mr. steam 300 series Guide

mr.ste m
®
towelwarmers
Series 300 Electric Towel Warmers
nstallation, Operation & Maintenance nstructions
_________________________
Model #
_________________________
Serial #
PUR 100559 Rev. 3/11

T ble of Contents
___________________
General nformation . . . . . . . . . . .3
Specifications . . . . . . . . . . . . . . . .3
Wall Preparation . . . . . . . . . . . . . .4
Mounting Dimensions . . . . . . . . . .4
nstallation: W328, W336, W348 . . .5
Electrical Connections . . . . . . . . . .6
Optional Programmable Timer . . . .7
nstallation: F328 . . . . . . . . . . . . .7
nstallation: Cord Models . . . . . . . .8
___________________
The towel warmer is
an electric device. t must be installed by
a licensed electrician in accordance with
the National Electrical Code (NEC) and
local code.
___________________
IMPO TANT NOTE: As you follow these
instructions, you will notice warning and
caution symbols. This blocked information is
important for the safe and efficient installa-
tion and operation of this Towel Warmer.
These are types of potential hazards that may
occur during this installation and operation:
states a hazard may
cause serious injury or death if precautions
are not followed.
signals a situation where
minor injury or product damage may occur if
you do not follow instructions.
IMPO TANT NOTE: This highlights
information that is especially relevant to a
problem-free installation.
All information in these instructions are based
on the latest product information available at
the time of publication. Sussman-Automatic
Corporation reserves the right to make
changes at any time without notice.
Series 300 Electric Towel Warmers
Models W328, W328CORD, F328, W336, W336CORD, W348, W348CORD
_______________________________________ _______________________________________
Model Serial #
!WA N ING
!WA N IN G
!CAUTION
mr.ste m®
Sussman-Automatic
Corporation®
[email protected]
www.mrsteam.com
PUR 100559 Rev. 3/11
43-20 34th Street
Long Islan City, NY 11101
TEL:800 76 STEAM
FAX:[phone]
9410 S. La Cienega Blv .
Inglewoo CA 90301
TEL: 800 72 STEAM
FAX: [phone]
W328
W328CORD
W338
W338CORD
W348
W348CORD
F328

mr.ste m®towelwarmers nstallation, Operation & Maintenance nstructions
_________________________________________________________________
INSTALLER:
___________________________________________________
READ TH S ENT RE NSTRUCT ON MANUAL THOROUGHLY BEFORE
BEG NN NG NSTALLAT ON. LEAVE THESE NSTRUCT ONS W TH
HOMEOWNER.
BE CERTA N ELECTR C TY S SHUT OFF AT
MA N PANEL BEFORE ATTEMPT NG TO W RE OR SERV CE THE
TOWEL WARMER. Follow instructions to make certain the Towel
Warmer is properly mounted and secured to the wall.
FA LURE TO FOLLOW THESE STEPS COULD RESULT N HAZARDOUS
COND T ONS NCLUD NG ELECTROCUT ON.
1. nstall in accordance with National and local codes.
2. Do not locate in shower stall, tub or near water spray.
3. Do not locate within
the shower or tub zone.
See illustration.
4. All models are to be
protected by dedicated
and suitably rated GFC
circuit breaker or equal.
TO ENSURE CORRECT OPERAT ON OF YOUR TOWEL WARMER,
PLEASE FOLLOW ALL NSTRUCT ONS CAREFULLY, OBSERV NG THE
"CAUT ON" and “WARN NG” NOTAT ONS FOR EACH STEP.
Inspect Towel W rmer
Unpack the Towel Warmer carefully to avoid any damage or loss of
any part. When opening the box be sure that the parts are not
accidentally discarded. Towel Warmers are shipped in specially
designed shipping cartons. The entire surface of the Towel Warmer
is hand-wrapped to protect the finish. t is your responsibility to
immediately inspect for any damage.
3
TOWEL WARMER SPECIFICATIONS
_____________________________________________________________
Model No. Dimensions (inches) Amps Volts/Phase Weight (lbs.)
WxHxD
_____________________________________________________________
W328 20 313⁄84 3⁄40.82 120/1 10
F328 197⁄8343⁄8113⁄40.82 120/1 10
W336 20 387⁄843⁄41.11 120/1 14
W348 20 491⁄443⁄41.40 120/1 18
HOMEOWNER:
_______________________________________________
THANK YOU for selecting Mr.Steam Towel Warmer, the perfect
addition to bathrooms, family spas, and exercise rooms within
your home. Our products have been a standard for quality and
comfort, and we are sure that you will experience continued
enjoyment from the Towel Warmer you have purchased by
following these instructions.
TOWEL WARMERS ARE HOT! The Towel
Warmer is an electrical heating appliance, intended only for
indoor residential applications and, as such, should be installed
and used with certain precautions for your safety.
1. NSTALLAT ON PROCEDURES FOR WALL-MOUNTED UN TS MUST
BE ACCOMPL SHED BY QUAL F ED PERSONNEL N STR CT
ACCORD W TH APPL CABLE NAT ONAL AND LOCAL BU LD NG
AND ELECTR CAL CODES.
2. DO NOT place TOWEL WARMER units inside a shower, sauna or
steam room enclosure or any other wet location or with
elevated temperature because the towel warmer may be an
electrocution hazard.
3. CAUT ON is advised when a Towel Warmer is accessible to
children because the towel warmer is hot.
4. A dedicated wall switch or timer should be used to control the
TOWEL WARMER unit. Contact Mr.Steam for an in-wall 24-hour-
7 day timer (PN W-103588) Note: All switches and control
devices must be installed on the load (black) side of the Towel
Warmer circuit in compliance with the National Electrical Code
(NEC) and local code. (see page 7for installation instructions)
IMPO TANT: The finish of your Towel Warmer can be
protected and maintained by an occasional wiping with a soft,
non-abrasive, damp cloth and lightly polished, thereafter, with a
soft dry cloth when the Towel Warmer is cold. Under no circum-
stances should abrasive cleaning powders, metal polish or chlo-
rine-based cleaners be used on any part of this product.
IMPO TANT: This appliance is for warming towels only.
DO NOT use this appliance to dry wet towels.
IMPO TANT: This appliance is intended for towels washed in
water. Fabrics that contain soap or detergent residue may show
what appears to be scorch marks. However this may be the dis-
coloration of the residue. Mr.Steam is not responsible for discolor-
ing or damage of any fabrics. Refer to the Mr.Steam towel warmer
warranty for additional terms and conditions.
For illustrative purposes only
!WA N IN G
!WA N IN G
!WA N IN G
Shower/Tub
Zone
Do not locate the
towel warmer within
the shower/tub zone
This picture shows the recommended
method of draping a towel on a towel
warmer. Ensure as much as possible of
the towel's surface is touching the towel
warmer for optimum towel warming.
Note: Dimensions are approximate
Note: Hard wired and cord connected models have the same dimensions, amps
and weight. Cord connected models include an integral 6 foot power cord.

