Motorola MOTO F902 User manual

F902
Quick Start Guide
MOTO
XT502
TM

Table of Contents
Table of Contents
What’s in the Box? ................................ 1
Your Phone ........................................... 2
Installing SIM Card, Battery and Memory
Card ...................................................... 3
Charging Battery ................................... 5
First Start Up ......................................... 6
The Home Screen ................................. 6
Making Your First Call........................... 7
Entering Information.............................. 8
Contacts ................................................ 9
Sending a Text Message ...................... 10
Sending a Multimedia Message............ 10
Sending a Voice MMS........................... 11
Setting up Wi-Fi®.................................. 11
Setting up an Email Account ................. 12
Sending and Receiving Emails ............. 13
Using the Browser................................. 14
Using Bluetooth® .................................. 16
Taking Photos and Videos .................... 16
Viewing Photos and Videos .................. 18
Changing Basic Phone Settings............ 20

Quick Start Guide
1
Congratulations on your purchase of the
Motorola XT502. This Quick Start Guide will
help you go through the basic features of your
phone to get you started.
For more detailed information, see the User
Guide which you can download from
www.motorola.com/support.
What’s in the Box?
Your package comes with the following items.
Motorola
XT502
AC Adapter
Quick Start
Guide Headset
L
R
Battery

Quick Start Guide
2
Your Phone
Home
Call
Trackball
Flash
Camera
Volume:
Press Up or
Down key to
increase or
decrease
volume.
Shutter
Power
Speaker
Microphone
End
Back
Touch screen
Earpiece
Micro USB
connector
Headset
jack
Strap holes
Search
Menu
Back cover

Quick Start Guide
3
Installing SIM Card, Battery
and Memory Card
Caution: Before assembling, charging, or using
your phone for the first time, please read the
important legal and safety information at the
back of this guide.
1. Open the back
cover.
2. If the battery is
inserted, lift and
remove the battery.
3. Insert the SIM card.
Make sure the gold
contacts are facing
down and the cut-off
corner facing
towards the battery
slot.

Quick Start Guide
4
4. Insert the memory
card with the gold
contacts facing
down.
5. Push the memory
card until it clicks
into place.
Note:
• To remove the memory card, push it down to
eject it from the slot.
• Do not remove the memory card while the
phone is turned on. Sudden removal of the
memory card may cause data loss or
unpredictable system crashes.
6. Insert the battery.
Make sure the
contacts of the
battery are aligned
with the connectors
on the battery slot.
7. Secure the hooks on
the back cover with
designated holes on
the phone and close
the back cover.

Quick Start Guide
5
Charging Battery
1. Open the Micro USB
connector cover.
2. Connect the USB
charger to the phone.
3. Plug the USB charger into a wall outlet to
start charging.
Note: To fully charge battery, charge it for
3 hours. Battery life will vary depending on
the applications used.
LED Indicators
Your phone has two LED indicators: green and
red.
LED Location Indication
Green
(solid)
Call key Battery is fully
charged.
Red
(solid)
End key Battery is charging.

Quick Start Guide
6
First Start Up
After installing the SIM card and charging the
battery, you are now ready to turn on the phone
- press and hold the Power key on the top of the
phone.
The Home Screen
From the Home screen, you can quickly access
common features and view notifications of
missed calls, receive messages and check
connection status.
Tap Application Drawer to open the
application menu.
Status Icons
Application Drawer
Tap an
icon to
open it.
Flick left/
right to
show more
home
screen
panels.
Notification - Flick down to display

Quick Start Guide
7
Making Your First Call
On the Home screen, tap Call Key.
To make a call
1. Enter the phone
number using the
keypad.
Tip: Tap to
erase a wrong
number. Tap and
hold to erase the
entire number.
2. Press Call Key to
dial.
3. To end the call,
press End Key.
To answer a call
To answer a call, press Call Key.

Quick Start Guide
8
Entering Information
Regardless of the application, you can enter
information using the on-screen keyboard.
To use the on-screen keyboard
When an application requires text input, tap the
input box to display on-screen keyboard.
1. Tap the input box to
display the on-
screen keyboard.
Note: To toggle
between upper
and lowercase, tap
. To display the
numeric and the
symbols keyboard,
tap . Tap to
toggle back.
2. Tap keys on the
keyboard to enter characters.
Note: If word dictionary is activated, the
screen displays a list of suggested words as
typing the characters.

Quick Start Guide
9
Contacts
To add a Contact
1. On the Home
screen, tap
Contacts.
2. Tap Menu > New.
3. Enter contact
information such as
name, phone
number, email
address etc. Tap
Done to save the
contact or tap
Revert to exit
without saving the changes.
Note: Your SIM card only stores the name
and the phone number. To store more
information such as an e-mail address,
create a new contact on the phone.
To import contacts
1. On the Home screen, tap Contacts.
2. Tap Menu > More > Import contacts.
3. Select to import contacts from SIM Card or
SD Card, then press OK.
4. Select contacts to import or tap Menu
again to select Import all.

