EDS-405A/408A Series
Hardware Installation Guide
Moxa EtherDevice™ Switch
Ninth Edition, December 2014

- 2 -
Overview
The Moxa EtherDevice™ EDS-405A/408A series, which includes both 5
and 8-port smart Ethernet switches, is a cost-effective solution for your
Ethernet connections. In addition, the built-in smart alarm function helps
system maintainers monitor the health of your Ethernet network.
Package Checklist
The Moxa EDS-405A/408A switches are shipped with the following items.
If any of these items is missing or damaged, please contact your
customer service representative for assistance.
•EDS-405A or EDS-408A Ethernet switch
•RJ45-to-DB9 console port cable
•Protective caps for unused ports
•Panel mounting kit (optional—must order separately)
•Hardware installation guide
•CD-ROM with user’s manual and Windows utility
•Warranty card

- 3 -
EDS-405A/408A Panel Layout (standard)
1. Grounding screw
2. Terminal block for power input
PWR1/PWR2 and relay output
3. Heat dissipation vents
4. Console port
5. DIP switches
6. Power input PWR1 LED
7. Power input PWR2 LED
8. Fault LED
9. MSTR/HEAD: LED indicator
10.
CPLR/TAIL: LED indicator
11.
TP port’s 100 Mbps LED
12.
TP port’s 10 Mbps LED
13.
Model Name
14.
10/100BaseT(X) ports
15.
Screw hole for wall mounting kit
16.
DIN-Rail kit

- 4 -
EDS-405A/408A-MM (SC-type) Panel Layout
NOTE:
T
he appearance of the EDS-405A-SS-SC is
identical to
that of the EDS-405A-MM-SC.
T
he appearance of the EDS-408A-SS-SC is
identical to
that of the EDS-408A-MM-SC.
1. Grounding screw
2. Terminal block for power input
PWR1/PWR2 and relay output
3. Heat dissipation vents
4. Console port
5. DIP switches
6. Power input PWR1 LED
7. Power input PWR2 LED
8. Fault LED
9. MSTR/HEAD: LED indicator
10.
CPLR/TAIL: LED indicator
11.
TP port’s 100 Mbps LED
12.
TP port’s 10 Mbps LED
13.
Model Name
14.
10/100BaseT(X) ports
15.
100BaseFX ports
16.
FX port’s 100 Mbps LEDs
17.
Screw hole for wall mounting kit
18.
DIN-Rail kit

- 5 -
EDS-405A/408A-MM (ST-type) Panel Layout
1. Grounding screw
2. Terminal block for power input
PWR1/PWR2 and relay output
3. Heat dissipation vents
4. Console port
5. DIP switches
6. Power input PWR1 LED
7. Power input PWR2 LED
8. Fault LED
9. MSTR/HEAD: LED indicator
10.
CPLR/TAIL: LED indicator
11.
TP port’s 100 Mbps LED
12.
TP port’s 10 Mbps LED
13.
Model Name
14.
10/100BaseT(X) ports
15.
100BaseFX ports
16.
FX port’s 100 Mbps LEDs
17.
Screw hole for wall mounting kit
18.
DIN-Rail kit

- 6 -
EDS-408A-3M Panel Layout (SC/ST-type)
NOTE:
The appearance of
the
EDS
-408A-3S-SC,
EDS
-408A-1M2S-SC, and
EDS
-408A-2M1S-SC are identical to
that of
the EDS-408A-3M-SC.
1. Grounding screw
2. Terminal block for power input
PWR1/PWR2 and relay output
3. Console port
4. DIP switches
5. Heat dissipation vents
6. Power input PWR1 LED
7. Power input PWR2 LED
8. Fault LED
9. MSTR/HEAD: LED indicator
10.
CPLR/TAIL: LED indicator
11.
10/100BaseT(X) ports
12.
TP port’s 100 Mbps LED
13.
TP port’s 10 Mbps LED
14.
100BaseFX ports
15.
1 FX port’s 100Mbps LEDs
100M-M: multi mode FX port
100M-S: single mode FX port
16.
Model Name
17.
Screw hole for wall mounting kit
18.
DIN-Rail kit

- 7 -
Mounting Dimensions (unit = mm)
Unit = mm (inch)

