DATA SHEET
Highlights
Designed specifically for
single-PC households
Simple, auto-launching
installation wizard (no CD
required), printed instructions,
and automatic configuration
make setup easy, even for
novices
Runs off the computer’s
power — no other power
source need
The easy, affordable way to upgrade dial-up service to broadband DSL
Ultimate Ease for the Consumer
The Motorola Netopia®3342N ADSL2+ USB Mini
Modem is the ideal solution for consumers who
want to upgrade easily and inexpensively from dial-
up to broadband DSL. Easy-to-follow on-screen and
printed instructions make installation simple and
painless.
The self-installing Mini Modem is designed
specifically for single-PC households. Simply
connect it to a USB port on a Windows®XP™ or
Vista™ computer, and Windows launches a self-
contained, flash-based installation wizard.
The ultra-compact Mini Modem is powered by the
computer, eliminating the need for an external
power supply. Its full-featured software is completely
self-contained on the the modem for ease of use
and simplicity. For quick Internet surfing, the Mini
Modem intelligently configures Internet Explorer*
browser settings to accommodate the change from
dial-up to broadband.
Easier for Providers, Too
The 3342N ADSL2+ USB Mini Modem is the
undisputed choice for providing alternative
broadband connectivity to single-PC households. Its
unique self-installation and automatic configuration
reduce service and support calls while greatly
improving customer satisfaction.
The Mini Modem supports a firewall and VPN.
Compliance with the DSL Forum’s TR-069 remote
management specification ensures comprehensive
remote manageability.
In addition to simplifying installation, the Mini
Modem’s intelligent software features reduce the
cost of ongoing customer support. One-click
diagnostics make customer self-support intuitive,
easy, and fast. The built-in Point-to-Point Protocol
over Ethernet (PPPoE) client eliminates licensing
costs and reduces the support burden usually
created by PPPoE client installation on home
computers.
3342N
Netopia®ADSL2+ USB Mini Modem
*Tested with Internet Explorer.

Motorola, Inc. 101 Tournament Drive, Horsham, Pennsylvania 19044 U.S.A. www.motorola.com
MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. Netopia is a registered trademark of Netopia, Inc., a wholly-owned subsidiary of
Motorola, Inc. Microsoft, Windows and Windows Me are registered trademarks of Microsoft Corporation and Windows XP and Windows Vista are trademarks of Microsoft
Corporation. All other product or service names are the property of their respective owners. © Motorola, Inc. 2008. All rights reserved.
548522-001-b 0708 5888 - 0K
DATA SHEET
3342N
Netopia ADSL2+ USB Mini Modem
Hardware Features
WAN INTERFACE
ADSL2/ADSL2+, RJ-11
LAN INTERFACE
Integrated USB cable (400 mm, 15.7") with USB Series "A"
connector
ENCODING AND LINE SPEED
ANSI T1.413 Issue 2
ITU G.992.1 (G.dmt) Annex A
ITU G.992.2 (G.lite)
ITU G.992.3 (ADSL2 DMT)
ITU G.992.4 (ADSL2 G.lite)
ITU G.992.5 (ADSL2+) Annex A
DSL Forum TR-067 capable
PROTOCOL SUPPORT
ATM Adaptation Layer 5 (AAL5)
Bridged or Routed Ethernet Encapsulation
IGMP
PPP over Ethernet Gateway
PPP over ATM (LLC and VC Multiplexing)
ROUTING
Network Address Translation (NAT), IP maps, and pinholes
IP multicast snooping
DHCP client, server, and relay
DNS proxy
Dynamic DNS
BRIDGING
Transparent bridged Ethernet over ATM
OPERATING SYSTEMS
Windows XP and Vista, self-installing
WHQL certified
SECURITY
Network Address Port Translation (NAPT)
Stateful firewall
Denial-of-service protection
Pinholes
Software and games control
MANAGEMENT
TR-069 remote management
Two-level password-protected access
Remote and local management using web UI (HTTP) and CLI
(Telnet)
Software upgradeable
Seven-layer diagnostics and system logs
SNMP v1 & v2 Utilities Ping, Traceroute, Reverse DNS
LEDs USB and DSL; Link, Status,
and Activity
REGULATORY
USA FCC Part 15 Class B
FCC Part 68
UL 60950
Canada Industry Canada ICES-003
Industry Canada CS-03
C-UL, CSA 60950
Europe EN 300 386
ITU K.21
EN 60950
RoHS
ENVIRONMENTAL
Operating: 0 ºC to 40 ºC
(32 ºF to 104 ºF)
Storage Temperature: 0 ºC to 70 ºC
(32 ºF to 158 ºF)
Relative Humidity (20% to 80% non-condensing)
Power: USB-powered 500mA at
5 VDC (max)
WEIGHT AND DIMENSIONS
Weight: 85 g (3 oz)
Dimensions: 0.95 in H x 1.8 in W x 3.4 in L
(24.1 mm x 45.5 mm x 87.4 mm)
