Mosquito Magnet PATRIOT PLUS User manual

2016-0850
2016-08-05
(Carton)(Principal Display Panel – does not include graphics, pictures or
illustrations)
Mosquito Magnet® Patriot Plus
Advanced Mosquito Control System
For Outdoor Use Only.
Attracts certain mosquitoes.
DOMESTIC
KEEP OUT OF REACH OF CHILDREN
READ THE LABEL BEFORE USING
REGISTRATION NO. 32375 PEST CONTROL PRODUCTS ACT
CAUTION - SKIN IRRITATION
WARNING - EYE IRRITATION
DANGER POISON
Box Contents:
1- Powerhead
1- Base Pole
1- Base
1- Bug Bag (Already Installed)
1-15 m (50 ft) Low Voltage Power Cord
10- Metal Cord Clips
1- Quick Clear Adapter
1- Owner’s manual
1- Mosquito Magnet® Octenol Mosquito Attractant
GUARANTEE 1-Octen-3-ol.......................1.66 g /lure
REG. NO. 28440 PCPA
Net Contents: 4.9g (.173 oz.) per cartridge
See enclosed label for additional Precautions, First Aid, Directions for Use and Storage
and Disposal instructions.
Woodstream Canada Corporation
25 Bramtree Court, Unit 1
Brampton, Ontario
Canada L6S 6G2
Tel: [phone]
www.mosquitomagnet.com

Mosquito MagnetPatriot Plus
Page 2 of 21
FIRST AID
If
swallowed
• Call a poison control centre or doctor immediately for treatment advice.
• Have person sip a glass of water if able to swallow.
• Do not induce vomiting unless told to do so by the poison control centre
or doctor.
• Do not give anything by mouth to an unconscious person.
If on skin
or clothing
• Take off contaminated clothing.
• Rinse skin immediately with plenty of water for 15 - 20 minutes.
• Call a poison control centre or doctor for treatment advice.
If in eyes
• Hold eye open and rinse slowly and gently with water for 15 - 20
minutes.
• Remove contact lenses, if present, after the first 5 minutes, then
continue rinsing eye.
• Call a poison control centre or doctor for treatment advice.
If inhaled
• Move person to fresh air.
• If person is not breathing, call 911 or an ambulance, then give artificial
respiration, preferably by mouth-to-mouth, if possible.
• Call a poison control centre or doctor for further treatment advice.
Take container, label or product name and Pest Control Product Registration
Number with you when seeking medical attention.
TOXICOLOGICAL INFORMATION
Treat symptomatically.
PRECAUTIONS
KEEP OUT OF REACH OF CHILDREN
Fatal or poisonous if swallowed. May irritate the skin. Avoid contact with skin. Causes
eye irritation. DO NOT get in eyes.
DO NOT contaminate irrigation or drinking water supplies or aquatic habitats by disposal
of wastes.
Hazardous to Humans and Domestic Animals. Wash hands before eating, drinking,
chewing gum, using tobacco or using bathroom facilities.
DIRECTIONS FOR USE
See Enclosed Operating Instructions for complete instruction for unpacking the device,
set up and operation of the unit. Please carefully read these instructions.

Mosquito MagnetPatriot Plus
Page 3 of 21
HOW IT WORKS
Our Patented CounterflowTM Technology is based on the key finding that mosquitoes are
drawn to the CO2 that humans exhale, and to the subtle skin scents which help
mosquitoes locate their target at close range. 18 years of research and independent testing
has enabled us to create a trap that releases these compounds in the precise balance
attractive to mosquitoes. MOSQUITO MAGNET® Patriot Plus begins catching
immediately.
STORAGE AND DISPOSAL
Mosquito Magnet® Octenol Mosquito Attractant Storage: Store in original container in a
cool, dry area and out of reach of children until ready to use.
Mosquito Magnet® Octenol Mosquito Attractant Disposal: DO NOT reuse the spent
lures. Dispose in household garbage. Unused or partially used products should be
disposed of at provincially or municipally designated waste disposal sites.
NOTICE TO USER
This pest control product is to be used only in accordance with the directions on the label.
It is an offense under the Pest Control Products Act to use this product in a way that is
inconsistent with the directions on the label. The user assumes the risk to persons or
property that arises from any such use of this product.

