User’s Guide
MOTORAZR TM V3c

1
Welcome
We are pleased that you have chosen the MOTO RAZR ™ V3c wireless phone.
040128o
Left Soft Key
Perform function
in lower left
display.
Voice Key
Create voice
records & voice
dial names.
Smart/
Speakerphone
Key
Volume Keys
Camera Key
4-Way
Navigation Key
Clear Key
Right Soft Key
Perform function
in lower right
display.
Power & End Key
Turn phone
on/off, end calls,
exit menu
system.
Send Key
Make &
answer calls.
Center Key
From home screen, open main
menu. In menus & lists, press
to select highlighted option.

2
Contents
Contents
Getting Started . . . . . . . 4
About This Guide. . . . . . 4
Install the Battery . . . . . 5
Charge the Battery . . . . 5
Turn On Your Phone. . . . 6
Adjust Volume . . . . . . . . 7
Make a Call . . . . . . . . . . 7
Answer a Call . . . . . . . . 7
Change the Call Alert. . . 8
View Your Phone
Number . . . . . . . . . . . . . 9
Highlight Features . . . . 10
Record and Play a Video
Clip . . . . . . . . . . . . . . . 10
Take and Send a Photo 12
Send a Multimedia
Message . . . . . . . . . . . 14
Receive a Multimedia
Message . . . . . . . . . . . 17
Bluetooth™
Connections . . . . . . . . 18
Synchronize Data. . . . . 20
TTY Operation . . . . . . . 21
Learning to Use Your
Phone
. . . . . . . . . . . . . . 23
The Home Screen . . . . 23
The 4-Way Navigation
Key. . . . . . . . . . . . . . . . 25
Menus . . . . . . . . . . . . . 26
Enter Text . . . . . . . . . . 28
Handsfree Speaker . . . 36
The External Display . . 37
Change a Code, PIN, or
Password. . . . . . . . . . . 37
Lock and Unlock
Keypad. . . . . . . . . . . . . 38
Lock and Unlock Phone 38
If You Forget a Code, PIN,
or Password. . . . . . . . . 39
Setting Up Your Phone 40
Set Ring Styles and
Alerts . . . . . . . . . . . . . . 40
Answer Options. . . . . . 41
Wallpaper. . . . . . . . . . . 41
Screen Saver . . . . . . . . 41
Display Brightness. . . . 42
Display Timeout. . . . . . 42
Backlight . . . . . . . . . . . 42
Talking Phone Settings 43
Hide or Show Location
Information . . . . . . . . . 43

3
Contents
Conserve Battery
Power . . . . . . . . . . . . . 43
Calling Features . . . . . . 45
Redial Number . . . . . . 45
Automatic Redial . . . . 45
Silence a Call Alert . . . 45
Call an Emergency
Number . . . . . . . . . . . 46
View Call History . . . . 46
The Notepad. . . . . . . . 47
Return an Unanswered
Call . . . . . . . . . . . . . . . 48
Attach a Number . . . . 48
Speed Dial . . . . . . . . . 48
1-Touch Dial . . . . . . . . 49
Voicemail . . . . . . . . . . 49
Phone Features . . . . . . . 50
Main Menu. . . . . . . . . 50
Settings & Tools Menu 51
Calling Features . . . . . 52
Messages. . . . . . . . . . 52
Contacts . . . . . . . . . . . 54
Personalizing Features 57
Menu Features . . . . . . 60
Dialing Features . . . . . 62
Call Monitoring . . . . . . 62
Bluetooth™ Wireless
Connections . . . . . . . . 64
Handsfree Features . . 65
Data and Fax Calls . . . 67
Network Features. . . . 67
Personal Organizer
Features . . . . . . . . . . . 68
Security . . . . . . . . . . . 69
News and
Entertainment. . . . . . . 70
Service & Repairs . . . . 71
SAR Data . . . . . . . . . . . 75
Content Copyright . . . . 76
AGPS & Emergency
Calls
. . . . . . . . . . . . . . . 76
Safety Information . . . . 80
Industry Canada Notice 83
FCC Notice . . . . . . . . . . 83
Use & Care . . . . . . . . . . 84
Warranty . . . . . . . . . . . . 85
Hearing Aids . . . . . . . . . 88
WHO Information . . . . . 89
Registration . . . . . . . . . 89
Export Law . . . . . . . . . . 89
Recycling Information . . 90
Perchlorate Label . . . . . 90
Privacy and Data
Security
. . . . . . . . . . . . . 90
Driving Safety . . . . . . . . 91
Index . . . . . . . . . . . . . . . 93

