Motorola ATRIX HD User manual

User’s Guide
MOTOROLA ATRIX™HD
11:35
100%
H 87°
L 76°
82°
Chicago
11
:
3
5
1
100%
100%
8
7
°
76°
H 8
L 7
82
82
2
°
C
Chicago
Thursday
Jul 26
11:35
Play StoreMessagesPeople
Camera
WWW.
BrowserPhone Email
AT&T
AT&T

1At a Glance
At a Glance
your phone ma p
Your Phone
•Smart: Use “SMARTACTIONS™” on page
21 to give your phone rules, like
“Auto-reply to texts when I’m driving,”
“Dim the touch screen when the battery
4:00
100%
Sunday
Feb 13
4:00
H 89°
L 63°
74°
Sunnyvale
10
0%
100%
H
89
°
L
63
°
7
4°
Sun
nyv
ale
Play Store
3
MessagesPeople
Camera
WWW.
Browser
4
Phone
8
Email
Headphone Jack
Micro USB / Charger
Micro HDMI
Volume Keys
Power / Sleep Key
HD Front Camera
AT&T
8MP Photo / 1080p
Video Camera (on
back)
AT&T
Notification Light
microSIM Card
microSD Card
is low,” or “Set the ringer to vibrate when
I’m at work.”
•Clear: You can capture 8MP photos and
1080p HD videos to show on your 4.5”
ColorBoost™ screen, or show them on
even larger screens with “DLNA™ Media
Devices” on page 72.
•Fast: Access files from your Google
Drive™ over Wi-Fi or 4G LTE
connections, using your phone’s 1.5GHz
dual-core processor (see “Quick Start:
Work” on page 59).
Note: Certain apps and features may not
be available in all countries.
This product meets the applicable
limit for exposure to radio waves
(known as SAR) of 1.6 W/kg (FCC &
IC). The limits and guidelines include a
substantial safety margin designed to
assure the safety of all persons, regardless
of age and health. The highest SAR values
measured for this device are listed in the

2 At a Glance
regulatory information packaged with your
product.
More Information
On the Web
•Interactive web tutorials are available at
www.att.com/Tutorials . Select
Manufacturer: Motorola and Model:
ATRI X H D from the drop-down menus.
•Detailed support information including
device specifications, user manual,
troubleshooting, user forums and
knowledgebase articles are available at
www.att.com/DeviceSupport .
•For information about your wireless
account, service plan or network, visit
www.att.com/Wireless .
•Learn about the importance of adding a
password on your device to protect your
privacy as well as how to report a lost or
stolen phone here:
www.att.com/stolenphone .
On the Phone
•Call AT&T Customer Care at
1-800-331-0500.
•Dial 611 from any AT&T device for
assistance with your service or device.
Find Accessories
Accessories for your smartphone are
available at
att.com/WirelessAccessories or
visit your local AT&T store.

3Contents
Contents
Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Home Screen & Apps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Control & Customize. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Calls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Contacts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Socialize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Browse. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Photos & Videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Books . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Locate & Navigate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Connect & Transfer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Protect. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
AT&T Network Notifications. . . . . . . . . . . . . . . . . . . . . . . 80
AT&T Features & Services . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Safety, Regulatory & Legal . . . . . . . . . . . . . . . . . . . . . . . . 83

4 Start
Start
let’s get up & running
Charge Up
Insert your SIM, charge up, then power up.
Note: This product uses a non-removable
battery. The battery should only be
replaced by a Motorola-approved service
1
Pull the card door
out and down.
2
Insert microSIM
card.
4
Power up.
Power (hold)
Sleep (press)
3
Charge up.
3 H
facility. Any attempt to remove or replace
your battery may damage the product and
void your warranty.
•Power: To turn the screen off or on, just
press Power . To turn your phone off
or on, press and hold Power .
If you ever need to reboot your phone,
press and hold both Power and
Volume Down until your phone turns off
(about 10 seconds). Then, just turn your
phone back on.
•Notification Light: The notification light
turns on when your phone starts
charging, and blinks when you have a
new message or notification.
Caution: Before assembling, charging,
or using your phone for the first time,
please read the important safety,
regulatory and legal information in this
guide.

