68014368001.book Page 1 Tuesday, August 24, 2010 3:19 PM

Quick Start Guide
1
Congratulations on your purchase of the
Motorola XT5. This Quick Start Guide will help
you go through the basic features of your phone
to get you started. For more detailed information,
see the User Guide which you can download from
www.motorola.com/support.
What’s in the box?
Your package comes with the following items. If
any are missing, please contact your retailer.
Important: A headset has been provided for
use with your mobile phone. This headset is the
only model headset that is warranted by Motorola
for operation with your phone.
Motorola
XT5
AC Adapter Battery
Quick Start
Guide Headset
L
R
68014368001.book Page 1 Tuesday, August 24, 2010 3:19 PM

Quick Start Guide
2
Your phone
Home
Call
Trackball
Flash
5.0 Megapixel
camera
Volum e:
Slide up/
down to
increase/
decrease
volume
Shutter
Power
Speaker
Microphone
End
Back
Touch
screen
Earpiece
Micro USB
connector
Headset jack
Strap
holes
Browser
Menu
Back cover
68014368001.book Page 2 Tuesday, August 24, 2010 3:19 PM

Quick Start Guide
3
Installing SIM card, battery
and memory card
Caution: before assembling, charging or using
your phone for the first time, please read the
important legal and safety information at the back
of this guide.
1. Open the back cover.
2. If the battery is inserted,
lift and remove the
battery.
3. Insert the SIM card.
Make sure the gold
contacts are facing down
and the cut-off corner is
facing towards the battery
slot.
1
2
68014368001.book Page 3 Tuesday, August 24, 2010 3:19 PM

Quick Start Guide
4
4. Insert the memory card
with the gold contacts
facing down.
5. Push the memory card
until it clicks into place.
Note:
• To remove the memory card, push it down
to eject it from the slot.
• Do not remove the memory card while the
phone is turned on. Sudden removal of
the memory card may cause data loss or
unpredictable system crashes.
6. Insert the battery. Make
sure the contacts of the
battery are aligned with
the connectors on the
battery slot.
7. Secure the hooks on the
back cover with
designated holes on the
phone and close the back
cover.
1
2
68014368001.book Page 4 Tuesday, August 24, 2010 3:19 PM

Quick Start Guide
5
Charging the battery
1. Open the micro USB
connector cover.
2. Connect the USB
charger to the phone.
3. Plug the USB charger
into a wall outlet to start
charging.
Note: to fully charge battery, charge it for
3 hours. Battery life will vary
depending on the applications used.
Note: the battery can also be charged
when you connect your phone to a
computer using the USB cable.
LED indicators
Your phone has two LED indicators: green and
red.
LED Location Indication
Green
(solid)
Call key Battery is fully
charged.
Red
(solid)
End key Battery is
charging.
68014368001.book Page 5 Tuesday, August 24, 2010 3:19 PM

Quick Start Guide
6
First start up
After installing the SIM card and charging the
battery, you are now ready to turn on the phone -
press and hold the power key on the top of the
phone.
The Home screen
From the Home screen, you can quickly access
common features and view notifications of missed
calls, receive messages and check connection
status.
Tap the Application Drawer to open the
application menu.
For more information about the home screen,
please refer to the user guide.
Status Icons
Application
Drawer
Tap an icon to
open it.
Flick left/right
to show more
home screen
panels.
Notifications - Flick
down to display
68014368001.book Page 6 Tuesday, August 24, 2010 3:19 PM

Quick Start Guide
7
Making your first call
On the Home screen, tap Phone ().
To make a call
1. Enter the phone
number using the
keypad.
2. Tip: tap to erase a
wrong number. Tap
and hold to erase
the entire number.
3. Press Call or tap
.
4. To end the call, press
End.
To answer a call
To answer a call, press Call .
68014368001.book Page 7 Tuesday, August 24, 2010 3:19 PM

Quick Start Guide
8
Entering information
You can enter information using the on-screen
keyboard.
To use the on-screen keyboard
When an application requires text input, tap the
input box to display the on-screen keyboard.
1. Tap the input box to
display the on-screen
keyboard.
Note: to toggle
between upper and
lowercase, tap . To
display the numeric
and the symbols
keyboard, tap .
Tap
to toggle
back.
2. Tap keys on the keyboard to enter
characters.
Note: if word completion is activated, the
screen displays a list of suggested words
as you type the characters.
68014368001.book Page 8 Tuesday, August 24, 2010 3:19 PM

Quick Start Guide
9
Contacts
To add a contact
1. On the Home screen,
tap Phone.
2. Go to the Contacts
tab.
3. Tap Menu > New
Contact.
4. Enter contact
information, such as
name, phone
number, email
address etc. Tap
Done to save the
contact or tap Revert to exit without saving
the changes.
Note: By default, new contacts are saved
in the phone memory. You can import
phone contacts from the SIM card by
pressing Menu > Import/Export.
To import contacts
1. On the Home screen, tap Phone.
2. Go to the Contacts tab.
3. Tap Menu > Import/Export.
4. Select to import contacts from the
SIM Card or SD Card.
68014368001.book Page 9 Tuesday, August 24, 2010 3:19 PM

