Mouvex SLP25 i Series User manual

PUMPS
SLP25 i SERIES
(manufactured from 2010 to 2013)
INSTRUCTIONS 1007-A00 e
Section 1007
Effective November 2011
Replaces March 2011
Original instructions
INSTALLATION
OPERATION
MAINTENANCE
Your distributor :
Z.I. La Plaine des Isles - F 89000 AUXERRE - FRANCE
Tel. : [phone] - Fax : [phone]
[email protected] - www.mouvex.com

2/33
NT 1007-A00 11.11 SLP25 i series pumps e
VANE PUMPS
SAFETY, STORAGE, INSTALLATION AND MAINTENANCE INSTRUCTIONS
MODELS : SLP SERIES
SLP25 i
1. OVERALL DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . .3
2. INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
2.1 Pump selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
2.2 Pipe diameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
2.3 Piping assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
2.4 Direction of rotation . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
2.5 Changing the direction of rotation . . . . . . . . . . . . . . . . .8
2.6 Protecting the installation against overpressure . . . . . .9
2.7 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
2.8 Hoisting devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
2.9 Installation of units . . . . . . . . . . . . . . . . . . . . . . . . . . .10
2.10 Alignment of motor/pump or reduction gearbox/pump
shafts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
2.11 Electric motors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
2.12 Diesel engines drive . . . . . . . . . . . . . . . . . . . . . . . . .11
3. USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
3.1 Pumping hot or cold liquids . . . . . . . . . . . . . . . . . . . .12
3.2 Pump full of liquid when stopped . . . . . . . . . . . . . . . .12
3.3 Noise level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
3.4 Starting-up the pump . . . . . . . . . . . . . . . . . . . . . . . . .12
3.5 Shutting down the pump . . . . . . . . . . . . . . . . . . . . . . .12
3.6 Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
3.7 Scrapping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
4. REQUIRED TOOLS AND TIGHTENING TORQUES . . . . .13
4.1 Necessary tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
4.2 Assembly torques . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
5. OPENING AND CLOSING THE NON-DRIVE SIDE OF PUMP .14
5.1 Opening the base on the non-drive side . . . . . . . . .15
5.2 Checking the vanes . . . . . . . . . . . . . . . . . . . . . . . . . .15
5.3 Changing the bushing . . . . . . . . . . . . . . . . . . . . . . . . .16
5.4 Closing the non-drive side base . . . . . . . . . . . . . . . . .16
6. OPENING AND CLOSING THE DRIVE SIDE BASE . . . . .17
6.1 Dismantling / reassembling connection manifold . . . .18
6.2 Dismantling / reassembling transmission . . . . . . . . . .18
6.3 Dismantling the adaptation unit base . . . . . . . . . . . . .19
6.4 Changing the bushing in the adaptation base . . . . . .20
6.5 Dismantling inlet manifold . . . . . . . . . . . . . . . . . . . . . .21
6.6 Dismantling / reassembling transmission square driver .21
6.7 Changing the transmission and/or hub nose seal . . .22
6.8 Reassembly of vanes and pushrods . . . . . . . . . . . . .22
7. BYPASS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
7.1 Bypass operation . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
7.2 Bypass orientation . . . . . . . . . . . . . . . . . . . . . . . . . . .24
7.3 Bypass inversion . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
7.4 Bypass adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . .25
7.5 Obtaining the flow . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
7.6 Energy consumption . . . . . . . . . . . . . . . . . . . . . . . . . .25
7.7 Replacing the spring . . . . . . . . . . . . . . . . . . . . . . . . . .25
8. TRANSMISSION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
8.1 Checking the bellows . . . . . . . . . . . . . . . . . . . . . . . . .27
8.2 Draining the bearing . . . . . . . . . . . . . . . . . . . . . . . . . .27
8.3 Transmission oil level control . . . . . . . . . . . . . . . . . . .27
8.4 Changing lip seals . . . . . . . . . . . . . . . . . . . . . . . . . . .28
9. MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
9.1 Checking the condition of vanes and the pushrods . .29
9.2 Checking the condition of friction bushings . . . . . . . .29
10. TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . .30
11. CERTIFICATE OF CONFORMITY . . . . . . . . . . . . . . . . .33
SUMMARY Page
TECHNICAL SPECIFICATIONS
• Construction I : Stainless steel
• Non-food grade pump
• Maximum pump speed : 1000 rpm
• Maximum differential pressure : 12 bar relative
•Maximum suction pressure : 1,5 bar relative
•Max admissible transmission torque : 135 Nm
Pump n° :
Date of bringing into service :
This is a SAFETY ALERT SYMBOL
When you see this symbol on the product, or in the manual, look
for one of the following signal words and be alert to the potential for
personal injury, death or major property damage.
Warns of hazards that WILL cause serious personal injury,
death or major property damage
Warns of hazards that CAN cause serious personal injury,
death or major property damage.
Warns of hazards that CAN cause personal injury or property
damage.
NOTICE
Indicates special instructions which are very important and
must be followed.
SAFETY INFORMATIONS
WARNING
CAUTION
DANGER

