Motorola MICOM-3F User manual

COMMERCIAL WARRANTY (STANDARD)
Motorola radio communications products are warranted to be free from defects in material and
workmanship for a period of ONE (1) YEAR, (except for crystals and channel elements which are
warranted for a period of ten (10) years) from the date of shipment. Parts, including crystals and
channel elements, will be replaced free of charge for the full warranty period but the labor to replace
detective parts will only be provided for One Hundred-Twenty (120) days from the date of shipment.
Thereafter purchaser must pay for the labor involved in repairing the product or replacing the parts at
the prevailing rates together with any transportation charges to or from the place where warranty
service is provided. This express warranty is extended by Motorola Communications and Electronics
Inc., 1301 E. Algonquin Road, Schaumburg, Illinois 60196, to the original purchaser only, and only
to those purchasing for purpose of leasing or solely for commercial, industrial, or governmental use.
THIS WARRANTY IS GIVEN IN LIEU OF ALL OTHER WARRANTIES EXPRESS OR IMPLIED WHICH
ARE SPECIFICALLY EXCLUDED, INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL MOTOROLA BE LIABLE FOR INCIDENTAL
OR CONSEQUENTIAL DAMAGES TO THE FULL EXTENT SUCH MAY BE DISCLAIMED BY LAW.
In the event of a defect, malfunction or failure to conform to specifications established by Seller, or if
appropriate, to specifications accepted by Seller in writing, during the period shown. Motorola, at its
option, will either repair or replace the product or refund the purchase price thereof, and such action
on the part of Motorola shall be the full extent of Motorola's liability hereunder.
This warranty is void if:
1. The product is used in other than its normal and customary manner.
2. The product has been subject to misuse, accident, neglect or damage.
3. Unauthorized alterations or repairs have been made, or unapproved parts used in the equipment.
This warranty extends only to individual products, batteries are excluded, but carry their own
separate limited warranty. Because each radio system is unique, Motorola disclaims liability for range,
coverage, or operation of the system as a whole under this warranty except by a separate written
agreement signed by an officer of Motorola.
Non-Motorola manufactured products are excluded from this warranty, but subject to the warranty
provided by their manufacturers, a copy of which will be supplied to you on specific written request.
To obtain performance of this warranty, purchaser must contact [email protected].
This warranty applies only within the United States.
COMPUTER SOFTWARE COPYRIGHTS
The Motorola products described in this instruction manual may include copyrighted Motorola
computer programs stored in semiconductor memories or other media. Laws in the United States
and other countries preserve for Motorola certain exclusive rights for copyrighted computer
programs, including the exclusive right to copy or reproduce in any form the copyrighted computer
program. Accordingly, any copyrighted Motorola computer programs contained in the Motorola
products described in this instruction manual may not be copied or reproduced in any manner
without the express written permission of Motorola. Furthermore, the purchase of Motorola products
shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license
under the copyrights, patents or patent applications of Motorola, except for the normal non-
exclusive, royalty free license to use that arises by operation of law in the sale of a product.

best radio for worst events
MICOM-3F/3T/3R
HF-SSB Transceivers
© Motorola Inc., 2004
Motorola Inc.
Land Mobile Products Sector
1301 E. Algonquin Road
Schaumburg, IL 60196
Service Manual
Cat. No. 6886859J01

Table of Contents
Page
Chapter
1 Introduction ........................................................................................................1-1
1-1. Notational Conventions ........................................................................................1-1
1-2. Scope of this Manual ............................................................................................1-1
1-3. Federal Communication Commission Regulations .................................................1-2
1-3.1 Compliance and Control Guidelines and Operating Instructions for
Mobile Two-Way Radios Installed in Vehicles .........................................1-2
1-3.2 Compliance and Control Guidelines and Operating Instructions for
Mobile Two-Way Radios Installed as Fixed Site Control Stations .............1-3
1-3.3 Electromagnetic Interference/Compatibility.............................................1-3
1-3.4 Facilities .................................................................................................1-4
1-3.5 Vehicles..................................................................................................1-4
1-3.6 Driver Safety...........................................................................................1-4
1-3.7 When using your radio while driving, please:..........................................1-4
1-3.8 Operational Warnings.............................................................................1-4
1-3.9 Restrictions.............................................................................................1-5
1-4. Safe Handling of CMOS Devices...........................................................................1-5
Chapter 2 Test Equipment & Spare Parts.............................................................................2-1
2-1. Test Equipment.....................................................................................................2-1
2-2. Spare Parts............................................................................................................2-2
Chapter 3 Disassembly & Reassembly.................................................................................3-1
3-1. General ................................................................................................................3-1
3-2. MICOM-3 Disassembly.........................................................................................3-2
3-2.1 Removing the Control Head ...................................................................3-2
3-2.2 Removing the Cover (8) ..........................................................................3-3
3-2.3 Removing the RF Shield (13)...................................................................3-3
3-2.4 Removing the High Power Board (4).......................................................3-3
3-2.5 Control Head Disassembly......................................................................3-3
3-3. MICOM-3 Assembly .............................................................................................3-4
3-3.1 Control Head Assembly ..........................................................................3-4
3-3.2 High Power Board Assembly...................................................................3-4
3-3.3 LORD Board Assembly ...........................................................................3-5
Cat. No. 6886859J01 i

