the motorola ROKR model E1 featuring iTunes®

1
HELLOMOTO
Introducing your new Motorola ROKR model E1 GSM wireless phone. Here’s a quick anatomy
lesson.
032385o.eps
Smart Key
Camera Key
Right Soft
Key
Volume Keys
5-Way
Joystick with
Center Select
Left Soft Key
iT unes
® Key
Open Menus
Stereo
Speakers
(both sides)
Turn on &
off, hang up,
exit menus.
Make &
answer calls.
Integrated
Short Range
Light
Mirror
Aim camera
lens for self
portraits
Camera Lens
Camera Key
Headset Jack
Accessory
Connector Port

2
check it out!
check it out!
check it out!
features
transfer music files
Use the memory card as the default USB
connection:
M > Settings > Connection > USB Settings
> Memory Card
On your computer, open iTunes®, connect
your phone to your computer, and drag and
drop music files to your phone.
Tip: You must have a memory card installed
in the phone in order to transfer songs to
the phone and play them using iTunes (see
page 27).
play music
Note:
You cannot listen to music through
most Bluetooth® headsets.
Play a song on your phone using iTunes:
iTunes > Songs > song name > Play
Tip: Disconnect your phone from your
computer to play songs.
Tip: You must have a memory card installed
in the phone in order to transfer songs to
the phone and play them using iTunes (see
page 27).
features

3
check it out!
create playlist
Create a playlist of songs on your phone:
On your computer, open iTunes, click the
Add ( + ) button, and type a name for the
playlist. Then drag songs from your music
library to your playlist.
Connect your phone to your computer and
drag and drop the playlist onto your phone.
rhythm lights
Activate lights to flash in sync with the
sounds around you:
M > Settings > Personalize > Rhythm Lights
ring lights
Choose ring lights for incoming calls:
M > Settings > Ring Styles> Ring Lights >
>light pattern
features
take photo & send
Press j to activate the camera. Point lens
and press
Capture to take a photo.
To send, press the
Store key and
select
Send .
record a video
To record a new video:
M > Multimedia/Sounds > Videos > [New Video]
Press the Capture key to start recording and
the
Stop key to end the recording.
send multimedia message
Send a message with pictures,
animations, sounds, and videos:
M > Messages > Create Message > New Multimedia
Message
features

4
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
www.hellomoto.com
Certain mobile phone features are dependent on the
capabilities and settings of your service provider’s
network. Additionally, certain features may not be
activated by your service provider, and/or the
provider’s network settings may limit the feature’s
functionality. Always contact your service provider
about feature availability and functionality. All
features, functionality, and other product
specifications, as well as the information contained
in this user’s guide are based upon the latest
available information and are believed to be accurate
at the time of printing. Motorola reserves the right to
change or modify any information or specifications
without notice or obligation.
MOTOROLA and the Stylized M Logo are registered
in the US Patent & Trademark Office. The Bluetooth
trademarks are owned by their proprietor and used by
Motorola, Inc. under license. The iTunes Trademark is
owned by Apple Computer and any use of such marks
by Motorola, Inc. is under license. Java and all other
Java-based marks are trademarks or registered
trademarks of Sun Microsystems, Inc. in the U.S. and
other countries. America Online, AOL, the America
Online & Design logo, the AOL & Design logo, and
the Triangle Logo, are registered trademarks of
America Online, Inc. in the United States and/or
other countries. All other product or service names
are the property of their respective owners.
© Motorola, Inc., 2005.
Caution: Changes or modifications made in the radio
phone, not expressly approved by Motorola, will void
the user’s authority to operate the equipment.
Manual Number: 6809495A47-O

5
contents
contents
check it out! . . . . . . . . . . 2
menu map. . . . . . . . . . . . 7
essentials . . . . . . . . . . . . 9
about this guide . . . . . . 9
SIM card . . . . . . . . . . . 10
battery . . . . . . . . . . . . 11
turn it on & off . . . . . . 13
make a call . . . . . . . . . 13
answer a call. . . . . . . . 14
your phone number . . 14
main attractions . . . . . . 15
use iTunes
®
. . . . . . . . 15
take & send a photo . . 20
record & play video clip 21
multimedia messages 23
lights. . . . . . . . . . . . . . 25
memory card . . . . . . . 27
Bluetooth® wireless . 30
basics. . . . . . . . . . . . . . . 33
display . . . . . . . . . . . . 33
menus . . . . . . . . . . . . 37
text entry . . . . . . . . . . 39
volume . . . . . . . . . . . . 43
navigation key. . . . . . . 43
smart key . . . . . . . . . . 43
handsfree speaker . . . 44
codes & passwords . . 44
lock & unlock phone . . 45
customize . . . . . . . . . . . 46
ring style. . . . . . . . . . . 46
time & date. . . . . . . . . 47
wallpaper . . . . . . . . . . 47
screen saver . . . . . . . . 48
themes . . . . . . . . . . . . 48
display appearance. . . 49
answer options. . . . . . 49
vibrations . . . . . . . . . . 49
calls . . . . . . . . . . . . . . . . 50
turn off a call alert. . . . 50
recent calls . . . . . . . . . 50
redial. . . . . . . . . . . . . . 51
return a call. . . . . . . . . 51
notepad . . . . . . . . . . . 52
hold or mute a call . . . 52
call waiting . . . . . . . . . 52
caller ID . . . . . . . . . . . 53
emergency calls . . . . . 53
international calls . . . . 54
1-touch dial . . . . . . . . . 54
voicemail . . . . . . . . . . 54
other features . . . . . . . . 56
advanced calling . . . . . 56
phonebook . . . . . . . . . 58
messages . . . . . . . . . . 62

