MGate MB3480
Quick Installation Guide
Version 7.1, October 2019
Technical Support Contact Information
www.moxa.com/support
Moxa Americas:
Toll
-free: 1-888-669-2872
Tel:
1-714-528-6777
Fax:
1-714-528-6778
Moxa China (Shanghai office):
Toll
-free: 800-820-5036
Tel:
[phone]
Fax:
[phone]
Moxa Europe:
Tel:
[phone]
Fax:
[phone]
Moxa Asia-Pacific:
Tel:
[phone]
Fax:
[phone]
Moxa India:
Tel:
[phone]
Fax:
[phone]

2019 Moxa Inc. All rights reserved.

- 2 -
Overview
The MGate MB3480 is a 4-port Modbus gateway that converts between
Modbus TCP and Modbus RTU/ASCII protocols. It can be used to allow
Ethernet masters to control serial slaves, or to allow serial masters to
control Ethernet slaves. Up to 16 TCP masters and 124 serial slaves can
be connected simultaneously.
Package Checklist
Before installing the MGate MB3480 Modbus gateway, verify that the
package contains the following items:
•1 MGate MB3480 Modbus gateway
•Power adapter
•4 Stick-on pads
•Quick installation guide (printed)
•Warranty card
Optional Accessory
•DK-35A: DIN-rail mounting kit (35 mm)
•Mini DB9F-to-TB Adapter: DB9 female to terminal block adapter
Notify your sales representative if any of the above items is missing or
damaged.
NOTE
This product is designed to be powered by a listed power
source marked "LPS" and is rated 12 to 48 VDC and 0.25 A
minimum. The device's operating temperature when using the
power adapter is 0 to 40°C (32 to 104°F), and 0 to 60°C (32 to
140°F)
when using an
alternative DC power source. If you need
additional assistance purchasing a power source, please contact
Moxa for more information.

- 3 -
Hardware Introduction
As shown in the following figures, the MGate MB3480 has 4 DB9 male
ports for transmitting serial data.
Reset Button—The reset button is used to load factory defaults. Hold
the reset button down for five seconds using a pointed object such as a
straightened paper clip. Release the reset button when the Ready LED
stops blinking in order to load the factory defaults.
LED Indicators—Six LED indicators are located on the top panel:
Name
Color
Function
Ready
Red
Steady on:
Power is on and the unit is booting up.
Blinking:
IP conflict exists, or DHCP or BOOTP
server did not respond properly.
Green Steady on: Power is on and the unit
is functioning
normally.
Blinking:
Unit has found by the Location
command in MGate Manager.
Off
Power is off or power error condition exists.
Link
Orange
10 Mbps Ethernet connection.
Green
100 Mbps Ethernet connection.
Off
Ethernet cable is disconnected or has a short.
P1/P2/
P3/P4
Orange
Unit is receiving data from device.
Green
Unit is transmitting data to device.
Off
No data is being exchanged with device.

- 4 -
Hardware Installation Procedure
STEP 1:
After unpacking the unit, connect the power supply or power
adapt
er to the unit. Make sure that the adapter is connected
to an earthed socket outlet.
STEP 2:
Use a standard straight
-
through Ethernet cable to connect the
unit
to a network hub or switch. Use a cross-over Ethernet
cable if you are connecting the gateway directly to a PC
.
STEP 3:
Connect your device to the desired port on the
unit.
STEP 4:
Place or mount the unit. The unit may be placed on a
horizontal surf
ace such as a desktop, mounted on a DIN-rail,
or mounted on the wall.
Wall or Cabinet Mounting
T
wo metal plates are provided for mounting
the unit on
to a wall or inside a cabinet.
Attach the plates to the unit
’
s rear panel with
the provided
screws. With the plates
attached, use screws to mount the unit on a
wall.
Mounting the MGate MB3480 onto a wall
requires two screws. The head of the screws
should be 5.0 to 7.0 mm in diameter, the
shaft should be 3.0 to 4.0 mm in diameter,
and the length of the screws s
hould be at
least 10.5 mm.
DIN-rail Mounting
DIN rail attachments can be purchased separately to mount the MGate
MB3480 on a DIN rail. When mounting the unit on a DIN rail, make
sure that it is oriented with the metal springs on top.
Wall Mounting
DIN-rail Mounting
Termination Resistor and Adjustable Pull High/Low Resistors
For some RS-485 environments, you may need to add termination
resistors to prevent the reflection of serial signals. When using
termination resistors, it is important to set the pull high/low resistors
correctly so that the electrical signal is not corrupted. For each serial
port, DIP switches are used for termination resistor and pull high/low
resistor settings. To enable the 120 Ωtermination resistor, set switch 3
on the assigned DIP switch to ON; set it to OFF (the default setting) to
disable the termination resistor. To set the pull high/low resistors to
150 KΩ(the default setting), set switches 1 and 2 on the assigned DIP
switch to the OFF position; set them both to ON for 1 KΩ.

- 5 -
MGate MB3480 DIP Switches
Pull High/low Resistors for the RS-485 Port
SW
1
2
3
Pull High
Pull Low
Terminator
ON
1 K
Ω
1 K
Ω
120
Ω
Default
OFF
150 K
Ω
150 K
Ω
–
Software Installation
You can download the MGate Manager, User's Manual, and Device
Search Utility (DSU) from Moxa's website: www.moxa.com. Please refer
to the User’s Manual for additional details on using the MGate Manager
and DSU.
The MGate MB3480 also supports login via a web browser.
Default IP address: 192.168.127.254
Default account: admin
Default password: moxa
Pin Assignments
Ethernet Port (RJ45)
Pin
Signals
1
Tx+
2
Tx-
3
Rx+
6
Rx-
Serial Port (Male DB9)
Pin RS-232
RS-422/485
(4-Wire)
RS-485 (2-
Wire)
1
DCD
TxD-(A)
–
2
RxD
TxD+(B)
–
3
TxD
RxD+(B)
Data+(B)
4
DTR
RxD-(A)
Data-(A)
5
GND
GND
GND
6
DSR
–
–
7
RTS
–
–
8
CTS
–
–
9
–
–
–

- 6 -
Environmental Specifications
Power Requirements
Power Input
12 to 48 VDC
Power Consumption
385 mA @ 12 VDC, 110 mA @ 48 VDC
Operating Temperature
0 to 60°C (32 to 140°F)
Storage Temperature
-40 to 85°C (-40 to 185°F)
Operating Humidity
5 to 95% RH
Dimensions
With ears:
Without ears:
35.5 x 102.7 x 181.3 mm
(1.40 x 4.04 x 7.14 inch)
35.5 x 102.7 x 157.2 mm
(1.40 x 4.04 x 6.19 inch)
