Mopar 82212517 User manual

1
REMOTESTART
JEEPWRANGLER
Jun 27,2013K6861135AB
4280548

2
CALLOUTDESCRIPTIONQUANTITY
1HoodSwitchHarness1
2WirelessControlModule(WCM)1
3FOBIKBlanks2
4RemoteStartAntenna1
5HoodAjarSwitch1
6HoodAjarSwitchBracket1
7ZipTies10
8Bolt1
9JClip1
CAUTION:
XBMremotestartcanONLYbeinstalledonvehiclesthathavethefollowingfactoryoptions:AutomaticTrans
mission,RemoteKeylessEntryandImmobilizer.
WinFobikbasedvehicles,thesalescodemustbeaddedtothedatabasepriortoinstallingthenewWCMmodule.
FailuretodosowillrendertheWCMmodule’sremotestartfunctioninoperative.
Thetechnicianshouldwait1/2hourbetweenaddingXBMsalescodeinDealerConnectbeforeinstallingthe
WCMmodule.Intheinterim,thetechniciancaninstallallothercomponentsexcepttheWCMmodule.
NOTE:Priortoinstallation,obtainthefourdigitPINfromthedealership'spartsdepartment.
NOTE:ThewiTECHsoftwarelevelmustbeatthelatestreleasetoperformthisprocedure.
NOTE:Priortoinstallation,thetechnicianshouldcuttheKEYFOBIKBlanksusingtheoriginalvehicle'sKey
FOBIKasatemplate.
1.VINmustbeupdatedwiththesalescodeoftheaddedaccessoryinordertoenablesystemfunctionality.Usingthe
DealerCONNECTwebsiteandthewiTECHdiagnosticapplication,completethevehicleconfiguration.
2.Logontohttps://dealerconnect.chrysler.com.
3.OntheHomepage,selectthe"Service"tab.
4.OntheServicepage,lookfortheGlobalClaimsSystemareaandselect"VehicleOption".
5.OntheVehicleOptionpage,enterthelasteightdigitsoftheVIN,thenselect"View".
6.Onthe"AvailableVehicleOption'"list,scrolldownthelistandselect"XBMRemoteStartSystem".
7.Clickthe"Add"buttonandmakesure"XBMRemoteStartSystem"appearsinthe"SelectedVehicleOption"liston
theright.
8.Clickthe"Save"buttontocompleteaddingthesalescodetothevehicledatabase.
PROCEDURESTEPS:

3
HOODSWITCHANDHARNESSINSTALLATION
1.Priortoinstallation,locatethehoodswitchconnec
tor/harness(1)locatedjustinfrontofthewindshield
washerreservoir.Iftheconnector/harnessispresent
itwillbeattachedtothevehicleharness.Ifthehood
switchconnector/harnessisnotpresent,usethe
suppliedwiringharnessinthekitandrefertothe
nextsectiontitledHOODSWITCHANDHARNESS
INSTALLATION(IFFACTORYHOODSWITCH
CONNECTOR/HARNESSISNOTPRESENT).
2.Disconnectandisolatethebatterynegativecable.
Waittwominutesforthesystemcapacitortodischarge
beforefurtherservice.
3.Openthevehicle'shood.
4.InstallthekitsuppliedJclip(1)totheinnerportionof
theradiatorsupportjustinfromthewindshieldwasher
resevoir.
5.Installthekitsuppliedhoodajarswitchbracket(1)us
ingthekitsuppliedbolt(2)totheinnerportionofthe
radiatorsupport.Tightentheboltto8Nm(71inlbs.).
4280316

4
6.Detachthefactoryinstalledhoodajarswitchharness
andpullthroughtheholemarked"TIPM"onthe
bracket.
7.Plugthekitsuppliedhoodajarswitchintotheharness
andseatthehoodajarswitchintotheholemarked
"TIPM".
HOODSWITCHANDHARNESSINSTALLATION(IFFACTORYHOODSWITCHCONNECTOR/HARNESS
ISNOTPRESENT)
1.Disconnectandisolatethebatterynegativecable.
Waittwominutesforthesystemcapacitortodischarge
beforefurtherservice.
2.Openthevehicle'shood.
3.InstallthekitsuppliedJclip(1)totheinnerportionof
theradiatorsupportjustinfromthewindshieldwasher
reservoir.

