Motorola I315 - SOUTHERNLINC User manual

Nextel
iDEN
Digital Multi-service Data-capable Phone
i315 Phone User’s Guide
@NNTN5503B@
NNTN5503B

i
Contents
Getting Started........................................... 1
Removing the Battery Door...............................2
Locating Your SIM Card....................................3
Battery...............................................................3
Powering On and Off.........................................6
Activating Service..............................................6
Enabling Security ..............................................6
Phone Programming .........................................7
Finding Your Phone Number and Direct
Connect®Number ........................................7
Nextel®Voice Mail ............................................8
Nextel Worldwide®Service ...............................8
Customizing Features .......................................8
Phone Basics ....................................................9
SIM Card Security ...........................................12
Locking the Keypad.........................................15
Accessories.....................................................16
Wireless Local Number Portability: Bringing
Your Phone Number From Another
Carrier.........................................................16
Nextel®Customer Care...................................17
Making Calls .............................................19
Phone Calls.....................................................19
Direct Connect®Calls .....................................19
Receiving Calls ...............................................20
Call Icons ........................................................20
Ways to Enter Calls.........................................21
Using Speakerphone.......................................23
Using Mute......................................................23
Making Emergency Phone Calls.....................23
Call Alerts..................................................25
Sending Call Alerts..........................................25
Receiving Call Alerts.......................................25
Using the Call Alert Queue..............................25
Direct TalkSM ........................................................ 27
Off-Network Walkie-Talkie ..............................27
Channels and Codes.......................................28
Private Direct TalkSM Calls..............................30
Making Emergency Calls in
Direct TalkSM Mode ....................................31
Setup Options .................................................31

ii
Recent Calls............................................. 33
Storing Recent Calls to Contacts ....................33
Deleting Recent Calls......................................34
Entering Text............................................ 35
Using Alpha Mode...........................................35
Using Word Mode............................................35
Special Function Keys.....................................36
Using Numeric Mode.......................................37
Using Symbols Mode ......................................37
Contacts ................................................... 38
Viewing Contacts.............................................39
Creating Entries...............................................40
Storing Numbers Faster ..................................41
Editing Entries.................................................42
Deleting Entries...............................................42
Checking Capacity ..........................................43
Creating Pauses and Waits.............................43
International Numbers.....................................43
Memo.........................................................44
Call Forwarding ........................................45
Forwarding All Calls ........................................45
Turning Off Call Forwarding............................46
Forwarding Missed Calls.................................46
Viewing Call Forwarding Settings ...................47
Advanced Calling Features .....................48
Call Waiting.....................................................48
Switching Between Calls.................................48
Putting a Call on Hold .....................................49
Calling 2 People..............................................49
Creating Pauses and Waits While Dialing.......50
Making International Calls...............................50
Setting One Touch Direct Connect®...............50
Group ConnectTM Calls...................................51
Call Timers......................................................52
Using Your Phone as a Modem ......................53
Making TTY Calls............................................54
Special Dialing Codes.....................................56

iii
Nextel®Phone Services.......................... 57
Caller ID ..........................................................57
Per-Call Blocking.............................................57
Per-Line Blocking............................................57
Alternate Line Service.....................................57
Call Restrictions ..............................................58
Nextel®411.....................................................58
Ring Tones............................................... 59
Setting Your Phone to Vibrate.........................59
Ring and Vibrate..............................................60
Assigning Ring Tones to Contacts..................60
Viewing Ring Tone Assignments.....................60
Downloading More Ring Tones.......................61
Managing Memory...........................................61
Deleting Custom Ring Tones ..........................61
Message Center....................................... 62
Accessing the Message Center.......................62
Message Center Options.................................62
Receiving Messages................................ 63
Message Notifications .....................................63
Message Center..............................................64
Voice Mail Messages................................65
Receiving a Message......................................65
Accessing Voice Mail from
the Message Center ...................................65
Sending Unanswered Calls to
Voice Mail...................................................65
Nextel®Voice Mail....................................66
Setting Up Your Voice Mail Box......................66
Playing Messages...........................................66
Changing Your Password ...............................67
Recording Your Name.....................................67
Recording Your Active Greeting......................68
Advanced Voice Mail Features .......................68
Nextel®Voice Mail Tree..................................73
SMS and Two-Way Messages .................74
SMS Messages...............................................74
Two-Way Messages and Net Alerts................75
Wireless Data Services............................78
Wireless Data Services...................................78