4
Getting Started
Getting Started
About This Guide
This guide shows how to locate a menu
feature as follows:
Find it: Press s > sCall History > Dialed
This example shows that from the home
screen, you must press the center key
s to
open the main menu, scroll to
Call History , then
scroll to and select
Dialed . Press S to scroll
and the center key
s to select a menu
option.
CAUTION: Before using the
phone for the first time, read the
Important Safety and Legal
Information included in the gray-
edged pages at the back of this
guide.
symbols
This means a feature is
network/subscription dependent and
may not be available in all areas.
Contact your service provider for
more information.
This means a feature requires an
optional accessory.

5
Getting Started
Install the Battery Charge the Battery
New batteries are shipped partially charged.
Before you can use your phone, you need to
install and charge the battery as described
below. Some batteries perform best after
several full charge/discharge cycles.
Using the Charger
1 Insert the
charger into the
USB connector
on your phone
as shown.
2 Plug the other
end of the
charger into the
appropriate electrical outlet.
3 When your phone indicates Charge Complete ,
remove the charger.
1.
2.
3.
4.

6
Getting Started
Tip: You can safely leave the charger
connected to the phone after charging is
complete. This will
not damage the battery.
Note: When you charge the battery, the
battery level indicator in the upper right corner
of the display shows how much of the
charging process is complete. At least 1
segment of the battery level indicator must be
visible to ensure full phone functionality while
charging.
Charging from a Computer
You can charge your battery by connecting a
cable from your phone’s mini-USB port to a
high-power USB port on a personal computer
(not a low-power one such as the USB port on
your keyboard or bus-powered USB hub).
Typically, USB high-power ports are located
directly on your computer.
Both your phone and the computer must be
turned on, and your computer must have the
correct software drivers installed. Cables and
software drivers are available in
Motorola Original data kits, sold separately.
Note: When your phone’s battery is dead or
has a very low charge, you must use the
phone’s charger to recharge the battery. You
cannot use a USB-cable connection to a
personal computer to charge a weak or dead
phone battery.
Turn On Your Phone
1 Open your phone.
2 Press and hold the
power key for 3
seconds.
The phone may
require several
seconds to power on.

7
Getting Started
3 If necessary, enter your 4-digit unlock
code (the last 4 digits of your phone
number) and press
OK to unlock the
phone.
Adjust
Volume
Press the up or down
volume keys to:
• increase or decrease earpiece volume
during a call
• increase or decrease ringer volume
setting when the home screen is
visible (phone must not be in a call and
flip must be open)
• silence an incoming call alert
Make a Call
1 Dial the number.
Tip: If you make a mistake, press the
clear key
B to delete the last digit. Press
and hold
B to clear all digits.
2 Press N to make the call.
3 Press P to end the call.
Tip: Closing the flip also ends the call unless
you are using the speakerphone.
Note: You must dial the phone number from
the home screen.
Answer a Call
When you receive a call, your phone rings
and/or vibrates and displays an incoming call
message.
1 Press N to answer.
040135o

8
Getting Started
2 Press P to end the call.
Tip: You can set the phone to answer calls
when you open the flip. (To activate, press
s > GSettings > In-Call Setup > Answer Options
>
Open To Answer .)
Note: If the phone is locked, you must first
enter your 4-digit unlock code to answer the
call.
Change the Call Alert
Phone Flip
Open
In the home screen,
press the down volume
key to switch to lower
call alert volume, then switch to vibrate and,
finally, silent alert. Press the up volume key to
cycle back from silent alert to vibrate and then
to the lowest alert volume setting.
Phone Flip Closed
Press the up or
down volume
key, then press
the smart/
speakerphone
key to scroll
through the alert styles:
Loud , Soft , Vibrate , Vibe then
Ring
, and Silent . The alert styles are shown on
the external display.
After scrolling to the desired alert style, press
the up or down volume key to save the setting
and return to the home screen.
040135o
Volume Keys
Smart/
Speakerphone
Key

9
Getting Started
View Your Phone
Number
To view your phone number from the home
screen:
• Press B# .
or
•
Press s > GSettings > mPhone Status
>
My Tel. Number
While you are on a call, press Options , then
select
My Tel. Number .

