Motorola R-2550 Owner's manual

Programming Reference
Motorola R-2550, and R-2600
Communications System Analyzer Series
0
M
MOrOROLA
Communications Test Equipment
0 Copyright Motorola, Inc. 1995
Publication 94990~6%80309E55-1.00
Printed in the U.S.A. (10 March 10,1995)

Limited Warranty (excludes export shipments)
Motorola Test Equipment Products (herein the “product”) that are manufactured or distributed by Motorola
Communications Group Parts Department are warranted by Motorola for a period of one (1) year from date of
shipment against defects in material and workmanship.
This express warranty is extended to the original purchaser only. In the event of a defect, malfunction, or failure
during the period of warranty, Motorola, at its option, will either repair, or replace the product providing that
Motorola receives written notice specifying the nature of the defect during the period of warranty, and the
defective product is returned to Motorola at 1313 East Algonquin Road, Schaumburg, IL 60196 transportation
prepaid. Proof of purchase and evidence of date of shipment (packing list or invoice) must accompany the return
of the defective product. Transportation charges for the return of the product to Purchaser shall be prepaid by
Motorola.
This warranty is void, as determined in the reasonable judgment of Motorola, if:
(a)
The product has not been operated in accordance with the procedures described in the operating
instruction:
(b)
The seals on non-user serviceable components or modules are broken;
(c)
The product has been subject to misuse, abuse, damage, accident, negligence, repair or alteration.
In no event shall Motorola be liable for any special, incidental, or consequential damages.
In the event Motorola elects to repair a defective product by replacing a module or subassembly, Motorola, at its
option, may replace such defective module or subassembly. Only the unexpired warranty of the warranty product
will remain in force on the replacement module or subassembly. Except as specifically set forth herein, all
warranties express or implied, includin,
0 any implied warranty of fitness for a particular purpose or
merchantability, are excluded.
94990-68803093551.00
i
Motorola Communications Analyzer
Programming Reference

Support Service
For service on your Motorola Test Equipment in the U.S. contact the test equipment service depot:
TEST EQUlPh4ENT SERVICE DEPOT
1308 Plum Grove Road
Schaumburg, Illinois 60173
800-323-6967
(In Illinois call 708-576-7025)
Motorola Communications Analyzer
Programming Reference
94990-68-%0309E55-1.00

Computer Software Copy-rights
The Motorola Products described in this instruction manual include copyrighted Motorola computer pro,grams
stored in semiconductor memories or other media. Laws in the United States and other countries preserve for
Motorola certain exclusive rights for copyrighted computer programs, including the exclusive right to copy or
reproduce in any form the copyrighted computer program. Accordingly, any copyrighted Motorola computer
programs contained in the Motorola products described in this instruction manual may not be copied or
reproduced in any manner without the express written permission of Motorola. Furthermore, the purchase of
Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any
license under the copyrights, patents or patent applications of Motorola, except for the normal nonexclusive,
royalty free license to use that arises by operation of law in the sale of a product.
This product contains silicon software designed by Ready Systems Corp. copyright 1989 Ready Systems Corp. All
rights reserved. Unpublished-rights reserved under the copyright laws of the United States.
RESTRICTED RIGHTS LEGEND
Use, duplication or disclosure by the Government is subject to restrictions as set forth in subparagraph (c)( 1 Xii) of
the Rights in Technical Data & Computer Software clause at DFARS 252.227-7013.
Ready Systems, 470 Potreno Avenue, Sunnyvale, CA 94086
Specifications subject to change without notice.
Motorola, Private-Line, and Digital Private-Line are trademarks of Motorola, Inc.
VRTX, RSC, Ready Systems Corp. are trademarks of Ready Systems Corporation.
. . .
111
Motorola Communications Analyzer
Programming Reference

