeit
Standard
Fernlicht
35 Bis zu 6Stunden
Bis zu 3 Stunden
70
Blinklicht Bis zu 8.5Stunden
50
Blitzlicht Bis zu 8.5Stunden
50
Gewicht
Ladedauer*
36.8g 2Stunden
* Ladedauer hängt von Steckdose oder Computer ab
BEDIENUNGSANLEITUNG
System Komponenten
Inhalte:
* Maske
* Gummibandhalterung
* USB Kabel
™
:
*
*
*
*
*
*
*
*
*
Materialien
*
!
*
*
*
Emax (LUX) Entfernung (M)
70 LUMEN
Spot Ausleuchtung 15 °
Gesamtausleuchtung 48 °
1M
2M
10M
250
32 1.5 lux
2.8
0.27 M
0.54 M
Streiflicht
2.7 M
8.75 M
™
WA-Moon-MASK-DE