3/33
NT 1007-A00 11.11 SLP25 i series pumps e
1. OVERALL DIMENSIONS
S1 S2
Temperature limiter device position
- Drilling Ø 8 - Always side of connecting manifold
S1 : outlet to the right* S2 : outlet to the left*
4 holes Ø 13.5 [0.531]
Weight :
84 kg
2 x 4 holes Ø 18 [0.709]
at 90° (PN 16/20)
SLP25 i
4 holes Ø 14 [0.551]
335 with bypass
282 without bypass
Connecting manifold
* View from motor side
BPlug (filling, breather)
EInlet tube vent
FBypass setting
JSpace for dismantling
PPump plate
V1 Inlet tube drain V2 Pump drain

4/33
NT 1007-A00 11.11 SLP25 i series pumps e
1. OVERALL DIMENSIONS (continued)
NOTA : Adjustments of the detection levels are made in the factory and must not be modified. For other dimensions, refer to pump overall dimension drawing. The transmission may only be dismantled in the factory.
CAUTION :
WRONG CONNECTION MAY DESTROY THE SENSOR.
Connection diagram
Connector
Do not use S2
Normal operation
Rupture detection
Bellows monitoring system (pressure switch)
SL MECH D 135

5/33
NT 1007-A00 11.11 SLP25 i series pumps e
1. OVERALL DIMENSIONS (continued)
NOTA : Adjustments of the detection levels are made in the factory and must not be modified. For other dimensions, refer to pump overall dimension drawing. The transmission may only be dismantled in the factory.
Bellows monitoring system (ATEX pressure switch)
SL MECH D 135
When the pressure drops, 3-2 opens. CAUTION :
Wrong connection may :
- create a fire risk, - make monitoring ineffective - damage the sensor
Connection diagram
Ex-free Zone
Ex-Zone 1 or 2, 21 or 22
Supply
voltage
Outlet
Yellow
Green
Microswitch

6/33
NT 1007-A00 11.11 SLP25 i series pumps e
1. OVERALL DIMENSIONS (continued)
NOTA : Adjustments of the detection levels are made in the factory and must not be modified. For other dimensions, refer to pump overall dimension drawing. The transmission may only be dismantled in the factory.
Double wall transmission with pressure gauge
SL MECH D 135

2.1 Pump selection
To obtain expected performance from MOUVEX series
SLP pump, regarding both performance and durability, it
is essential that the type of pump, its rotation speed and
the materials used in its construction are suitably deter-
mined in accordance with the pumped liquid and the ins-
tallation and operating conditions.
OOur technical departments are at your disposal any
time for all necessary informations.
2.2 Pipe diameter
To obtain optimum conditions of use, it is important to check
the following recommendations regarding the sizing of
pipes :
• The pipe diameter will be determined depending on
their length and the flow and viscosity of liquid pumped,
so that pressure losses stay within the admissible limits
for the motor-driven pump unit. It is therefore difficult to
give general and precise instructions. However, it is
never a disadvantage to over-dimension pipe diame-
ters, especially for the section on the inlet side.
• In the case of thin liquids and the piping on the discharge
side,one can generally allow a diameter equal to the
pump ports and a larger diameter for the piping on the
inlet side, if the value for the inlet power of the pump is
negative or especially high.
• For viscous liquids, special attention should be paid to
determining the pipe diameters. Indeed, the variation in
pressure loss is proportional to the viscosity and inver-
sely proportional to the diameter exponent 4. A slight
reduction in the pipe diameter could therefore have
serious consequences on the pump’s operating conditions.
Our Technical Services are always available to provide you
with precise data if you give them accurate information
or, even better, the installation drawings.
2.3 Piping assembly
In order to achieve the best operating conditions, it is
important to take account of the following recommenda-
tions regarding piping assembly :
• The positioning of the pump in the transfer or recycling
circuit should always be chosen so as to reduce the
height and length of the piping as much as possible.
• Wherever possible, siphons and reverse slopes should-
be avoided in the inlet piping.
• Particular care needs to be taken with the sealing on
the inlet side to prevent air entering.
• Pipe elbows must always have a large radius (more
than 3 times the diameter of the pipes) and must not be
mounted too close to the pump flanges (min. recom-
mended distance : 10 times the pipe diameter), on both
the inlet and discharge sides.
• The pipes are supported and aligned with the pump so
as to avoid generating stress on the pump flanges.
Non-compliance with this instruction can lead to defor-
mation of pump parts, misalignment of bearings and
accelerated material wear, even causing parts to break.
• For ease of any adjustments and checks, it is recom-
mended that pressure tapping ports to which pressu-
re/vacuum gauges may be fitted, are provided as close
as possible to the pump’s suction and discharge ports
(preferably at a distance of less than 5 times the pipe
diameter).
• If the suction head is especially high or if you want to
prevent the pipes emptying at shutdown, you can install
a foot valve. This should have a large diameter so as
not to generate additional pressure loss.
• We recommend placing valves as close as possible to
the pump ports to avoid having to drain the entire system
each time maintenance is carried out. These valves
should have the same diameter as the pipes and pre-
ferably be full bore models.
• All steps should be taken to prevent foreign bodies
from entering the pump (the use of a filter at the pump
intake is therefore strongly recommended).
• Before installing new pipes or tanks, check that they
are carefully cleaned to remove waste from welding,
rust, etc. which when carried through by the liquid
could cause deterioration to the pump.
• The pipes should be designed to allow thermal expan-
sion/contraction (the use of flexible couplings or expan-
sion loops is therefore recommended).
• If there is danger of the liquid freezing or solidifying, it
must be possible to drain the piping by installing taps
at the low points and air vents at the high points.
7/33
2. INSTALLATION
NT 1007-A00 11.11 SLP25 i series pumps e