About this Reference
This manual documents the control and measurement functions provided by the remote interface to the R-2550
and R-2600 Communications System Analyzer Series (R-2600, R-2660, R-2670, R2680). It is intended to provide
all the information necessary to develop application programs that remotely control both units. General usage of
the R-2600 analyzers is described in the R-2600 Communications System Analyzer Series Operator’s Manual,
publication 68-80386B72. General usage of the R-2550 analyzers is described in the R-2550 Communications
System Analyzer Operators Manual, publication 68-80309E.54.
All of the analyzer models operate in a similar manner and many of the remote command are identical for all
products. Where there are differences in the remote commands for the analyzers, the text clearly identifies them.
Section 1
Introduction discusses configuration requirements, the layer model provided by the remote interface, and the three
modes of operation: Standard RS-232, Extended RS-232, and IEEE 488.2.
Section 2
Interface Functions discusses remote and local operations, RS-232 and IEEE 488.1 protocols, and print functions.
Section 3
Syntax Overview discusses the Talker and Listener syntax provided by the analyzer. Differences between the
syntax of the Standard RS-232 mode and the Extended RS-232 and IEEE 488.2 modes are explained.
Section 4
Status Reporting discusses the control and status data structures provided by the IEEE 488.2 model. The
capabilities of the model that are provided when operating under RS-232 control are described.
Section 5
Programming Conventions discusses optional command parameters and optional response parameters.
Section 6
Command Set Organization presents an overall description of the command set; describing command groupings
and manual entries for the commands. A quick reference to the command set is also provided.
Sections 7 and on
The individual command and query pages give detailed descriptions of each command, including syntax,
parameters, responses, and special notes.
Motorola Communications Analyzer
Programming Reference
iv

Contents
1. Introduction........................................................................................................................................................ 1
Configuration
Requirements
.....................................................................................................................
I
Layer Model .............................................................................................................................................
1
Standard
RS-232 Mode.
............................................................................................................................
2
Extended
RS-232 Mode............................................................................................................................
2
IEEE
488.2 Mode.....................................................................................................................................
2
2 Interface Functions.. ............................................................................................................................................
3
Remote, Local,
and Local
Lockout..
.........................................................................................................
.
RS-232 .....................................................................................................................................................
4
IEEE
488
.................................................................................................................................................
-6
Prim Functions .........................................................................................................................................
8
3. Syntax Overview.. ..............................................................................................................................................9
Listening Formats...................................................................................................................................
10
TaIking Formats .....................................................................................................................................
12
Standard
RS-232 Mode Format Exceptions.............................................................................................
13
4. Status Reporting.. .............................................................................................................................................
14
Standard Event
Status Register
...............................................................................................................
16
Standard Event
Status Enable
Register ...................................................................................................
17
Error Queue and Event
Status
Register..
.................................................................................................
18
Status Queue and Event
Status Register.. ................................................................................................
19
Calibration Event
Status
Register ...........................................................................................................
19
StatusByteRegister ................................................................................................................................20
Service Request Enable Register..
..........................................................................................................
.21
5. Programming Conventions ...............................................................................................................................
22
Optional Command Parameters ..............................................................................................................
22
Optional
Response Parameters...............................................................................................................
.25
6. Command Set Organization............................................................................................................................
..2 6
Window Levels.......................................................................................................................................
26
Command Transparency........................................................................................................................
-26
Sequential and Overlapped Commands...................................................................................................
26
Command
Descriptions..
.........................................................................................................................
27
Quick Overview......................................................................................................................................
28
7. Common Commands........................................................................................................................................
32
*cLS
...................................................................................................................................................
...3 3
*EsE
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . _ . . . . . . . . . . . . ._ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..................... 34
*ESEv
*..... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..~.....~...................... . . .._ . . . . . . . . . . . . . . . . . . . . ..35
*ESRv
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .._...............................................................................................................
36
*IDN? (R-2550) . . . . . . . . . . . . . . . . . . . . . . . . . . .._............. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
*IDN? (R-2600)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ............ 38
*opt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ...... . ._....._.. _ ............ 39
*0PC9
- ....................................................................................................................................................
40
*OPT?
(R-2550) .....................................................................................................................................
41
*OPT? (R-2600) .....................................................................................................................................
42
*RST
. . . . . . . . . .._............................. ._. . . . . . . . . . . . ._ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
*sRE
. . . . . . . . . . . . . . . . . . . . . . .._.........................................._.................................................................................. 44
*SRI?
. . . . ..-.-......................................_......_............................................_..........._..........................._.........
45
*!YlW
- . . . . . . . . . . . . . . . . . . . . . . . . . . . ..-...._......................._..........................................-......._.....-............-...................
46
*TRG
....................................................................................................................................................
-47
*TST?.
....................................................................................................................................................
.
*wAI
. . . . . . . . . . .._.................. * . . . . . _.. _..._. _ . . . . . . . . . . . . . . _ .*_........._.............................. * . . . . . . . . .._........................__...... 49
94990~688030!2355-1.00
V
Motorola Communications Analyzer
Programming Reference