iv
Accessing Wireless Data Services
From Your Phone .......................................79
Navigation Keys ..............................................79
Guides and Demos..........................................80
GPS Enabled............................................ 81
IMPORTANT: Things to Keep in Mind ............81
Making an Emergency Call .............................82
Viewing Your Approximate Location ...............83
Enhancing GPS Performance.........................84
Updating Satellite Almanac Data.....................86
Setting Privacy Options...................................86
Using GPS with Map Software........................87
Customizing Your Phone........................ 90
Setting the Volume..........................................90
Setting Your Phone to Not Ring ......................90
Seeing the Display Better................................91
Using Settings.................................................91
Optional Features............................................93
Games .......................................................94
Using a Headset .......................................95
Attaching a Headset........................................95
Using a Remote PTT Button ...........................95
Nextel®Customer Care............................96
Domestic Customer Care................................96
Nextel Worldwide®Customer Care.................97
Understanding Status Messages............98
Nextel®Terms and
Conditions of Service.........................100
Safety and General Information ............122
RF Operational Characteristics.....................122
Portable Radio Product Operation and
EME Exposure..........................................122
Electro Magnetic Interference/Compatibility..125
Medical Devices............................................125
Operational Warnings ...................................126
Operational Cautions ....................................127
Accessory Safety Information .......................128

v
MOTOROLA LIMITED WARRANTY ...... 130
Limited Warranty
Motorola Communication Products
(International)..................................... 134
Patent and Trademark Information ...... 138
Index ....................................................... 139

vi

vii
DECLARATION OF CONFORMITY
Per FCC CFR 47 Part 2 Section 2.1077(a)
Responsible Party Name: Motorola, Inc.
Address: 8000 West Sunrise Boulevard
Plantation, FL 33322 USA
Phone Number: 1 [phone]
Hereby declares that the product:
Product Name: i315
Model Number: H69XAH6RR1AN
Conforms to the following regulations:
FCC Part 15, subpart B, section 15.107(a),
15.107(d) and section 15.109(a)
Class B Digital Device
As a personal computer peripheral, this device
complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
Note: This equipment has been tested and
found to comply with the limits for a Class
B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against
harmful interference in a residential
installation. This equipment generates,
uses and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur
in a particular installation.
If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is
encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.

1
Getting Started
audio jack
accessory connector
volume
controls
speaker
(in back)
Push-to-talk
(PTT) button
microphone
antenna
space key
back key
DIRECT
CONNECT /
GROUP CONNECT
speaker on/off
option keys power button
pPower button.
Navigation key — press the arrows to
scroll through menus and lists.
mMenu key — accesses context-sensitive
menus.
AOption key — selects the option
appearing above it on the display.
Note: Throughout this User Guide, the
option keys will be represented
by A.
sSend key — places phone calls.
eEnd key — ends phone calls; returns to
idle screen; using Wireless Data Services,
returns to Net main menu.

2
Removing the Battery Door
To start using your i315 phone:
•Make sure your SIM card is in place.
•Charge the battery.
•Activate your service.
•Enable security.
Removing the Battery Door
1Make sure the phone is powered off. See
“Powering On and Off” on page 6.
2Slide the release button forward until it releases
the battery door.
Note: If the release button does not slide
forward to release the battery door, rotate
the circular piece in the center of the
release button to unlock it.
3Remove the battery door from the back of your
phone.
release
button
speaker

3
Getting Started
Locating Your SIM Card
Your SIM (Subscriber Identity Module) card is a
small piece of plastic located in the SIM card
holder in the back of your phone, underneath the
battery.
If there is no SIM card in your phone, contact
Nextel Customer Care at 1-800-639-6111.
Battery
Inserting the Battery
Your phone comes with a High Capacity Lithium
Ion battery.
1Remove the battery door.
2Insert the top of the battery into the battery area.
Press the bottom of the battery to secure it.
3Replace thebattery door andpress it gentlyuntil
you hear a click.
SIM card
holder
SIM card

4
Battery
4If you want to ensure the battery door does not
accidentally come off, rotate the circular piece in
the center of the release button to lock it.
Charging the Battery
Your phone comes with a rapid travel charger.
1Plug the charger into an electrical outlet.
2Open the connector cover.
3Plug the other end of the charger into the
accessory connector.
Charger Attached appears on the display.
Tip: To remove the charger from the accessory
connector: Press the buttons on the sides
of the plug. Pull the plug straight out.
4If you have purchased optional batteries or
chargers, see “Charging Times” on page 5.
Note: While the phone is charging, the keypad
backlight will not illuminate.
connector
cover