- 8 -
DIN-Rail Mounting
The aluminum DIN-Rail attachment plate should already be fixed to the
back panel of the EDS-405A/408A when you take it out of the box. If you
need to reattach the DIN-Rail attachment plate, make sure the stiff metal
spring is situated towards the top, as shown in the following figures.
STEP 1:
Insert the top of the DIN
-Rail into
the slot just
below the stiff metal
spring.
STEP 2:
The DIN
-Rail attachment unit will
snap into place as shown.
To remove the Moxa EtherDevice switch from the DIN-Rail, simply
reverse Steps 1 and 2.
Wall Mounting (optional)
For some applications, you will find it convenient to mount the
EDS-405A/408A on the wall, as shown in the following figures.
STEP 1:
Remove the aluminum
DIN
-Rail attachment plate
from
the EDS-405A/408A’s
rear panel, and then attach
the wall mount plates
with
M3 screws
, as shown in the
diagram
at the right.
STEP 2:
Mounting
the EDS-405A/408
A on the wall requires 4
screws. Use the
switch, with wall mount plates
attached, as a guide to mark the correct locations of
the 4 screws. The heads of the screws should be less
than 6.0 mm in diameter, and the shafts should be
less than 3.5
mm in diameter, as shown in the figure
at the right.
NOTE
Before tightening the screws into the wall, make sure the screw
head and shank size are suitable by inserting the screw into one
of the keyhole-shaped apertures of the wall mounting plates.
Do not screw the screws in completely—leave about 2 mm to allow room
for sliding the wall mount panel between the wall and the screws.
STEP 3: Once the screws are fixed in the wall, insert the four screw heads
through the large parts of the keyhole-shaped apertures, and then slide
the EDS-405A/408A downwards, as indicated. Tighten the four screws for
added stability.

- 9 -
ATEX Information
1. Certificate number: DEMKO 08 ATEX
0712961X
2. Ambient range (-40°C ≤Tamb ≤75°C
)
3. Certification string:
EDS-405A: Ex nA nC IIC T4 Gc
EDS-408A: EX nA nC op is IIC T4 Gc
4. Standards covered ( EN 60079-0:2012, EN 60079-15:2010)
5. The conditions of safe usage:
•These products must be mounted in an IP54 enclosure.
•Install in an area of pollution degree 2 or less.
•Use a conductor wire of size 0.2 mm² or greater.
•PROVISIONS SHOULD BE MADE,
EXTERNAL TO THE APPARATUS,
TO PREVENT THE RATED VOLTAGE FROM BEING EXCEEDED BY
TRANSIENT DISTURBANCES OF MORE THAN 40%.
Wiring Requirements
WARNING
Safety First!
Be sure to disconnect the power cord before installing and/or
wiring your
Moxa EtherDevice Switch.
Calculate the maximum possible current in each power wire and
common wire. Observe all electrical codes dictating the
maximum current allowable for each wire size.
If the current goes above the maximum ratings, the wiring could
overheat, causing serious damage to your equipment.
Be sure to read and follow these important guidelines:
•Use separate paths to route wiring for power and devices. If power
wiring and device wiring paths must cross, make sure the wires are
perpendicular at the intersection point.
NOTE: Do not run signal or communications wiring and power wiring
through the same wire conduit. To avoid interference, wires with
different signal characteristics should be routed separately.
•Use the type of signal transmitted through a wire to determine which
wires should be kept separate. The rule of thumb is that wiring that
shares similar electrical characteristics can be bundled together.
•Keep input wiring and output wiring separate.
•When necessary, you should label the wiring to all devices in the
system.
Grounding the EtherDevice Switch
Grounding and wire routing help limit the effects of noise due to
electromagnetic interference (EMI). Run the ground connection from the
ground screw to the grounding surface prior to connecting devices.

- 10 -
ATTENTION
This product is intended to be mounted to a well
-grounded
mounting surface, such as a metal panel.
Wiring the Relay Contact
The Relay Contact consists of the two middle contacts of the terminal
block on the EDS-405A/408A’s top panel. Refer to the next section for
detailed instructions on how to connect the wires to the terminal block
connector, and how to attach the terminal block connector to the terminal
block receptor.
In this section, we explain the meaning of the two contacts used to
connect the Alarm Contact.
FAULT: The two middle contacts of the
6
-contact terminal block connector
are used to
detect both power faults and port faults. The
two wires attached to the
fault contacts form
a
n open circuit when:
A relay warning event
is triggered.
OR
T
he EDS-405A/408A is
the Master of this Turbo
Ring, and the Turbo Ring
is broken.
OR
There is a s
tart-up failure.
If
none of these three conditions is satisfied,
the fault circuit will remain closed.
Wiring the Redundant Power Inputs
The top two contacts and the bottom two contacts of the 6-contact
terminal block connector on the EDS-405A/408A’s top panel are used for
the EDS-405A/408A’s two DC inputs. Top and front views of one of the
terminal block connectors are shown in the following figures:
STEP 1: Insert the negative/positive DC wires
into the
V-/V+ terminals, respectively.
STEP 2:
To keep the DC wires from pulling
loose, use a small flat
-blade screwdriver to
tighten the wire
-clamp screws on the front of
the termi
nal block connector.
STEP 3:
Insert the plastic terminal block
connector prongs into the terminal block
receptor, which is
located on the
EDS-405A/408A’s top panel.
ATTENTION
Before connecting
the EDS-405A/408A to the DC power inputs,
make sure the DC power source voltage is stable.