6
contents
email . . . . . . . . . . . . . . 64
personalizing . . . . . . . . 66
call times . . . . . . . . . . . 68
handsfree . . . . . . . . . . 69
data & fax calls . . . . . . 70
network . . . . . . . . . . . . 70
personal organizer . . . . 70
security . . . . . . . . . . . . 71
fun & games . . . . . . . . 72
troubleshooting. . . . . . . 73
SAR Data . . . . . . . . . . . . 74
index. . . . . . . . . . . . . . . . 76

7
menu map
menu map
main menu
s Recent Calls
• Received Calls
• Dialed Calls
• Notepad
•CallTimes
e Messages
• Create Message
• Message Inbox
•Voicemail
• Media Templates
• Email Msgs
•BrowserMsgs
• Info Series
•QuickNotes
• Outbox
n Phonebook
á Internet
• Internet
• Browser Setup
Ç Rogers Mall
• Get Music & Tones
•GetGames
• Get Graphics
•GetEmail
Q Games & Apps
h Multimedia/Sounds
•Themes
•Camera
• Pictures
• Sounds
• Videos
i iTunes
w Settings
• (see next page)
This is the standard main
menu layout.
Your phone’s
menu may be a little
different.
* optional features

8
menu map
settings menu
l Personalize
• Rhythm Lights
• Home Screen
•MainMenu
•Skin
• Greeting
• Wallpaper
• Screen Saver
• Quick Dial
t Ring Styles
•Style
• Style Detail
• Ring Lights
• Event Lights
É Tools
• SIM Applications*
•Calculator
• Datebook
• Shortcuts
•AlarmClock
• Shortcuts
• Dialing Services
•FixedDial
• Service Dial
• Quick Dial
L Connection
• Bluetooth Link
•Sync
• USB Settings
H Call Forward
U In-Call Setup
•In-CallTimer
• My Caller ID
• Answer Options
• Call Waiting
Z Initial Setup
• Time and Date
• 1-Touch Dial
• Display Timeout
• Backlight
•TTYSetup*
•Scroll
• Vibe Sync
• Language
• Brightness
•DTMF
• Master Reset
• Master Clear
m Phone Status
• My Tel. Numbers
• Active Line
• Battery Meter
• Storage Devices
• Other Information
S Headset
J Car Settings
∅ Airplane Mode
j Network
• New Network
• Network Setup
• Available Networks
• My Network List
• Service Tone
• Network Jingle
• Call Drop Tone
u Security
• Phone Lock
• Lock Keypad
• Lock Application
•FixedDial
• Call Barring
• SIM PIN
•NewPasswords
• Certificate Mgmt
c Java Settings
• Java App Loader
• Java System
• Delete All Apps
•AppVibration
•AppVolume
•AppPriority
• App Backlight
• Set Standby App
* optional features

9
essentials
essentials
about this guide
This guide shows how to locate a menu
feature as follows:
Find it: Press M > Recent Calls > Dialed Calls
This example shows that, from the home
screen, you press
M to open the menu,
highlight and select
sRecent Calls , then
highlight and select
Dialed Calls .
Press
S to scroll to and highlight a menu
feature. Press the
Select key to select the
highlighted menu feature.
CAUTION: Before using the
phone for the first time, read the
Important Safety and Legal
Information
included in the gray-
edged pages at the back of this
guide.
symbols
This means a feature is
network/subscription dependent
and may not be available in all areas.
Contact your service provider for
more information.
This means a feature requires an
optional accessory.

10
essentials
SIM card
Your Subscriber Identity Module (SIM) card
contains personal information like your phone
number and phonebook entries.
Caution: Don’t bend or scratch your SIM
card. Keep it away from static electricity,
water, and dirt.
032386o
1.
032387o
2.
032388o
3.

11
essentials
battery
battery tips
Battery life depends on the network, signal
strength, temperature, features, and
accessories you use.
• Always use
Motorola Original batteries
and chargers. The warranty
does not cover damage
caused by non-Motorola batteries
and/or chargers.
• New batteries or batteries stored for a
long time may take more time to
charge.
• When charging your battery, keep it
near room temperature.
• When storing your battery, keep it
uncharged in a cool, dark, dry place,
such as a refrigerator.
• Never expose batteries to
temperatures below -10°C (14°F) or
above 45°C (113°F). Always take your
phone with you when you leave your
vehicle.
• It is normal for batteries to gradually
wear down and require longer charging
times. If you notice a change in your
battery life, it is probably time to
purchase a new battery.
032389o
4.