5
Getting Started
Charging Times
Check your battery and charger type against the
below grid to determine appropriate charging
times.
Recommended charging times:
For best results, charge the batteries within the
temperature range of 50°F to 104°F (10°C to
40°C).
Prolonged charging is not recommended.
Removing the Battery
1With the phone powered off, remove the battery
door.
2Remove the battery by pushing the battery
toward the antenna and lifting it out.
Battery Use and Maintenance
•The Motorola iDEN Approved Lithium Ion
chargers provide optimum performance. Other
chargers may not fully charge the iDEN Lithium
Ion battery or may yield a reduced number of
lifetime charge cycles.
•Extreme temperatures degrade battery
performance. Do not store the battery where
temperatures exceed 140°F (60°C) or fall below
4°F (-20°C).
•Lithium Ion batteries have a self discharge rate
and without use, lose about 1% of their charge
per day.
Battery Charger
Rapid Standard
Standard
Lithium Ion 2 hours 4 hours
Extended
Capacity
Lithium Ion
2.5 hours 6 hours
High
Capacity
Lithium Ion
3.5 hours 7.5 hours

6
Powering On and Off
•The battery capacity is degraded if the battery is
stored for long periods while fully charged. If
long term storage is required, store at half
capacity.
Powering On and Off
To power your phone on:
Press p.
As your phone connects to the network, you will
see a connecting message. When the idle screen
appears, the phone is ready to use.
To power your phone off:
Press and hold p.
Activating Service
The first time you power on your phone, your
service is activated.
A screen then appears prompting you to select Ok
to update your browser information. This screen
will only appear during initial activation. See
“Enabling Security”.
Enabling Security
You must enable security the first time you power
on yourphone or within 20 days of first activation of
your phone.
1Press Aunder Ok.
Note: If you press Aunder Later, the idle
screen will appear. The next time you
select Net from the main menu, you will
be prompted to enable security beforeyou
can use Wireless Data Services.
2You are prompted to enable security. Press A
under Yes. A series of screens and then the
default homepage displays.
3Press eto return to the idle screen.

7
Getting Started
Phone Programming
Within 24 hours of enabling security, you will
receive a Net alert containing your Personal
Telephone Number (PTN), Nextel Customer Care
number, Direct Connect®number, and Talkgroup
lists for Group ConnectTM calls.
1When you receive a Net alert saying New
Browser Message - Receive Programming
Info, press Aunder Goto.
2You are prompted to accept changes to your
lists. Press Aunder Ok.
3You are prompted again to accept changes to
your lists. Press Aunder Ok.
4A confirmation screen displays. Press Aunder
Ok.
5Press eto return to the idle screen.
Finding Your Phone Number
and Direct Connect®Number
My Info lets you view your phone number, Direct
Connect number, and other phone information:
1Press mto access the main menu.
2Scroll to My Info.
3Press Aunder Select.
4Scroll to see your information:
•Name— Enter your name. See “Entering
Text” on page 35.
•Line1and Line 2 — your phone numbers for
phone lines 1 and 2. These are filled in when
you receive your first Net alert after enabling
security on your phone.
•DirectConnect— Your Direct Connect
number is the number that others use to
contact you using Direct Connect®service. It
isfilled in when youreceiveyour first Net alert
after enabling security on your phone. To view
your Direct Connect number, scroll to Direct
Connect and press Aunder View.
• Group ID — the number of the Talkgroup you
have joined.
• Carrier IP — the IP address assigned to
Nextel. It is filled in when you register for
packet data services. To view your Carrier IP
address, scroll to Carrier IP and press A
under View.
• IP1 Address and IP2 Address — the IP
addresses assigned to you for using the
Internet with your phone. To view your IP
addresses, scroll to the IP address you want
to view and press Aunder View.

