Motorola MOTORAZR V3M User manual

1
HELLOMOTO
Introducing your new red MOTO RAZR
TM
V3m wireless phone. Here’s a quick anatomy lesson.
Camera Lens
Smart/
Speakerphone
Key
Take self-portrait
photo with
camera when flip
is closed.
External Display
View incoming
call information,
use as camera
viewfinder when
flip is closed.
Accessory
Connector Port
Insert charger
& phone
accessories.
040128o
Left Soft Key
Perform function
in lower left
display.
Voice Key
Create voice
records & voice
dial names.
Smart/
Speakerphone
Key
Volume Keys
Camera Key
4-Way
Navigation Key
Clear Key
Right Soft Key
Perform function
in lower right
display.
Power & End Key
Turn phone
on/off, end calls,
exit menu
system.
Send Key
Make &
answer calls.
Center Key
From home screen, open main
menu. In menus & lists, press
to select highlighted option.

2
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
1-800-331-6456 (United States)
1-888-390-6456 (TTY/TDD United States for hearing
impaired)
1-800-461-4575 (Canada)
www.hellomoto.com
Certain mobile phone features are dependent on the
capabilities and settings of your service provider's
network. Additionally, certain features may not be
activated by your service provider, and/or the
provider's network settings may limit the feature's
functionality. Always contact your service provider
about feature availability and functionality. All
features, functionality, and other product
specifications, as well as the information contained
in this user's guide are based upon the latest
available information and are believed to be accurate
at the time of printing. Motorola reserves the right to
change or modify any information or specifications
without notice or obligation.
MOTOROLA and the Stylized M Logo are registered
in the US Patent & Trademark Office. The Bluetooth
trademarks are owned by their proprietor and used by
Motorola, Inc. under license. All other product or
service names are the property of their respective
owners.
© Motorola, Inc., 2006.
Caution: Changes or modifications made in the radio
phone, not expressly approved by Motorola, will void
the user’s authority to operate the equipment.
Manual number: 6809507A32-O

3
contents
contents
menu map . . . . . . . . . . . . 5
Use and Care . . . . . . . . . 7
essentials . . . . . . . . . . . . 8
about this guide . . . . . . 8
battery . . . . . . . . . . . . . 9
turn it on . . . . . . . . . . . . 11
adjust volume. . . . . . . 12
make a call . . . . . . . . . 12
answer a call. . . . . . . . 12
change call alert . . . . . 13
view your phone number .
13
main attractions . . . . . . 14
airplane mode. . . . . . . 14
play music . . . . . . . . . 14
take & send photo . . . 15
record & play video clip 17
send multimedia message
19
receive multimedia
message. . . . . . . . . . . 21
memory card . . . . . . . 22
cable connections. . . . 24
Bluetooth® connections. .
25
TTY operation . . . . . . . 27
basics . . . . . . . . . . . . . . 29
home screen . . . . . . . 29
navigation key. . . . . . . 31
menus . . . . . . . . . . . . 32
enter text . . . . . . . . . . 34
handsfree speaker . . . 40
external screen. . . . . . 41
change a code, PIN, or
password . . . . . . . . . . 42
lock/unlock keypad . . . 42
lock/unlock phone . . . . 42
if you forget a code, PIN,
or password . . . . . . . . 43
customize . . . . . . . . . . . 44
ring styles & alerts . . . 44
answer options. . . . . . 45
wallpaper . . . . . . . . . . 45
screen saver . . . . . . . . 45
screen brightness. . . . 46
display timeout . . . . . . 46
backlight . . . . . . . . . . . 47
talking phone settings 47
AGPS & your location . 47
AGPS limitations & tips 48
conserve battery. . . . . 49
calls . . . . . . . . . . . . . . . . 50
change active line . . . . 50