Contents (coIltinued)
8. Calibration .......................................................................................................................................................
50
CM
(R-2600) .........................................................................................................................................
-51
CS .........................................................................................................................................................
-52
9. DTMF Modulation
Source.. ..............................................................................................................................
53
DE.....................................................................................................................................................
m.54
DS ..........................................................................................................................................................
55
10. Tone Encode
Modulation Source..................................................................................................................
..5 6
EA .._...._............._._........... _ . .._............_........ _ . . . . . . . . . . . . _ . . . . . . . . . . . . . . . . . . .._..........._.._............_..........._.................. 57
EB ..........................................................................................................................................................
58
ED..........................................................................................................................................................
59
EF ...........................................................................................................................................................
60
EG (R-2550).
.........................................................................................................................................
-61
EG (R-2600).
..........................................................................................................................................
62
EN
..........................................................................................................................................................
63
EP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .._..........._..........._................~.............~........
64
EQ..........................................................................................................................................................
65
ER ..........................................................................................................................................................
66
ES
........................................................................................................................................................... 67
ET (R-2550)
.........................................................................................................................................
..6 8
ET (R-2600)
...........................................................................................................................................
70
EV ..........................................................................................................................................................
72
El ...........................................................................................................................................................
74
E2.. .........................................................................................................................................................
75
E3 . . . .._._......_.............................._............................ _ . . . . . . . . . . . ..__............_.................................................... 76
E4.. .........................................................................................................................................................
78
E5.. .........................................................................................................................................................
80
11. Special Fum.ions
...........................................................................................................................................
82
FA. . . . . . . . . . . . . . . . .
.._......._..............~......_........................._._......__............._..................._..__.............................. 83
FC . .._......_......................._._.............._......._............._.._..................._......................._.............._...._............. 84
FD
..........................................................................................................................................................
85
FF
...........................................................................................................................................................
86
FG ..........................................................................................................................................................
87
FP
........................................................................................................................................................... 89
FR
.......................................................................................................................................................... 90
Fs
...........................................................................................................................................................
91
FV? (R-2550)
.........................................................................................................................................
93
FV? (R-2600)
.........................................................................................................................................
94
12. General Remote
Functions ..............................................................................................................................
95
GB
..........................................................................................................................................................
96
GC
..........................................................................................................................................................
97
GK . . . .._._......_.._...................__..................__...... _ . . . . . . . . . . . . . . . ..____.. _ __..._..... _.._ . . . . . . . . _...__ .._............_..._.......__......
99
GL........................................................................................................................................................
100
GM
.......................................................................................................................................................
101
GS ........................................................................................................................................................
102
GZ........................................................................................................................................................
103
G2
........................................................................................................................................................
104
Motorola Communications Analyzer
Programming Reference
vi