Mosquito MagnetPatriot Plus
Page 4 of 21
OPTIONAL TEXT:
The Mosquito Magnet® Patriot Plus captures and kills mosquitoes.
Mosquito Magnet® Patriot Plus – Over 18 Years of Mosquito Research
Ideal for large yards. Place up to 15.24 metres (50 ft) away from the nearest power
source.
Thank You for purchasing a Mosquito Magnet® Patriot Plus.
Advanced CounterFlow Technology™ for increased catch.
Fold-up base for easy, compact storage.
Simple assembly and start-up.
Added Safety Features:
oSelf-regulated propane shut-off valve
oTank stability guardrail
Silent and Odourless.
24/7 Operation.
Easy operation and advanced diagnostic features.
Advanced Diagnostics – For Easy Monitoring.
Mosquito Magnet® Patriot Plus Catches Mosquitoes.
Self-regulated propane shut-off valve for added safety.
Easy assembly and start-up
Weather-resistant.
Real Results!
Propane tank sold separately.
CounterFlow Technologygives you the edge!
The Mosquito Magnet® Patriot Plus mimics a human by emitting carbon dioxide (CO2),
the same natural compound humans exhale with each breath. This CO2is combined with
a short-range attractant to further enhance catch.
Trap begins catching immediately.
(Uses) no open flame.
We have over 18 years of research and several patents to support our innovative design of
the Mosquito Magnet® Patriot Plus.
Patented CounterFlow Technology, scientifically proven to attract and capture
mosquitoes.
For questions call our Technical Call Center: 800-953-5737
Gas fired UL/CE Listed
Gas Fired Insect Control Equipment
47WB
Patents:
oUSA: Nos. 5,813,166; 6,145,243; 6,286,249; 6,817,140; 6,840,005; 6,848,466;
6,892,492; 7,074,830; 7,243,458; 7,281,351; 7,293,387; 7,536,824; 7,614,180;
7,752,803; and 7,987,631
oCanada: Nos. 2,265,944; 2,322,038; and 2,460,876
oOther patents pending
The Mosquito Magnet® Patriot Plus features our exclusive, patented CounterFlow
Technologybased on over 18years of mosquito research.
Easy to bury cord. (Burying clips included).
15 meter (50 ft) cord included.
Advanced mosquito trapping system.

