Morita Tri auto mini User manual

Thinking ahead. Focused on life.
Cordless Endodontic Treatment Motorized Handpiece
Tri Auto mini Operation Instructions

1
Operation 2018-10-21
Thank you for purchasing the Tri Auto mini.
For optimum safety and performance, read this manual thoroughly before using the equipment and pay close attention to
warnings and notes. Keep this manual in a readily accessible place for quick and easy reference.
Table of Contents
Warnings and Prohibitions...................................................................................................................................... 4
Features..................................................................................................................................................................... 5
Parts Identication and Accessories...................................................................................................................... 6
Usage......................................................................................................................................................................... 7
(1) Before Use.............................................................................................................................................................................. 7
Charge Battery ....................................................................................................................................................................... 7
Connect Contra Angle ............................................................................................................................................................ 8
File Installation........................................................................................................................................................................ 9
Check Operation................................................................................................................................................................... 10
(2) Operation ...............................................................................................................................................................................11
Basic Operation .....................................................................................................................................................................11
Memory Settings: Primary Functions.................................................................................................................................... 12
Memory Settings: Additional Operation Settings .................................................................................................................. 13
Memory Settings: Other Settings.......................................................................................................................................... 14
(3) After Use ............................................................................................................................................................................... 15
Usage; Operation with the Root ZX mini.............................................................................................................. 16
Install File Electrode ............................................................................................................................................................. 16
Connect the Transmission Cable.......................................................................................................................................... 18
Meter Display........................................................................................................................................................................ 19
Operation.............................................................................................................................................................................. 19
Maintenance............................................................................................................................................................ 22
Cleaning ............................................................................................................................................................................... 22
Disinfection ........................................................................................................................................................................... 23
Disinfection: Wipe with Ethanol (for non-autoclavable parts) ............................................................................................... 24
Lubrication ............................................................................................................................................................................ 25
Packing................................................................................................................................................................................. 26
Sterilization ........................................................................................................................................................................... 26
Replacement Parts, Transport and Storage Environments............................................................................... 27
Inspection................................................................................................................................................................ 29
Troubleshooting ..................................................................................................................................................... 31
Technical Specications........................................................................................................................................ 33
Specications ....................................................................................................................................................................... 33
Symbols................................................................................................................................................................................ 34
Electromagnetic Disturbances (EMD) .................................................................................................................. 35
Safety and Accident Prevention for the Operation of Electrical Medical Devices ........................................... 37

2Operation 2018-02-21
Prevent Accidents
Do not fail to receive clear instructions concerning the various ways to use this equipment as described in this accompanying
Operation Instructions.
Fill out and sign the warranty and give the dealer from whom you purchased the equipment his copy.
Do not fail to give clear instructions concerning the various ways to use this equipment as described in this accompanying
operator’s manual.
After instructing the customer in the operation of the equipment, have him ll out and sign the warranty. Then ll in your own
section of the warranty and give the customer his copy. Do not fail to send the manufacturer’s copy to J. MORITA MFG. CORP.
Most operation and maintenance problems result from insufcient attention being paid to basic safety precautions and not being
able to foresee the possibilities of accidents. Problems and accidents are best avoided by foreseeing the possibility of danger
and operating the equipment in accordance with the manufacturer’s recommendations. First thoroughly read all precautions and
instructions pertaining to safety and accident prevention; then, operate the equipment with the utmost caution to prevent either
damaging the equipment itself or causing bodily injury.
The following symbols and expressions indicate the degree of danger and harm that could result from ignoring the
instructions they accompany:
The user (e.g., healthcare facility, clinic, hospital etc.) is responsible for the management, maintenance and use of medical de-
vice.
This equipment must only be used by dentists and other legally licensed professionals.
Do not use this equipment for anything other than its specied dental purpose.
Attention Customers
Attention Dealers
Prevent Accidents
The warning symbols ( ) and caution symbols ( ) that appear next to the main text on the right hand side of the page refer
to and are explained by the Warnings and Cautions at the bottom of the page.
This alerts the user of important points concerning operation or the risk of equipment damage.
This warns the user of the possibility of extremely serious injury or complete destruction of the equipment as well as
other property damage including the possibility of re.
This warns the user of the possibility of mild injury or damage to the equipment.