10
Highlight Features
Highlight Features
You can do much more with your phone than
make and receive calls! This section
describes some of your phone’s highlights.
Record and Play a Video
Clip
You can record a video clip with your
phone, and send it to other wireless
phone users in a multimedia message.
Record a Video Clip
To activate your phone’s video camera:
Find it: Press s > EMy Stuff > Video Camera
Tip: You can also activate your phone’s video
camera by pressing and releasing the camera
key
b .
Camera Lens
Smart/
Speakerphone
Key
Take self-portrait
photo with
camera when flip
is closed.
External Display
View incoming
call information,
use as camera
viewfinder when
flip is closed.
Accessory
Connector Port
Insert charger
& phone
accessories.

11
Highlight Features
The active viewfinder image appears on your
display.
Press
Options to open the Videos Menu (see
“Videos Menu” following the steps below).
1 Point the camera lens at the video
subject.
Press
S left or right to change lighting
conditions to
Automatic , Sunny , Cloudy , Indoor
(Home)
, Indoor (Office) , or Night .
2 Press the camera key b to begin
recording.
3 Press the camera key b or Stop to stop
recording.
4 Press Options , then highlight Store Only and
press
Select to save the video.
or
Press B to delete the photo and return
to active viewfinder.
Videos Menu
From the video camera viewfinder, press
Options to open the Videos Menu , which can
include the following options:
480x640
Press right soft key to
return to previous screen.
Press left soft key to
view
Options menu.
Options Exit
N
Zoom
1x
621
Displays when
you press S to
change video
settings.
Option
Go To Videos
Go to the Videos list to view stored video
clips.

12
Highlight Features
Play a Video Clip
To play a video clip stored on your phone:
Find it: Press s > EMy Stuff > Videos
Scroll to the clip you want to view and press
the center key
s .
Take and Send a Photo
To activate your phone’s camera:
Find it: Press s > EMy Stuff > Camera
Tip: You can also activate your phone’s
camera by pressing the camera key
b .
The active viewfinder image appears on your
phone’s display.
Press
S up and down to select and adjust
one of the following settings:
Video Camera Setup
Change Auto Repeat , Video Length , Full Screen , or
Recording Sound .
View Free Space
See how much memory remains for storing
video clips.
Option
Option
Zoom
Increase or decrease image size.
480x640
I
Press right soft key to
return to previous screen.
Press left soft key to
view
Options menu.
Options Exit
N
Zoom
1x
621
Displays when
you press
S to
change camera
settings.

13
Highlight Features
To view other options, press Options to open
the
Pictures Menu (see “Pictures Menu”
following these steps).
Point the camera lens at the photo subject,
then:
1 Press the camera key b to take the
photo.
2 Press the camera key b again to save
the photo.
or
Press Options to open the Store Options menu.
Then select
Store Only , Apply as Wallpaper , Apply
as Screen Saver
, or Apply as Contacts Entry .
or
Press Send to go to the Send Options screen.
Then select
Send To .
Pictures Menu
The Pictures menu can include the following
options:
Style
Set to Color , Black and White , Antique , or Negative .
Lighting Conditions
Set to Automatic , Sunny , Cloudy , Indoor (Home) , Indoor
(Office)
, or Night .
Option
Option
Go To Pictures
View pictures and photos stored on your
phone.
Auto-Timed Capture
Set a timer for the camera to take a photo.
Capture Title
Assign a name to a captured photo.

14
Highlight Features
Send a Multimedia
Message
A multimedia message contains embedded
media objects (possibly including photos,
pictures, animations, sounds, or voice
records). You can send a picture message to
other multimedia messaging-capable phones
and to other email addresses.
Send the Message
Find it: Press s > FMessages > Create Message
> New Multimedia Msg
1 Press keypad keys to enter message text.
2 Press Options to open the MMS Menu .
Note: See “MMS Menu Options” on
page 16 for descriptions of all menu
options.
3 Scroll to Insert and press Select .
4 To insert a stored multimedia object, scroll
to
Picture , Voice Record , Sound , or Video , and
press
Select . Then scroll to the desired
object and press
Insert .
or
To take and insert a new photo, scroll to
New Picture and press Select . Take the photo
and press
Insert .
or
Camera Setup
Change resolution, image quality, or shutter
tone.
View Free Space
See how much memory remains for storing
pictures.
Option

15
Highlight Features
To record and insert a new video clip,
scroll to
New Video and press Select . Record
the video clip, then press
s to store it.
Select
Insert to add the new video to the
Multimedia Msg .
5 Press Send To .
6 Scroll to and select the entry to receive
the message.
or
Scroll to and select [New Number] or [New Email
Address]
, then enter the recipient’s phone
number or email address and press the
center key
s .
7 Press Send to send the message.
or
Press Options to open the MMS Menu and
select
Message Options (see table below),
Message Details , Save to Drafts , or Abort Message .
The
Message Options menu can include:
Option
Cc
Enter names of recipient(s) to receive
message copy. Names entered here can be
viewed by all message recipients.
Bcc
Enter names of recipient(s) to receive
message copy. A recipient name entered
here can be viewed by
ONLY that recipient
and
NOT by other recipients.
Subject
Enter the message subject.
Attachments
Add a picture or sound.
Priority
Set to Normal or Urgent .

