Mountain Buggy Carrycot
Instruction Manual
P
P
A
A
S
S
S
S
E
E
D
D
S
S
A
A
F
F
E
E
T
T
Y
Y
P
A
S
S
E
D
S
A
F
E
T
Y

English 1-10
Designed and made in New Zealand by Mountain Buggy Ltd. Manufactured by Tritec Manufacturing Ltd,
an ISO 9001 certied company. Models made to BS 7409:1996, AS/NZS 2088:2000.
Français 11-20
Conçu et fabriqué en Nouvelle-Zélande par Mountain Buggy Ltd. Fabriqué par Tritec Manufacturing Ltd,
une société certiée ISO 9001. Modèles conformes à la BS 7409:1996, AS/NZS 2088:2000.
Deutsch 21-30
Entwickelt und hergestellt in Neuseeland durch Mountain Buggy Ltd und produziert von Tritec
Manufacturing Ltd., einem nach ISO 9001 zertizierten Unternehmen. Modelle nach BS 7409:1996, AS/NZS
2088:2000.
Italiano 31-40
Ideato e fatto in Nuova Zelanda da Mountain Buggy Ltd. Prodotto da Tritec Manufacturing Ltd, una ditta
certicata con ISO 9001. Modelli sono conformi alla BS 7409:1996, AS/NZS 2088:2000.
Español 41-50
Proyectado y fabricado en Nueva Zelanda por Mountain Buggy Ltd. Producido por Tritec Manufacturing Ltd,
una empresa certicada con ISO 9001. Modelos se conforman a la BS 7409:1996, AS/NZS 2088:2000.
Nederlands 51-60
Ontworpen en gefabriceerd in Nieuw Zeeland door Mountain Buggy Ltd en geproduceerd door Tritec
Manufacturing Ltd. een ISO 9001 gecerticeerde onderneming. Modellen gemaakt volgens de BS 7409:1996,
AS/NZS 2088:2000.
Svenska 61-70
Design och framställning i Nya Zeeland av Mountain Buggy Ltd. Tillverkad av Tritec Manufacturing Ltd, ett
företag met ISO 9001 certikat. Modeller ar tillverkade enligt BS 7409:1996, AS/NZS 2088:2000.
This manual covers all carrycot attachments – single, double and twin options.
Carrycots t onto the following Mountain Buggy® models:

1
ENGLISH
Welcome
Congratulations on your purchase of a Mountain Buggy carrycot.
We know how precious and inspiring a new little person can be in your world. It’s so
important to be able to show your baby to the world and just as important to show the
world to your baby.
At Mountain Buggy you and your baby matter to us. That’s why we have spent years
researching and developing a product that is safe, comfortable and in tune with
modern parents needs. We want you to be able to live your new family lifestyle with all
the freedom and satisfaction you have always experienced.
We also know that many parents use strollers incorrectly and as a result may put
their children at risk. Please take the time to read through this manual carefully. Your
Mountain Buggy carrycot will provide you with optimum safety if you follow the
instructions as detailed.
If you have any concerns, questions or comments about your Mountain Buggy carrycot
or how to use it, please do not hesitate to contact us. We’d love to hear from you.
Fitting a carrycot to your buggy is simple. However, it is important to follow the correct
instructions.

2
Important:
Please read instructions carefully, follow them strictly and keep these instructions for
future reference. Your child’s safety is your responsibility and may be compromised if you
do not follow these instructions.
Warning
•Carrycot is suitable for newborns through to 6 months old, or until baby can sit up
unaided.
•Baby must not be in Carrycot when it is being fastened or removed from the stroller
frame.
•Depth from top of mattress to top of side of Carrycot at any position within 300mm/11.8in
from harness attachment points, should not be reduced to less than 150mm/5.5in when
mattress is in position. Mattresses purchased separately should conform to BS 1877 part
10.
•Do not add a mattress thicker than 25mm.
•Check snap locks are closed and rmly attached to frame so Carrycot will not tip or fall.
•Check Carrycot is horizontal and located correctly onto stroller frame. Refer back to
diagrams for your model to ensure positioning of snap locks is correct.
•Do not use Carrycot if you are unable to secure it to stroller frame. In this case contact
store where stroller was purchased for more help.
•Check that Carrycot attachment devices are correctly engaged before use.
•Always remove Carrycot before folding stroller.
For the sake of your precious passenger, please
read these warnings before using your Mountain
Buggy Carrycot.