3
Operation 2018-10-21
■J. MORITA MFG. CORP. will not be responsible for accidents, equipment damage, or bodily injury resulting from:
1. Repairs made by personnel not authorized by J. MORITA MFG. CORP.
2. Any changes, modications, or alterations of its products
3. The use of products or equipment made by other manufacturers, except for those procured by J. MORITA MFG. CORP.
4. Maintenance or repairs using parts or components other than those specied by J. MORITA MFG. CORP. and other than
in their original condition
5. Operating the equipment in ways other than the operating procedures described in this manual or resulting from the safety
precautions and warnings in this manual not being observed
6. Workplace conditions and environment or installation conditions which do not conform to those stated in this manual such
as improper electrical power supply
7. Fires, earthquakes, oods, lightning, natural disasters, or acts of God.
■The useful life of the Tri Auto mini is 6 years (based on self-certication) from the date of shipment provided it is regularly and
properly inspected and maintained.
■J. MORITA MFG. CORP. will supply replacement parts and be able to repair the product for a period of 10 years after the
manufacture of the product has been discontinued.
Disclamer
In Case of Accident
Intended Operator Prole
Patient Population
If an accident occurs, the Tri Auto mini must not be used until repairs have been completed by a qualied and trained technician
authorized by the manufacturer.
This equipment must only be used by dentists and other legally licensed professionals.
Age Child to Elderly
Weight N/A
Nationality N/A
Sex N/A
Health It is not intended for use on patients wearing pacemakers or ICDs.
Condition Conscious and mentally alert person. (Person who can stay still during treatment.)
• This equipment is not recommended for use in children under 12 years of age.

4Operation 2018-02-21
: This indicates when not to use the equipment.
Warnings and Prohibitions
• This equipment must not be connected to or used in combination with any other apparatus or system. It must not be used as
an integral component of any other apparatus or system.
• J. MORITA MFG. CORP. will not be responsible for accidents, equipment damage, bodily injury or any other trouble which
results from ignoring this prohibition.
• A rubber dam should be used when performing endodontic treatment.
• No modication of this equipment is allowed.
• Electromagnetic wave interference could cause this equipment to operate in an abnormal, random and possibly dangerous
manner. Cellular phone, transceivers, remote controls and all other devices which transmit electromagnetic waves located
inside the building should be turned off.
• Instruments which produce considerable electrical noise such as electric scalpels can cause the Tri Auto mini to operate
abnormally. Turn the Tri Auto mini off before using any instruments that produce electrical noise.
• Do not use this equipment on patients who have a pacemaker or an Implantable Cardioverter Debrillator (ICD).
• Illumination devices such as uorescent lights and lm viewers which use an inverter can cause the Tri Auto mini to operate
erratically. Do not use the Tri Auto mini near lights such as these.
• This equipment must not be connected to or used in combination with any other apparatus or system. It must not be used
as an integral component of any other apparatus or system. J. MOTIRA MFG. CORP. will not be responsible for accidents,
equipment damage, bodily injury or any other trouble which results from ignoring the above prohibitions.
• Blocked canals cannot be accurately measured.
• Do not perform maintenance while using the instrument for treatment.
* J. MORITA MFG. CORP. is not responsible for any accidents or other types of trouble that are caused by not following the
prohibitions and other conditions noted above.

5
Operation 2010-12-16
Features
Features and intended use:
The Tri Auto mini is a compact, cordless endodontic treatment motorized handpiece for preparation and enlargement of root canals.
It may be connected to the Root ZX mini, an apex locator (sold separately).
Instructions for how to use the Tri Auto mini when it is connected to the Root ZX mini are printed on a blue background like this one.
Liquid Crystal Display (LCD) :
The LCD is easy to read and shows all settings as well as how the motor is running.
Controls :
Speed : Eleven rotation speeds can be set from 50 to 1,000 rpm.
Torque Reverse : The motor automatically reverses its rotation if the torque load exceeds the set value to reduce
the risk of jamming.
Slow Down : The le slows down as torque increases.
The le slows down as it approaches the apex if the Tri Auto mini is connected to the Root ZX mini.
Forward & Reverse : The le may rotate in both forward and reverse directions.
Auto Start & Stop* : The le starts when it is inserted in the canal and stops when it is taken out.
Apical Reverse or Stop* : The motor reverses or stops when the tip of the le reaches a preset position inside the canal.
Apical Torque Reduction* : The automatic torque reverse value is reduced as the le tip approaches the apex.
* These controls can be used if the Tri Auto mini is connected to the Root ZX mini.
Memory:
Six combinations of speed, torque etc. can be memorized.