2.4 Direction of rotation
• In its standard configuration, the SLP series MOUVEX
pump is supplied as non reversible and with anticlock-
wise rotation.
NOTE :
ALL VIEWS IN THIS INSTRUCTION MANUALSHOW PARTS IN
THE STANDARD DIRECTION OF ROTATION.
The rule for the discharge side and the direction of rota-
tion is as follows :
• For anticlockwise rotation (standard), the discharge
should be on the right side of the pump.
• For clockwise rotation, the discharge should be on the
left side of the pump.
In all cases, suction is from the top.
Operation in the opposite direction from that designed
for the pump is authorised nonetheless for a maximum
duration of 5 minutes as long as it remains below the
pressure limits (1,5 bar at the bellows).
The direction of rotation may be reversed :
• On request at the time the order is placed. In this case
the pump will be supplied with clockwise rotation.
• Or manually, referring to the following §.
2.5 Changing the direction of rotation
REGARDLESS OF THE INTERNAL DESIGN OF THE PUMP, THE
DIRECTION OF ROTATION SHOULD NOT BE CHANGED UNTIL
THE PUMP HAS COME TO A COMPLETE STOP, HAS COOLED
DOWN AND HAS BEEN DRAINED.
• Dismantle the connection manifold (see § DISMANTLING
/ASSEMBLING THE CONNECTION MANIFOLD).
• Dismantle the relief valve (see § ORIENTATION OF
BYPASS).
• Change the position of the rotor, the vanes and the
pushrods (for a pump with pushrods) : see § OPENING
AND CLOSING THE PUMP ON THE NON-DRIVE SIDE.
• Remove the vanes 44317 and the pushrods 44318.
• This may be carried out by removing the vanes 44317
horizontally and then the pushrods 44318 using a
screwdriver and pushing them to one of the pump outlet
ports.
• Follow the same procedure for the other vanes 44317.
• Remove the circlips 11119 (BE CAREFUL not to
scratch the shaft).
• Remove the rotor 44301, turn it over and re-assemble
it so that the rotor pushrods 44301 match up with the
holes in the shaft 44501.
• Place a suitable screw at the end of the shaft to pull it
and reveal the circlip groove.
• Replace the circlips 11119 taking care not to scratch the
shaft 44501.
• Re-assemble the vanes 44317 and the pushrods 44318
facing the correct direction (see § VANE CHECKS).
• Re-assemble the bypass facing the correct direction
(see § DIRECTION OF BYPASS).
• Re-assemble the connection manifold on the correct
side (see § DIRECTION OF ROTATION).
Screw
SLP25 M8
CAUTION
8/33
2. INSTALLATION (continued)
NT 1007-A00 11.11 SLP25 i series pumps e