- 11 -
Communication Connections
EDS-408A models have 5, 6, or 8 10/100BaseT(X) Ethernet ports, and 3,
2, or 0 (zero) 100BaseFX (SC/ST-type connector) fiber ports. EDS-405A
models have 3 or 5 10/100BaseT(X) Ethernet ports, and 2 or 0 (zero) 100
BaseFX (SC/ST-type connector) fiber ports.
10/100BaseT(X) Ethernet Port Connection
The 10/100BaseT(X) ports located on the EDS’s front panel are used to
connect to Ethernet-enabled devices.
Next, we show pinouts for both MDI (NIC-type) ports and MDI-X
(HUB/Switch-type) ports, and also show cable wiring diagrams for
straight-through and cross-over Ethernet cables.
10/100Base T(x) RJ45 Pinouts
MDI Port Pinouts
MDI-X Port Pinouts
8-pin RJ45
Pin
Signal
1
Tx+
2
Tx-
3
Rx+
6
Rx-
Pin
Signal
1
Rx+
2
Rx-
3
Tx+
6
Tx-
RJ45 (8-pin) to RJ45 (8-pin) Straight-Through Cable Wiring
RJ45 (8-pin) to RJ45 (8-pin) Cross-Over Cable Wiring
100BaseFX Ethernet Port Connection
The concept behind the SC/ST port and cable is quite straightforward.
Suppose you are connecting devices I and II; contrary to electrical signals,
optical signals do not require a circuit in order to transmit data.
Consequently, one of the optical lines is used to transmit data from device
I to device II, and the other optical line is used transmit data from device
II to device I, for full-duplex transmission.

- 12 -
Remember to connect the Tx (transmit) port of device I to the Rx (receive)
port of device II, and the Rx (receive) port of device I to the Tx (transmit)
port of device II. If you make your own cable, we suggest labeling the two
sides of the same line with the same letter (A-to-A and B-to-B, as shown
below, or A1-to-A2 and B1-to-B2).
SC-Port Pinouts
SC-Port to SC-Port Cable Wiring
ST-Port Pinouts
ST-Port to ST-Port Cable Wiring
ATTENTION
This is a Class 1 Laser/LED product. To avoid causing serious
damage to your eyes, do not stare directly into the laser beam.
Redundant Power Inputs
Both power inputs can be connected simultaneously to live DC power
sources. If one power source fails, the other live source acts as a backup,
and automatically supplies the EDS-405A/408A with power.
Relay Contact
The Moxa EtherDevice switch has one relay contact located on the top
panel. For detailed instructions on how to connect the relay contact power
wires to the two middle contacts of the 6-contact terminal block
connector, see the Wiring the Relay Contact section. A typical scenario
would be to connect the fault circuit to a warning light located in the
control room. The light can be set up to switch on when a fault is detected.
The relay contact has two terminals that form a fault circuit for connecting
to an alarm system. The two wires attached to the fault contacts form an
open circuit when (1) a relay warning event is triggered, (2) the
EDS-405A/408A is the Master of this Turbo Ring, and the Turbo Ring is
broken, or (3) there is a start-up failure. If none of these three conditions
occur, the fault circuit will be closed.