12
essentials
Contact your local recycling center for
proper battery disposal.
Warning: Never dispose of batteries in a fire
because they may explode.
Warning: Before using your phone, read the
battery safety information in the “Safety and
General Information” section included in the
gray-edged pages at the back of this guide.
battery installation
032386o
1.
032390o
2.
032391o
3.

13
essentials
battery charging
New batteries
are not fully
charged. Plug
the travel
charger into
your phone
and an
electrical outlet. Your phone displays
Charge Complete when finished.
Tip: Relax, you can’t overcharge your battery.
It will perform best after you fully charge and
discharge it a few times.
turn it on & off
Caution: When you turn on the phone, it may
prompt you to enter your SIM card PIN code
to unlock the SIM card. If you enter an
incorrect PIN code 3 times in a row, your SIM
card is disabled and your phone displays
SIM Blocked . Contact your service provider.
To turn on your phone,
press and hold
O for
a few seconds or until
the display turns on. If
prompted, enter your
6-digit SIM card PIN
code and/or 4-digit
unlock code.
Note: You might be prompted to personalize
your phone. Select
Yes to change settings, or
No to go to the idle display. You can set your
personal options later (see page 66).
To turn off your phone, press and hold
O for
2 seconds.
make a call
Enter a phone number and press N to make
a call.
032392o
032393o.eps

14
essentials
answer a call
When your phone rings and/or vibrates, press
N to answer. To “hang up,” press O .
your phone number
From the home screen, press M# to see
your number.
Tip: Want to see your phone number while
you’re on a call? Press
M > My Tel. Numbers .
To store or edit your name and number
on your SIM card, press the
Edit key
while displaying it. If you don’t know
your phone number, contact your service
provider.

15
main attractions
main attractions
You can do much more with your phone than
make and receive calls!
use iTunes®
You can use iTunes desktop to buy and
download music to your computer from the
Internet, listen to CDs and digital music, and
create playlists of your favorite songs. You
can then transfer music to your phone that
you’ve bought online or from CDs and play
them through iTunes on your phone.
Note: iTunes supports MIDI, MP3, AAC and
WAV song formats.
opening iTunes
Tip: You must have a memory card installed
in the phone in order to transfer songs to the
phone and play them using iTunes (see
page 27).
Press the
o key to see the iTunes display.
iTunes
Exit Play
Playlist
Artists
Albums
Songs
Shuffle Songs
>
>
>
>
>

16
main attractions
playing songs
Note: You cannot listen to music through
most Bluetooth® headsets.
Tip: You must have a memory card installed
in the phone in order to play songs using
iTunes (see page 27).
To play an
individual song , press S down
to scroll to
Songs > song name and press the
Play key.
To play
all the songs in a list , press S
down to scroll to
Albums , Artists , or Playlist . Then
press
S right to select All and press the Play
key.
Tip: Don’t forget to disconnect your phone
from your computer to play songs. But don’t
disconnect while you transfer music.
iTunes controls
features
turn iTunes off & on
Press the o key.
select a menu item
Press S to scroll to menu items, and
select by pressing right.
To return to a previous item, press
S left.
Tip: You can use the left and right soft keys
to
Play songs or Exit menus.
pause a song
From the iTunes idle display, press S up
to switch from Play (
c ) to Pause( T ). Or
from iTunes press the
Pause key.
start a song over
Press S back once.

17
main attractions
installing iTunes on your
Computer
Before you can download songs to your
phone, you must install iTunes on your
computer. To install iTunes on your computer:
1 Place the iTunes CD-ROM (provided in
the box with your phone) into your
computer’s CD-ROM drive or use the
provided URL in a web browser to
download the latest iTunes desktop
software.
2 Follow the prompts to install the
software.
3 When the installation finishes,
double-click the iTunes icon
i on your
desktop to open iTunes.
For more information about the iTunes
desktop software see
http://www.hellomoto.com.
play the previous song
Press S back twice.
fast forward
Press S forward and hold.
rewind
Press S back and hold.
shuffle songs
Press o to display the iTunes menu. Press
S down to scroll to Shuffle Songs , and then
press
Play .
hide iTunes
To hide the iTunes application while playing
music:
Press
M and select Hide .
features

18
main attractions
using the iTunes Music Store
Using iTunes, you can hear, buy, and
download your favorite songs from the iTunes
Music Store (available only in some
countries). There are over a million songs
available in most stores for purchase. You can
use an Apple account to purchase songs from
the music store.
To browse for and buy music:
1 Open iTunes and click Music Store in the
Source List.
2 Click the Sign In button and follow the on
screen instructions to set up an account
or enter your existing Apple account
information.
3 When logged into your account, browse
and buy music.
Tip: When you buy a song the name
displays in the Purchased Music playlist.
You can drag and drop these songs into
playlists you create or directly onto your
phone.
For more information about the iTunes Music
Store, open iTunes and select Help > iTunes
and Music Store Help.
transferring music
To transfer music from the iTunes computer
software to your phone:
1 First, set up the phone to use the memory
card as the default USB connection.
On your phone: Press
M> Settings
>
Connection > USB Settings > Memory Card .
2 On your computer, open iTunes.
3 Using the USB cable, connect your phone
to your computer.