2.6 Protecting the installation against over-
pressure
To protect the installation from any overpressure, the
use of a pressure relief safety device is recommended.
The standard pump is supplied fitted with a single inter-
nal relief valve to protect the system in one operating
direction. Its orientation therefore depends on the opera-
ting direction of the pump (refer to § RELIEF VALVE).
It is also possible to order the following option :
• Without relief valve : the pump then has no other inbuilt
safety device. In this case, the pump must be protected
(for example with a pressure switch) to reduce any
overpressure.
If the rotation of the pump is to be used in both direc-
tions, (whatever the operating conditions), it is recom-
mended to use a device that protects the pump from
overpressure when rotating in both directions (pressure
switch, etc.).
2.7 Cleaning
As the pumps are well-greased when supplied, it may be
necessary to clean them before starting them up.
They may be cleaned either by circulating an appropria-
te liquid or by dismantling the pump and carefully clea-
ning the internal parts (in which case, refer to § relating
to pump maintenance).
2.8 Hoisting devices
Hoisting points :
The strap must pass between the cradle and the
manifold.
• Use straps designed for the weight of the pump (see
overall dimension drawing).
WARNING
FAILURE TO INSTALL ADEQUATELY
SIZED PRESSURE RELIEF VALVE(S)
CAN CAUSE PROPERTY DAMAGE, PER-
SONAL INJURY OR DEATH.
WARNING
Hazardous pressure
can cause
personal injury
or property damage.
INCORRECT SETTINGS OF THE PRESSURE
RELIEF VALVE CAN CAUSE PUMP
COMPONENT FAILURE, PERSONAL
INJURY, AND PROPERTY DAMAGE.
WARNING
Hazardous pressure
can cause
personal injury
or property damage.
9/33
2. INSTALLATION (continued)
NT 1007-A00 11.11 SLP25 i series pumps e

10/33
2. INSTALLATION (continued)
2.9 Installation of units
The correct seating of a unit is essential for ensuring
smooth operation and longevity. The base must be flat,
level and sufficiently resistant to absorb stresses caused
by the motor-driven pump without being distorted
(concrete blocks must conform to the BAEL 91 standard).
Where the unit is fastened using anchor lugs or bolts, it
must be wedged carefully to prevent any distortion of the
chassis when tightening the bolts. Distortion of the chas-
sis could cause prejudicial stress to the pump and the
drive device and put the coupling out of alignment, cau-
sing vibrations, noise and premature wear. Check that
the chassis is clear of the floor and off the support
plates.
Where the chassis is a one-piece unit in folded sheet
metal, it is recommended to leave a clear horizontal
space of around 50 cm between one end of the chassis
and the other to allow access to the locking nuts on the
pump, the reduction gearbox and the motor. In all cases,
the space around the pump unit should allow enough
room for dismantling the pump (refer to the overall
dimension drawing at the beginning for details of these
distances).
The chassis is equipped with an earth connection that
must be used to protect personnel and equipment.
The mounting base of the vane pump body and the
pump bearing are not on the same level (see § OVE-
RALL DIMENSIONS). Different wedging must therefore
be used for these two bases.
2.10 Alignment of motor/pump or reduction
gearbox/pump shafts
The motor and pump shafts are accurately aligned in the
factory before dispatch, but they must be checked auto-
matically upon arrival and realigned if necessary. To align
the coupling and the shaft, use a straight edge to check
the offset and thickness gauges for angular misalignment.
The 3 figures below illustrate the operation and show the
admissible deviations :
It is important to check the alignment at each stage of
installation to ensure that no stresses are caused to the
unit or the pump :
• after fixing to the base.
• after attaching piping.
• after pump has operated at normal operating tempera-
ture.
Reminder :
The coupling must not be relied on to compensate for a
misalignment.
NEVER START A UNIT IF THE COUPLING ALIGNMENT IS
INCORRECT. THIS WILL INVALIDATE OUR WARRANTY.
Make this check for 4 points :
up - down - left - right
Correct
Out-of-parallelism
Angular defect
(maximum : 1°)
DISCONNECT THE ELECTRICITY SUPPLY
BEFORE ANY MAINTENANCE OPERATION.
WARNING
Dangerous voltage.
Can cause
injury and death.
OPERATION WITHOUT THE SHAFT
PROTECTOR CAN CAUSE SERIOUS
PERSONAL INJURY, MAJOR PROPERTY
DAMAGE, OR DEATH.
WARNING
Do not operate
without guard
in place.
BE CAREFUL WITH THE WEIGHT OF
THE PARTS WHEN THEY ARE BEING
REMOVED.
WARNING
The weight ot the parts can
be dangerous and may
provoke bodily injuries or
material damages.
NT 1007-A00 11.11 SLP25 i series pumps e