4
contents
redial . . . . . . . . . . . . . . 50
automatic redial. . . . . . 50
silence a call alert . . . . 51
emergency calls . . . . . 51
use AGPS during
emergency call . . . . . . 51
recent calls . . . . . . . . . 52
notepad . . . . . . . . . . . . 53
return unanswered call 54
attaching a number . . . 54
speed dial . . . . . . . . . . 54
1-touch dial . . . . . . . . . 55
voicemail . . . . . . . . . . . 55
other features . . . . . . . 56
advanced calling . . . . . 56
messages . . . . . . . . . . 57
contacts. . . . . . . . . . . . 59
personalize . . . . . . . . . 63
call times & costs . . . . 68
Bluetooth® wireless
connections. . . . . . . . . 69
handsfree . . . . . . . . . . 70
data & fax calls . . . . . . 72
network . . . . . . . . . . . . 72
personal organizer . . . . 73
security . . . . . . . . . . . . 74
news & entertainment 75
service & repairs . . . . . . 77
Specific Absorption Rate
Data
. . . . . . . . . . . . . . . 78
index . . . . . . . . . . . . . . . 80

5
menu map
menu map
main menu
e Messaging
•Voicemail
• Create Message
• Message Inbox
•Drafts
• Outbox
•QuickText
• Browser Alerts
L Web Browser
n Contacts
s Recent Calls
• Received
• Dialed
• Notepad
•CallTimes
•DataTimes
•DataVolumes
h Media Gallery
•Camera
•Pictures
• Sounds
•VideoCamera
•Videos
É Tools
• Calculator
• Datebook
•VoiceRecords
•AlarmClock
• Airplane Mode
w Settings
(see next page)
This is the standard main
menu layout. Your phone’s
menu may be a little different.
m Phone Status
•MyTel.Number
• Active Line
•BatteryMeter
• Storage Devices
• Other Information

6
menu map
settings menu
t Ring Styles
•Style
•Style Detail
l Personalize
• Home Screen
• Main Menu
•Skin
• Greeting
• Wallpaper
• Screen Saver
• Sound Settings
U In-Call Setup
• In-Call Timer
• Answer Options
•MSGAlert
u Security
• Phone Lock
• Lock Keypad
• Lock Application
• Restrict Calls
• New Passwords
Z Initial Setup
• SpeakerPhone
• Auto PIN Dial
• Auto Redial
• Display Timeout
• Backlight
•TTYSetup
•Scroll
• Language
• Battery Save
• Brightness
•DTMF
• Hyphenation
• Master Reset
• Master Clear
j Network
• Current Network
• Set Mode
• Service Tone
• Call Drop Tone
J Car Settings
• Auto Answer
• Auto Handsfree
• Power-off Delay
• Charger Time
S Headset
• Auto Answer
•VoiceDial
ò Location
• Location On
•911Only
L Connection
• Incoming Call
• Bluetooth Link

7
Use and Care
Use and Care
Use and Care
To care for your Motorola phone, please keep it away from:
liquids of any kind dust and dirt
Don’t expose your phone to water,
rain, extreme humidity, sweat, or
other moisture.
Don’t expose your phone to dust, dirt,
sand, food, or other inappropriate
materials.
extreme heat or cold cleaning solutions
Avoid temperatures below -10°C/
14°F or above 45°C/113°F. To clean your phone, use only a dry soft cloth. Don’t use alcohol or other
cleaning solutions.
microwaves the ground
Don’t try to dry your phone in a
microwave oven. Don’t drop your phone.

8
essentials
essentials
about this guide
This guide shows how to locate a menu
feature as follows:
Find it: Press s > sRecent Calls > Dialed
This example shows that from the home
screen, you must press the center key
s to
open the main menu, scroll to
Recent Calls , then
scroll to and select
Dialed . Press S to scroll
and the center key
s to select a menu
option.
CAUTION: Before using the phone for the
first time, read the
Important Safety and
Legal Information
included in the
gray-edged pages at the back of this guide.
032259o
symbols
This means a feature is network/
subscription dependent and may not
be available in all areas. Contact your
service provider for more
information.
This means a feature requires an
optional accessory.

9
essentials
battery
install battery
1
2
3
4
charge battery
New batteries are shipped partially charged.
Before you can use your phone, you need to
install and charge the battery as described
below. Some batteries perform best after
several full charge/discharge cycles.
To charge using the charger:
1
Insert the charger
into the USB
connector on your
phone as shown.
2 Plug the other end
of the charger into
the appropriate
electrical outlet.