Contents
(continued)
13. KHz Modulation Source
...............................................................................................................................
105
KS ........................................................................................................................................................
106
14. Meterino
5 .........................................................................................................................................
107
MA
.......................................................................................................................................................
108
.......................................................................................................................................................
109
MF ........................................................................................................................................................
110
MP .....
...................................................................................................................................................
112
MR
.......................................................................................................................................................
114
MS ........................................................................................................................................................
116
Mx..
.....................................................................................................................................................
117
hI2 .......................................................................................................................................................
118
15. Non-Sequence Decode..
................................................................................................................................
I 19
ND
........................................................................................................................................................
120
NP ........................................................................................................................................................
121
NQ?
......................................................................................................................................................
122
NT ........................................................................................................................................................
123
16. Display..
......................................................................................................................................................
-124
OB
........................................................................................................................................................
125
OE
........................................................................................................................................................
126
OG
........................................................................................................................................................
128
OM
.......................................................................................................................................................
130
OS
........................................................................................................................................................
133
O-l-
........................................................................................................................................................
136
17. Memory Resets..
..........................................................................................................................................
I37
PM (R-2550)
.........................................................................................................................................
138
PM (R-2600)
.........................................................................................................................................
139
PS (R-2550).......................................................................................................................................... 140
PS (R-2600)
..........................................................................................................................................
141
18. RF Control
...................................................................................................................................................
142
RD ........................................................................................................................................................
143
RG..
......................................................................................................................................................
14.5
RM .......................................................................................................................................................
147
RS ........................................................................................................................................................
149
RT ........................................................................................................................................................
151
19. Sequence
Decode .........................................................................................................................................
153
SG
........................................................................................................................................................
154
SQ?
......................................................................................................................................................
156
ss
.........................................................................................................................................................
1.57
sv
........................................................................................................................................................
158
sx........................................................................................................................................................ 160
s5
.........................................................................................................................................................
161
20. External Modulation
.....................................................................................................................................
163
xs........................................................................................................................................................ 164
21. Inquiry ..........................................................................................................................................................
165
C? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .................................
166
E?
.........................................................................................................................................................
167
M? ........................................................................................................................................................
168
S? .........................................................................................................................................................
169
94990-68-80309E55-1.00
vii
Motorola Communications Analyzer
Programming Reference

Motorola Communications Analyzer
Programming Reference
This page intentionally ief blank
. . .
VIII

1. Introduction
The R-2550, and the R-2600 are both equipped with a standard RS-232 interface. Optionally, the R-2600 is
equipped with an IEEE 488 interface. An IEEE 488 interface is not available on the R-2550 analyzer. Either of
these interfaces may be used to remotely control the analyzer using a set of commands, queries, and responses that
are defined within this document.
Note
Throughout this document, the term analyzer is used to refer to either the R-2550 or the R-2600.
Whenever digerences exist between the finctionality of the two products, specific references to
the model are made.
Configuration Requirements
All R-2550 software versions are capable of providing the applicable capabilities described throughout this
reference.
The R-2600 must be equipped with software version VOI .05 or greater to use the capabilities described throughout
this reference. Software versions preceding VO1.05 provide the remote control capabilities described in the
original, and the “1 June 91? printing of the Motorola R-2600 Communications System Analyzer Operator’s
Manual, publication 68-P80386B72. The original printing has no date on the back cover. Subsequent revisions
show the revised printing date on the back cover.
Note
Application programs developed for older versions of the R-2600 sofrware are firlly compatible
with the material described in this document.
To use the IEEE-488 interface, the R-2600 must be equipped with the IEEE-488 option and software version
Vol.05 or greater.
The set of installed options can be determined by accessing the Version menus. To determine the software version,
press the SPF hardkey on the front panel. The Special Functions screen will be displayed. Cursor down to the
Version selection and press the Display Table softkey. The Version screen will be displayed. Cursor down through
each of the major option selections and press the DispZay Table softkey. The installed options will be displayed.
Layer Model
The Communications Analyzer is designed to act as a device under the influence of a controller. Communication
between the Analyzer and a controller is accomplished using a set of codes and formats as defined in one of two
models. Each model is built upon a layered protocol, which allows controllers using the RS-232 interface to
access the IEEE 488.2 communications protocols.
The layer model defines four different levels of communication that occur between the analyzer and a controller.
At the lowest layer, the R-2600 supports either the RS-232 or the IEEE 488.1 hardware interfaces. Above this
layer, the R-2600 supports either the IEEE 488.2 syntax and data structure model or the backwards-compatible
RS-232 remote interface. An additional set of common IEEE 488.2 commands and queries exist at the third layer,
providing access to the IEEE 488.2 data structures. The fourth and highest layer provides analyzer specific
commands and queries.
94990-6&80309E551.00 Motorola Communications Analyzer
Programming Reference