2.11 Electric motors
Check that the supply voltage matches the indications
on the motor rating plate.
Comply with the wiring diagram, make sure the wires are
rated for the power and check the contacts which must
be thoroughly tightened. The motors must be protected
by appropriate circuit breakers and fuses. Connect the
regulatory ground connections.
Rotation direction check :
This check should be carried out on the pump with no
liquid being pumped through and both the suction and
discharge circuits venting so as to avoid generating
unexpected pressure (at suction for example). This will
avoid damaging either the pump or the system.
Start the pump empty to check that the connections are
sound and that the direction of rotation corresponds to
the system intake and discharge directions. If it should
be required to reverse the direction of rotation, follow the
instructions below :
Three-phase motor : switch any 2 current input wires.
Bi-phase motor : switch two same-phase wires.
Single-phase motor : follow the instructions on the notice
supplied with the motor.
2.12 Diesel engines drive
Do not forget that these engines are not reversible. It is
therefore essential to check carefully the pump’s intake
and discharge sides before connecting the unit to the
pipes.
The use of diesel engines drive is now well known.
However, we strongly advise careful reading of the
accompanying technical manual.
THE SURFACES OF THE PUMP CAN
BE AT A TEMPERATURE LIABLE TO
CAUSE INJURY OR SEVERE DAMAGE.
CAUTION
Excessive temperature-
can cause injury or
severe damage.
OPERATION WITHOUT THE SHAFT
PROTECTOR CAN CAUSE SERIOUS
PERSONAL INJURY, MAJOR PROPERTY
DAMAGE, OR DEATH.
WARNING
Do not operate
without guard
in place.
PUMPS OPERATING AGAINST A CLOSED
VALVE CAN CAUSE SYSTEM FAILURE,
PERSONAL INJURY AND PROPERTY
DAMAGE.
WARNING
Hazardous pressure
can cause
personal injury
or property damage.
TAKE ALL NECESSARY MEASURES
TO RENDER ANY START-UP, EVEN
ACCIDENTAL, OF THE PUMP DURING
THE WORK IMPOSSIBLE.
WARNING
Any unforeseen start-up
can cause serious
injuries or important
material damages.
DISCONNECT THE ELECTRICITY SUPPLY
BEFORE ANY MAINTENANCE OPERATION.
WARNING
Dangerous voltage.
Can cause
injury and death.
11/33
2. INSTALLATION (continued)
NT 1007-A00 11.11 SLP25 i series pumps e

12/33
3. USE
3.1 Pumping hot or cold liquids
For hot liquids : after the initial start-up, make sure that
the screws and bolts are tightened to compensate for
the effects of expansion.
3.2 Pump full of liquid when stopped
Where the pump circuit is to be positioned between
valves and / or check valves, account must be taken of
the temperature variations that may occur and lead in
particular to expansion of the liquid in the circuit. In this
case, a means must be provided of discharging the
expanded volume. The use of a relief valve may fulfil this
function. The opening pressure of this valve should be
compatible with the admissible pressure for the various
components of the circuit.
It is also advisable to fit a discharge device enabling the
circuit to be completely emptied for any maintenance work.
Where liquids contain particles that may settle on shut-
down, it is necessary to ensure that the consistency of
the deposit will not prevent the pump being restarted.
3.3 Noise level
The noise level of a pump is generally influenced by the
conditions of use. Cavitation and the pumping of pro-
ducts with high gas content generally increase the noise
level.
Under the following pumping conditions :
• excluding cavitation
• maximum differential pressure : 12 bar
• rotation speed 1000 rpm
• product viscosity of 1 cSt
The noise level expected for an SLP series pump in good
operating condition without the drive is less than :
• SLP25 i . . . . 74 dB(A)
3.4 Starting-up the pump
Before starting the pump, make sure that the following
conditions are met :
• The circuit should be in one of its pumping configu-
rations, with the appropriate valves open, especially
those on the suction side.
• For liquids requiring heating, they must be brought to
their pumping temperature before starting the pump.
3.5 Shutting down the pump
When shutting down the pump, it is recommended to
wait for it to stop completely before closing the valves,
especially the suction valve.
OPERATION WITHOUT THE SHAFT
PROTECTOR CAN CAUSE SERIOUS
PERSONAL INJURY, MAJOR PROPERTY
DAMAGE, OR DEATH.
WARNING
Do not operate
without guard
in place.
FAILURE TO RELIEVE SYSTEM PRESSURE
PRIOR TO PERFORMING PUMP SERVICE
OR MAINTENANCE CAN CAUSE PERSONAL
INJURY OR PROPERTY DAMAGE.
WARNING
Hazardous pressure
can cause
personal injury
or property damage.
IF PUMPING HAZARDOUS OR TOXIC
FLUIDS, THE SYSTEM MUST BE FLUSHED
PRIOR TO PERFORMING ANY SERVICE
OPERATION.
WARNING
Toxic or hazardous
fluids can cause
serious injury.
FAILURE TO INSTALL ADEQUATELY
SIZED PRESSURE RELIEF VALVE(S)
CAN CAUSE PROPERTY DAMAGE, PER-
SONAL INJURY OR DEATH.
WARNING
Hazardous pressure
can cause
personal injury
or property damage.
THE SURFACES OF THE PUMP CAN
BE AT A TEMPERATURE LIABLE TO
CAUSE INJURY OR SEVERE DAMAGE.
CAUTION
Excessive temperature-
can cause injury or
severe damage.
NT 1007-A00 11.11 SLP25 i series pumps e