Mosquito MagnetPatriot Plus
Page 5 of 21
Advanced Mosquito Defense Systems.
Simple, one button, computer controlled operation.
Our patented catalytic conversion process turns propane gas into CO2. The high power fan
enhances CO2production.
Clear hood allows at-a-glance viewing of net.
Patented CounterflowTM Technology mixes the CO2with heat, moisture and attractant to
enhance the catch rate.
Mosquitoes follow the scent to the trap where they are vacuumed into the net.
Mosquitoes are trapped in the net, then dehydrate in 24 hours.
Stable base holds propane tank in place.
Wheels provide easy placement.
Scientifically proven to attract and capture mosquitoes – Based on 18 years of research
and testing.
Attracts and Kills Mosquitoes.
Customer Care Hotline [phone].
Backed by a 1 year limited warranty through a Certified Service Location.
What Attracts Mosquitoes?
oOnly female mosquitoes bite, using the protein from the blood to reproduce.
Mosquitoes are attracted to the combination of Carbon Dioxide (CO2), moisture
& heat (human breath). An additional attractant for mosquitoes is the scent of
human skin.
How Does It Work?
oThe Mosquito Magnet® Patriot Plus (trap) mimics a human’s breath by
converting propane to carbon dioxide (CO2) which is mixed with heat & moisture
through a patented catalytic conversion process.
oThe patented Counterflow™ Technology then expels a silent, odourless plume of
CO2which lures the mosquitoes to the trap.
oAs mosquitoes approach in search of a human, they are caught in a vacuum
which draws them into the trap’s bug bag.
oWithin 24 hours the mosquitoes dehydrate and die
oThe self-contained bug bag eliminates the need to touch mosquitoes. Replace
your bug bag every 21 days or sooner to maximize air flow.
oYour propane tank will last 21 days.
oUse your Mosquito Magnet® Quick Clear Cartridge to clear the gas nozzle after
every tank change. Without this proprietary feature the nozzle might be prone to
clog due to contaminants in the propane.
Note: Through scientific testing Mosquito Magnet Patriot Plus has discovered & patented
the precise formula of CO2, heat and moisture to attract mosquitoes.
Where Should I Place My Trap?
oPlace your trap upwind 9-12 m (30-40 ft.), within 1.5-1.8 m (5-6 ft) of mosquito
habitat (standing water, bushes, flowerbeds, treeline, marshbed, etc.). It is
recommended that the trap be placed in the shade.
3X Larger Bug Bag Traps more Mosquitoes

Mosquito MagnetPatriot Plus
Page 6 of 21
(Manual)
MOSQUITO MAGNET®
PATRIOT PLUS
Advanced Mosquito Defense Systems
Operation Manual
DOMESTIC
KEEP OUT OF REACH OF CHILDREN
READ THE LABEL BEFORE USING
Please retain these Operating Instructions for future reference
REG. NO. 32375 PCPA
Leader in 360º Customer Support
oCustomer Care Hotline: [phone]
oOnline Assistance (Available)
oCertified Service Locations
For Outdoor Use Only
Woodstream Canada Corporation
25 Bramtree Court, Unit 1
Brampton, Ontario
Canada L6S 6G2
Tel: [phone]
www.mosquitomagnet.com

Mosquito MagnetPatriot Plus
Page 7 of 21
Welcome
Congratulations on your purchase of Mosquito Magnet® Patriot Plus.
Backed by over 18 years of research and independent testing, Mosquito Magnet® Patriot
Plus is scientifically proven to capture and kill mosquitoes.
Mosquito Magnet Patriot Plus is easy to use. The link www.mosquitomagnet.com/videos
provides key information for getting started. In this manual, you’ll learn everything you
need to know about how it works, optimal trap placement, maintenance, storage and
warranty information. The keys to success are trap placement, utilization of the correct
attractant for your area and routine maintenance. For optimal catch rate, you’ll need to
change the propane tank and attractant every 21 days and use the Quick Clear Cartridge
every tank change.
Our Customer Care line is available to answer all your questions regarding your new
purchase. Please feel free to contact us…
Customer Care: 1-800-953-5737
Woodstream Canada Corporation
25 Bramtree Court, Unit 1
Brampton, Ontario
Canada L6S 6G2
Tel: [phone]
www.mosquitomagnet.com
Patents:
USA: Nos. 5,813,166; 6,145,243; 6,286,249; 6,817,140; 6,840,005; 6,848,466;
6,892,492; 7,074,830; 7,243,458; 7,281,351; 7,293,387; 7,536,824; 7,614,180; 7,752,803;
and 7,987,631
Canada: Nos. 2,265,944; 2,322,038; and 2,460,876
Other patents pending
Made in China

Mosquito MagnetPatriot Plus
Page 8 of 21
FOR YOUR SAFETY
If you smell gas:
1. Shut off the gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, immediately call your gas supplier or your fire department.
FOR YOUR SAFETY
1. Do not store or use gasoline or other flammable vapours and liquids in the vicinity
of this or any other appliance.
2. An LP cylinder not connected for use shall not be stored in the vicinity of this or
any other appliance.