6Operation 2018-02-21
Parts Identi cation and Accessories
Parts Identi cation
Accessories
Charger Switch
Battery
*Inside motor handpiece
Transmission Cable
(Option)
Spray Nozzle
* Use this same nozzle when
replacing a can of AR SPRAY or
MORITA MULTI SPRAY.
Power Supply Cord
File Electrode
(Option)
AR SPRAY or
MORITA MULTI SPRAY
* Sold Separately
Contra Angle
Main Switch
Liquid Crystal Display
Select Switch
Plus and Minus Switches
Power Supply Cord
Charge LED (orange)
Power LED (green)
Charger
Motor Handpiece
Handpiece Rest
(Option)

7
1 2
Operation 2018-10-21
(1) Before Use
Usage
Temperature: +10°C to +35°C (+50°F to +95°F)
Humidity: 30% to 80% (without condensation)
Atmospheric Pressure: 70 kPa to 106 kPa
* If the unit has not been used for some time, make sure it works properly before using it again.
⹅Operating Environments
Charge Battery The battery is built into the motor handpiece.
Green LED
Orange LED
• The battery is not charged when the unit is shipped from the factory and must be charged before using the unit.
• Do not pull or yank the cord when disconnecting the AC adapter. Always grip the connectors.
• Use only the power cord provided and plug both ends all the way in.
• Charger and power supply cord must be located outside the so called patient environment (2.0 m around the patient location).
• If an electrical storm occurs while the battery is being charged, do not touch the charger or its cord as there would be a risk receiving an electric shock.
• Do not get the charger wet or use it where it might get wet.
Charge the battery as soon as the battery power indicator gets down to its last bar.
If the orange charge LED goes off immediately or doesn’t light up when the handpiece is put into the charger, the battery is probably fully charged.
To make sure, take the handpiece out and put it back in again.
Make sure the contact areas for the handpiece and charger are free of debris, especially metal fragments. Wipe with ethanol to remove any foreign
debris. Do not press down too hard to wipe the charging areas; this could bend the electrical contacts.
Do not leave the charger where it will be exposed to direct sunlight.
Unplug the battery charger when it is not being used.
Do not use any charger; use only the one that comes with the Tri
Auto mini.
Connect the power cord to the charger and then plug
it in. Turn the charger on. The green Power LED will
light up.
* Ambient (room) temperature for charging is from +10 ºC (+50 ºF) to +40 ºC (+104 ºF).
Put the handpiece into the charger as far as it will
go. The orange Charge LED will light up to show that
charging has begun.
* Charging time is about 120 minutes.
Green LED

8Operation 2018-02-21
The number of bars shows how much battery power is left.
Recharge the battery when there is only one bar left.
If the battery runs almost completely out, the Tri Auto mini will automatically turn itself off after
about 10 seconds. Recharge the battery as soon as possible.
If the battery power is very low and a large load is applied to the  le, the motor may stop or the
unit may turn itself off.
This is for safety; there may not be enough power to run the motor with suf cient stability.
Recharge the battery if the display shown to the left appears frequently.
Contra Angle Motor Handpiece
Line up the marks.
Approx. 290°
Do not force the contra angle to rotate beyond its limit.
The rotation range of the contra angle is about 290°.
Set it so that it reaches the treatment area and the
display is easy to see.
Line up the match marks and push the contra angle onto the handpiece until there is an audible click.
* The contra angle must be lubricated with the AR SPRAY or MORITA MULTI SPRAY before using for the  rst time.
Refer to “Autoclaving the Contra Angle”.
• Push the contra angle all the way onto the handpiece and then give it a light tug to make sure it is securely attached.
• Make sure the connection components for both the handpiece and the contra angle are not damaged. An improper connection could cause the motor to re-
verse unexpectedly and result in injuring the patient.
Connect Contra Angle
Charge Battery
Approx. 290°

9
Operation 2018-02-21
File Installation
Use either Nickel-titanium or stainless steel  les.
Hold down the  le release button
Insert the  le and turn it back and forth until it lines up
with the latch mechanism.
Push the  le all the way into the latch. Release the
 le release button.
For use with the Root ZX mini, connect the  le electrode
and the transmission cable .
File release button
• Use caution when inserting and removing  les to avoid injury to  ngers.
• Inserting and removing  les without holding the  le release button down will damage the chuck.
• Make sure the Tri Auto mini is turned off before inserting or removing  les.
• Do not connect the  le electrode if the handpiece is not connected to the Root ZX mini.
• Never use deformed or damaged  les.
• Give the  le a light tug to con rm it is securely held in place. If the  le is not securely placed, it could come out and injure the patient.