13/33
3. USE (continued)
3.6 Storage
MOUVEX pumps and motor-driven pump units are well
lubricated when delivered to protect the internal parts
during brief storage in a building where :
• the temperature must remain between 10°C and 49°C.
• the relative humidity does not exceed 60%.
• exposure to vibration is limited (maximum movement :
0,05 mm).
We recommend the following procedure for longer periods
of storage :
3.6.1 Storage
If the pump is stored with its gear motor unit, the recom-
mendations of the manufacturer for this equipment should
be followed.
Pump ports should be filled with a non-corrosive liquid
that is compatible with the pump components in order to
prevent corrosion.
Unpainted external surfaces of the pump (e.g. shafts,
couplings, etc.) should be covered in some form of anti-
corrosion protection.
The best storage conditions are inside a building that
meets the conditions described above.
If inside storage is not possible, the equipment should
be covered to prevent direct exposure to sun and rain.
This protection should also protect the equipment from
any condensation.
It is recommended to turn the pump by hand every two
months to distribute the lubricant around the interior.
Items should then be placed where there is no risk of
components being damaged if they are moved slightly
by vibrations.
3.6.2 Restarting
Follow the standard start-up procedure for the pump/
motor-driven pump, as well as the instructions below.
Turn the pump by hand to make sure the parts move
freely.
If the pump has a safety internal relief valve, remove it and
inspect the parts and make sure they move freely (see §
RELIEF VALVE FOR DISMANTLING INSTRUCTIONS).
For the transmission unit, the bearing must be drained
(see § DRAINING OF BEARING).
3.7 Scrapping
The pump must be scrapped in compliance with the
regulations in force.
During this operation, particular care must be paid to the
drainage stages of the pump (pumped product) and of
its transmission (lubricant).
IF PUMPING HAZARDOUS OR TOXIC
FLUIDS, THE SYSTEM MUST BE FLUSHED
PRIOR TO PERFORMING ANY SERVICE
OPERATION.
WARNING
Toxic or hazardous
fluids can cause
serious injury.
NT 1007-A00 11.11 SLP25 i series pumps e
4. REQUIRED TOOLS AND TIGHTENING TORQUES
4.1 Necessary tools
•Open-end spanners 8 - 11 - 13 - 16 - 17
• Socket wrench 13
• Opening circlip pliers
• Screwdriver
• Extractor
• Torque wrench
• Wrench for 6 hexagonal hollows of 3
• Pin punch Ø 3 and Ø 4
• Lip seal extractor
• Chisel
4.2 Assembly torques
• M6..........8 Nm
• M8........18 Nm
• M10......30 Nm
• M12......50 Nm

14/33
NT 1007-A00 11.11 SLP25 i series pumps e
5. OPENING AND CLOSING THE NON-DRIVE
SIDE OF PUMP
Before any disassembly, make sure that the pump has been drained and take all the necessary precautions to prevent it from
starting up.The pump must not start up, even accidentally.
DISCONNECT THE ELECTRICITY SUPPLY
BEFORE ANY MAINTENANCE OPERATION.
WARNING
Hazardous pressure
can cause
personal injury
or property damage.
WARNING
The weight of the parts can
be dangerous and may
provoke bodily injuries or
material damages.
THE SURFACES OF THE PUMP CAN
BE AT A TEMPERATURE LIABLE TO
CAUSE INJURY OR SEVERE DAMAGE.
CAUTION
Excessive temperature-
can cause injury or
severe damage.
WARNING
Hazardous pressure
can cause
personal injury
or property damage.
WARNING
Hazardous or toxic
fluids can cause
serious injury.
CAUTION
Slippery lubricant.
Spills should be
cleaned up.
TAKE ALL NECESSARY MEASURES
TO RENDER ANY START-UP, EVEN
ACCIDENTAL, OF THE PUMP DURING
THE WORK IMPOSSIBLE.
WARNING
Any unforeseen start-up
can cause serious
injuries or important
material damages.
WARNING
Dangerous voltage.
Can cause
injury or death.
FAILURE TO RELEASE ALL SYSTEM AIR
AND WHEN EQUIPPED, HYDRAULIC PRES-
SURE, CAN CAUSE PROPERTY DAMAGE,
PERSONAL INJURY OR DEATH.
BE CAREFUL WITH THE WEIGHT OF
THE PARTS WHEN THEY ARE BEING
REMOVED.
DISCONNECTING THE FLUID OR PRES-
SURE CONTAINMENT COMPONENTS
DURING PUMP OPERATION CAN CAUSE
SERIOUS PERSONAL INJURY, DEATH
OR MAJOR PROPERTY DAMAGE.
IF PUMPING HAZARDOUS OR TOXIC
FLUIDS, THE SYSTEM MUST BE FLUSHED
PRIOR TO PERFORMING ANY SERVICE
OPERATION.
THE PUMP LUBRICANT IS VERY SLIPPERY
AND MAY CAUSE SERIOUS INJURY.
ANY SPILLS MUST BE CLEANED UP.