R-2550 Remote Interface Layer Model
I
R-2550 Specific Commands and Queries
IEEE 488.2 Common Commands and Queries
1 ~~.~-i~~~~~~~~ 1
The R-2550 operates within the layer model in one of two modes, Standard RS-232, or Extended RS-232.
R-2600 Remote Interface Layer Model
R-2600 Specific Commands and Queries
IEEE 488.2 Common Commands and Queries
I
R-2600 Specific
Syntax and Data Structures
I
IEEE 488.2
Syntax and Data Structures
I
I
RS-232 Hardware Protocols
I
IEEE 488.1 Hardware Protocols
I
The R-2600 operates within the layer model in one of three modes, Standard RS-232, Extended RS-232, and
IEEE 488.2.
I
Remote Mode
I
Hardware 1 Status Reporting I Syntax
Standard RS-232
RS-232
I
Backwards
I
Backwards
Compatible Compatible
Extended RS-232
RS-232
I
Backwards IEEE 488.2
Compatible
IEEE 488.2
I
IEEE 488.1
I
IEEE 488.2
I
IEEE 488.2
Note
Application programs using the Standard RX32 model can gain access to the Extended RS-232
model via the G2 command.
Standard RS-232 Mode
When the analyzer is initially powered on, it assumes all communications will occur over the RS-232 hardware
interface using the Standard RS-232 mode. On the R-2600, if activity is detected on the IEEE 488 interface, the
R-2600 will immediately switch to the IEEE 488.2 mode. The Standard RS-232 mode is completely backward
compatible with versions of software before Version VO1.0.5. Application programs written for older versions of
software can utilize the Standard RS-232 mode without change.
Extended W-232 Mode
The Extended RS-232 mode provides some additional services from the IEEE 488.2 specification while operating
over the RS-232 hardware interface. Within this mode, all of the IEEE 488.2 status and data structures and
syntactic definitions are available to provide a consistent and powerful remote interface while still relying upon
the RS-232 hardware for the low-level communications interface.
IEEE 488.2 Mode
The IEEE 488.2 mode provides a remote interface via the IEEE 488.1 hardware that is fully compliant with the
IEEE 488.2 specification. This is the only mode of operation available for the IEEE 488 interface. The most
important aspect of this specification is the status and error control/reporting capabilities, defmed in Section 4.
Motorola Communications Analyzer
Programming Reference
2
94990-6&80309E55-1.00

2. Interface Functions
Remote, Local, and Local Lockout
The analyzer can be in one of three states: power off, local (front panel) control, and remote control. Upon
power-up, the analyzer will automatically enter the local control state.
The R-2550 enters the remote control state upon detection that a remote device is trying to take control over the
RS-232 interface. Once in the remote control state the R-2550 executes commands input through the RS-232
interface.
The analyzer enters the remote control state upon detection that a remote device is trying to take control over
either the RS-232 or IEEE-488 interfaces. Once in the remote conuol state the analyzer executes commands input
through the remote control interface.
The only front panel controls available to the operator are:
l power switch
l squelch knob
l brightness control knob
l volume control knob
.
“go to local” hard key
The Fl hard key functions as the “go to local” key while in the remote control state. A local lockout feature is
available when the analyzer is in the remote control state. The “go to local” hard key is not accepted while the
local lockout feature is enabled. The local lockout feature is disabled upon entering the remote control state.
The analyzer will remain in the remote conuol state until any of the following occtm
l a “go to local” keystroke from front panel
l detection of “go to local” from remote controller
l power is switched off
The analyzer display indicates the unit is under remote control as long as it is in the remote control state. While
the local lockout feature is enabled the display indicates local lockout is enabled. An indication that the Fl key is
the “go to local” key is displayed if and only if the local lockout feature is disabled and the analyzer is in the
remote control state.
The analyzer will enter the local control state upon:
l powerup
l detection of the “go to local” command (GL) through the remote control interface
l acceptance of a “go to local” keystroke from the front panel
94990-6&80309E55-1.00
Motorola Communications Analyzer
Programming Reference