10 Operation 2018-02-21
Check Operation
Main Switch
File release button
Plus and Minus Switches
• Stop using the Tri Auto mini if you feel or notice anything unusual. The Tri Auto mini cannot be used for every canal and should be used along with manual
enlargement.
• File break more easily at fast speeds; always follow the  le manufacturer’s usage recommendations. Also always check the speed settings before use.
• Do not use any type of  les except nickel-titanium and stainless steel ones.
• Nickel-Titanium  les are easily broken; note the following points.
• Open the canal up to the apical constriction manually before using a nickel-titanium  le.
• Never use excessive force to insert the  le.
• First remove all foreign matter, such as bits of cotton from the root canal.
• Never use excessive force to advance the  le down the root canal.
• Do not use for extremely curved canals.
• Try not to trigger the auto torque reverse function when advancing the  le down the canal.
• Do not skip  le sizes; suddenly using a much larger  le could break it.
• If you encounter resistance or the auto torque reverse is triggered, back the  le up 3 or 4 mm and carefully advance it down the root canal again. Or re-
place the  le with a smaller size. Never use excessive force.
• Do not force the  le down the root canal or press it against the root canal wall.
• Do not use the same  le continuously in one position as this may create “steps” on the root canal wall.
• Always take  le out of the contra angle after use.
• Operate the Tri Auto mini outside the oral cavity to make sure it will operate properly before using it for treatment.
• Some canals may be impossible to enlarge; always take an X-ray to check.
• Nickel-titanium  le may suddenly snap depending on the curvature and shape of the canal; stop using the  le if you notice or feel anything amiss.
• Files will eventually break due to metal fatigue and should be replaced before they reach this point.
• Electric noise or a malfunction could interfere with the motor control. Do not depend entirely on the unit controlling itself; always watch the display and be
aware of tactile feedback.
• Files will jam and break if too much force is applied to them.
• Files may break even when the torque reverse is turned on, depending on the setting value. Never exert excessive force on the  le.
• Files designed for use with engines break easily if too much force is applied. Also do not use these  les for canals with excessive curvature.
• Always examine  les for stretching and other deformities or damage before using them. Any type of deformity could result in the  le breaking.
• Do not let the  le release button on the contra angle press against the teeth opposite to the treatment area; this could cause the  le to come out and result in
an injury.
• Do not press the  le release button while the motor is running. It could heat up and cause a burn, or the  le could come out and cause an injury.
If a malfunction occurs, the Tri
Auto mini will stop working. In
this case, contact your local
dealer or J. MORITA OFFICE.
■Make sure the contra angle and handpiece are properly and securely connected.
■ Make sure the  le is securely installed; give it a light tug.
■Check switch operation.
Turn the Main switch on and use the Plus or Minus switches to select a memory. Then press the main switch again to
see if the Tri Auto mini runs smoothly.
Refer to page 18 for instructions on checking the Tri Auto mini’s
operation when it is connected to the Root ZX mini.
The number that appears after Error will depend on the
type of malfunction.

11
Operation 2018-02-21
Basic Operation
Torque Reverse Setting
Memory Number
Rotation Direction
Battery Power
Speed Setting
Torque Reverse Setting Current Torque
Standby Display Torque Display
• Do not fail to check the new settings whenever you change the Memory Number.
1. Turn Tri Auto mini on: Press Main switch.
The standby display will appear.
When the standby display is being shown, you can turn the Tri Auto mini off by holding down the Select Switch and
pressing the Main Switch
* The Tri Auto mini turns itself off automatically if it is not used for 3 minutes (factory setting).
When connected to the Root ZX mini, refer to page 19 for
meter readings and operation.
(2) Operation
Main Switch
(Turn power on and starts/stops rotation)
Liquid Crystal Display
Select Switch
Plus and Minus Switches
(Select memory and change settings)
2. Select Memory number: Press Plus or Minus switch.
* There are six memories for various combinations of speed, torque reverse and rotation direction settings.
* The backlight will temporarily change color if changing the memory number changes anything other than the speed, torque
reverse, and rotation direction settings.
3. Start motor: Press Main switch again.
The Torque Display will appear.
* If you hold the Main Switch down when you start the motor, it will run only while the switch is held down and stop when the
switch is released.
* You can temporarily change the torque reverse setting while the motor is running by pressing the Plus or Minus switch.
* The color of the backlight changes depending on the load applied to the  le.
* The backlight starts blinking when the load approaches the torque reverse setting.
4. Stop motor: Press Main switch again.
The standby display will reappear.
• The temperature of the motor handpiece rises up to +47.5°C (+117.5°F) when the ambient temperature is +40 °C (+104 °F).