15/33
5. OPENING AND CLOSING THE NON-DRIVE
SIDE OF PUMP (continued)
5.1 Opening the base on the non-drive side
• Unscrew the 4 screws 44410 and 2 screws 44411.
• Place 2 screws 44410 in the 2 diametrically opposed
tapped holes.
• Detach the front cover 44410 by screwing the 2 screws
simultaneously.
• When the cover is loose on the shaft, withdraw it
manually while supporting it.
• Check the seal 44403 and the front disk 44422 (see §
MAINTENANCE).
• Check the bushing 44407 inside the cover 44401 (see
§ MAINTENANCE).
• Seal 44714 may be checked and change if necessary
by unscrewing the 3 screws 44726 and removing the
cover 44712.
5.2 Checking the vanes
• Remove a vane 44317 situated horizontally.
• Check it for wear (see § MAINTENANCE). In the case
of abnormal wear, check the state of the body and front
cover faces.
• The pushrods 44318 may be removed (and replaced)
using a screwdriver through one of the pump ports.
• Replace the vane 44317 (with a new one if necessary),
making sure it is fitted in the right direction and making
sure it slides properly in its slot. Take care with the
pushrods if applicable. Take care with the pushrods if
applicable.
Clockwise rotation*
Anticlockwise rotation*
• Turn the pump shaft manually to bring the next vane to
a horizontal level.
Follow the same procedure for each vane.
View of vanes
assembly
NT 1007-A00 11.11 SLP25 i series pumps e
* view from motor side

5.3 Changing the bushing
Dismantling :
• Place the front cover 44401 vertically on side casing.
• Insert the extractor inside the ring 44407, as far as the
front cover 44401.
• When the extractor is in place, remove the bushing 44407.
Remounting :
• Place the cover 44401 vertically.
• Position the bushing 44407 over the hole.
• Slide the bushing on, pushing it with a sleeve on a press.
The face of the bushing 44407 must be assembled
according to dimension X marked below.
5.4 Closing the non-drive side base
• Assemble the seal 44403.
• Place the base disk 44422 in the base. TAKE CARE
with its positioning.
• The notch must be correctly positioned with the pin as
indicated in the diagram below.
• Place the front cover 44401 on the shaft 44501 and
tighten it as much as possible by hand.
• Tighten the 4 screws 44410 and 2 screws 44411.
• Turn the shaft whilst tightening screws 44410 and the
2 screws 44411.
• If the cover 44712 has been removed, reassemble seal
44714, check it and change it if necessary.
• Reposition the cover and tighten the 3 screws 44726.
X
SLP25 4,9 °0,1
16/33
5. OPENING AND CLOSING THE NON-DRIVE
SIDE OF PUMP (continued)
NT 1007-A00 11.11 SLP25 i series pumps e

17/33
NT 1007-A00 11.11 SLP25 i series pumps e
6. OPENING AND CLOSING THE DRIVE SIDE BASE
Before any disassembly, make sure that the pump has been drained and take all the necessary precautions to prevent it from
starting up. The pump must not start up, even accidentally.
Uncouple the pump by removing the coupling sleeve.
Remove the pump mounting screws.
Place it on a workbench or on a clear, flat surface.
DISCONNECT THE ELECTRICITY SUPPLY
BEFORE ANY MAINTENANCE OPERATION.
WARNING
Hazardous pressure
can cause
personal injury
or property damage.
WARNING
The weight of the parts can
be dangerous and may
provoke bodily injuries or
material damages.
THE SURFACES OF THE PUMP CAN
BE AT A TEMPERATURE LIABLE TO
CAUSE INJURY OR SEVERE DAMAGE.
CAUTION
Excessive temperature-
can cause injury or
severe damage.
WARNING
Hazardous pressure
can cause
personal injury
or property damage.
WARNING
Hazardous or toxic
fluids can cause
serious injury.
CAUTION
Slippery lubricant.
Spills should be
cleaned up.
TAKE ALL NECESSARY MEASURES
TO RENDER ANY START-UP, EVEN
ACCIDENTAL, OF THE PUMP DURING
THE WORK IMPOSSIBLE.
WARNING
Any unforeseen start-up
can cause serious
injuries or important
material damages.
WARNING
Dangerous voltage.
Can cause
injury or death.
FAILURE TO RELEASE ALL SYSTEM AIR
AND WHEN EQUIPPED, HYDRAULIC PRES-
SURE, CAN CAUSE PROPERTY DAMAGE,
PERSONAL INJURY OR DEATH.
BE CAREFUL WITH THE WEIGHT OF
THE PARTS WHEN THEY ARE BEING
REMOVED.
DISCONNECTING THE FLUID OR PRES-
SURE CONTAINMENT COMPONENTS
DURING PUMP OPERATION CAN CAUSE
SERIOUS PERSONAL INJURY, DEATH
OR MAJOR PROPERTY DAMAGE.
IF PUMPING HAZARDOUS OR TOXIC
FLUIDS, THE SYSTEM MUST BE FLUSHED
PRIOR TO PERFORMING ANY SERVICE
OPERATION.
THE PUMP LUBRICANT IS VERY SLIPPERY
AND MAY CAUSE SERIOUS INJURY.
ANY SPILLS MUST BE CLEANED UP.