8
Nextel®Voice Mail
•Ckt— Your circuit data number is the number
you use if you want to use your phone to
transfer circuit data. See “Using Your Phone
as a Modem” on page 53. You receive this
number from Nextel.
Note: If you request equipment related
transactions on your account, Nextel
Customer Care may require you to
provide specific information about your
phone. By pressing manytime while in My
Info, a context-sensitive menu will appear
that includes your phone's service status,
unit information, and phone identification
numbers including IMEI, SIM ID, and
Serial Number (SN). Please be prepared
to supply the representative with this
information when requesting these types
of transactions.
Nextel®Voice Mail
You must set up your voice mail box before you
can retrieve messages. See “Setting Up Your
Voice Mail Box” on page 66.
Nextel Worldwide®Service
You can use your phone to make calls
internationally in select cities using other iDEN®
networks by calling Nextel Customer Care to
activate international dialing on your account.
Countries in which you can useyour phone include
Argentina, Brazil, Canada, Israel, Jordan, Mexico,
Peru, the Philippines, and Singapore*.
* Credit approval may be required. Other conditions may apply.
Customizing Features
You can control many features of your phone,
including the volumeof incoming sound, rings, and
other tones. See “Customizing Your Phone” on
page 90.

9
Getting Started
Phone Basics
Any time your phone is powered on, the display
provides you with information and options.
The screen shown above is the idle screen. The
idle screen appears when your phone is on, but not
engaged in any activity.
Text Area
This area displays menus, messages, names,
phone numbers, and other information.
Display Options
Two display options appear at the bottom of most
screens. You select a display option by pressing
the option key below it.
Menus and Lists
Your phone’s features are arranged in menus,
submenus, and lists.
To access the items in a menu or list, scroll using
the navigation key at the top of your keypad. This
key lets you scroll up, down, left, or right. Holding
down the appropriate part of the navigation key
speeds up scrolling.
In this guide, this symbol >tells you to select a
menu or list item. For example, Settings >
Security means:
1Scroll to Settings on the main menu.
2Press Aunder Select to see the Settings
screen.
3Scroll to Security and press Aunder Select to
see the Security screen.
Menu Key
Many features provide context-sensitive menus
that let you access related features and actions.
The Sicon appears any time a context-sensitive
menu is available. Press mto access the menu.
status icons
text area
menu icon
display options

10
Phone Basics
Main Menu
All your phone’s features can be accessed through
the main menu. When you are using a feature, the
icon for that feature appears in the upper left
corner of the display.
aNet Access to Wireless Data
Services. See page 78.
bSettings Customize your phone.
See page 90.
mRing Tones Assign ring tones and turn
ringer off. See page 59.
jMy Info View personal phone
information, including
phone number and Direct
Connect number. See
page 7.
nDownloads Provides a catalog of ring
tones that you can
download directly to your
phone. Items in this
catalogchange frequently,
so check regularly for
fresh content. See
page 61.
lGPS Find your approximate
geographical location.
See page 81.
dContacts Create, view, store, edit
contacts. See page 38.
eMessages Access messages. See
page 62.
fCall Forward Set call forwarding
options. See page 45.
gMemo Store a number to access
later. See page 44.
hCall Timers Phone usage information.
See page 52.
kCall Alert Lists call alerts. See
page 25.
GGames Access Games. See
page 94.
iRecent Calls Lists recent calls. See
page 33.
mDirecTalk Launch Direct TalkSM.
Access Setup and Help.
See page 27.

11
Getting Started
Status Icons
Status icons appear in the two rows at the top of
the display. Some appear at all times. Others
appear only when your phone is engaged in certain
activities or when you have activated certain
features.
abcd
efgd
Battery Strength — More bars on
the battery indicate a greater
charge.
opqr
sSignal Strength — More bars next to the antenna indicate a
stronger signal.
APhone In Use — Your phone is
active on a phone call.
BDirect Connect In Use — Your
phone is active on a Direct
Connect call.
CTalkgroup In Use — Your phone
is active on a Group Connect call.
12Active Phone Line — 1 indicates
phone line 1 is ready to make
calls; 2 indicates phone line 2 is
ready to make calls.
mDirect Talk — Your phone is off
network and set to Direct Talk
mode.
GHI
JKLCall Forward — Your phone is set to forward calls. See “Call
Forwarding” on page 45.
vMR Ringer Off — Your phone is set
not to ring.
uSpeaker Off — Sets Direct
Connect and Group Connect
sound to come through the
earpiece rather than through the
speaker.
wy Messages — You have one or
more messages. See “Receiving
Messages” on page 63.
ljik
mn T9 Text Input — You are using T9 Text Input to enter text. See
“Entering Text” on page 35.
DEF Internet — You are ready to
browse the internet or are
browsing the internet using a
secure connection.