Mosquito MagnetPatriot Plus
Page 9 of 21
CONTENTS
Safety Instructions............................................................................................................3-4
Principal Parts......................................................................................................................5
Assembly Instructions.........................................................................................................6
Trap Assembly
Set-Up.............................................................................................................................7-10
Trap Placement
Burying the Power Cord
Propane Tank Installation
Octenol Attractant Installation
Instructions.........................................................................................................................11
Starting Instructions
Shut Down Instructions
When Not In Use
End of Season Storage
For Optimal Results
Maintenance.......................................................................................................................12
Maintenance Schedule
Propane Tank Changing Tips
Quick Clear Valve..............................................................................................................13
Troubleshooting.................................................................................................................14
Warranty............................................................................................................................15
Questions or Comments
Please contact Woodstream Canada Corporation if you have any questions or experience
any problems with your Mosquito Magnet® Patriot Plus: 1-800-953-5737
Woodstream Canada Corporation
25 Bramtree Court, Unit 1
Brampton, Ontario
Canada L6S 6G2
Tel: [phone]
www.mosquitomagnet.com

Mosquito MagnetPatriot Plus
Page 10 of 21
How the Mosquito Magnet® Patriot Plus Works
Mosquitoes use the long-range attractant carbon dioxide (CO2) to locate people. Once in
close proximity, mosquitoes use short-range attractants such as scents emitted from the
skin, to determine which person they are going to bite. The Mosquito Magnet Patriot Plus
mimics a human by converting propane to CO2, with its patented catalytic conversion
technology, in combination with a short-range attractant.
Attracted by the CO2and short-range attractants, mosquitoes are drawn to the Mosquito
Magnet Patriot Plus. When they reach the trap, mosquitoes are vacuumed into a bug bag
by our patented Counterflow Technology™, where they dehydrate and die within 24
hours.
The Mosquito Magnet Patriot Plus is silent and odorless. When properly placed in your
yard, the trap begins working immediately. The Mosquito Magnet Patriot Plus only
targets mosquitoes, not beneficial insects such as butterflies, bees or moths.
Model No.: Patriot Plus
Serial No.:
Type of Gas: Propane
Manifold Pressure: 2.7 kPa (11’WC)
Minimum Gas Supply Pressure: 2.7 kPa (11’WC)
Input Rating: 685 kJ/Hr. (759 Btu/Hr).
Minimum Clearances: 50-60 cm (20 – 24”)
Patented Counterflow Technology™

Mosquito MagnetPatriot Plus
Page 11 of 21
SAFETY INSTRUCTIONS
Please read and follow all safety instructions and warnings.
Children and adults should be alerted to the hazards of high surface temperatures and
should stay away to avoid burns or clothing ignition.
Young children should be carefully supervised when they are in the area of the heater.
KEEP OUT OF REACH OF CHILDREN
Clothing or other flammable materials should not be hung from the heater, or placed on
or near the heater.
Note: Some or all of the following required safety instructions for propane powered
devices may apply to your trap. Allow trap to cool for 5 minutes before re-starting.
WARNING: Improper installation, adjustment, alteration, service or maintenance can
cause injury or property damage. Read the installation, operating and maintenance
instructions thoroughly before installing or servicing the trap.
CAUTION: The gas pressure regulator provided with this appliance must be used. This
regulator is set for an outlet pressure of 2.7 kPa (11” WC). The minimum inlet gas supply
pressure is 2.7 kPa (11” WC) from regulator.
This unit is not intended to be installed in or on recreational vehicles and/or boats.
The gas supply must be turned off at the LP-Gas supply cylinder when this
appliance is not in use.
The installation must conform with local codes or, in the absence of local codes,
with the National Fuel Gas Code, ANSI Z223. 1-1998 for US and with the CAN1-
B149 for Canada.
To test for a gas leak, place soapy water around the connector, regulator, and gas
hose assembly. If bubbles appear, there is a gas leak.
Inspect the hose before each use of the unit. If it is evident there is excessive
abrasion or wear, or the hose is cut, it must be replaced prior to the unit being put
into operation. The replacement hose shall be that specified by the manufacturer.
The trap is equipped with an internal spark ignition device. Failure to follow
starting procedure will result in the trap not starting.
Installation and repair should be done by a qualified service person (find service
centers on www.mosquitomagnet.com). The heater should be inspected before use