Quick Start Guide
10
Sending a Text Message
1. On the Home
screen, tap
Messaging.
2. Tap New message.
3. In the To field, enter
the phone number or
choose a contact.
4. Type message in the
Type to compose
field.
5. Tap Send.
Sending a Multimedia
Message
A multimedia message (MMS) can contain
graphic and audio files.
1. On the Home screen, tap Messaging.
2. Tap New message > Menu > Add sbj.
3. The message automatically converts to an
MMS message.
4. Enter the phone number or e-mail address
of the recipient in the To field, then type
subject in the Subject field.
5. To add components, tap Menu > Attach to
attach pictures or videos.
6. Tap Send.

Quick Start Guide
11
Sending a Voice MMS
1. On the Home
screen, tap
Messaging.
2. Tap New Message
>Menu > Attach >
Record audio.
3. Tap to record
your message.
4. Tap to stop
recording.
• Tap to play the
recording. Tap Save to store the recording. Tap
Discard to delete the recording. After storing
the recording, you can also tap to Play,
Replace and Remove the recording.
5. Enter the phone number in the To field.
The voice message can be sent up to 20
recipients.
6. Compose your message, then tap Menu >
Add sbj. to add subject and tap Send.
Setting up Wi-Fi®
Connect to a wireless network to browse
Internet.
1. On the Home screen, tap > Settings.
2. Tap Wireless controls.
3. Tap Wi-Fi to activate.

Quick Start Guide
12
4. Tap Wi-Fi settings > Network
notification to start detecting networks.
The available networks will then be listed.
5. Tap Add Wi-Fi network to add a
connection.
Note: Connecting to a secured network will
prompt for the password. Enter the password
then tap Connect.
Setting up an Email
Account
1. On the Home
screen, tap >
Email >Others. (If
you are using
GmailTM, YahooTM,
HotmailTM or
Microsoft
ExchangeTM email
accounts, please tap
that email service
provider's name
directly.)
2. Enter your E-mail address and
Password, then tap Next.
3. Select account type, then confirm Incoming
server settings (If you are using GmailTM,
YahooTM, HotmailTM or Microsoft
ExchangeTM email accounts, a Attention
screen will be prompted, tap OK), the
phone will automatically retrieve the e-mail
settings.

Quick Start Guide
13
Note: If successful, the E-mail setup
wizard displays a successful message, (If
you are using GmailTM, YahooTM, HotmailTM
or Microsoft ExchangeTM email accounts,
please set account name and outgoing
messages display name, then tap Done). If
e-mail settings are not found, tap Edit
details.
4. Enter Your Account Name and the
Outgoing messages display name, then
tap Done.
Sending and Receiving
Emails
Composing and sending E-mails
1. On the Home
screen, tap >
Email, then tap an
e-mail account.
2. Tap Menu >
Compose.
3. In the To field, enter
the recipient’s e-mail
address.
4. Enter Subject.
5. Compose your
e-mail.
6. Tap Send.

Quick Start Guide
14
Adding attachments to an e-mail
message
1. Tap Menu > Add attachment.
2. Select items to attach.
Receiving e-mails
E-mails are automatically received in Inbox
folder when your phone is connected to a
wireless network.
1. On the Home screen, tap > Email,
then tap an e-mail account.
2. Tap Menu > Refresh.
Using the Browser
To open a web page
1. Tap > Browser.
2. Tap Menu > Go.
3. Tap the address bar.
4. Type the URL then tap Go.

Quick Start Guide
15
Tap Menu to see more options.
To quickly browse Internet from the
Home Screen
From the Home screen panels, you can browse
internet right away with Google Search.
1. Tap Google Search widget,
then type text to search.
2. Tap .
Touch
the web
page and
drag/flick
it to
scroll.
TM

Quick Start Guide
16
Using Bluetooth®
1. On the Home
screen, tap >
Settings.
2. Tap Wireless
controls.
3. Tap Bluetooth to
activate.
4. To search for a new
device, tap
Bluetooth settings
>Scan for devices.
5. Tap the device you
want to link with to connect.
6. Enter the Passcode to start pairing, then
tap OK.
Note: The passcode you enter on your
phone must be the same passcode to be
entered on the other bluetooth device.
Taking Photos and
Videos
This phone is equipped with a high quality
camera to take photos and videos.
To take a photo
1. On the Home screen, tap > Camera.
The screen automatically switches to
landscape view.

Quick Start Guide
17
2. Aim the phone at the subject, then half
press the Shutter key or tap and hold to
focus.
3. The focus frame turns green to indicate
focus is set, fully press the Shutter key or
tap to take the shot.
To record video
1. On the Home screen, tap >
Camcorder.
2. Aim the phone at the subject.
3. Press the Shutter key or tap to start
recording.
4. Press the Shutter key or tap again to
stop.