MOUNTING DIMENSIONS
Note: “C” dimension is not applicable for cord connected models
IMPO TANT NOTE: Towel Warmers may have small
dimensional variations and must be measured prior
to installation. Do not use dimensions to determine
location of mounting holes.
mr.ste m®towelwarmers nstallation, Operation & Maintenance nstructions
_________________________________________________________________
4
WALL PREPARATION
• DO NOT mount the Towel Warmer without providing
structurally secure upper and lower headers as shown.
• DO NOT mount the Towel Warmer directly to sheet
rock or any other non-structural surface.
• Use longer fasteners as required if the finished wall surface
prevents adequate mounting with the screws provided.
• Provide a clearance hole in the lower header as required
to route field wiring to the Towel Warmer wiring box.
(not applicable for cord connected models)
IMPO TANT NOTE: See electrical rough-in instruc-
tions on page 7.
IMPO TANT NOTE: Towel Warmers may have small
dimensional variations and must be measured prior to
installation. Do not use dimensions to determine
location of mounting holes.
!CAUTION
MOUNTING DIMENSIONS (inches)
Hard Wired & Cord Connected
MODEL ABC
W328 18
7
⁄
16
17
15
⁄
16
7
1
⁄
4
W336 18
7
⁄
16
25
9
⁄
16
7
1
⁄
4
W348 18
7
⁄
16
35
3
⁄
4
7
1
⁄
4
This
End
Up
Wiring Box
Upper Header (Z)
Lower Header (Z)
Finished
wall surface
Towel Warmer
MOUNTING DIMENSIONS (inches)
Hard Wired & Cord Connected
MODEL X(min) Y Z (min)
(Header horizontal length) (Header vertical length) (Header size)
W328 19 17
15
⁄ 16 2 6
W336 19 25
9
⁄ 16 2 6
W348 19 35
3
⁄ 4 2 6
For Technical Service Assistance:
East Coast Tel: [phone]
West Coast Tel: [phone]

mr.ste m®towelwarmers nstallation, Operation & Maintenance nstructions
_________________________________________________________________
5
INSTALLATION:
W328, W336, W348
TO P EVENT SHOCK HAZA D, THE ELECT ICITY MUST BE
TU NED OFF AT THE MAIN PANEL BEFO E ANY WI ING IS DONE.
IMPO TANT NOTE:
See electrical rough-in instructions on page 7 .
nstall Towel Warmers in upright position only. Locate with wiring
box on bottom as shown. Failure to install properly may result
in a hazardous condition. See page 4.
!WA N IN G
!WA N IN G
Allen
Wrench
Wiring Box
Mounting
Bracket
Mounting
Screw
Towel
Warmer
Mounting
Bolt
Sleeve
Extension
7. Slide the towel warmer onto
the mounting brackets. Mark
the location for the wiring box
escutcheon.
8. Remove the towel warmer and
secure the escutcheon to the
wall per the instructions on
page 7.
9. Slide the towel warmer onto the mounting
brackets. Secure the towel warmer in place
using the mounting bracket set screws.
1. Remove Towel Warmer and
parts from the packing
materials.
2. Using the allen key provided,
loosen the wiring box set
screw. Set screw location
varies by model as hown. DO
NOT remove the wiring box.
3. Gently rotate the wiring box
as shown. Tighten the set
screw firmly to prevent the
wiring box from rotating.
4. Locate the mounting brackets
on the wall by measuring the
mounting holes on the towel
warmer.
5. Using the screws provided
secure the brackets to the
wall.
6. nsert the sleeves into the
extensions. Using the
mounting bolts secure the
extensions and sleeves to
the 4threaded holes on
the towel warmer.
Wiring Box
Escutcheon
Escutcheon
Set Screw
Wiring Box
Mounting Bracket
Extension
Mounting
Bracket
Set Screw
• (4) Mounting bolts
• (4) Sleeves
• (4) Extensions
• Wiring box escutcheon
• (2) Allen wrenches
• nstructions
• Warranty
BOX CONTENTS:
• Towel Warmer
• (4) Mounting Screws
• (3) Wiring Box Mounting Screws
• (2) Wiring Box Set Screws
• (4) Mounting Brackets
• (4) Mounting bracket Set Screw
(Note: Cord connected models use
4 knurled thumb screws )
Wiring Box
Mounting
Screws
Wiring
Box
Escutcheon