Mosquito MagnetPatriot Plus
Page 12 of 21
and at least annually by a qualified service person. More frequent cleaning may be
required as necessary. It is imperative that the control compartment, burners, and
circulating air passageways of the heater be kept clean.
Maintain adequate clearances of 50-60 cm (20”–24”) around air openings into the
combustion chamber, clearances from combustible material, provisions for
accessibility and for combustion and ventilating air supply. Keep the trap area
clear and free from combustible materials, gasoline, and other flammable vapours
and liquids. The appliance is not to be used in locations where flammable vapour
or explosive dust is likely to exist.
Do not obstruct the flow of combustion and ventilation air.
Keep the ventilation openings of the cylinder enclosure free and clear from debris.
Clean the trap with a water damp cloth, if necessary.
A maximum of a 9 kg (20 lb.) LP-Gas cylinder shall be used.
The LP-Gas cylinder must be provided with a shut-off valve terminating in an LP-
Gas supply cylinder valve outlet specified for Connection No. 510 in the Standard
for Compressed Gas Cylinder Valve Outlet and Inlet Connections, ANSI/CGA-V-
1-1977.
The LP-Gas cylinder supply system must be arranged for vapour withdrawal and
the cylinder must include a collar to protect the cylinder valve.
The LP-Gas cylinder used shall be constructed and marked in accordance with the
specifications for LP-Gas cylinders of the National Standard of Canada
CAN/CSA-B339.
The trap shall be used outdoors only in a well ventilated space and shall not be
used in a building, garage, or any other enclosed area.
The LP-Gas cylinder must be disconnected and removed from the appliance, if
the appliance is stored indoors.
LP-Gas cylinders must be stored outdoors in a well-ventilated area out of reach of
children.
Disconnected cylinders must have threaded valve plugs tightly installed and must
not be stored in a building, garage, or any other enclosed area.

Mosquito MagnetPatriot Plus
Page 13 of 21
The pressure regulator and hose assembly supplied with this appliance must be
used for connection to the LP-Gas cylinder. Replacement pressure regulators and
hose assemblies must be specified by the manufacturer.
Avoid improper use of extension cords. Keep connections away from moisture
and avoid damage to the cord.
If the supply cord is damaged, it must be replaced by the manufacturer or its
service agent or a similarly qualified person in order to avoid hazard.
Please contact Customer Care if you have any questions at: 1-800-953-5737 or visit
www.mosquitomagnet.com.
Warning: SHOCK! An electric shock hazard may exist if water from a garden hose is
directed at the Mosquito Magnet Patriot Plus. Route the power cord in the safest possible
manner to avoid personal injury.
PRINCIPAL PARTS OF MOSQUITO MAGNET® PATRIOT PLUS
[ILLUSTRATION OF UNIT AND COMPONENTS]
Mosquito Magnet® Patriot Plus
Power Head (1)
Trumpet (1)
Support Pole (1)
Support Leg (1)
Base Propane Tank Cradle (1)
Parts Included
Bug Bag (Already Installed)
Mosquito Magnet® Octenol Mosquito Attractant Cartridge (Added Attractant)
15 m (50') Power Cord
Quick Clear Adapter
10 Metal Power Cord Burying Clips
ASSEMBLY INSTRUCTIONS
Trap Assembly
Step 1: Place base upside down on a flat surface, slide U-shaped support legs into slots
on base until they lock in place.
Step 2: Turn base and leg assembly right-side-up and place support pole into cavity on
base.