3-3.4 MICOM-3 Assembly ...............................................................................3-5
Chapter 4 Radio Tuning Procedure......................................................................................4-1
4-1. General ................................................................................................................4-1
4-2. Transmitter Calibration .........................................................................................4-1
4-3. Power Calibration .................................................................................................4-1
4-4. Oscillator Calibration ............................................................................................4-1
Chapter 5 Theory of Operation............................................................................................5-1
5-1. Introduction..........................................................................................................5-1
5-2. Transmitter ...........................................................................................................5-1
5-3. Receiver ...............................................................................................................5-7
5-4. Synthesizer ...........................................................................................................5-8
5-5. Electronic Boards ..................................................................................................5-10
5-5.1 LORD Board...........................................................................................5-12
5-5.2 High-Power Board..................................................................................5-14
Chapter 6 Troubleshooting ..................................................................................................6-1
6-1. Overview..............................................................................................................6-1
6-2. Troubleshooting Charts .........................................................................................6-1
Chapter 7 Schematic Diagrams, Layouts and Parts Lists .....................................................7-1
ii Cat. No. 6886859J01

Performance Specifications
MICOM-3F – Model M90AMNOKV5-K
MICOM-3T – Model M91AMNOKV5-K
MICOM-3R – Model M95AMNOKV5-K
General Transmit Frequency Range 1.6 to 30 MHz
Receive Frequency Range 0.1 to 30 MHz (0.1 to 1.6 MHz reduced
performance)
RF Input Impedance 50 Ω
Number of Channels 200 simplex or half duplex, user
programmable
Scanning 5 groups with up to 100 channels per group,
including 1 guard channel.
Programmable scan rate: 1 to 5 sec. per
channel, in 1 sec. steps
Frequency Stability 0.6 ppm (0.1 ppm optional) @ -30°to 60°C
Frequency Drift (Aging) 1 ppm/year
Synthesizer Lock Time 10 msec. max.
Frequency Resolution 10 Hz
Operating Temperature Range -30°to +60°C
Storage Temperature Range -40°to +85°C
Humidity Max. 95% @ 50°C
Remote Control Interface RS-232C (optional)
Modes of Operation • ]3E SSB
• R3E PILOT
• H3E AME
• J2ACW
• J2B RTTY, ARQ, FEC, PACKET, MCW
• B8C FAX, DATA, FSK
Operating Voltage 13. 8 VDC ±20%, negative ground
Dimensions
MICOM-3F 92 H ×302 W ×270 D mm
(3.7 H ×11.9 W ×10.7 D inch)
MICOM-3R 92 H ×302 W ×285 D mm
(3.7 H ×11.9 W ×11.3 D inch)
MICOM-3T 92 H ×302 W ×285 D mm
(3.7 H ×11.9 W ×11.3 D inch)
Cat. No. 6886859J01 iii