RS-232
The RS-232 port is a 2.5pin female 9” connector that supports connectivity to the conuoller or printer output via
serial connection. The following table describes the pin definitions.
Pin(s) Name
Description
1
GND
ground
2
TXD
transmit data
3
RXD
receive data
4
RTS
request to send
5
CTS
clear to send
6 DSR
data set ready
7
SIG GND
signal ground
8
DCD-
data carrier detect (not connected)
9-19
not used
20
DTR-
data terminal ready
21
not used
22
Ring Indicator (not connected)
23-25
not used
DB-25
DB-9
Analyzer Printer or PC
TxD 2 2RxD
RxD3 3TxD
CTS 5 7 RTS
DSR 6
I
4 DTR
DCD 8
DTR 20 8 CTS
GND 7
5
GND
Cable Diagram: PN 3080387B59
Note
For printer use, pins 5 and 20 of this port should be tied together inside the cable to the printer.
30-80387B85 primer cable provides this interface. Using this cable allows normal RS-232
communications without any handshaking capabilities.
Motorola Communications Analyzer
Programming Reference 4
94990-6&80309E55-1.00

The following cables diagrammed are used with the Monitor Service Software (MSS) and Field Installation
Software (FE) to install software options in the analyzer.
DB-25
Analyzer
DB-9
Personal Computer
TxD 2
RxD 3
RTS 4
CTS 5
DSR 6 -
DCD 8
DTR 20
5
GND 7
Cable Diagram: 25 to 9 pin
RxD
TxD
RTS
DTR
DCD
CTS
DSR
GND
DB-25 DB-25
Analyzer
Personal Computer
TxD 2
F&D3
RTS 4
CTS 5
DSR 6
DCD 8
DTR 20
GND 7
94990-6&80309355-1.00
Cable Diagram: 25 pin
5
3 RXD
2 TXD
4 RTS
20 DTR
8 DCD
5 CTS
6 DSR
7 GND
Motorola Communications Analyzer
Programming Reference

TheRS-232 hardwareinterfacesupportsthefunctionalitydescribedinthefollowing tabk
Baud Rate
Stop Bits
Parity
Data Bits
Auto Line-Feed
150
300
1200
2400
4800
9600
1
1.5
2
None
Even
odd
Yes
No
IEEE 488 (available only on the R-2600)
The IEEE 488 interface provides a high-speed hardware interface supporting communication among multiple
devices within the same area. Each device on the IEEE 488 bus has its own address, allowing the Controller in
charge to communicate directly with any device on the bus. Devices can either talk or listen, depending on if the
device is transmitting information or receiving information, respectively.
The interface capabilities of the R-2600, as defined by IEEE 488.1, are SHl, AHl, TE6, LE4, SRl, RLl, PPO,
DCl, DTl, CO, and E2.
The R-2600 allows both primary and secondary addressing. Both Primary addresses and Secondary addresses
range from 0 to 30. Secondary addressing can be disabled. The R-2600 uses the same address for both Talk and
Listen modes.
The IEEE 488 address of the R-2600 is accessed from the Remote Interface menu. To modify the address, press
the SPF hardkey on the front panel. The Special Functions screen will be displayed. Cursor down to the Remote
Interface selection and press the Display Table softkey. The Remote Interface screen will be displayed. The screen
allows modification of both the Primary and Secondary addresses.
Note
The Primary and Secondary address selections will only be available on the Remote Znterface
menu if the R-2600 is equipped with the ZEEE 488 option.
To disable secondary addressing, place the cursor on the Secondary Address and press the Disable softkey. The
Secondary Address will be displayed as two dashes, indicating that Secondary Addressing has been disabled-
Motorola Communications Analyzer
Programming Reference
94990-6&80309E55-1.00

Note
The IEEE 488 Secondary Address will initially be disabled when the R-2600 is shipped from the
factory. The Reset capabilities of the R-2600 will not alter the Primary or Secondary Address
settings - they can only be modified under local control by operator interaction.
TheIEEE 488 interfaceprovidesbothcommandanddatacommunications,dependinguponthebuscommandson
thatinterface.The setofbus commands is given in the following table.
Bus Command Mnemonic Description
DAV Data Valid Indicates the condition of information
on the DIO signal lines.
NRFD Not Ready for Indicates the condition of readiness
Data of the R-2600 to accept data.
NDAC Not Data Accepted Indicates the condition of acceptance
of data by the R-2600.
ATN Attention Asserted true to indicate the data is
to be interpreted as control data,
device data otherwise.
IFC
Interface Clear Places the R-2600 IEEE interface in a
known, quiescent state.
SRQ
Service Request The R-2600 asserts this line to
request service from the controller.
EOI
End or Identify Used by the R-2600 Talker state to
indicate the end of a multi-byte
transfer.
94990-6&80309ES1.00
Motorola Communications Analyzer
Programming Reference