10
essentials
3 When your phone indicates Charge Complete ,
remove the charger.
Tip: You can safely leave the charger
connected to the phone after charging is
complete. This will
not damage the battery.
When you charge the battery, the battery level
indicator in the upper right corner of the
screen shows how much of the charging
process is complete. At least one segment of
the battery level indicator must be visible to
ensure full phone functionality while charging.
To charge from your PC:
You can charge your battery by connecting a
cable from your phone’s mini-USB port to a
high-power USB port on a computer (not a
low-power one such as the USB port on your
keyboard or bus-powered USB hub). Typically,
USB high-power ports are located directly on
your computer.
Both your phone and the computer must be
turned on, and your computer must have the
correct software drivers installed. Cables and
software drivers are available in Motorola
Original data kits, sold separately.
battery tips
• Battery life depends on the network,
signal strength, temperature, features,
and accessories you use.
Always use Motorola
Original batteries and
chargers. The warranty
does not cover damage
caused by non-Motorola batteries and/
or chargers.
• New batteries or batteries stored for
a long time may take more time to
charge.

11
essentials
• When charging your battery, keep it
near room temperature.
• When storing your battery, keep it
uncharged in a cool, dark, dry place.
• Never expose batteries to
temperatures below -10°C (14°F) or
above 45°C (113°F). Always take your
phone with you when you leave your
vehicle.
• It is normal for batteries to gradually
wear down and require longer charging
times. If you notice a change in your
battery life, it is probably time to
purchase a new battery.
Contact your local recycling center for
proper battery disposal.
Warning: Never dispose of batteries in a fire
because they may explode.
Before using your phone, read the battery
safety information in the “Safety and General
Information” section included in this guide.
turn it on
1 Open your phone.
2 Press and hold the
power key for three
seconds.
The phone may
require several
seconds to power on.
3 If necessary, enter your four-digit unlock
code (the last four digits of your phone
number) and press
OK to unlock the
phone.

12
essentials
adjust
volume
Press the up or down
volume keys to:
• increase or decrease earpiece volume
during a call
• increase or decrease ringer volume
setting when the home screen is
visible (phone must not be in a call and
flip must be open)
• silence an incoming call alert
make a call
1 Dial the number.
Tip: If you make a mistake, press the
clear key
B to delete the last digit. Press
and hold
B to clear all digits.
2 Press N to make the call.
3 Press P to end the call.
Tip: Closing the flip also ends the call unless
you are using the speakerphone feature (see
page 40).
Note: You must dial the phone number from
the home screen. See page 29.
answer a call
When you receive a call, your phone rings
and/or vibrates and displays an incoming call
message.
1 Press N to answer.
2 Press P to end the call.
Tip: You can set the phone to answer calls
when you open the flip. (To activate, press
s > wSettings > In-Call Setup > Answer Options
>
Open To Answer .)
Note: If the phone is locked, you must first enter
your four-digit unlock code to answer the call.
040135o

13
essentials
change call alert
phone flip open
In the home screen,
press the down volume
key to switch to lower
call alert volume, then
switch to vibrate and, finally, silent alert. Press
the up volume key to cycle back from silent
alert to vibrate and then to the lowest alert
volume setting.
phone flip closed
Press the up or
down volume
key, then press
the smart/
speakerphone
key to scroll
through the alert styles:
Loud , Soft , Vibrate , Vibe then
Ring
, and Silent . The alert styles are shown on
the external screen.
After scrolling to the desired alert style, press
the up or down volume key to save the setting
and return to the home screen.
view your phone
number
To view your phone number from the home
screen:
• Press B# .
or
• Press s > mPhone Status
>
My Tel. Number .
While you are on a call, press
Options , then
select
My Tel. Number .
040135o
Volume Keys
Smart/
Speakerphone
Key

14
main attractions
main attractions
You can do much more with your phone than
make and receive calls!
airplane mode
Note: Consult airline staff about the use of
Airplane Mode in flight. Turn off your phone
whenever instructed to do so by airline staff.
Airplane mode turns off your phone’s calling
features in locations where wireless phone
use is prohibited. You can use the phone’s
other non-calling features in airplane mode.
Find it: Press s > ÉTools > Airplane Mode
>
Airplane Mode > On or Off
Your phone can prompt you to activate or
deactivate airplane mode each time you turn
on the phone:
Find it: Press s > ÉTools > Airplane Mode
>
Prompt at Startup > On or Off
play music
You can use your phone to play MP3 music
files that you download to your phone with
your phone’s browser (see page 75). You can
also create playlists of your favorite songs.
To play a music file or playlist:
Find it:
Press s > hMedia Gallery > Sounds
1 Scroll to the desired music file or playlist.
2 Press the center key s .
You can play music stored in phone
memory or on an optional memory card