Quick Start Guide
10
5. Select contacts to import or tap Menu again
to select Import all.
Sending a text message
1. On the Home screen,
tap Messaging.
2. Tap New message.
3. In the To field, enter
the phone number or
choose a contact.
4. Type message in the
Type to compose
field.
5. Tap Send.
Sending a
multimedia message
A multimedia message (MMS) can contain
graphic and audio files.
1. On the Home screen, tap Messaging.
2. Tap New message.
3. Enter the phone number or email address
of the recipient in the To field, then type the
Subject.
4. To add components, tap Menu > Attach to
attach pictures or videos.
5. Tap Send.
68014368001.book Page 10 Tuesday, August 24, 2010 3:19 PM

Quick Start Guide
11
Sending a voice MMS
1. On the Home screen,
tap Messaging.
2. Tap New message
>Menu > Attach
>Record audio.
3. Tap to record your
message.
4. Tap to stop
recording.
• Tap to play the
recording.
• Tap Save to store the recording.
• Tap Discard to delete the recording.
• After storing the recording, you can also
tap to Play, Replace and Remove the
recording.
5. Enter the phone number in the To field. The
voice message can be sent to up to 20
recipients.
6. Compose your message and tap Send.
68014368001.book Page 11 Tuesday, August 24, 2010 3:19 PM

Quick Start Guide
12
Setting up Wi-Fi™
Connect to a wireless network to browse Internet.
1. On the Home screen, tap > Settings.
2. Tap Wireless & networks to access the
Wireless Manager.
3. Tap Wi-Fi to activate.
4. Tap Wi-Fi settings > Network notification
to start detecting networks. The available
networks will then be listed.
5. Select an entry from the list of detected
networks to add a connection.
Note: Connecting to a secured network
will prompt for the password. Enter the
password then tap Connect.
68014368001.book Page 12 Tuesday, August 24, 2010 3:19 PM

Quick Start Guide
13
Setting up an email account
1. On the Home screen,
tap > Email
2. Choose from existing
types of email (e.g.
Yahoo
®
, Gmail
TM
, etc).
3. Enter your email
address and
Password. Tick Save
Password, then tap
Next.
4. The phone will
automatically retrieve
the email settings.
Note: If successful, the email setup wizard
displays a successful message, tap Next. If
email settings are not found, tap Manual
setup.
5. Enter Your name and the Account display
name, then tap Next.
6. Tap Done.
68014368001.book Page 13 Tuesday, August 24, 2010 3:19 PM

Quick Start Guide
14
Sending and receiving emails
Composing and sending emails
1. On the Home screen,
tap > Email, then
tap an email account.
2. Tap Menu
>Compose.
3. In the To field, enter
the recipient’s email
address.
4. Enter Subject.
5. Compose your email.
6. Tap Send.
Adding attachments to an email
message
1. Tap Menu > Add attachment.
2. Select items to attach.
Receiving emails
Emails are automatically received in your Inbox
folder when your phone is connected to a
wireless network.
1. On the Home screen, tap > Email, then
tap an email account.
2. Tap Menu > Refresh.
68014368001.book Page 14 Tuesday, August 24, 2010 3:19 PM

Quick Start Guide
15
Using the browser
To open a web page
1. Tap Browser ( ) or tap > Browser.
2. Tap the address bar.
3. Type the URL then tap .
Tap Menu to see more options.
To quickly browse Internet from the
Home screen
From the Home screen, you can browse internet
right away with Google
TM
search.
1. Tap the Google
TM
search
widget, then type text to search.
2. Tap .
Touch the web
page and
drag/flick it to
scroll.
68014368001.book Page 15 Tuesday, August 24, 2010 3:19 PM

Quick Start Guide
16
Using Bluetooth
TM
1. On the Home screen,
tap > Settings.
2. Tap Wireless &
networks.
3. Tap Bluetooth to
activate.
4. To search for a new
device, tap Bluetooth
settings > Scan for
devices.
5. Tap an entry from the
list of detected.
6. Enter the Passcode to start pairing, then
tap Next.
Note: the passcode you enter on your
phone must be the same passcode to be
entered on the other bluetooth device.
7. Tap Done.
68014368001.book Page 16 Tuesday, August 24, 2010 3:19 PM

Quick Start Guide
17
Taking photos and videos
This phone is equipped with a 5.0 megapixel
camera to take photos and videos.
To take a photo
1. On the Home screen, tap > Camera.
The screen automatically switches to
landscape view.
2. Aim the phone at the subject, then half
press the Shutter key or tap and hold to
focus.
3. The focus frame turns green to indicate
focus is set, fully press the Shutter key or
tap to take the shot.
To record video
1. On the Home screen, tap > Camcorder.
2. Aim the phone at the subject.
68014368001.book Page 17 Tuesday, August 24, 2010 3:19 PM