Print Functions
The standard print function gives the user the opportunity to send the data displayed on the R-2600 CRT display
to a printer. When the cPR1, key is selected on the front panel, the data is sent over the RS-232 serial bus in
ASCII format. With the standard print function, only the text information is printed, the scope trace data is not
printed.
If the R-2600 has the Graphics Mode Option installed, the screen data can be sent over the RS-232 serial bus as
graphics data. If the user’s printer is capable of IBM-EPSON graphics, all of the data displayed on the CRT will be
printed, including the scope Uace.
The Graphics Control Command Sequence to implement 8-pin Bit Image Mode Graphics is as follows:
ESC+@
Printer Initialization.
EsC+A+S Line Space Setting
ESC+L+nl+nZ Dot Density, number of columns of dots per line
Where: ESC =
ASCII Escape Character 1B (Hexidecimal)
@ =Printer
Lnitialization
A =
Line Space Setting
8
=
8172 of an inch
L = Dot Density Designation = Double Density
nl,n2 =
number of columns of dots on a line = 0,2
Note
The printfunction is not available on the R-2550.
Motorola Commuuications Analyzer
Programming Reference
8
94990-6&80309E55-1.00

3. Syntax Overview
The analyzer functions as a Listener when accepting information from a controiler and as a Talker when
responding with information back to the controller. The syntax for both the Listening and Talking formats is
defined using BNF notation, which is described below.
Example
Notation Usage
[
item ] item is optional
( item 1 item may occur 0 or more times
iteml I item2 select either item1 or item2
[AlBIC[Dl
can form the following strings
*AR
*CD
l B
l C
bul the following strings are illegal
l ABCD* BB
*AD
l D
Example
can form at Least the following strings
l K
l EGK
l EK
l FGIK
l EFFK
l GGHK
but the following strings are illegal
l EF
l GHGIFK
l EEK
l EFFGEK
l HIK
l IK
94990-6&80309E551.00
9
Motorola Communications Analyzer
FVogramming Reference

Listening Formats
The analyzer meets all required IEEE-488.2 encoding syntax. The syntax is specified to be very flexible to allow a
maximum variety of controller’s to utilize the analyzer remote interface. This flexibility also allows the analyzer
language to appear in a form that is more understandable to the reader.
The following list gives the syntax for a <Terminated Program Message>, which is the syntax accepted by the
analyzer as a Listener.
<Terminated Promam Message>
[ <program Message> ] <program Message Terminator,
&romam Message Terminator>
[ <White Space> ] “END I NL “END 1 NL
cProm Message
{ [ cF’rogram Message Unit ] ; }
&romam Message Univ
<Command Message Unit> I <Query Message Univ
<Command Message Unio
<Command Program Header> [ <White Space> <program Data> { cProgram Data Separator>
cProgram Data> >]
cOuerv Message Unit>
<Query Program Headen [ <White Space> Program Data> { cPro,gram Data Separator>
<Program Data> } ]
<Command Program Header,
[ -cWhite Space> ] [ * ]cAlpha> { _ I <Alpho I d)igiu }
<Ouerv Program Header,
[ <White Space> ] [ * ] <Alpha> { _ I <Alpha> I cDigit> } ?
<Promam Data>
cDecimal Numeric Program Data> I cSning Program Data>
cDecimal Numeric Promnm Data>
cMantissa> [ <White Space> ] [ <Exponent ]
<Mantissa>
[+I-] {cDigi~}.cDigi~{cDigi~}l
[+I-]cDigio{cDigiu}[.{<Digiu}]
<BxDonent>
EIe{c?VhiteSpace>}[+I-]cDigiD{d>igit>}
&.rinn Program Dara>
’ { ” I <Non-Single Quote Character> > ’ I
” { ” ” I <Non-Double Quote Character> } ”
cWhi te Snace
<White Space Character> { <white Space Character, >
<White Snace Character>
is an ASCII-encoded character in the following range:
l 00 through 09 (hexadecimal)
l OB through 20
Motorola Communications Analyzer
Programming Reference
10 94990_6&80309E55-
1.00
