Motorola DC800 User manual

motorola.com
Bluetooth
®
Tr a n s c e i ve r

DRAFT
1
Welcome
Welcome to the world of Motorola
digital wireless communications! We
are pleased that you have chosen the
Motorola DC800 Bluetooth
®
Transceiver.
1 Pairing Button. 2 Power Button.

DRAFT
2
Transceiver Indicators
Stereo
Tr a n s c e i v e r
Status LED Indicator
Power Off Off
Pairing Mode On (Steady)
Pairing
Successful
10 rapid flashes
Standby (No
Music Playing)
Flashes every
3-seconds
(0.1 seconds ON,
2.9 seconds OFF)
Standby (Music
Playing)
Flashes every
8-seconds
(2.0 seconds ON,
6.0 seconds OFF)

DRAFT
3
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
www.hellomoto.com
1-800-331-6456 (United States)
1-888-390-6456 (TTY/TDD United States for
hearing impaired)
1-800-461-4575 (Canada)
The use of wireless devices and their accessories
may be prohibited or restricted in certain areas.
Always obey the laws and regulations on the use
of these products.
MOTOROLA and the Stylized M Logo are
registered in the US Patent & Trademark Office.
The Bluetooth trademarks are owned by their
proprietor and used by Motorola, Inc. under
license. All other product or service names are
the property of their respective owners.
© Motorola, Inc., 2005.
6809489A95-O

DRAFT
5
Contents
Introduction . . . . . . . . . . . . . . . . . . . 12
Transceiver Controls . . . . . . . . . . . 14
Using Your Transceiver . . . . . . . . . . 17
Connecting To Your Home Audio
System . . . . . . . . . . . . . . . . . . . . . 18
Pairing Your Transceiver with a
Bluetooth Headset . . . . . . . . . . . . 23
Transceiver Features . . . . . . . . . . . 29
Transceiver Indicators . . . . . . . . . . 31
Export Law Assurances . . . . . . . . . 34

DRAFT
6
Safety Information
Safety
Information
IMPORTANT INFORMATION ON SAFE
AND EFFICIENT OPERATION. READ
THIS INFORMATION BEFORE USING
YOUR DEVICE.
Users are not permitted to make
changes or modify the device in any
way. Changes or modifications not
expressly approved by the party
responsible for compliance could void
the user’s authority to operate the
equipment. See 47 CFR Sec. 15.21.
This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference, and

DRAFT
Safety Information
7
(2) this device must accept any
interference received, including
interference that may cause undesired
operation. See 47 CFR Sec. 15.19(3).
Electromagnetic
Interference/Compatibility
Note: Nearly every electronic device is
susceptible to electromagnetic
interference (EMI) if inadequately
shielded, designed, or otherwise
configured for electromagnetic
compatibility.
Facilities
To avoid electromagnetic interference
and/or compatibility conflicts, turn off
your device in any facility where posted
notices instruct you to do so. Hospitals
or health care facilities may be using

DRAFT
8
Safety Information
equipment that is sensitive to external
radio frequency (RF) energy.
Aircraft
When instructed to do so, turn off your
device when on board an aircraft. Any
use of a device must be in accordance
with applicable regulations per airline
crew instructions.
Medical Devices
Hearing Aids
Some devices may interfere with some
hearing aids. In the event of such
interference, you may want to consult
with your hearing aid manufacturer to
discuss alternatives.
Other Medical Devices
If you use any other personal medical
device, consult the manufacturer of your
device to determine if it is adequately

DRAFT
Safety Information
9
shielded from RF energy. Your physician
may be able to assist you in obtaining
this information.
Industry Canada Notice to
Users
Operation is subject to the following
two conditions: (1) This device may not
cause interference and (2) This device
must accept any interference, including
interference that may cause undesired
operation of the device. See Ref IC: RSS
210 Sec. 5.11. The term “IC:” before the
certification/registration number
signifies that registration was
performed based on a Declaration of
Conformity indicating that Industry
Canada technical specifications were
met. It does not imply that Industry
Canada approved the equipment. See

DRAFT
10
Safety Information
Ref IC Self-Marking 6(f) and RSP-100
Sec. 4.
FCC Notice to Users
This equipment has been tested and
found to comply with the limits for a
Class B digital device, pursuant to part
15 of the FCC Rules. These limits are
designed to provide reasonable
protection against harmful interference
in a residential installation. This
equipment generates, uses and can
radiate radio frequency energy and, if
not installed and used in accordance
with the instructions, may cause
harmful interference to radio
communications. However, there is no
guarantee that interference will not
occur in a particular installation. If this
equipment does cause harmful
interference to radio or television

DRAFT
Safety Information
11
reception, which can be determined by
turning the equipment off and on, you
are encouraged to try to correct the
interference by one or more of the
following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between
the equipment and the receiver.
• Connect the equipment to an
outlet on a circuit different from
that to which the receiver is
connected.
• Consult the dealer or an
experienced radio/TV technician
for help.

DRAFT
12
Introduction
Introduction
Your stereo Bluetooth
®
transceiver
connects to your home audio system
turning it into a wireless music system!
• Listen to music from your phone’s
built-in MP3 player over your
home audio system speakers
• Play CDs on your home audio
system and send the music
wirelessly to your Motorola
Bluetooth Stereo Headset
• Use high power Bluetooth (Class
1) which allows you to roam
around your house and even as
far as 300 feet (10 meters) while
listening to music

DRAFT
Introduction
13
•
Play MP3’s from your home
computer or laptop and listen to
them over your home audio
speakers using the Motorola USB
Adapter. Your computer and
stereo can be up to 300 feet (100
meters) apart.
• Use your transceiver with any
Bluetooth audio device, even
products from other
manufacturers

DRAFT
14
Introduction
Transceiver Controls
1 Pairing Button — Connects
transceiver to other Bluetooth devices,
such as the HT820 headset.
2 Power Button — Turns transceiver
on or off.
1 Pairing Button. 2 Power Button.

DRAFT
Introduction
15
.
3 Housing Feet — Built-in recessed
feet rotate 90 degrees allowing
the transceiver to stand vertically.
Feet fold flush for compact
storage.
3 Housing Feet.

DRAFT
16
Introduction
4 a & b Audio Out Left / Audio Out
Right —
Music output from your
transceiver to play on your home
audio system.
5 a & b Audio In Left / Audio In
Right —
Music input to your
transceiver to play on the remote
device.
6 Power Jack — Plug in power
supply.
4a Audio Out Left
4b Audio Out Right
5a Audio In Left
5b Audio In Right
6 Power Jack

DRAFT
Using Your Transceiver
17
Using Your
Transceiver
Your transceiver can connect to any
device that contains audio input and
output jacks. The following steps
describe how to connect to your home
audio system. The steps are the same
to connect the transceiver to any other
device with audio input and output
jacks.

DRAFT
18
Using Your Transceiver
Connecting To Your
Home Audio System
The transceiver transmits stereo music
to a Bluetooth
®
enabled device such as
the HT820 Stereo Bluetooth Headset. It
also also receive stereo music from a
Bluetooth enabled device such as a
mobile phone, MP3 player, or PC.

DRAFT
Using Your Transceiver
19
To connect your transceiver:
Step
1 Use the included RCA cables to
connect the
Audio Out Left and
Audio Out Right jacks on the
transceiver to unused Audio In Left
and Audio In Right jacks on your
home audio system.
Audio Out Right
Audio Out Left
Audio Out Right
Audio Out Left
Home Audio System