3
ENGLISH
Removing the Sunhood
1. Standing beside your stroller and using a
reasonable degree of force, pull the sunhood
support wire towards you (by about 50mm/2in).
2. Remove support wire W from sunhood bush J on
the side nearest to you.
3. Unfasten sunhood domes that
attach the sunhood to stroller
frame and to stroller seat back.
Removing the Seat
1. Unfasten domes on seat that attach to frame.
2. Urban (Jungle) Only: unfasten strap
underneath seat at point A.
3. Terrain Only: remove seat support wire from
stroller frame at C and D. Push seat forward,
then slide fabric o seat
support wire.
Preparing your Stroller to fit the Carrycot
A
W
J
CD
Before you can attach the Carrycot to your stroller you will need to remove the fabric
sunhood and seat on your stroller.

4
IMPORTANT INFORMATION FOR DOUBLE AND
TRIPLE STROLLERS
If you have a double or triple stroller you will need to remove the centre metal bars of the
frame to release the domed fabric. You may then need to reattach the metal bars without
the fabric, depending on whether you are attaching a Double or a Twin Carrycot. See chart
below.
How to remove the centre bar(s)
1. Terrain only: undo seat base nut with a spanner at
point F and remove hinge pin from seat base.
2. Urban and Terrain models: unfasten wing nut at
point G and remove centre bar at both ends (points
G and H).
Double Stroller Frame Triple Stroller Frame
Twin
Carrycot
No centre bar No centre bar on side attaching Twin
Carrycot. Centre bar remains on side not
accommodating Twin Carrycot.
Double
Carrycot
Centre bar required.
Remove hammock fabric
from seat you wish to
replace with Carrycot.
Centre bar required.
Remove hammock fabric from seat you
wish to replace with Carrycot. Double
Carrycot can only be tted to outside
seat positions.
Preparing your Stroller (continued)
Centre bar
Seat base
Heel
rest
H
F
G
›››

5
ENGLISH
Fitting your Carrycot to your Stroller
Mountain Buggy oer a range of carrycot and stroller combinations, so please choose the
instructions you need to follow from the list below based on which carrycot model you are
wanting to attach to which stroller.
Single Stroller Double Stroller Triple Stroller
Single Carrycot Conguration 1
Double Carrycot Conguration 2 Conguration 2
Twin Carrycot Conguration 1 Conguration 2
Instructions for Conguration 1 are located on pages 6-7
Instructions for Conguration 2 are located on pages 8-10
Examples of Carrycot combinations
Double Stroller with Double Stroller with Triple Stroller with
2 Double Carrycots Twin Carrycot 1 Double and 1 Twin
Carrycot

6
Preparation
You will need to have all components on the parts list
shown to t Carrycot to your stroller.
Have a look at sides of Carrycot. There are three holes
on each side of Carrycot to allow snap locks to be tted.
Conguration varies depending on the Mountain Buggy
model you have.
•Two snap locks are tted to each side of Carrycot.
The unused hole can be tted with the spare screw
and cover button.
How to t the Snap Locks
1. Place one snap lock over hole A. Make sure it is
aligned correctly with the hole in Carrycot.
2. Using Allen key, rotate screw in snap lock in
clockwise direction until screw is tight. Snap lock
will still be able to rotate but is rmly attached.
3. Connect second snap lock according to model
directions below.
4. Repeat on other side.
For Urban (Jungle) models
5. Fit second snap lock to position B.
6. Fit small screw and cover button to hole C.
For Terrain Models
5. Fit second snap lock to position C.
6. Fit small screw and cover button to hole B.
Configuration 1 Instructions
A
PLEASE FOLLOW THESE INSTRUCTIONS IF YOU
ARE FITTING:
a: a Single Carrycot to a Single Stroller
b: a Twin Carrycot to a Double Stroller
Fitting the Snap Locks to the Carrycot
A
B
C
URBAN
TERRAIN
C
B
A
›››
2 x screws
2 x cover buttons
Allen key
Carrycot
PARTS LIST
4 x snap locks