12 Operation 2018-02-21
Memory Settings
Memory Settings: Primary Functions
The factory settings are shown below. These settings can be changed.
** These functions are available only when connected to the Root ZX mini.
Setting Memory
M1, M4 M2, M5 M3, M6
Speed (rpm) 400 400 250
Torque Reverse (Ncm) 1.0 0.8 0.6
Rotation Direction Forward
Torque Slow Down OFF
Canal Measurement Linkage** ON
Apical Reverse or Stop** Reverse
Auto Start or Stop** ON
Apical Slow Down** OFF
Apical Torque Reduction** OFF
Primary Functions:Rotation Speed, Torque Reverse, Rotation Direction
1. Select a memory number for the standby display by
pressing the Plus or Minus switch.
2. Press the Select Switch to choose one of the primary
functions.
3. Press the Plus or Minus switch to change the setting.
* The display will go back to the standby display if 5
seconds (factory setting) elapses without a switch being
pressed.
Speed Settings:
50, 100, 150, 200, 250, 300, 400, 500, 600, 800 and 1000 rpm
Torque Reverse Settings:
0.2, 0.4, 0.6, 0.8, 1.0, 1.5, 2.0, 2.5 and 3.0 Ncm
This function can also be turned off: TRL (torque reverse-less).
Rotation Direction:
Fwd: Forward, Rev: Reverse
Standby Display
Rotation Direction
Speed
Torque Reverse
• If the torque reverse function is turned off, the  le could jam inside the canal and break.
• Torque reverse should be set depending on the canal and the  le.
• If the torque reverse seems to be activated too frequently increase its value.

13
Torque Slow Down
Linked Function
Apical Reverse or Stop
Auto Start & Stop
Apical Slow Down
Apical Torque Reduction
Pantalla de espera
Operation 2014-03-20
Memory Settings: Additional Operation Settings
Additional Functions:Torque Slow Down (TORQ.SL.D.), Linked to canal measurement (LINKED FUNCTION**),
Apical Reverse or Stop (APICAL ACT.**), Auto Start and Stop (AUTO STT/STP**), Apical Slow Down
(APICAL SL.D.**), Apical Torque Reduction (APICAL TRQ.D.**)
1. Select a memory number for the standby display; press the Plus or Minus switch.
2. Hold down the Select switch for at least 1 second to show the displays for
additional operation settings.
3. Press the Select switch to go from one display to the next.
4. Change the setting; press the Plus or Minus switch.
* The display will go back to the standby display if 5 seconds (factory setting) elapses without a
switch being pressed.
Torque Slow Down:
When this is turned on, the motor will slow down as the torque load increases.
Standby Display
Linked Function**:
When this is turned on, the functions below will be activated.
Apical Reverse or Stop**:
The  le will reverse or stop when the  le tip reaches the Flash Bar.
Auto Start & Stop**:
When this is turned on, the  le starts rotating when it is inserted and stops when it is taken out
of the canal.
Apical Slow Down**:
When this is turned on, the  le slows down as it approaches the apex.
Apical Torque Reduction**:
When this is turned on, the torque setting that triggers reverse rotation is reduced as the  le
tip approaches the apex.
** These functions are available only when connected to the Root ZX mini.

14
Tiempo para vuelta al
modo de espera:
Beeper Volume
Auto Power Off Time
Positive Display Negative Display
Right Handed Left Handed
Backlight Color Change
Operation 2010-12-16
Memory Settings: Other Settings
Other Settings: The factory settings are shown below.
1. With unit turned off, hold down Select Switch and then press the Main Switch.
2. Press the Select Switch to select one of the settings.
3. Press the Plus or Minus switches to change the setting.
4. Press the Main Switch to return to the standby display.
Beeper (BEEP VOLUME) Big Right or Left Handed (DOMI. HAND) Right
Auto Power Off (AUTO PWR) 3 min. Backlight (B.L.COLOR CHANGE) ON
Positive/Negative Display (DISP. TYPE) Posi Return to Standby Time (S.S.R TIME) 5 sec.
Return to Standby Time
Beeper Volume:
Press Plus or Minus switch to set beep volume used for switch operation and alarms at Off,
Low or Big.
Auto Power Off Time:
The time lapse for automatic shut off when the unit is not used can be set from 1 to 15 min-
utes. Press Plus or Minus switch to set the time.
Positive / Negative Display:
Set display for black on white background or vice versa.
Right or Left Handed:
Set display for right- or left-handed user. Display turns up-
side down for left-handed users.
Backlight Color Change:
When this is turned on, the backlight will change color depending on torque and le tip loca-
tion. It also changes color for setting displays. Does not change color when turned off.
Return to Standby Time:
Set the time that elapses before display returns to standby from settings displays. Set from 1
to 15 seconds by pressing Plus or Minus switches.