- 13 -
Turbo Ring DIP Switch Settings
EDS-405A/408A series switches are plug-and-play managed redundant
Ethernet switches. The proprietary Turbo Ring protocol was developed by
Moxa to provide better network reliability and faster recovery time. Moxa
Turbo Ring’s recovery time is less than 300 ms (Turbo Ring) or 20 ms
(Turbo Ring V2) —compared to a 3 to 5-minute recovery time for
commercial switches—decreasing the possible loss caused by network
failures in an industrial setting.
There are 4 Hardware DIP Switches for Turbo Ring on the top panel of the
EDS-405A/408A that can be used to set up the Turbo Ring easily within
seconds. If you do not want to use a hardware DIP switch to set up Turbo
Ring, you can use a web browser, Telnet, or console to disable this
function.
NOTE
Refer to the Turbo Ring DIP Switch section and Using
Communication Redundancy
section in the user’s m
anual for
detail
ed information about the settings and usage of Turbo Ring
and Turbo Ring V2.
EDS-405A/408A Series DIP Switches
The default setting for each DIP Switch is OFF. The
following table explains the effect of setting the DIP
Switch to the ON position
.
“Turbo Ring” DIP Switch Settings
DIP 1
DIP 2
DIP 3
DIP 4
Reserved for
future use.
ON: Enables this
EDS as
the Ring
Master.
ON: Enables the
default “Ring
Coupling” ports.
ON: Activates
DIP
switches 1, 2,
3 to configure
“Turbo Ring”
settings.
OFF: This EDS
will not be the
Ring Master.
OFF: Do not use
this EDS as the
ring coupler.
OFF: DIP
switches 1, 2, 3
will be disabled.
“Turbo Ring V2” DIP Switch Settings
DIP 1
DIP 2
DIP 3
DIP 4
ON: Enables the
default “Ring
Coupling
(backup)” port.
ON: Enables this
EDS as the Ring
Master.
ON: Enables the
default “Ring
Coupling” port.
ON: Activates
DIP switches 1,
2, 3 to configure
“Turbo Ring V2”
settings.
OFF: Enables the
default “Ring
Coupling
(primary)” port.
OFF: This EDS
will not be the
Ring Master.
OFF: Do not use
this EDS as a ring
coupler.
OFF: DIP
switches 1, 2, 3
will be disabled.

- 14 -
NOTE
If you do not enable any of the EDS-405A/408A switches to be
the Ring Master, the Turbo Ring protocol will automatically
choose the EDS
-
405A/408A with the smallest MAC address range
to be the Ring Master. If you accidentally enable more than one
EDS
-405A/408A to be the Ring Master, these EDS-405A/408A
switches will auto
-negotiate to determine which switch
will be the
Ring Master.
NOTE
To switch on the Master or Coupler functions of the DIP switch,
you need to enable the Turbo Ring Pole first.
LED Indicators
There are several LEDs on the EDS’s front panel. The function of each LED
is described in the following table.
LED
Color
State
Description
PWR1 AMBER
On
Power is being supplied to power input
PWR1.
Off
Power is not being supplied to power
input PWR1.
PWR2 AMBER
On
Power is being supplied to power input
PWR2.
Off
Power is not being supplied to power
input PWR2.
FAULT RED
On
When (1) a relay warning event is
triggered, (2) the EDS-405A/408A is
the Master of this Turbo Ring, and the
Turbo Ring is broken, or (3) start-up
failure.
Off
When a relay warning event is not
triggered.
MSTR/HEAD
GREEN
On
When the EDS-405A/408A is set as the
Master of the Turbo Ring, or as the
Head of the Turbo Chain.
Blinking
The EDS-405A/408A has become the
Ring Master of the Turbo Ring, or the
Head of the Turbo Chain, after the
Turbo Ring or the Turbo Chain is down.
Off
When the EDS-405A/408A is not the
Master of this Turbo Ring or is set as
the Member of the Turbo Chain.
CPLR/TAIL GREEN
On
When the EDS-405A/408A coupling
function is enabled to form a back-up
path, or when it's set as the Tail of the
Turbo Chain.
Blinking
When the Turbo Chain is down.
Off
When the EDS-405A/408A disables the
coupling function, or is set as the
Member of the Turbo Chain.
10M
(TP) GREEN
On
TP port’s 10 Mbps link is active.
Blinking
Data is being transmitted at 10 Mbps.
Off
TP Port’s 10 Mbps link is inactive.