7
ENGLISH
Configuration 1 Instructions (continued)
Fitting the Carrycot to the Frame
1. Ensure snap locks are rotated so screw holes are
on top.
2. Open snap locks.
3. Place Carrycot onto Buggy frame. Conrm
positioning as pictured below.
4. Push snap locks rmly down at, making sure you hear the lock ‘click’, indicating
they are fully locked.
Fitting the Feet to the Carrycot
1. Take one foot and place provided screw through
hole in narrow end of foot.
2. Screw whole unit into one of the 4 holes located
on bottom of Carrycot.
3. Ensure foot is screwed tightly.
4. Repeat process for all 4 feet.
To remove: unscrew each foot from bottom of Carrycot.
✔
✘
TERRAIN URBAN
X
Y
sunhood joint
Place snap lock X directly above
sunhood joint
X
Y
tube joint
Place snap lock Y directly above tube joint

8
Configuration 2 Instructions
Fitting the Snap Locks and Slider Plate to the Carrycot
Preparation
Make sure you have all the necessary
parts as outlined in this picture.
NB: The sliding plates part kit is
not supplied with a twin carrycot
and will need to be separately
purchased to attach the twin to
a triple stroller. Also note that the
snap locks used in Conguration 1
are dierent from those used in this
instruction.
Work out which side you want to
attach the Carrycot to. If you want to position the Carrycot onto the right side of stroller,
put the snap locks onto the right side of the Carrycot and the sliding plate onto the left. To
position the Carrycot onto the left side of the stroller the snap locks go on the left side of
the stroller and the sliding plate on the right.
NB: Left and right are considered from the point of view of the user when they are
pushing the buggy.
Attaching Snap Locks
1. Place one snap lock over hole A. Make sure it is
aligned correctly with the hole in Carrycot.
2. Using Allen key, rotate screw in snap lock in
clockwise direction until screw is tight. Snap lock
will still be able to rotate but is rmly attached.
3. Connect second snap lock according to model
directions for Urban or Terrain.
A
PLEASE FOLLOW THESE INSTRUCTIONS IF YOU
ARE FITTING:
a: a Double Carrycot to a Double Stroller
b: a Double Carrycot to a Triple Stroller
c: a Twin Carrycot to a Triple Stroller
›››
SLIDING PLATE PARTS KIT
1 x sliding plate
1 x Allen key
2 x screws
2 x snap locks 1 x cover buttons
1 x screw
PARTS LIST
Carrycot

9
ENGLISH
Configuration 2 Instructions (continued)
For Urban (Jungle) models
5. Fit second snaplock to position B.
6. Fit small screw and cover button to hole C.
For Terrain Models
5. Fit second snap lock to position C.
6. Fit small screw and cover button to hole B.
Fitting the Sliding Plate to the Carrycot
•Position sliding plate on opposite side of Carrycot to snap locks.
•Sliding plate screws are located at Holes A and C in side of Carrycot. Hole B is not
required.
•There are 4 screw holes in sliding plate. Use diagram below to locate which two
holes are required for your stroller model.
Urban
•Align Hole 1 of sliding plate with Hole A of Carrycot.
Align Hole 3 of sliding plate with Hole C of Carrycot.
•Place screws into Holes 1 and 3. Using Allen key,
tighten in a clockwise direction.
1
4
2
3
A
B
C
URBAN
TERRAIN
C
B
A
3
URBAN
1

