Mooreco Nest Easel 781P User manual

Nest Easel
UPDATED AS OF: 06/02/2022
781P, 785P, 785E-DD
1 of 11
INSTRUCCIONES DE ENSEMBLAJE
NO LA TIRE
INSTRUCTIONS DE MONTAGE
NE PAS JETER
ASSEMBLY INSTRUCTIONS
DO NOT THROW AWAY!

Parts List
UPDATED AS OF: 06/02/2022 2 of 11
Hardware
P1 - Board
P2 - Lower Leg
P3 - Upper Leg
P4 - Middle Tray
P5 - Top Support
P6 - Book Rack Front
P7 - Book Rack Back
x1
x2
x2
x1
x1
x1
x1
A - M6 x 15mm Screw
B - M6 x 30mm Screw
C - M6 x 60mm Screw
D - M6 Interior Threaded Post
E - 2” Locking Casters
F - Flip Chart Hook
G - Plastic Reciever
H - #10 - 1” Wood Screws
I - #10 - 1/2” Wood Screws
J - Allen Wrench
K - Caster Wrench
x5
x5
x5
x5
x4
x4
x4
x4
x4
x2
x1

For full product warranty details, please visit:
Para obtener información sobre la garantía del producto, consulte este sitio (ingles):
Pour plus d’informations sur la garantie du produit, consultez ce site (anglais):
For questions on assembly or missing/damaged parts, please contact us using the
following information.
Para preguntas sobre el ensamblaje o piezas faltantes o dañadas, por favor
contáctenos usando la siguiente información.
Pour toute question sur le montage l-assamblage manquantes ou endommagées,
veuillez nous contacter en utilisant les l’information ci-dessous.
To register your product for warranty, please visit:
Para registrar la garantía del producto, vea este sitio (en ingles):
Pour enregistrer la garantie de votre produit, consultez ce site (en anglais):
Review full assembly instructions and
check that all parts are present before
beginning assembly. Heavy or large
furniture may require multiple persons in
order to properly assemble. If you have
questions regarding assembly, contact
the manufacturer before continuing.
Damage due to incorrect assembly may
not be covered by warranty. Do not use
product unless all screws are tight. Check
all screws for tightness at least every
six months. If parts are broken, missing,
damaged, or worn, stop use of the product
until repairs are made by your dealer using
factory authorized parts.
WARNINGS AND DISCLAIMERS
WARRANTY
CARE & MAINTENANCE
PRODUCT REGISTRATION
UPDATED AS OF: 06/02/2022 3 of 11
Phone:
1.800.749.2258
(Monday – Friday, 8AM – 5PM
Central Time)
http://moorecoinc.com/warranty
https://moorecoinc.com/register
Email:
[e-mail]

STEP 1
UPDATED AS OF: 06/02/2022 4 of 11
STEP 2
Attach Middle Tray (P4) to two (2) Lower Legs (P2) at desired height using two (2)
M6 x 60mm Socket Screws (C).
Attach each of the Upper Legs (P3) to the each of the Lower Legs (P2) using four (4)
M6 x 15mm Socket Screws (A).
C
P4
P2
P2
P3
A

Slide Top Support (P5) over Markerboard (P1) and secure to the two Upper Legs(P3)
using two (2) each M6 x 60mm Socket Screws (C).
STEP 3
UPDATED AS OF: 06/02/2022 5 of 11
Insert Markerboard (P1) into Middle Tray (P4). Make sure the four small holes on marker
board are on the top.
P4
P1
P5
C
STEP 4

STEP 5
UPDATED AS OF: 06/02/2022 6 of 11
P6
P7
B
E
Attach Book Rack Front Panel (P6) and Book Rack Back Panel (P7) to the two Lower Leg
Frames (P2) using four (4) M6 x 30mm Socket Screws (B) and four (4) M6 Interior Threaded
Posts (D).
STEP 6
Attach all four (4) Locking Casters (E) to the lower legs. Tighten the Casters using
Caster Wrench (K).
D

STEP 7
UPDATED AS OF: 06/02/2022 7 of 11
THIS COMPLETES ASSEMBLY INSTRUCTION
F
Peel the paper from the back of adhesive pad on Plastic Chart Support (F). Attach 2 Plastic
Chart Supports on each side of board. Insert 2 pins on back side of Chart Support (F)
through holes in markerboard (P1).
Complete

Panel Wings
UPDATED AS OF: 06/02/2022 8 of 11
INSTRUCCIONES DE ENSEMBLAJE
NO LA TIRE
INSTRUCTIONS DE MONTAGE
NE PAS JETER
ASSEMBLY INSTRUCTIONS
DO NOT THROW AWAY!

Parts List
UPDATED AS OF: 06/02/2022 9 of 11
Hardware
P1A - Wing Panel
P2A - Plastic Hanger
x2
x4
A1 - M6 x 15mm Screw
B1 - M6 Interior Threaded Post
x4
x4

Attach two Plastic Hangers (P2A) to the side of the Wing Panel using two (2) M6
Interior Threaded Post (B1) and two (2) M6 x 15mm Socket Screws (A1).
STEP 1
UPDATED AS OF: 06/02/2022 10 of 11
With hardware from Nest Easel, screw two Plastic Reciever (G) onto the outside of the
Upper Legs (P3) with two #10 - 1” Wood Screws (H) and two #10 - 1/2” Wood Screws (I).
Repeat with the other side of the whiteboard.
P4
P1
P5
C
STEP 2

STEP 7
UPDATED AS OF: 06/02/2022 11 of
THIS COMPLETES ASSEMBLY INSTRUCTION
F
Peel the paper from the back of adhesive pad on Plastic Chart Support (F). Attach 2 Plastic
Chart Supports on each side of board. Insert 2 pins on back side of Chart Support (F)
through holes in markerboard (P1).
Complete
