Audio Output 1W(8Ω)
Modulation Method GFSK, 1Mbps, 0.5BT Gaussian
Maximum Data Rate Asynchronous: 2178.1kbps / 177.1kbps
Synchronous: 1306.9kbps / 1306.9kbps
Bluetooth Class Class 2
Hopping 1600hops / sec, 1MHz Channel Space
Transmit Power 1 dBm
Coverage Range 10 Meters
Receiver Sensitivity -80 dBm / 0.1% BER
ContinuousTalkTime 10 Hours
Stand-byTime 330 Hours
Weight 65g
Dimension 51.2 mm (W) X 112.9 mm (H) X 15.7 mm (D)
ChargingVoltage DC5.0V
ChargingTime MAX 3 Hours
OperatingTemperature -20° to +70°C
StorageTemperature -40° to +85°C
Battery Lithium Polymer 3.7V 600mAH
SAFETY AND GENERAL INFORMATION
1. Please read this guidebook carefully and follow the instruction.
2. To avoid any damage or malfunction of the unit, do not drop it from high place.
3. Keep away unit from humidity, water and any other liquid. And if the unit is exposed by water, moisture and other liquid
directly, then do not operate it normally to avoid any electrical shock, explosion and damage of the unit.
4. Do not place or keep the unit near the heat sources such as direct sun light, radiators, stoves or other
apparatus which produce heat. It may cause explosion, degrade of performance and reduce
battery life.
5. Do not modify, repair & disassemble unit at discretion
(especially battery: it may cause an explosion)
6. Do not place the heavy objects on the unit.
7. Use only supplied and approved charger.
8. Replacement or service must be done at a qualied service center or manufacturer.
9. Unplug this unit when unused for long period of time or during lightening storms.
[CAUTIONS] ELECTRIC SHOCKHAZARD
The battery used in this device may present a risk of re or chemical burn if mis-treated.
FCC STATEMENT
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
-13- Germany
2. This device must accept any interference received , including interference that may cause undesired operation.
[Note]The manufacturer is not responsible for AzNY interference, for example RADIO orTV interference,
caused by unauthorized modications to this equipment. Such modications could void the
user’s authority to operate the equipment.
EU
This product is CE marked according to the provision of the R&TTE Directive (99/5/EC).
Here by MOVON Corporation, declares that this product is in compliance with the essential requirements and other relevant
provisions of Directive 1999/5/EC. Please note that this product uses radio frequency bands not harmonized within EU.
Within the EU this product is intended to be used in Austria, Belgium, Denmark, Finland, France,Germany, Greece, Ireland,
Italy, Luxembourg,The Netherlands, Portugal, Spain, Sweden, United Kingdom and within EFTA in Iceland, Norway and
Switzerland. Bluetooth is a trademark owned by the Bluetooth SIG, Inc.
WARRANTY
The condition of this warranty and our responsibilities under this warranty are as follows:
Supplier’s warranty is non-transferable. And this warranty is limited to the original purchaser only.
- You must be able to prove the date of original purchase of the unit with a dated receipt.
- The warranty is not applicable if the product has been subject to physical abuse, improper installation, modication or
repair by unauthorized third party.
- The responsibility of supplier’s products shall be limited to the repair or replacement of the product at it’s sole discretion.
- Specically exempt from any warranty are limited-life consumable components subject to normal wear and tear such as
batteries, decorates and other accessories.
- A supplier will not take any responsibility if the failure of the unit has resulted from accident, abuse, misuse or any
unauthorized repair, modication or disassemble.
- Modication and repair of the unit should be done by authorized and qualied service personnel, center or returned to
the manufacturer.
- This warranty gives you specic legal rights and you may also have other rights which vary under local laws.
WEEE SYMBOL INFORMATION
Correct Disposal ofThis Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate collection systems)This marking shown
on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its
working life.
To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from
other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product or their local government oce, for
details of where and how they can take this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product
should not be mixed with other commercial wastes for disposal.
[IMPORTANT NOTE]To comply with RF exposure requirements, this device may not be co-located
with any other transmitter or antenna.
-14- Germany