15
main attractions
(see page 22). To switch between phone
memory and a memory card:
Find it:
Press s > hMedia Gallery > Sounds
1 Press the Options key.
2 Scroll to Switch Storage Devices and press the
Select key.
3 Scroll to TRANS-T-Flash (the memory card) or
Phone and press the center key s .
To create a playlist:
Find it:
Press s > hMedia Gallery > Sounds
1 Scroll to [New Playlist] and press the center
key
s .
2 Press the appropriate keys to enter the
playlist
Name: , then press the Ok key.
3 With Audio Files: highlighted, press the
center key
s .
4 Scroll to a music file you want to add to
the playlist and press the center key
s to
select it.
A check mark appears next to the file
when you select it. To deselect the file,
press the center key
s again.
5 Repeat step 4 to add more files.
6 Press the Done key when you are finished
adding files.
7 Press the Done key again to save the
playlist and return to the
Sounds menu.
take & send photo
To activate your phone’s camera:
Find it: Press s > h Media Gallery > Camera
Tip: You can also activate your phone’s
camera by pressing the camera key
b .

16
main attractions
The active viewfinder image appears on your
phone’s screen.
To select and adjust one of the following
settings,
press S up and down:
To view other options, press Options to open
the
Pictures Menu :
option
Zoom
Increase or decrease image size.
Style
Set to Color , Black and White , Antique , or Negative .
480x640
I
Press right soft key to
return to previous screen.
Press left soft key to
view
Options menu.
Options Exit
N
Zoom
1x
621
Displays when
you press S to
change camera
settings.
Lighting Conditions
Set to Automatic , Sunny , Cloudy , Indoor (Home) ,
Indoor (Office) , or Night .
option
Go To Pictures
View pictures and photos stored on your
phone.
Switch Storage Device
Store photos in phone memory or on
an optional memory card (see page 22).
Auto-Timed Capture
Set a timer for the camera to take a photo.
Capture Title
Assign a name to a captured photo.
option

17
main attractions
To take a photo, point the camera lens at the
photo subject, then:
1 Press the camera key b to take the
photo.
2 Press Options to open the Store Options menu.
Then select
Store Only , Apply as Wallpaper , Apply
as Screen Saver
, or Apply as Phonebook Entry .
or
Press Send to save the photo and go to the
Send Options screen. Then select Send in
Message
or Send to online album .
record & play video clip
You can record a video clip with your
phone and send it to other wireless
phone users in a multimedia message.
record video clip
To activate your phone’s video camera:
Find it: Press s > h Media Gallery
>
Video Camera
Tip: You can also activate your phone’s video
camera by pressing and holding the camera
key
b .
Camera Setup
Change resolution, image quality, or shutter
tone.
View Free Space
See how much memory remains for storing
pictures.
option

18
main attractions
The active viewfinder image appears.
To view options, press Options to open the
Videos Menu :
To record a video clip:
1
Point the camera lens at the video
subject.
Press
S left or right to change lighting
conditions to
Automatic , Sunny , Cloudy , Indoor
(Home)
, Indoor (Office) , or Night .
2 Press the camera key b to begin
recording.
3 Press the camera key b or Stop to stop
recording.
option
Go To Videos
Go to the Videos list to view stored video
clips.
Switch Storage Device
Store video clips in phone memory or
on an optional memory card (see page 22).
480x640
Press right soft key to
return to previous screen.
Press left soft key to
view
Options menu.
Options Exit
N
Zoom
1x
621
Displays when
you press S to
change video
settings.
Video Camera Setup
Change Auto Repeat , Full Screen , Video Length , or
Recording Sound .
Recording Sound
Turn on/off a sound that plays when the
video camera is recording a clip.
option