Weight
MICOM-3F 5.7 kg (12.5 lb)
MICOM-3R 5.9 kg (13 lb)
MICOM-3T 5.8 kg (12.8 lb)
ALE Per FED-STD-1045 and MIL-STD-188/141B
Transmit
Voice (125 W P.E.P) 14 A (see Note 2 on page vi)
2 Tones (125 W P.E.P) 23 A
Single Tone 28 A
Receive
Full Audio 3 A (see Note 2 on page vi)
Current
Consumption
@ 13.8 VDC
Squelch 2.2 A (see Note 2 on page vi)
Transmitter Peak Envelope Power
(P.E.P)
125 W
Frequency Range 1.6 to 30 MHz
Emissions Authorized J3E, R3E, H3E, J2A, J2B, B8C
Applicable Parts of FCC Rules 15, 80, 90
FCC
Information
FCC Type Acceptance Number
Standard for Stability ABZ9QCC1635
0.1 ppm High Stability Option ABZ9QCC1634
Vibration US MIL-STD 810C Method 514.2
US MIL-STD 810D 514.3
US MIL-STD 810E 514.4
Shock US MIL-STD 810C Method 516.2
US MIL-STD 810D 516.3
US MIL-STD 810E 516.4
Military and
Industrial
Standards
Rain US MIL-STD 810C Method 506.1
US MIL-STD 810D 506.2
US MIL-STD 810E 506.3
Dust US MIL-STD 810C Method 510.1
US MIL-STD 810D 510.2
US MIL-STD 810E 510.3
Salt Fog US MIL-STD 810C Method 509.1
US MIL-STD 810D 509.2
US MIL-STD 810E 509.3
The MICOM-3 also meets the EIA-RS152B for shock, vibration and applicable test
procedures, US FCC for channel occupancy, spurious, interference and frequency
tolerance. It is manufactured according to the demanding standards of ISO 900
and EMC (Electromagnetic Compatibility).
iv Cat. No. 6886859J01

Output Power 125 W P.E.P and average
Reduced Power Levels 25 W, 62 W, 100 W (RSS programmable)
Audio Bandwidth
Voice 350 to 2700 Hz at -6 dB
CW 650 to 1150 Hz
Low Speed Data 1450 to 1950 Hz
High Speed Data 350 to 3300 Hz (see Note 2 on page vi)
Audio Bandwidth Ripple 3 dB
Intermodulation • -31 dB/P.E.P
• -35 dB/P.E.P typical (see Note 1 on page vi)
Harmonic Emissions • -64 dB/P.E.P
• -70 dB/P.E.P typical (see Note 1 on page vi)
Spurious Emissions • -64 dB/P.E.P
• -70 dB/P.E.P typical (see Note 1 on page vi)
Carrier Suppression -50 dB/P.E.P
Undesired Sideband Suppression -55 dB/P.E.P
Audio Distortion 2.5%
1/2 Power Microphone Sensitivity 25 to 125mV (RMS)/600 Ω
Hum & Ripple -50 dB
Inband Noise -60 dB (30 Hz BW)
TX/RX Switching Time 10 msec
Transmitter
Tx Tuning Adjustments None
Receiver Sensitivity (SINAD) SSB • 0.5 µV for 10 dB SINAD
• 0.35 µV typical (see Note 1 on page vi)
• 0.1 to 1.6 MHz with reduced performance
1/2 Rated Power Sensitivity 1 µV for 2.5W audio at speaker
Selectivity -6 dB @ 350 to 2700 Hz
-60 dB @-1 kHz; +4 kHz
Image Rejection -80 dB
IF Rejection -85 dB
Undesired Sideband Rejection -55 dB @ -1 kHz
Spurious -80 dB
Intermodulation -80 dB
Crossmodulation -100 dB @ 100 kHz
Desensitization -100 dB @ 100 kHz
Cat. No. 6886859J01 v

Reciprocal Mixing -100 dB @ 100 kHz
Audio Power at Speaker 5W @ 2.5% distortion
RGC Range 5 µV to 1V (2 dB change in output level)
RGC Time Constants
Voice Attack time 10 msec
Release time 1500 msec
Data Attack time 10 msec
Release time 10 msec
Squelch Constant SINAD (digital)
Clarifier Range ±200 Hz in 10 Hz steps (see Note 2 on page vi)
Receiver Tuning Adjustments None
Preselector Sections Sub-octave (1.6 MHz to 30 MHz range)
Maximum Antenna Input 20 kV transient, 100V RMS for 2 minutes
Controls Standard and optional: Volume, on/off, scroll, squelch, scan, USB/LSB, call,
monitor, priority, function and accessory/programming connector
Note 1: Values noted as "Typical" are valid over 90% or more of the frequency range.
Note 2: Optional for authorized dealers only.
Specifications subject to change without notice.
vi Cat. No. 6886859J01