Mosquito MagnetPatriot Plus
Page 14 of 21
Step 3: Place trap power head onto pole. Press down firmly with two hands to secure.
Step 4: Completed assembly should have the front of power head in the same direction as
base U-shaped legs.
Step 5: Insert attractant as directed in attractant packaging.
Step 6: Place the base of the propane tank into the molded cradle supplied.
Step 7: Making sure propane tank is fully closed, attach propane regulator hose to
propane tank. Secure tightly by hand. Do not use tools.
Step 8: Plug power connector into the trap power slot located on the back of the power
head.
Step 9: Plug Adapter into properly grounded electrical outlet.
Step 10: Turn propane valve on slowly. See the Propane Tank Installation section.
SET-UP
Trap Placement
1. Determine the direction of the prevailing wind. Check local weather patterns if you are
unsure.
2. Stand in the center of the area you are trying to protect and look toward the prevailing
wind.
3. Proper placement of the trap will be 9-12 m (30-40 ft.) in front of you, within 1.5-1.8
m (5-6 ft) of mosquito habitat (i.e., standing water, bushes, flowerbeds, treeline,
marshbed, etc.). Ensure that trap is not directly against any blockades such as buildings,
fences, etc.
4. It is recommended that the trap be placed in the shade.
5. Do not place trap directly above a water source (sprinklers, hose, etc.).
6. Trap must be placed on level ground to avoid tipping or uneven propane distribution.
7. Go to www.mosquitomagnet.com to build your own yard diagram.
Burying the Power Cord
Make sure unit is unplugged and in proper position. Use the Cord Burying Clips supplied.
Place clips approximately 1 m (3 feet) apart, press into ground by hand making sure not
to damage power cord. For alternate placement, follow steps illustrated below.
1. Use straightedge shovel or garden spade and dig a trench about 8-10 cm (3”- 4”) deep
from power source to trap.
2. Place cord into trench carefully stretching as you go to remove any twists in cord.

Mosquito MagnetPatriot Plus
Page 15 of 21
3. Use cedar shingle or folded cardboard to place cord into bottom of trench. Recover the
trench with removed soil.
Propane Tank Installation
1. After trap is placed in its ideal location, place propane tank onto the molded cradle.
2. Make sure propane tank is fully closed. Attach propane regulator hose to propane tank.
Secure tightly by hand. Do not use tools.
3. Turn propane on by slowly turning valve counter-clockwise. Take care not to turn too
quickly to avoid engagement of safety valve.
DO NOT MOVE TRAP WITH TANK ATTACHED!
TANK MUST BE DISCONNECTED FROM REGULATOR BEFORE TRAP IS
RELOCATED TO AVOID DAMAGE TO REGULATOR AND/OR TRAP. BE
ADVISED, DAMAGE CAUSED FROM FAILURE TO COMPLY WITH THIS
INSTRUCTION IS NOT COVERED UNDER WARRANTY.
Octenol Attractant Installation
See Mosquito Magnet® Octenol Mosquito Attractant label for installation, use, storage
and disposal instructions.
INSTRUCTIONS
**READ MANUAL BEFORE STARTING**
Starting Instructions
It is recommended that you read the entire manual before starting the Mosquito Magnet®
Patriot Plus trap.
1. Insert attractant in compartment per instructions in attractant packaging.
2. Connect regulator to propane tank (See the Propane Tank Installation section).
3. Plug power connector into the trap.
4. Plug AC adapter into electrical outlet. (To avoid the risk of electrical shock, connect
only to properly grounded outlets.) Adapter unit is not intended to be mounted.
5. Slowly turn propane tank valve on.
6. Turn rocker switch to “on” position.
7. The red light on the switch will flash for up to 20 minutes (warm up phase).
8. Once the light stops flashing and is solid, the Mosquito Magnet Patriot Plus is fully
operational.
NOTE: Should you experience an interruption of power, be sure to restart trap.
Shut Down Instructions
To shut down the Mosquito Magnet Patriot Plus, simply close the valve on the propane
tank and switch to the “off” position.

