Motorola 3200 User manual

1
2
2
1

WELCOME
Congratulations on your purchase of a cellular
telephone from
Motorola , the world leader in
cellular technology.
All Motorola cellular telephones are designed
and manufactured to meet Motorola's exacting
specificationsandworld-classqualitystandards.
This product is no exception.
This cellular telephone has been manufactured
to withstand rigorous durability tests including
temperature, humidity, shock, dust, vibration
and a drop test.
Ourtestingstandards,ourcommitmentto Total
Customer Satisfaction and over sixty five years
of experience in personal communications
means you can depend upon the quality of this
Motorola product.

WELCOME

To Turn On
1.Insert SIM Card. 2.Turn on: 3.If prompted: PIN Code & Unlock Code
To Make a Call
1.Check is off.
2. Telephone number (No dial tone).
3.
4.To end the call:
Quick User Guide

To Answer a Call
To end the call:
To Recall a Short-number
By short-number: Short-number
By name: First letter
Emergency Call
Inform operator about your subscriber number, position and the type of emergency. Stay by the telephone.
Quick User Guide

Press out and keep in a secure place
SIM Card Data
Subscriber number: PIN Code * (4 to 8 digits): Unblocking Code (8 digits): Barring Password * (4 digits): * Changeable

Press out and keep in a secure place
Telephone Data
Serial number: Unlock Code * (3 or 4 digits): Security Code ** (6 digits): * Changeable, upon delivery = 1 2 3 ** Changeable, upon delivery = 0 0 0 0 0 0

SAFETY
i
IMPORTANT
READ THIS INFORMATION BEFORE USING
YOUR
PORTABLE/PERSONAL
CELLULAR TELEPHONE
First introduced in 1984, the portable cellular
telephone is one of the most exciting and
innovative electronic products ever
developed. With it you can stay in contact with
your office, your home, emergency services,
and others.
General
For the safe and efficient operation of your
phone, observe these guidelines.
Your portable/personal cellular telephone is a
radio transmitter and receiver. When the
phone is ON, it sends out and receives radio
frequency (RF) energy. The phone operates
in the GSM frequency range of 890MHz to
960MHz (or DCS 1800 frequency range of
1710MHz and 1880MHz) and employs
commonly used Time Division Multiple
Access (TDMA) digital modulation techniques.
When you use your phone, the cellular
system handling your call controls the power
level at which your phone transmits. The
pulsed power level can range from 0.02 of a
watt to 2 watts.

SAFETY
ii
Exposure to Radio Frequency Energy
Research on health effects from RF energy
has focused for many years on FM radio
technology. That research and studies
regarding newer radio technologies, such as
TDMA, have found no credible scientific
evidence that adverse health effects result
from the use of a portable cellular telephone.
In 1991 the Institute of Electrical and
Electronic Engineers (IEEE), and 1992 the
American National Standards Institute (ANSI)
adopted the 1982 ANSI Standard for safety
levels with respect to human exposure to RF
energy.
Over 120 scientists, engineers, and
physicians from universities, government
health agencies, and industry, after reviewing
the available body of research, developed this
updated Standard. In March, 1993 the
Federal Communications Commission (FCC)
of N. America proposed the adoption of this
updated Standard. The design of your phone
complies with this updated Standard. Of
course, if you want to limit RF exposure even
further than the updated ANSI Standard, you
may choose to control the duration of your
calls and operate your phone in the most
power efficient manner.

SAFETY
iii
Efficient Phone Operation
For your phone to operate at the lowest power
level, consistent with satisfactory call quality:
If your phone has an extendable antenna,
extend it fully. Some models allow you to
place a call with the antenna retracted.
However, your phone operates more
efficiently with the antenna fully extended.
Hold the phone as you would any other
telephone. While speaking directly into the
mouthpiece, position the antenna up and over
your shoulder.
Do not hold the antenna when the phone is
"IN USE". Holding the antenna affects call
quality and may cause the phone to operate
at a higher power level than needed.
Antenna Care and Replacement
Do not use the phone with a damaged
antenna. If a damaged antenna comes into
contact with the skin, a minor burn may result.
Replace a damaged antenna immediately.
Consult your manual to see if you may
change the antenna yourself. If so, use only a
manufacturer-approved antenna. Otherwise,
have your antenna repaired by a qualified
technician.
Use only the supplied or approved antenna.
Unauthorised antennas, modifications or
attachments could damage the phone and
may contravene local RF emission regulations
or invalidate type approval.