5
4.Installthekitsuppliedhoodajarswitchbracket(1)us
ingthekitsuppliedbolt(2)totheinnerportionofthe
radiatorsupport.Tightentheboltto8Nm(71inlbs.).
5.Feedtheconnectorofthekitsuppliedhoodajarswitch
harness(2)andpullthroughtheholemarked"TIPM"
onthebracket(3).
6.Plugthekitsuppliedhoodajarswitch(1)intothehar
ness(2)andseatthehoodajarswitchintothehole
marked"TIPM".
7.Usingfishtapeorequivalent,pullthekitsuppliedhar
nessunderthebracket(3)locatedonthedriverside
fender.
8.Removethegroundbolt(2)locatedontheinnerdriver
sidefender.
9.Installthegroundbolteyelet(1)fromthekitsupplied
harnessandreinstallthegroundbolt.

6
10.Routethekitsuppliedviolet/whiteharness(1)
alongthefendertowardstherearoftheengine
compartment.
11.Usethekitsuppliedtiewraps(2)tosecurethehar
nesstotheexistingvehicleharness.
12.Continueroutingthekitsuppliedharness(1)alongthe
backofthebackoftheenginecompartmenttowards
thepassengerside.Securetheharnesswiththekit
suppliedtiewraps(2).
13.Routethekitsuppliedharness(1)aroundthebattery
towardstheTIPM.Securetheharnesswiththekitsup
pliedtiewraps(2).

7
14.RemovethecoverfromtheTotallyIntegratedPower
Module(TIPM).
15.RemovetheB+cableandnut(1)fromtheterminal
locatedontheTIPM.
16.Usingasuitableflatbladetool,disengagetheTIPM's
upperretainingtabs(2)andliftuptoremovetheTIPM
(1)fromit'sbracket.
17.GrasptheTIPMandrotatetheassemblyuptofreeit
fromitsmountingbracket.Positiontheassemblyup
righttoaccesstheelectricalconnectorslocatedonthe
bottomoftheunit.
18.Removetheconnectormarked"D"(1).
19.Locatecavity3(3)inthewireendviewofthe"D"
connector.
4280316

8
20.Removethesecondarylock(2)andweatherseal(1)
fromtheconnector.
21.Ifpresent,detachthetab(3)locatedinthewireend
viewofcavity3.
22.Removetheprimarylock(1)formtheconnector.
23.Inserttheviolet/whitewirepin(1)fromthehoodswitch
harnessintocavity3ofthe"D"connector.Makesure
thatthepinisthoroughlyengagedintothecavity.
24.Reinstalltheprimarylockintothe"D"connector.
25.Reinstallthesecondarylockandweathersealinto
the"D"connector.
26.Reconnectthe"D"connectorintotheTIPM.

9
27.ReinstalltheTIPM(1)toit'smountingbracket.Make
sureallretainingtabs(2)arefullyengaged.
28.InstalltheB+cableandnut(1)totheterminallocated
ontheTIPM.
29.ReinstalltheTIPMcover.
WIRELESSCONTROLMODULE(WCM)ANDREMOTESTARTANTENNAINSTALLATION
WARNING:Toavoidseriousorfatalinjuryonvehiclesequippedwithairbags,disabletheSupplementalRestraint
System(SRS)beforeattemptinganysteeringwheel,steeringcolumn,airbag,seatbelttensioner,impactsensor
orinstrumentpanelcomponentdiagnosisorservice.Disconnectandisolatethebatterynegative(ground)ca
ble,thenwaittwominutesforthesystemcapacitortodischargebeforeperformingfurtherdiagnosisorservice.
ThisistheonlysurewaytodisabletheSRS.Failuretotaketheproperprecautionscouldresultinaccidental
airbagdeployment.
1.UsingaC4755trimstickoranotherequivalent,gen
tlyprytheedgesoftheinstrumentpanelendcaptrim
panel(1)toremove.Repeatfortheoppositeside.

10
2.UsingaC4755trimstickoranotherequivalent,gently
prytheupperandloweredgesofthekneeblockertrim
panel(1)toremove.
3.RemovethelowerinstrumentclustertoI/Pfastener
(1)onthelefthandsideofthesteeringcolumn.
4.RemovethelowerinstrumentclustertoI/Pfastener
(1)ontherighthandsideofthesteeringcolumn.