6.1 Dismantling / reassembling connection
manifold
• For ease of operation, the relief valve by be removed.
• Remove the 4 bolts 21013/21014.
• Unscrew the 8 screws 11116.
• Put down the connection manifold 11108.
• Remove seals 11117 and 21012, replacing them if
necessary.
• Follow the procedure in reverse for reassembly.
6.2 Dismantling / reassembling transmission
• Loosen the screws 11114.
• Remove the transmission from the base 11100.
• Remove seal 11104, replacing it if necessary.
• Follow the procedure in reverse for reassembly, care-
fully positioning the square block 11013 in the drive
11105 as shown below.
Transmission
Transmission
BE CAREFUL WITH THE WEIGHT OF
THE PARTS WHEN THEY ARE BEING
REMOVED.
WARNING
The weight ot the parts can
be dangerous and may
provoke bodily injuries or
material damages.
BE CAREFUL WITH THE WEIGHT OF THE
PARTS WHEN THEY ARE BEING REMO-
VED. IT IS ADVISABLE TO HOLD THE
CONNECTION MANIFOLD WHEN DIS-
MANTLING.
WARNING
The weight of the parts can
be dangerous and may
provoke bodily injuries or
material damages.
18/33
6. OPENING AND CLOSING THE DRIVE SIDE BASE (continued)
NT 1007-A00 11.11 SLP25 i series pumps e

19/33
6. OPENING AND CLOSING THE DRIVE SIDE BASE (continued)
6.3 Dismantling the adaptation unit base
• For ease of handling, this unit may be positioned verti-
cally as shown, preferably on blocks.
• Loosen the 6 screws 44410.
• Place 2 screws 44410 in the 2 diametrically opposed
tapped holes T.
• Detach the front cover of the body by tightening the 2
screws simultaneously.
• Remove the casing 44101.
• Remove vanes 44417 and pushrods 44418 using a
screwdriver if these were not removed when the base
was dismantled (see § VANE CHECKS).
• Remove and check the seal 44403.
• Check pushrods 44318 and vanes 44317 (see § MAIN-
TENANCE) and change them as necessary.
• Remove circlips 11119.
• Pull out the rotor 44301.
• Remove keys 44536.
• Check the wear of the keyways and of the 2 keys 44536.
• Remove the carbon disk 44422 and check it for wear.
• Place the remainder of the assembly in horizontal posi-
tion.
• Remove the shaft unit 44501 / drive 11105 / key 11112 /
circlips 11110.
• Remove circlips 11110.
• Remove the drive 11105 and check it for wear (must be
checked with the square bushing 11013, as these 2
parts should be changed at the same time).
Height X of blocks
(mm)
SLP25 17,5
NT 1007-A00 11.11 SLP25 i series pumps e

20/33
6. OPENING AND CLOSING THE DRIVE SIDE BASE (continued)
• Check the bushing 11108 and change if necessary as
follows :
- Extract the pin 11109 using a pin punch.
- Break the bushing 11108 using a chisel. TAKE CARE
not to damage the surface below the bushing.
- Replace the new bushing 11108, heating it (in oil
bath or High Frequency) to 110ºC max.
Position the bushing 11108 carefully to allow the
fitting of pin 11109.
- Assemble pin 11109.
The pin must not stick out into the bore of the
drive 11105 or beyond the bushing 11108.
6.4 Changing the bushing in the adaptation
base
• Break the bushing 11107 using a chisel and taking care
not to damage the bore in the base 11120.
• For reassembly, place the base 11120 vertically on its
biggest surface.
• Position the bushing 11107 over the hole.
• Slide the bushing 11107 on, pushing it with a sleeve on
a press. The bushing 11107 must fit closely to the base
11120.
Dimensions of bushing :
Ø int Ø ext L
SLP25 50 60 40
CAUTION
CAUTION
NT 1007-A00 11.11 SLP25 i series pumps e