5Start
Caution: Please read “Battery Use &
Safety” on page 83.
Battery Life
Your phone is like a small computer, giving
you a lot of information and apps, at 4G
LTE speed, with a touch display!
Depending on what you use, that can take
a lot of power.
To start getting the most out of your
battery, touch Apps > Settings >
Battery. This shows you what’s using the
most battery.
To save even more battery life between
charges, you could reduce:
•recording or watching videos, listening
to music, or taking pictures.
•widgets that stream information to your
home screen, like news or weather.
•unused online accounts that you
registered (“Accounts” on page 6).
•Wi-Fi and Bluetooth® use:
Touch Apps > Settings, then touch
the switch next to Wi-Fi or Bluetooth to
turn them when you don’t need
them.
•GPS use: Touch Apps > Settings >
Location services, and uncheck GPS
satellites.
•network searching: If you are out of
coverage, to keep your phone from
looking for networks, press and hold
Power to open the Power key menu,
then touch Airplane mode.
•display brightness: Touch Apps >
Settings > Display > Brightness >
(dimmer setting).
•display timeout delay: Touch Apps >
Settings > Display > Sleep > (shorter
setting).
OFF

6 Start
AT&T R e a d y 2 G o
AT&T Ready2Go helps you set up your new
device using the browser on your
computer.
1. From the home screen, touch Apps >
AT&T Ready2Go.
2.Touch Get Started. You’ll see a web
address and a code.
3.On your computer’s browser, go to the
web address.
4.Enter your information and choose the
setup you want.
5.Save your profile to update your device.
Accounts
To add, edit, or delete accounts anytime,
touch Apps > Settings > Accounts &
sync. For more, see “Add or Delete
Accounts” on page 45. To set up email
accounts, see “Email” on page 39.
For help with your Google™ account, visit
http://accounts.google.com .
To delete an account (along with its
contacts and messages on your phone),
touch Apps > Settings > Accounts &
sync, touch the account, then touch
Menu > Remove account.
Old Phone to New Phone
Are you switching from an Apple™ or
Blackberry phone? Get all your important
information set up on your new Motorola
smartphone in a few easy steps. The
Welcome Home To Motorola application
transfers contacts, email addresses,
calendar meetings, events, tasks, music,
playlists, photos, and videos from your old
phone to your new Motorola smartphone.
Note: If you are switching from another
Android™ phone, your Google™ account’s
contacts, events, Gmail™ and other
settings start downloading as soon as you
log into your Google account. If you are

7Start
switching from another type of device,
contact your service provider for
assistance.
To move information from an Apple or
Blackberry phone to your Motorola
smartphone:
1. On your computer, go to
www.markspace.com/welcomehome/ , and
download the free Microsoft®
Windows® or Apple Macintosh version
of the Welcome Home To Motorola
application.
2.Install and run the application on your
computer. You can skip registration.
3.Follow the application instructions on
your computer to transfer information
from your old phone to your Motorola
smartphone.
The Welcome Home To Motorola
application will prompt you to connect
your old phone to the computer with a USB
cable, and backup the data you want to
transfer.
Next, you will be instructed to install the
Welcome Home To Motorola app on your
Motorola smartphone, connect the
smartphone to your computer with a USB
cable, then transfer and unpack the data
onto the Motorola smartphone.