MICOM-3F Model Complements
FKN4345A DC Cable
FLN2776A Control Head Assembly
FTN6069A Control Head Board
FLN2774A High Power Assembly
FTN6068A High Power Board
FLN2773A Low RF Assembly
FTN6067A Low RF Board
FMN1615A Microphone MICOM-3
FHN5910A MICOM-3 Microphone Module
HMN3596A GM300 Microphone Kit
6802941C60 MICOM-3 Owner's Manual
Operating Options
G424 Add PC Control and Programming Software Package
S135 Enhanced Digital Noise Blanker (recommended for mobile installations)
G112 Enhanced High frequency stability option (0.1 ppm)
S809 Enhanced Interface cable kit for CW key & headphones (Note 1)
G469 Enhanced 24VDC Operation (DC/DC converter)
G419 Enhanced USB COM port for connecting external keyboard
G423 Add ALE DTM/DBM (data transfer message/data block message)
G421 Add Internal GPS Receiver with polling application
G849 Interface option for external secure voice device (VP-116)
Mobile Station Accessories
FAD1410 Automatic Tuning Whip Antenna
or
F2265 Automatic Antenna Tuner
1.6-30 MHz, lightweight, compact housing, includes 17 foot (5.2 m)
RF cable and instruction manual
FAD1400 12 ft Whip Antenna (not required with FAD1410)
FLN2272 Mobile Mounting Kit
FSN1600 External Speaker Assembly
Cat. No. 6886859J01 vii

Fixed Station Operating Options (Note 2)
S71 Delete Delete hand microphone
S308 Add Phone patch interface cable kit, radio to phone patch (Note 1)
G561 Add Interface cable for MICOM Link unit
Fixed Station Accessories
FMN1614 Desk microphone
FLN2271 Junction box for connecting up to 4 accessories in addition to CW key and
headphones (Note 1)
FLN2294 Package kit for continuous duty data transmission. Includes FLN2271
junction box
FPN5590 AC Power supply with autoswitching for 110/220VAC
Service Manuals
6886859J01 MICOM-3F/3T/3R Service Manual
6886862J01 Service manual for MICOM-RM1000 1kW linear amplifier
Field Retrofit Kits
FLN2515 Interface cable kit for CW key & Headphones
FLN2517 Interface cable kit for Phone patch unit
FLN2530 Interface cable for MICOM Link unit
FLN2539 24VDC Operation (DC/DC converter)
FVN4841 PC Control and Programming Software Package
Remote Control Application Option
G420 2-wire Remote Control Head (up to 5 km)
1 kW Linear Amplifier
FLN3175 MICOM-RM1000 1 kW Linear Amplifier Unit (require option G156
interface cable option)
Spare Boards Kit
FEN1672 Recommended Spare Boards Kit for MICOM-3F
viii Cat. No. 6886859J01

4 Year Extended Warranty
FRN8465 4 Year Warranty for MICOM-3F
Note 1: The MICOM-3 includes one accessory port for connecting one accessory device (phone
patch, deskset, ARQ/RTTY modem, fax modem, computer, or headphones). If the
simultaneous connection of two or more (up to 4 plus CW & headphones) devices to the
accessory port is required, order FLN2271 junction box listed in this page. The FLN2271 is
included with FLN2294 package kit.
Note 2: For Fixed Station Operation, order S71 (delete palm microphone), FMN1614 desk
microphone and F2369 AC power supply/charger.
Cat. No. 6886859J01 ix

MICOM-3T Model Complements
FKN4345A DC Cable
FLN2775A Control Head Assembly
FTN6070A Control Head Board
FLN3173A High Power Assembly
FTN6068A High Power Board
FLN2773A Low RF Assembly
FTN6067A Low RF Board
FMN1615A Microphone MICOM-3
FHN591UA MICOM-3 Microphone Module
HMN3596A GM300 Microphone Kit
6886867J01 MICOM-3F/3T/3T Owner's Guide
Operating Options
G424 Add PC Control and Programming Software Package
G112 Enhanced High frequency stability option (0.1 ppm)
S809 Enhanced Interface cable kit for CW key & headphones (Note 1)
G469 Enhanced 24VDC Operation (DC/DC converter)
G419 Enhanced USB COM port for connecting external keyboard
G423 Add ALE DTM/DBM (data transfer message/data block message)
G421 Add Internal GPS Receiver with polling application
G849 Interface option for external secure voice device (VP-116)
Mobile Station Accessories
FAD1410 Automatic Tuning Whip Antenna
or
F2265 Automatic Antenna Tuner
1.6-30 MHz, lightweight, compact housing, includes 17 foot (5.2 m)
RF cable and instruction manual
FAD1400 12 ft Whip Antenna (not required with FAD1410)
FLN2272 Mobile Mounting Kit
FSN1600 External Speaker Assembly
x Cat. No. 6886859J01