Mosquito MagnetPatriot Plus
Page 16 of 21
When Not In Use
If the unit is not in use, the gas must be turned off at the supply cylinder. Storage of this
unit indoors is permissible only if the cylinder is disconnected and removed. Cylinders
must be stored outdoors, out of reach of children and must not be stored in a building,
garage or any other enclosed area.
End of Season Storage
Push ON/OFF switch to OFF position to shut down the trap. The LED light will go out
and the fan will continue running until trap is cool. Close the propane tank valve and
disconnect regulator.
Any open Mosquito Magnet® Octenol Mosquito Attractant should be removed and
discarded. See attractant label for disposal instructions. The bug bag should also be
discarded prior to storing the trap.
STORAGE: The trap should be stored indoors in a garage or shed in the off-season.
Cover trumpet to prohibit insects from nesting. Cover unit with trap cover available at
www.mosquitomagnet.com or with a tarp and secure tightly at the bottom to keep out
dust, spider webs and other debris.
NOTE: It is recommended that you use the Quick Clear adapter before seasonal storage
to avoid build-up of contaminants during off-season (see Easy Quick Clear Valve
section).
For Optimal Results (unit must run for 24 hours/day)
Allow trap to cool for 5 minutes before re-start.
Never spray insecticide in or around trap.
Trap can be left running in the rain.
If using lime or fertilizer compounds, be sure to shut down the trap first to prevent
dust or fine mist from being drawn into trap and clogging bug bag.
Warning: Improper installation, adjustment, alteration, service or maintenance can cause
injury or property damage. Read the installation, operating and maintenance instructions
thoroughly before installing or servicing this equipment.
Caution: The gas pressure regulator provided with this appliance must be used. This
regulator is set for an outlet pressure 2.7 kPa (11.0’ WC). water column.
The gas supply must be turned off at the LP-Gas supply cylinder when this appliance is
not in use.
Leader in 360° Customer Support
• Customer Care Hotline: [phone]
• Online Product Registration Available
• Certified Service Locations – Information Available at www.mosquitomagnet.com

Mosquito MagnetPatriot Plus
Page 17 of 21
MAINTENANCE
Maintenance Schedule
21 Day Maintenance Cycle -Refill propane. (Propane lasts approximately 21 days
with 24-hour/7-days operation.)
Replace short-range attractant cartridge. See Mosquito Magnet® Octenol
Mosquito Attractant label for instructions
Empty or replace bug bag.
Utilize the Quick Clear adapter at every tank change.
Periodically wipe down the outside of the trap with a clean, water damp
cloth.
Propane Tank Changing Tips
When attaching the regulator knob to a tank after a tank change, be sure to fully tighten
the regulator knob onto the tank. No need to use tools, but do turn the knob as far as
possible by hand. When this is done, loosen the knob 1/4 turn, then re-tighten to
maximize seal.
The purpose for this is to fully engage the regulator onto the tank. If the regulator is not
fully engaged, the flow of gas may be restricted to the point where the trap will show a
gas empty code. If this occurs, press the off button, close the tank valve, and remove
regulator from the tank. Re-attach the regulator and try again.