11
5.Removethestoragebinliner(1)locatedinthetopcen
teroftheI/P .
6.Removethestoragebinscrew(1)fromthetopcenter
oftheI/P.
7.UsingtrimstickC4755orequivalent,gentlyprythe
windowswitchassembly(1)awayfromtheinstrument
clusterbezel.
8.Unlocktheconnector,disconnectthewindowswitch
assembly(1)andremove.

12
9.RemovetheinstrumentclustertoI/Pscrew(1)located
inthewindowswitchcavity.
10.UsingtrimstickC4755orequivalent,gentlyprythe
edgesofinstrumentclusterbezel(1)awayfromthe
I/Ptodisengagethesnapretainers.
11.Removetheinstrumentclusterbezel(1)fromtheI/P.
NOTE:Steeringwheelremovedforclarity.
12.Positionthecolumntiltatthefulldownwardposition.
13.Removethetwoscrews(4)attachingtheupper
shroud(1)tothelowershroud(2).Afterremoving
thescrews,uncliptheshroudsfromeachotherby
applyinghandpressurealongtheseamswherethe
shroudsconnectonthesides,thenremovetheupper
shroud.
14.Removethescrew(3)attachingthelowershroud(2)
tothesteeringcolumn(6).Removethelowershroud
(2).

13
15.Removethefourscrews(3)thatsecuretheinstrument
cluster(1)totheinstrumentpanelarmature(2).
16.Pullthetopoftheinstrumentclusterrearwardfar
enoughtoaccessanddisconnecttheinstrument
panelwireharnessconnectorsfromtheconnector
receptaclesonthebackoftheclusterhousing.
17.Removetheinstrumentclusterfromtheinstrument
panel.
18.Removetheglovebox(1).
19.Removethetrimplug(1)fromtheaccessholeinthe
topofthedefrostergrillbetweenthewindshieldand
theI/P .
20.Workingthroughtheaccesshole,loosenthenutthat
securesthepassengerairbagupperbracketandthe
instrumentpanelarmaturetothestudnearthe
windshieldfenceline.

14
21.Reachupintotheinstrumentpanelgloveboxopening
toaccessandremovethetwonuts(3)thatsecurethe
passengerairbaglowerstudstotheinstrumentpanel
armature(2)oneachsideofthegloveboxlatchstriker
(1).
22.Removethetwoboltsfromthegrabhandleapplique
(1).
23.UsingtrimstickC4755orequivalent,removetheap
pliquebygentlypryingtheedgesofthegrabhandle
applique(1)awayfromthegrabhandle(3)todisen
gagetheretainers.
24.RemovethetwograbhandletoI/Pbolts.
25.Removethegrabhandle(3).
26.UsingtrimstickC4755orequivalent,gentlyprythe
edgesofpassengersideI/Pcover(1)awayfromthe
I/Ptodisengagethesnapretainers.
27.SlightlyrepositionthepassengersideI/Pcover(1).Do
notremoveatthistime.
CAUTION:Donotpullontheinstrumentpanelwire
harnesstakeoutsorpryontheconnectorinsulators
todisengagetheconnectorsfromthepassenger
airbaginflatorconnectorreceptacles.Improper
removalofthesetakeoutsandtheirconnector
insulatorscanresultindamagetotheairbagcircuitsortheconnectorinsulators.
28.Disconnecttheinstrumentpanelwireharnessconnectorsfromtheairbaginflators.Firmlygraspandpullthelock
straightoutfromtheconnectorinsulator,thenpulltheinsulatorsstraightoutfromtheairbaginflatortodisconnect
themfromtheconnectorreceptacles.
29.RemovethepassengerairbagandI/Pcover(1)fromtheinstrumentpanelasaunit.

15
30.Ifequipped,removethecompassmodule(1)fromthe
mountingtabslocatednearthetopcenteroftheI/P .
Donotdisconnectthecompassmodule.
31.Installtheremotestartantenna(1)intothemounting
tabslocatednearthepassengersidedoor.The
remotestartantennamustbeinstalledwithit's
labelfacingupandtheharnessfacingtowards
thedriversideofthevehicle.
32.Beginroutingtheremotestartantennaharness
towardsthedriversideofthevehicle.
33.AttachthePIAedgebiterclip(1)totheI/Pjustunder
thecompassmoduletab.
34.Attach the tie wrap (2) to the compass module
mountinglocation.Cliptheexcessofftheendofthe
tiewrap.