Fixed Station Operating Options (Note)
S71 Delete Delete hand microphone
S308 Add Phone patch interface cable kit, radio to phone patch (Note 1)
G561 Add Interface cable for MICOM Link unit
Fixed Station Accessories
FMN1614 Desk microphone
FLN2271 Junction box for connecting up to 4 accessories in addition to CW key and
headphones (Note 1)
FLN2294 Package kit for continuous duty data transmission. Includes FLN2271
junction box
FPN5590 AC Power Supply with Autoswitching for 110/220 VAC
Service Manuals
6886859J01 MICOM-3F/3T/3R Service Manual
Field Retrofit Kits
FLN2515 Interface cable kit for CW key & headphones (Note)
FLN2517 Interface cable kit for phone patch unit (Note)
FLN2530 Interface cable for MICOM Link unit
FLN2539 24VDC Operation (DC/DC converter)
Spare Boards Kit
FEN1673 Recommended Spare Boards Kit for MICOM-3T
4 Year Extended Warranty
FRN8466 4 Year Warranty for MICOM-3T
Note: The MICOM-3T includes one accessory port for connecting one accessory device (phone
patch, deskset, ARQ/RTTY modem, fax modem, computer, or headphones). If the
simultaneous connection of two or more (up to 4 plus CW & Headphones) devices to the
accessory port is required, order FLN2271 junction box listed in this page. The FLN2271 is
included with FLN2294 package kit.
Cat. No. 6886859J01 xi

MICOM-3R Model Complements
FKN4345A DC Cable
FLN2777A Control Head Assembly
FTN6069A Control Head Board
FLN3174A High Power Assembly
FTN6068A High Power Board
FLN2773A Low RF Assembly
FTN6067A Low RF Board
6886867J01 MICOM-3F/3T/3R Owner's Guide
Operating Options
G424 Add PC Control and Programming Software Package
G112 Enhanced High frequency stability option (0.1 ppm)
S809 Enhanced Interface cable kit for CW key & headphones (Note 1)
G469 Enhanced 24VDC Operation (DC/DC converter)
G419 Enhanced USB COM port for connecting external keyboard
G423 Add ALE DTM/DBM (data transfer message/data block message)
G421 Add Internal GPS Receiver with polling application
G849 Interface option for external secure voice device (VP-116)
Mobile Station Accessories
FLN2537 Automatic Antenna Tuner
1.6 to 30 MHz, lightweight, compact housing, includes 17 foot (5.2 m)
RF cable and instruction manual
FLN2538 Mobile Mounting Kit
Fixed Station Operating Options
S308 Phone patch interface cable kit, radio to phone patch (Note 1)
G561 Interface cable for MICOM Link unit
Military Type Audio Accessories
FMN5501 Military type Handset (H-250/U)
FSN5503 Military type External Speaker (LS-454/U)
xii Cat. No. 6886859J01

Fixed Station Accessories (Note)
FLN2271 Junction box for connecting up to 4 accessories in addition to CW key and
headphones
FLN2294 Package kit for continuous duty data transmission. Includes FLN2271
junction box
FPN5590 AC Power supply with autoswitching for 110/220VAC
Service Manuals
6886859J01 MICOM-3F/3T/3R Service Manual
Field Retrofit Kits
FKN4403 Interface cable kit for CW key & headphones (Note)
FKN4404 Interface cable kit for phone patch unit (Note)
FKN4405 Interface cable kit for fax modem (Note)
FKN4406 Interface cable kit for RTTY/ARQ modem (Note)
FLN2273 Spare RSS software package (Note)
Remote Control Application Option
G420 2-wire Remote Control Head (up to 5 km)
Spare Boards Kit
FEN1674 Recommended Spare Boards Kit for MICOM-3R
FEN1678 Recommended Spare Module Package for MICOM-RM1000 1 kW Linear
Amplifier
4 Year Extended Warranty
FRN8467 4 Year Warranty for MICOM-3R
FRN8470 4 Year Warranty for MICOM-RM1000 1 kW Linear Amplifier
Note: The MICOM-3R includes one accessory port for connecting one accessory device (phone
patch, deskset, ARQ/RTTY modem, fax modem, computer, or headphones). If the
simultaneous connection of two or more (up to 4 plus CW & Headphones) devices to the
accessory port is required, order FLN2271 junction box listed in this page. The FLN2271 is
included with FLN2294 package kit.
Cat. No. 6886859J01 xiii