SAFETY
iv
Driving
Check the laws and regulations on the use of
cellular telephones in the areas where you
drive. Always obey them. Also, when using
your phone while driving, please:
• give full attention to driving,
• use hands-free operation,
if available, and
• pull off the road and park before
making or answering a call if driving
conditions so require.
Electronic Devices
Most electronic equipment, for example in
hospitals and motor vehicles is shielded from
RF energy. However, RF energy may effect
some malfunctioning or improperly shielded
electronic equipment.
Vehicle Electronic Equipment
Check with your vehicle manufacturer's
representative to determine if any on board
electronic equipment is adequately shielded
from RF energy.
Medical Electronic Equipment
Consult the manufacturer of any personal
medical devices (such as pacemakers,
hearing aids, etc) to determine if they are
adequately shielded from external RF energy.

SAFETY
v
Turn your phone OFF in health care facilities
when any regulations posted in the area
instruct you to do so. Hospitals or health care
facilities may be using RF monitoring
equipment.
Aircraft
Turn your phone OFF before boarding any
aircraft.
• Use it on the ground only with crew
permission.
• Do not use in the air.
To prevent possible interference with aircraft
systems, Federal Aviation Administration
(FAA) regulations require you to have
permission from a crew member to use your
phone while the plane is on the ground. To
prevent interference with cellular systems,
local RF regulations prohibit using your phone
whilst airborne.
Children
Do not allow children to play with your phone.
It is not a toy. Children could hurt themselves
or others (by poking themselves or others in
the eye with the antenna, for example).
Children could damage the phone, or make
calls that increase your telephone bills.

SAFETY
vi
Blasting Areas
To avoid interfering with blasting operations,
turn your unit OFF when in a "blasting area"
or in areas posted: "turn off two-way radio".
Construction crews often use remote control
RF devices to set off explosives.
Potentially Explosive Atmospheres
Turn your phone OFF when in any area with a
potentially explosive atmosphere. It is rare,
but your phone or its accessories could
generate sparks. Sparks in such areas could
cause an explosion or fire resulting in bodily
injury or even death.
Areas with a potentially explosive atmosphere
are often, but not always, clearly marked.
They include fuelling areas such as petrol
stations; below decks on boats; fuel or
chemical transfer or storage facilities; and
areas where the air contains chemicals or
particles, such as grain, dust, or metal
powders.
Do not transport or store flammable gas,
liquid, or explosives, in the compartment of
your vehicle which contains your phone or
accessories.
Before using your phone in a vehicle powered
by liquefied petroleum gas (such as propane
or butane) ensure that the vehicle complies
with the relevant fire and safety regulations of
the country in which the vehicle is to be used.

SAFETY
vii
This Cellular Telephone complies with
all applicable RF safety standards.
This cellular telephone meets the standards
and recommendations for the protection of
public exposure to RF elctromagnetic energy
established by governmental bodies and other
qualified organisations, such as the following:
•Verband Deutscher Elektroingenieure
(VDE) DIN-0848
•Directives of the European
Community, Directorate General V in
Matters of Radio Frequency
Electromagnetic Energy
•National Radiological Protection
Board of the United Kingdom.
GS-11, 1988.
•American National Standards Institute
(ANSI)/IEEE. C95. 1-1992
•National Council on Radiation
Protection and Measurements
(NCRP). Report 86
•Department of Health and Welfare
Canada, Safety Code 6.

MANUAL UPDATES
Overnight Charger
The charger's slot accepts batteries alone or
while attached to the telephone.
Please see table for approximate recharge
times.
Approx. Recharge Time.Battery Type
The yellow lamp on the charger indicates that
the telephone or battery is properly inserted
and charging.
700 mAh
1500 mAh 5 hours
10 hours