8 Home Screen & Apps
Home Screen & Apps
you have quick access
Quick Start:Home Screen &
Apps
Start from the home screen to explore
apps and more.
11:35
100%
H 87°
L 76°
82°
Chicago
100%
100%
H
87°
L
76
°
Thursday
Jul 26
11:35
Play StoreMessagesPeople
Camera
WWW.
BrowserPhone Email
AT&T
AT&T
Widgets
Status & Notifications
Shortcuts
Favorites Tray
Shortcuts
App & Widget List
•Screen lock: To unlock the screen,
touch and flick to . To turn the
screen off, press Power .
•Status bar & notifications: Icons at the
top of your screen show notifications
(like a new email or calendar reminder)
on the left, and phone status on the
right. Flick the bar down and touch a
notification to open it, or flick the
notification to the right to remove it.
•App & widget list: To show all of the
apps and widgets, touch Apps . Flick
left to scroll through the apps. Touch
WIDGETS at the top to show widgets.
•Circles widget: These circles show the
date (plus call and text notifications),
weather, and your data/battery usage.
Flick the weather circle to add locations.
Flick the data/battery circle to show
settings, battery remaining, or data used
since your last billing cycle (accurate
within the last 24 hours—for details, visit
www.att.com/Wireless ).

9Home Screen & Apps
Tips & tricks
•Flick shortcuts and widgets: Some
shortcuts (like People) have a quick
view—just flick up the quick menu
arrows next to the shortcut. You can also
flick to scroll in some widgets (like
Calendar).
Redecorate Your Home
Customize the way your home screen
looks, and give yourself quick access to
your favorite things:
•Change wallpaper: Touch and hold an
empty spot on your home screen to
choose your wallpaper.
•Create shortcut folders:
To create a folder of
shortcuts on your home
Play Music Play Books
Play Music Play Bookks
screen, touch and hold a shortcut, then
drop it on top of another shortcut.
You can create a folder of apps to use
when you have spare time, when you
want music, or when you need to contact
people—whatever goes together for you.
•Add widgets & shortcuts: Touch
Apps , touch and hold the app or
widget, then drag it to one of your home
screen pages. To see all your apps and
widgets, flick the menu to the left, or
touch APPS or WIDGETS at the top.
Tip: Some apps include special widgets.
To download apps, touch Apps
>Play Store.
•Resize widgets: You can resize some
widgets—touch and hold a widget until
you feel a vibration, then release. Drag
the blue diamonds at the edges to
resize.
•Move or delete widgets & shortcuts:
Touch and hold a widget or shortcut until

10 Home Screen & Apps
you feel a vibration, then drag it to
another spot, another page, or Remove
at the top of the screen.
•Add, rearrange, or delete pages: To
show other pages of shortcuts and
widgets, flick the home screen left.
To add, reorder, or delete pages, from
your home screen touch Home .
Touch to add a page, or touch and
hold an existing page and drag it to left
or right to reorder, or drag it up to
Remove.
•Ringtones and more: For more about
customizing, see “Control & Customize”
on page 16.
Search
Search your apps, contacts, files, places,
and the Web:
At the top of the home screen,
touch for a text search, or for
voice search.
•To choose what your searches cover
(like apps and the web) or change
search location and history settings: In
the search window, touch Menu >
Settings.
•To add a
suggestion to the
search box
without starting
the search,
touch .
For instance, to
find Motorola headsets, you can enter
moto, touch next to the suggestion
motorola, then enter he and touch the
suggestion headsets.
•To become a super searcher, visit
www.google.com/insidesearch .
moto
motorola
Choose
motorola
and enter
a second
word.
Search on
just
motorola.

11Home Screen & Apps
Status & Notifications
At the top of the
screen, icons on
the left notify you
about new
messages or
events (flick the
bar down for details). Icons on the right tell
you about phone status:
network
strength ( = 4G
LTE )
battery charging
( full)
Wi-Fi in range
( connected)
silent
Bluetooth® on
( connected)
vibrate
GPS active alarm set
airplane mode warning
December 21, 2012
Active Smart Actions
Meeting
8:00 AM
Abe Baudo
1 new message
8:00 AM
4:00
1
2
Network and Wi-Fi icons turn blue ( )
when your phone exchanges data with
your Google™ account.
Note: Apps you download from the
Google Play™ Store app might show other
icons in the status bar to alert you to
specific events.
Download Apps
Google Play™
Google Play™ is a new entertainment hub
full of music, movies, books, apps, and
games. You can instantly access your
content from all your Android™ devices.
Find it: Play Store
•Find: To search, touch in the top right.
•Review: To show details and reviews for
an app you found, just touch it.
Tip: For the full list of reviews, touch See
all below the third review—then touch