Related Publications Available Separately
The following documents offer additional information:
6886867J01 MICOM-3F/3T/3T Owner's Guide
68P02942CSD MICOM-3 HF-SSB Transceiver, 1.6-30 MHz, 125 W P.E.P and Average,
Radio Service Software, User’s Guide
xiv Cat. No. 6886859J01

Chapter 1
Introduction
1-1. Notational Conventions
Throughout the text in this publication, you will notice the use of warnings, cautions and notes. These
notations are used to emphasize that safety hazard exist, and care must be taken and observed.
Warning
This Warning symbol denotes a hazard. It calls attention to a procedure
or practice that could result in personal injury if not performed correctly.
Caution The Caution symbol denotes a hazard. It calls attention to a procedure or
practice that could result in damage to or destruction of part or all of the
product if not performed correctly.
Note An operational procedure, practice or condition, etc., which is essential to
emphasize.
Throughout this manual, MICOM-3F, MICOM-3T and MICOM-3R are referred to as MICOM-3.
1-2. Scope of this Manual
This manual includes model/kit information, specifications, disassembly/reassembly procedures,
alignment, troubleshooting, and all theory, schematic diagrams, printed circuit board details and parts
lists for all parts in the equipment described.
Caution This manual is intended for use by experienced technicians who are familiar
with similar types of equipment.
Cat. No. 6886859J01 1-1

1-3. Federal Communication Commission Regulations
The FCC has established limits for safe exposure to radio frequency (RF) emissions from mobile
two-way radios. The FCC requires manufacturers to demonstrate compliance with RF exposure
limits before mobile two-way radios can be marketed In the U.S. When two-way radios are
approved for occupational/controlled environment exposure limits, the FCC requires users to be
fully aware of, and exercise control over, their exposure. Awareness and control of RF exposure
can be accomplished by education or training through appropriate means such as information
and instructions in user manuals or safety booklets, or other appropriate means. This user safety
booklet includes useful information about RF exposure and helpful instructions on how to
control your RF exposure.
Your Motorola two-way radio is designed and tested to comply with a number of national and
international standards and guidelines (listed below) regarding human exposure to radio frequency
electromagnetic energy. This radio complies with the IEEE (FCC) and ICNIRP exposure limits for
occupational/controlled RF exposure environments at usage factors of up to 50% talk-50% listen.
In terms of measuring RF energy for compliance with FCC exposure guidelines, your radio radiates
measurable RF energy only while it is transmitting (during talking), not when it is receiving
(listening) or in standby mode.
Your Motorola two-way radio complies with the following RF energy exposure standards and
guidelines:
• United States Federal Communications Commission, Code of Federal Regulations; 47CFR part 2
sub-part J
• American National Standards Institute (ANSI) / Institute of Electrical and Electronic Engineers
(IEEE) C95.1-1992
• Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999 Edition
• International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998
• Ministry of Health (Canada) Safety Code 6: Limits of Human Exposure to Radiofrequency
Electromagnetic Fields in the Frequency Range from 3 kHz to 300 GHz, 1999
• Australian Communications Authority Radiocommunications (Electromagnetic Radiation –
Human Exposure) Standard, 2001
• ANATEL, Brasil Regulatory Authority, Resolution 256 (April 11, 2001: Additional Requirements
for SMR, Cellular and PCS Product Certification.
1-3.1 Compliance and Control Guidelines and Operating Instructions for
Mobile Two-Way Radios Installed in Vehicles
To control your exposure and ensure compliance with the occupational/ controlled environment
exposure limits, always adhere to the following procedures:
• To transmit (talk), push the Push-To-Talk (PTT) button; to receive, release the PTT button.
Transmit only when people outside the vehicle are at least the minimum lateral distance
away (as shown in table below) from a properly installed, externally-mounted antenna.
The table below lists the minimum lateral distance for bystanders in an uncontrolled environment
from the transmitting antenna at several different ranges of rated radio power for mobile radios
installed in a vehicle.
1-2 Cat. No. 6886859J01