16
Highlight Features
MMS Menu Options
While creating a multimedia message, press
Options to open the MMS Menu , which can include
the following options:
Option
Insert
Insert multimedia objects, a new page for
message text, or a phone number from the
Contacts , Received , or Dialed list.
Message Options
(See table on page 15.)
Delete Page
Delete the current message page (appears
only if you have entered text into the boy of
the message before pressing
Options ).
Preview
View the current contents of the message
(appears only if you have entered text into
the boy of the message before pressing
Options ).
Set Page Timing
Set the length of time that the page will be
displayed.
Save as Template
Save message as a template.
Message Details
View message statistics.
Save to Drafts
Save the message to the Drafts folder.
Option

17
Highlight Features
Receive a
Multimedia Message
When you receive a multimedia message,
your phone displays the
g (message waiting)
indicator and
New Message , and plays an alert.
Copy Text
Highlight and copy a part of the message
text (appears only if you have entered text
into the boy of the message before
pressing
Options ).
Cut Text
Highlight and cut a part of the message text
(appears only if you have entered text into
the boy of the message before pressing
Options ).
Copy All Text
Copy all message text (appears only if you
have entered text into the boy of the
message before pressing
Options ).
Cut All Text
Cut all message text (appears only if you
have entered text into the boy of the
message before pressing
Options ).
Option
Paste
Insert, at the cursor position, copied or cut
text (appears only when you have coped
text with
Copy Text or Copy All Text ).
Entry Mode
Select a text entry mode.
Entry Setup
Set up a text entry method.
Cancel Message
Open the Msg Abort Options screen.
Option

18
Highlight Features
Open the flip and press READ to view the
message now, or to save it in your
Message Inbox
to view later.
To view messages in your
Message Inbox :
Find it: Press s > FMessages > Inbox
1 Scroll to the desired message.
2 Press the center key s to open the
message. Your phone first displays the
picture, then the message.
Multimedia messages that you receive can
contain different media objects:
• Photos, pictures, and animations are
displayed as you read the message.
• A sound file begins playing when its
slide is displayed. Use the volume keys
to adjust the volume as the sound file
plays.
• Attached files are appended to the
message. To open the attachment,
highlight the file indicator/filename and
press
VIEW (image file type), PLAY (sound
file).
Bluetooth™
Connections
Your phone supports Bluetooth™
connections. You can connect your phone to a
Bluetooth headset or car kit, or connect to a
PC to exchange and synchronize files.
Your phone supports these Bluetooth profiles:
• headset (optional Motorola Original™
accessory)
• Handsfree Car Kit (optional
Motorola Original accessory)
Tip: Want to know more about your headset
or car kit? For specific information about a
device, refer to the instructions that came
with it.

19
Highlight Features
Note: All multimedia (video player, audio
player, shutter tones) play from the
speakerphone when your phone is connected
to another Bluetooth device.
Turn Bluetooth Power On or
Off
Set Bluetooth power to be on whenever your
phone is on.
Note: To extend battery life, use the above
procedure and set Bluetooth power to
Off
when not in use. If you turn Bluetooth power
Off , your phone will not connect to accessories
until you turn Bluetooth power
On and
reconnect to the accessories.
Pair with a Headset,
Handsfree Device, or PC
Before you try to connect to another
Bluetooth device,
make sure your phone’s
Bluetooth power is
On and the device is in
pairing mode (see the user guide for the
device you are attempting to pair with). You
cannot perform pairing while your phone is
connected to another device.
To pair your phone to a headset accessory,
handsfree car kit, or PC that supports
Bluetooth wireless connections:
Your phone displays a list of device(s) located
within range of the phone. If your phone is
already connected to a device, your phone
lists that device and identifies it with a
\
Find it: s > GSettings > Connection
> Bluetooth Link > Setup
> Power > On
Find it: s > GSettings > Connection
> Bluetooth Link > Handsfree
> [Look For Devices]