- 15 -
100M
(TP) GREEN
On
TP port’s 100 Mbps link is active.
Blinking
Data is being transmitted at 100 Mbps.
Off
TP Port’s 100 Mbps link is inactive.
100M
(FX) GREEN
On
FX port’s 100 Mbps is active.
Blinking
Data is being transmitted at 100 Mbps.
Off
FX port’s 100 Mbps is inactive.
Auto MDI/MDI-X Connection
The Auto MDI/MDI-X function allows users to connect the
EDS-405A/408A’s 10/100BaseTX ports to any kind of Ethernet device,
without needing to pay attention to the type of Ethernet cable being used
for the connection. This means that you can use either a straight-through
cable or cross-over cable to connect the EDS-405A/408A to Ethernet
devices.
Specifications
Technology
Standards IEEE802.3, 802.3u, 802.3x, 802.1D, 802.1Q,
802.1w, 802.1p
Protocols
IGMP V1/V2 device, GMRP, GVRP, SNMPv1/v2c/v3,
DHCP Server/Client, TFTP, SNTP, SMTP, RARP,
RMON, HTTP, Telnet, Syslog, DHCP Option
66/67/82, BootP, LLDP, Modbus TCP, IPv6
MIB
MIB-II, Ethernet-Like MIB, P-BRIDGE MIB, RMON
MIB Group 1, 2, 3, 9, Bridge MIB, RSTP MIB
Forwarding and
Filtering Rate
148810 pps
Processing Type
Store and Forward
Flow Control
IEEE802.3x flow control, back pressure flow control
Interface
RJ45 Ports
10/100BaseT(X) auto negotiation speed, F/H duplex
mode, and auto MDI/MDI-X connection
Fiber Ports
100BaseFX ports (SC/ST connector)
Console
RS-232 (RJ45)
LED Indicators PWR1, PWR2, FAULT, 10/100M (TP port),
100M (Fiber Port), CPLR/TAIL and MSTR/HEAD
Relay Contact
One relay output with current carrying capacity of 1A
@ 24 VDC
DIP Switches
Master, Coupler, Turbo Ring, Reserve
Optical Fiber
Multi-mode
Single-mode
Wavelength
1300 nm
1310 nm
Max. Tx
-10 dBm
0 dBm
Min. Tx
-20 dBm
-5 dBm
Rx Sensitivity
-32 dBm
-34 dBm
Link Budget
12 dB
29 dB
Typical Distance
5 kma, 4 kmb40 kmc
Saturation
-6 dBm
-3 dBm
a. when using [50/125 μm, 800 MHz*km] cable
b. when using [62.5/125 μm, 500 MHz*km] cable
c. when using [9/125 μm, 3.5 PS/(nm*km)] cable

- 16 -
Power
Input Voltage
EDS-405A/408A:
12 to 45 VDC, redundant inputs
EDS-408A-3S-SC-48:
±24/±48 VDC (-60 to -19 VDC or 19 to 60
VDC), redundant inputs (The mixing of
power polarity system is prohibited.)
Input Current (@ 24 V) EDS-405A: Max. 0.24 A
EDS-408A: Max. 0.21 A
EDS-405A-MM, EDS-405A-SS: Max. 0.32 A
EDS-408A-MM, EDS-408A-SS: Max. 0.26 A
EDS-408A-3M/3S/2M1S/1M2S: Max. 0.32 A
Connection
One removable 6-pin terminal block
Overload Current Protection
Present
Reverse Polarity Protection
Present
Physical Characteristics
Housing
Metal, IP30 protected
Dimensions
53.6
×
135
×
105 mm
Weight 0.65 kg (EDS-405A models)
0.89 kg (EDS-408A models)
Installation
DIN-Rail, Wall Mounting (optional kit)
Environmental Limits
Operating Temperature
0 to 60°C (32 to 140°F);
-40 to 75°C (-40 to 167°F ) for -T models
Storage Temperature
-40 to 85°C (-40 to 185°F)
Ambient Relative Humidity
5% to 95% (non-condensing)
Regulatory Approvals
Safety
EDS-405A/408A: UL 60950-1, UL 508, CSA
C22.2 No. 60950-1, EN 60950-1
EDS-408A-3S-SC-48: UL508 (Pending)
Hazardous Location
UL/cUL Class I, Division 2, Groups A, B, C
and D
ATEX Zone 2 :
EDS-405A:Ex nC nL IIC T4
EDS-408A: EX nA nC op is IIC T4 Gc
EMI
FCC Part 15, CISPR (EN 55022) class A
EMS
EN 61000-4-2 (ESD), Level 3
EN 61000-4-3 (RS), Level 3
EN 61000-4-4 (EFT), Level 3
EN 61000-4-5 (Surge), Level 3
EN 61000-4-6 (CS), Level 3
Shock
IEC 60068-2-27
Freefall
IEC 60068-2-32
Vibration
IEC 60068-2-6
WARRANTY
5 years

- 17 -
Technical Support Contact Information
www.moxa.com/support
Moxa Americas:
Toll
-free: 1-888-669-2872
Tel:
1-714-528-6777
Fax:
1-714-528-6778
Moxa China (Shanghai office):
Toll
-free: 800-820-5036
Tel:
[phone]
Fax:
[phone]
Moxa Europe
:
Tel:
[phone]
Fax:
[phone]
Moxa Asia
-Pacific:
Tel:
[phone]
Fax:
[phone]