16
35.Continueroutingtheharnesstowardsthedriverside.
36.RemovetheI/Ptostructurescrew(1)locatedinthe
topcenteroftheI/P ,pullgentlyonthecenterbracket
andpushtheharnessbehindit.
37.InstalltheI/Ptostructurescrew(1).Tightenthescrew
securely.
38.Attachtie strap (2) to I/P structure.
39.Routetheharness(2)throughtotheinstrumentclus
terarea.
40.Attach a tie strap(2)totheinstrumentcluster
harnesses(1).Cliptheexcessofftheendofthetie
wrap.
41.Finishroutingtheremotestartantennaharness(2)
throughtothesteeringcolumnareanearthewireless
controlmodule(WCM)(1).

17
42.Removetheonerightmultifunctionswitchretaining
screw(3)fromthesteeringcolumncontrolmodule
(SCCM)(1).
43.Pullrightswitch(2)outofSCCM.
44.Disconnecttherightswitchelectricalconnector(1)
fromtheSCCM(2).
45.RemovetheWCMmountingscrewontheignitionlock
assemblyandseparatetheWCM(1and3)fromthe
ignitionlockassembly(5).
46.DisconnecttheWCMelectricalconnector(4).
47.RemovetheWCM(1and3)fromthecolumn(2)and
discard.

18
48.ObtainthesuppliedWCM(1and3)fromthekitand
connecttheremotestartantennatotheWCM(1and
3).
49.PositiontheWCM(1and3)ontheignitionlockhous
ing(5)andinstalltheretainingscrewonthetopofthe
ignitionlockhousing(5).
50.ConnecttheWCMelectricalconnector(4).
51.Connecttherightstalkelectricalconnector(1)tothe
SCCM(2).
52.Slidetherightstalk(2)intothegrooveoftheSCCM
(1)andinstalltheoneretainingscrew(3).

19
NOTE:Steeringwheelremovedforclarity.
53.Pushthetiltlever(5)downward.
54.Installthelowershroud(2)overthetiltleverandonto
thecolumn.
55.Positionthecolumntilt(5)atthefullupwardposition.
56.Pushthetiltlever(5)upward,lockingitinplace.
57.Installthescrew(3)attachingthelowershroud(2)to
thesteeringcolumn(6).
58.Positionthecolumntiltatthefulldownwardposition
andlockitinplace.
59.AttachthePIAedgebiterclip(1)tothelowershroud
(2).
60.Installtheuppershroudoverthelowershroud,clip
pingtheshroudstooneanother.
61.Installthetwoscrewsattachingtheuppershroudto
thelowershroud.
62.Positiontheinstrumentcluster(1)closeenoughto
theinstrumentpaneltoreconnecttheinstrument
panelwireharnessconnectorstotheconnector
receptaclesonthebackoftheclusterhousing.
63.Positiontheinstrumentclustermountingtabstothe
mountingholesintheinstrumentpanelarmature(2).
64.Installandtightenthefourscrews(3)thatsecurethe
mountingtabsoftheinstrumentcluster.Tightenthe
screwsto2N∙m(17in.lbs.).

20
65.Reconnectthetwoconnectorinsulatorsofthe
instrumentpanelwireharnesstakeoutstothe
airbaginflatorconnectorreceptaclesoneachside
oftheairbaghousingbypressingstraightinonthe
connectors,thenpushingthelocksstraightintothe
connectors.Becertaintoengageeachkeyedand
colorcodedconnectortothematchingconnector
receptacle.
66.PositionthepassengersideI/Pcover(1)totheI/P .
Makecertainthattheupperpassengerairbagbracket
isengagedwiththestudandunderthenutonthe
windshieldfencelineandthatthetwolowerstudsof
theairbagareengagedintheholesoftheinstrument
panelarmature.
67.PushtheedgesofpassengersideI/Pcover(1)tothe
I/Ptoengagethesnapretainers.
68.InstallthetwograbhandletoI/Pbolts.Tightenthe
boltssecurely.
69.Installthegrabhandleappliquebypushingtheedgesofthegrabhandleapplique(1)intothegrabhandletoengage
theretainers.
70.Installthetwoboltstothegrabhandleapplique(1).
71.Installandtightenthetwonuts(3)thatsecurethepas
sengerairbaglowerstudstotheinstrumentpanelar
mature.Tightenthenutsto6N∙m(55in.lbs.).