10
Terrain
•Align Hole 1 of sliding plate with Hole A of Carrycot.
Align Hole 2 of sliding plate with hole C of Carrycot.
•Place screws into Holes 1 and 2. Using Allen key,
tighten in a clockwise direction.
Warning: check that Carrycot attachment devices are correctly engaged before use.
Fitting the Carrycot to the Frame
1. Ensure snap locks are rotated so screw holes are on top.
2. Open snap locks.
3. Place Carrycot between side tube and centre bar of
stroller. Locate centre bar lug then move sliding plate
down centre bar until groove in sliding plate locks onto
located lug.
4. Push snap locks rmly down at, making sure you hear
the lock ‘click’, indicating they are fully locked.
To t a second Double Carrycot onto a Double or Triple Stroller
repeat above instructions.
To remove Carrycot from frame: open snap locks and lift Carrycot o frame.
Fitting the Feet to the Carrycot
1. Take one foot and place provided screw through
hole in narrow end of foot.
2. Screw whole unit into one of the 4 holes located
on bottom of Carrycot.
3. Ensure foot is screwed tightly.
4. Repeat process for all 4 feet.
To remove: unscrew each foot from bottom of Carrycot.
Configuration 2 Instructions (continued)
12
TERRAIN
1

INTERNATIONAL DISTRIBUTORS
Mountain Buggy New Zealand & Head Oce
Freepost 4432 (within New Zealand)
PO Box 38-781, Wellington Mail Centre,
New Zealand
Ph: [phone] or 0800 428 449
Fax: [phone]
Email: [e-mail]
www.mountainbuggy.com
Australia
Mountain Buggy Australia
223A East Boundary Road
East Bentleigh, Victoria 3165, Australia
Ph: [phone]
Fax: [phone]
Email: [e-mail]
www.mountainbuggy.com.au
U.K. & Ireland
Mountain Buggy (UK) Ltd
Mill Farm, Fairmile, Ottery St Mary
Devon EX11 1LS, England
Ph: ++44 01 404 815 555
or 07000 4 BUGGY (07000 428 449)
Fax: ++44 01 404 815 444
Email: [e-mail]
www.mountainbuggy.co.uk
Europe
One Tree Hill
Postbus 4, 3130 AA Vlaardingen, The Netherlands
Ph: ++31(0) 182 551 895
Fax: ++31(0) 182 551 457
Email: [e-mail]
www.onetreehill.nl
Japan
Oce U Corporation
2-22-8, Higashi Kawaguchi, Kawaguchi City,
Saitama Prefecture, Japan 333-0801
Ph: [phone] Mob: [phone]
Fax: [phone]
www.mountainbuggy.co.jp
Singapore & Hong Kong
Mountain Buggy Asia
PO Box 603, 144 Upper Bukit Timah Rd #04-16-17
Beauty World Centre, Singapore 588177
Ph/Fax: [phone] (Singapore)
Ph/Fax: [phone] (Hong Kong)
Email: [email protected]
www.mountainbuggy.com/asia
USA
Sycamore Kids Inc.
208 Commerce Drive, Fort Collins, CO 80524 USA
Toll Free Phone/Fax: [phone]
Email: suppor[email protected]
www.mountainbuggyusa.com
Canada
Mountain Buggy Canada Inc
4298 Capilano Road, North Vancouver, B.C., V7R 4J7,
Canada
Toll Free Phone: 1866 MTNBUGGY (1866 686 28449)
Email: [e-mail]
www.mountainbuggy.ca
South Africa
Suolk Trading CC
PO Box 2990, Cape Town 8004, South Africa
Ph: ++27 11 485 3458
Fax: ++27 11 485 5273
Email: [email protected]
www.mountainbuggy.com
JAN 07