15
Operation 2018-02-21
Restore Default Memories
Take Out File
Restore the original factory settings for the memories in the following way.
* This will restore the original memory settings. You cannot restore settings for just one memory.
1. Hold down the Select Switch, the Plus Switch and the Minus Switch and then turn the unit on with the Main Switch.
2. The "MemClear" display will appear. Press the Select Switch to restore the default memories or press the Main switch to
cancel the operation.
3. Wait unit the “Finished” display appears and then press the Main switch to go to the standby display.
• Take care not to injure your  ngers when inserting and removing  les.
• Never insert or remove  les without holding down the button; this will damage the chuck.
• Make sure the unit is turned off before inserting or removing  les.
1. Hold down the Select switch and press the Main switch to turn the power off.
* The power will go off automatically if the unit is not used and no switches are pressed for 3 minutes.
2. Hold down the  le release button and pull the  le straight out.
(3) After Use

16
1
3
2
Operation 2018-02-21
Install File Electrode
Pick up the installation jig for the electrode with your right
hand and then slide the electrode in a little so that the
contact on the contra angle goes between the bracket
prongs.
* It is easier to get the bracket in if you push the end down
slightly.
Good: Contact must go under the electrode.
No Good: Contact must not go on top of the electrode.
Take out the silver screw used to secure the le electrode. Take out the black screw and remove the cap that covers
the elctrode installation area.
Usage; Operation with the Root ZX mini
Electrode Site Cap
File Electrode
Installation Jig
Push Down
Bracket
Contact (gold)
No GoodGood
Do not mix up the black screw used for the cap and the silver screw used for the electrode.
• Make sure the screw is properly tightened up; otherwise it might come out and be swallowed.
Pull out the installation jig and push the electrode all the
way in. Then secure it with the silver screw.
* The contact must go between the bracket prongs
and then underneath the electrode.

17
4 5
6
Operation 2018-02-21
Install File Electrode
Push the le electrode down so that it pinches the le as
shown in the illustration.
Hold down the le release button.
Insert the le and turn it back and forth until it lines up
with the latch mechanism.
Push the le all the way into the latch. Release the
le release button.
Swing the electrode back as shown in the illustration.
File Electrode
Inserting and removing les without holding the le release button down will damage the chuck.
Do not let the electrode pinch the cutting part of the le.
The le electrode may not t on some types of les.
The le electrode cannot be used for les with a shank diameter greater than 1.2 mm, les with large cutting heads such as largo burrs, les with
shanks that are not round and Gates Glidden drills. Do not mix up the black screw used for the cap and the silver screw used for the electrode.
• Use caution when inserting and removing les to avoid injury to ngers.
• Make sure the le goes all the way in. Give the le a light tug to make sure it is properly installed.
File release button

18
1 2
Operation 2018-02-21
Connect the Transmission Cable
Check Operation
Take off the cap and plug the cable’s white plug all
the way into the handpiece.
Plug the cable’s gray plug into the Root ZX mini.
■ Make sure  le electrode is making good contact with the  le.
■ Touch the  le with the contrary electrode and make sure the meter goes all the way to its end and there are no
segments that do not light up.
Plug: White
Plug: Gray
Do not mix up the cable plugs.
Watch out because the motor might start up when you do this.
• Make sure the plugs go straight in.
• After insertion give plugs a light tug to make sure they are securely connected. Otherwise, data may not be transmitted acurately.
• Do not bump the plugs or drop anything on them when they are plugged in.
• Use only the special cable provided. Other cable could be electrically risky and result in damage or injury. Make sure the  le goes all the way in. Give the  le
a light tug to make sure it is properly installed.
• Check the meter activity before each patient and do not use the instrument if all the segments of the display do not light up. This suggests that the meter can-
not make an accurate reading.
* Refer to the user manual for the Root ZX mini.