Mosquito MagnetPatriot Plus
Page 18 of 21
EASY QUICK CLEAR VALVE
Important: Extinguish all smoking materials prior to use of Easy Quick Clear Valve. Do
not stand directly behind the Quick Clear cartridge during operation.
Use of PROTECTIVE eyewear is recommended.
Quick Clear is recommended for regular maintenance to remove built-up contaminants.
Recommended for use at every tank change. Also recommended for use before seasonal
storage to avoid build up of contaminants during the off-season. Instructions for “Easy
Quick Clear Valve” maintenance procedure shall be provided on a label attached to trap
where easily visible by user.
The Easy Quick Clear Valve is a threaded knob located on the back of your trap. It
should be used with the adapter included with your trap, and a threaded Quick Clear
cartridge available on our website at: www.mosquitomagnet.com or at your local
hardware or home improvement store.
1. Important: Shut down your trap. Let fan run until it stops (about 5 minutes).
2. Close the propane tank valve by turning to the “OFF” position. (Turn the tank
valve clockwise.)
3. Remove the protective cap from Easy Quick Clear valve located in the back of the
trap.
4. Hand-screw the Quick Clear adapter on to Easy Quick Clear valve, until finger
tight.
5. Hand-screw the Quick Clear cartridge into the Quick Clear adapter clockwise
until hand tight while holding the adapter in place. Important: Do not over-
tighten.
6. While holding the adapter in place slowly unscrew Quick Clear cartridge up to
1/4 turn only in counter clockwise direction from the Quick Clear adapter only.
The strong flow of compressed air lasts approximately 45 seconds. Be sure to
allow Quick Clear cartridge to run out completely. (Hissing will stop when
cylinder is empty. Quick Clear cartridge will be cold to the touch.)
7. Unscrew the Quick Clear cartridge to remove. Discard empty Quick Clear
cartridge after use, it is not reusable or refillable.
8. Unscrew the Quick Clear adapter to remove.
Use caution when removing Quick Clear adapter and cartridge, as some
compressed air may come out at this time.
Remember to keep the Quick Clear adapter for future use.
9. Replace Easy Quick Clear Valve protective cap, and proceed with normal start up
of your trap. If use of Easy Quick Clear valve feature does not resolve starting
trouble, contact Customer Care 1-800-953-5737.

Mosquito MagnetPatriot Plus
Page 19 of 21
TROUBLESHOOTING GUIDE
Problem Possible Causes Solutions
Your Mosquito
Magnet® Patriot
Plus won’t start.
1. Is the propane tank
empty?
2. If propane tank is new, it
may have air blockage, has
it been purged?
3. If tank has been opened
too quickly, security check
valve may have triggered.
4. Is the power cord plugged
in?
5. Is there a loose
connection?
1. Weigh tank and check against
“empty” weight written on tank.
2. Bring tank to filling location. Air may
be in fuel line. Ask for tank to be
purged.
Hint: If you have another propane
powered device operating on a
standard, 9 kg (20 lb) propane tank, try
hooking that tank up to the trap to verify
that the issue is with your tank.
3. Disconnect the regulator from the
tank and reconnect. Then open the
regulator valve slowly.
4. Verify all electrical connections.
Make sure you are using the correct
power requirements for your unit.
5. Make sure regulator is fully engaged,
and propane tank valve is fully open.
The Mosquito
Magnet Patriot
Plus won’t stay
running
1. The tank regulator isn’t
fully engaged.
2. Propane tank may be
empty or need to be purged.
3. Regulator is not fully
engaged
4. Fuel line may be blocked
by propane contaminants.
1. Make sure the regulator is fully
engaged, and propane tank valve is fully
open.
2. Go through above steps 1, 2 and 3.
3. See tank changing tips section. Hand
tighten the propane tank regulator until
slightly snug.
4. Follow Easy Quick Clear Valve
instructions.
Low or no catch 1. Mosquitoes may not be
out yet.
2. Trap improperly placed.
1. Verify temperature is consistently
above 10°C (50°F).
2. Follow steps in the “Trap Placement”
section of your owner’s manual.
3. Keep trap in constant operation 24
hours/day, 7 days/week.

Mosquito MagnetPatriot Plus
Page 20 of 21
Customer Care
**Please have your serial number, date of purchase & model type available**
All of us at Woodstream Canada Corporation want you to get complete satisfaction from
your trap. Should you have any problems you cannot resolve, simply call one of our
trained Customer Service Representatives at 1-800-953-5737 or visit
www.mosquitomagnet.com. We will help you get up and running.