CONTENTS
Page 1
ESSENTIAL INFORMATION
1
INTRODUCTION...........................................5
DISPLAY, INDICATORS AND KEYPAD.......5
Display .....................................................5
Indicators .................................................5
Keypad ....................................................6
Volume Control ........................................8
BASIC OPERATION .....................................9
About the SIM Card .................................9
Inserting the SIM Card.............................9
On/Off ....................................................11
Entering the PIN Code...........................12
Electronic Lock ......................................13
Automatic Lock ......................................14
Placing a Call.........................................14
Receiving a Call .....................................14
Call in Absence......................................15
ADVANCED CALL PLACEMENTS .............15
Automatic Redial....................................15
International Calls ..................................16
Emergency Calls....................................16
SHORT-NUMBERS.....................................17
Short-number Programming ..................17
Entering a Name....................................18
Entering the Short-number ....................18
Programming Examples ........................19
Short-number Recalling/Dialling ............20
Speed Dialling........................................22
Short-number Clearing ..........................22
Last Number Entered.............................22

CONTENTS
Page 2
MEMORY FEATURES ................................23
Notepad .................................................23
Last Number Dialled ..............................23
SYSTEM REGISTRATION..........................24
Automatic Roaming ...............................24
Manual Roaming....................................25
Displaying the Preferred List..................26
Changing the Preferred List...................26
MENU OPERATION....................................27
Overview Menu Headings and Features28
Status Review........................................30
Master Reset .........................................31
Master Clear ..........................................31
INTERFACE FEATURES............................32
Silent Ringer ..........................................32
Silent Keypad.........................................33
Tone Signalling Features.......................33
Silent Notepad .......................................33
Memory Linking .....................................34
Pauses in Memory .................................34
DTMF Signalling ....................................35
Long Tone DTMF...................................36
PIN Code Enable/Disable ......................36
Language Selection ...............................37
CALL MONITORING ...................................37
One Minute Audible Call Timer..............37
Programmable Audible Call Timer.........38
One Time - Prog. Audible Call Timer.....38
Visual Call Timers and Meters...............38
To Display Call Timers...........................40
To Display Call Meters...........................40
Programming of Rates...........................41
Automatic Monitor Displays ...................41
ADVANCED INFORMATION
2

CONTENTS
Page 3
CALL RESTRICTIONS................................42
Restricted Keypad Dialling.....................42
Restricted Memory Access ....................43
Restricted Incoming Calls ......................43
Restricted Phone Number Length .........44
Full Service ............................................44
CALL BARRING ..........................................45
Activating Call Barring ...........................46
Cancelling Call Barring ..........................47
Status of Call Barring.............................47
Changing Call Barring Password...........48
Special Call Barring Messages..............48
CALL FORWARDING .................................49
Activating Call Forwarding .....................50
Cancelling Call Forwarding ....................51
Status of Call Forwarding ......................51
Special Call Forwarding Messages .......52
DISPLAY SIGNAL STRENGTH ..................53
CHANGING THE UNLOCK CODE..............53
CHANGING THE PIN CODE ......................54
UNBLOCKING THE SIM CARD..................55
CHANGING THE SECURITY CODE ..........56
SHORT MESSAGE SERVICE (SMS) .........57
Automatic Cell Broadcast ......................57
Point to Point Short Messages ..............59
Receiving Point to Point Messages .......59
Storage of Point to Point Messages ......60
Reading Point to Point Messages..........60
Clearing Messages From Memory.........61
Embedded Callback Numbers ...............62
Short Message Alert Tone .....................62
ADVANCED INFORMATION
2

CONTENTS
Page 4
ADVANCED INFORMATION
2
CALL WAITING AND CALL HOLDING .......63
Call Waiting............................................63
Call Holding ...........................................64
Call Hold and Waiting Combinations .....64
Call Hold and Making New calls ............66
Call Hold and Call Waiting Messages....66
Emergency Calls and Call Hold/Wait.....67
ACCESSORIES AND OPTIONS
3
BATTERY OPERATION..............................69
Battery Maintenance..............................69
Replacing the Battery ............................69
Battery Meter .........................................70
Battery Saving Feature (DTX) ...............70
BATTERY CHARGING ...............................71
Overnight Internal Charger ....................71
Single Pocket Desktop Rapid Charger ..72
BATTERY SAVER.......................................72
HANDS FREE CAR KIT ..............................73
Insertion / Removal................................74
Car Kit Functions ...................................75
Handsfree Calls .....................................75
Automatic Answer..................................76
Safety Timer ..........................................77
INDEX .........................................................79