12 Home Screen & Apps
Most helpful first or Options to
customize the list.
•Download: To download an app you
found, touch it to open details and then
touch Download, or the price, in the top
right.
Tip: Google Play creates a home screen
shortcut whenever you download an
app. To change this in the Google Play
Store app, touch Menu > Settings
>Auto-add widgets.
•Share: To share an app you found, touch
it to open details and then touch at the
top.
•Reinstall: To show or reinstall apps you
downloaded from the Google Play Store
app, touch Menu > My Apps.
•On a computer: To find and manage
apps from any computer, go to
http://play.google.com using your
Google™ account and password.
There, you can browse apps on the big
screen, manage your apps across
multiple devices (like a phone and
tablet), and even set new apps to
download to your devices.
•Music, Books & Movies: You can also use
the Google Play Store app to download
“Music” on page 52, “Books” on page 54,
and “Movies” on page 51.
•Help: To get help and more, touch
Menu in the top right.
Apps from the Web
You can get apps from online app stores
using your browser.
Note: Choose your apps and updates
carefully, as some may impact your
phone’s performance.
To let your phone install apps that are not
from Google Play, touch Apps >

13Home Screen & Apps
Settings > Security & Screen Lock and
check Unknown sources.
To download files from your browser, see
“Downloads” on page 47.
Choose Carefully
Apps are great. There's something for
everyone. Play, communicate, work, or
have fun. But remember, choose your
apps carefully. Here are a few tips:
•To help prevent spyware, phishing, or
viruses from affecting your phone or
privacy, use apps from trusted sites, like
the Google Play Store app.
•In the Google Play Store app, check the
app’s ratings and comments before
installing.
•If you doubt the safety of an app, don't
install it.
•Like all apps, downloaded apps will use
up memory, data, battery, and
processing power—some more than
others. For example, a simple battery
level widget will use less than a
streaming music player app. After
installing an app, if you're not happy with
how much memory, data, battery or
processing power it's using, uninstall it.
You can always install it again later.
•Just like web browsing, you may want to
monitor childrens’ access to apps to
help prevent exposure to inappropriate
content.
•Certain apps may not provide
completely accurate information. Take
care, especially when it comes to
personal health.
Show, Remove & Restore Apps
To show the app list, from your home
screen touch Apps , then flick left to
scroll through apps. To close the app list,
touch Home or Back .

14 Home Screen & Apps
•Uninstall apps: Touch Apps >
Settings > Apps > ALL, touch an app,
then touch Disable or Uninstall in the
top right (if available).
Disable removes the app from your
Apps list—to Enable it, reopen this
window and touch Enable (disabled
apps are at the bottom of this window).
If an app locks up your phone as soon as
you turn it on, restart in Safe Mode: Turn
off your phone, then turn it back
on—when you see the “Motorola” logo
during power-up, press and hold both
volume keys until you see the home
screen, with Safe Mode in the lower left.
Then, try removing the app.
•Reinstall apps: To reinstall apps from
the Google Play™ Store, touch Apps
>Play Store > Menu > My apps. The
apps you downloaded are listed and
available for download.
•Share, show, or clear app details: Touch
Apps > Settings > Apps. A bar at the
bottom tells you how much app storage
space you have left. At the top, touch the
list of DOWNLOADED, RUNNING, or ALL
apps, then touch an app in the list to
show its details and storage usage. You
can touch Share, Clear data or other
options.
Tip: To quickly show these app details
from your app list: Just touch and hold
an app, drag it to More options at the
top of your screen, then choose App
info.
•Show app data usage: To show which
apps are using the most data,
touch Apps > Settings > Data usage.
For more, see “Data Use” on page 70.
Update Your Phone
Use your phone or computer to check,
download, and install phone software
updates:

15Home Screen & Apps
•Using your phone:
If your phone notifies you about an
update, follow the instructions to
download and install it.
To manually check for updates,
touch Apps > Settings > About
phone > System updates.
Your phone downloads updates over
your Wi-Fi connection (if available) or
mobile network. We recommend that
you download updates when you have a
Wi-Fi connection. Remember, these
updates can be quite large (25MB or
more) and may not be available in all
countries. If the mobile network updates
are not available in your country, update
using a computer.
•Using your computer:
On your computer, go to
www.motorola.com/support and check
the “Software” links. If an update is
available, just follow the installation
instructions.

16 Control & Customize
Control & Customize
how it acts & looks
Quick Start:Control &
Customize
Touch, hold, drag, or flick to open
shortcuts, widgets, menus, and more.
•Touch: Choose an icon or option.
11:35
100%
H 87°
L 76°
82°
Chicago
100%
100%
H
87°
L
76
°
Thursday
Jul 26
11:35
Play StoreMessagesPeople
Camera
WWW.
BrowserPhone Email
AT&T
AT&T
Open (touch) or
move/delete (touch &
hold)
Back
Home
Recent apps
Change wallpaper
(touch & hold)
Open pages (flick left)
•Touch & hold: Move items on the home
screen, or open options for items in a list
(like People).
•Drag or flick: Scroll slowly (drag) or
quickly (flick).
•Pinch or double-tap: Zoom in and out
on websites, photos, and maps.
•Twist: Twist a map with two fingers to
rotate it, and pull two fingers down to tilt
it.
•Speak: Touch Apps > Voice
Commands to tell your phone what you
want (touch in a search window, or
in a keypad).
Tips & tricks
•Screen off & on: Press Power to turn
the screen off or on.
Note: During a
call, your screen
might stay dark if
the sensor just above it is covered. Don't

17Control & Customize
use covers or screen protectors (even
clear ones) that cover this sensor.
•Screen lock: To
unlock the screen,
touch and flick
to . To add a
password or facial
recognition
security to your
unlock screen,
touch Apps >
Settings >
Security & Screen
Lock > Screen
lock.
•Wallpaper: To change your wallpaper,
touch and hold an empty spot on the
home screen.
•Widgets & apps: To add an app shortcut
or widget to your home screen, touch
Apps , touch and hold the app or
widget, then drag it to one of your home
screen pages.
Touch and flick to (or
touch):
Text Camera
Unlock Call
•Pages: To show or add other pages of
shortcuts and widgets, flick the home
screen left. To delete pages from your
home screen, touch Home , touch
and hold a page, then drag it up to
Remove.
•Ringtone for a contact: To set a
ringtone for a contact, touch People,
touch the contact, then touch Menu
>Set ringtone.
•Ringtone, display & other settings: To
change settings, flick the status bar
down and touch in the top right. Then,
choose Sound, Display, or other
settings.
•Home screen: For more about changing
your home screen, see “Redecorate Your
Home” on page 9.
Touch
Find your way around:

18 Control & Customize
•Back: Step back—touch Back to go to
the previous screen.
•Home: Jump back—touch Home to
return to the home screen. On your first
home screen page, touch Home to
show all the pages.
•Recent apps: Switch
apps—touch Recent to show your
recent apps, and touch an app to reopen
it. To remove an app from the list, flick it
left or right. To scroll the list, flick up or
down.
•Menu: Open options—when Menu
appears in the corner of the screen, you
can touch it to open options for the
current screen.
Lost or stuck? If you’re not sure what to do
next, try one of these:
•To open a text message, see contact
details, or open items in a list, touch the
message, contact, or item.
•To show options for a list item (if
available), touch and hold the item.
•To reboot your phone if needed, press
and hold both Power and Volume
Down until your phone turns off (about
10 seconds). Then, just turn your phone
back on.
Press
Power Key
Press and hold
Power to open a
menu where you can
choose Power off,
Sleep (no Wi-Fi
connections),
Airplane mode (no network or other
connections—see “Airplane Mode” on
page 74), vibrate , or silent .
To conserve battery, prevent accidental
touches, or when you want to wipe
smudges off your screen, turn off the
