MSI MS-7314 User manual

i
Wind Board
MS-7314 (v1.X) Mainboard
G52-73141X1
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

ii
CopyrightNotice
Thematerialin thisdocumentisthe intellectualpropertyof MICRO-STAR
INTERNATIONAL.Wetakeeverycareinthepreparation ofthisdocument, butno
guarantee isgiven astothecorrectnessof itscontents.Ourproductsareunder
continualimprovementand we reservetheright tomakechangeswithout notice.
Trademarks
Alltrademarksarethe propertiesoftheirrespectiveowners.
NVIDIA, the NVIDIAlogo,DualNet, and nForceareregisteredtrademarksortrade-
marks ofNVIDIACorporationintheUnitedStatesand/orothercountries.
AMD,Athlon ,Athlon XP,Thoroughbred ,andDuron areregisteredtrade-
marks ofAMDCorporation.
Intel®and Pentium®areregisteredtrademarks of IntelCorporation.
PS/2and OS®/2areregisteredtrademarks ofInternationalBusiness Machines
Corporation.
Windows®95/98/2000/NT/XP/Vistaareregistered trademarksofMicrosoft
Corporation.
Netware® isaregisteredtrademarkof Novell, Inc.
Award®isaregisteredtrademarkof PhoenixTechnologiesLtd.
AMI®isaregistered trademark ofAmericanMegatrendsInc.
Revision History
Revision RevisionHistory Date
V1.0 FirstreleaseforPCB1.X June2008
TechnicalSupport
If aproblemariseswithyoursystemand nosolution canbeobtainedfromtheuser’s
manual,pleasecontactyourplaceofpurchaseorlocaldistributor. Alternatively,
pleasetrythe followinghelpresourcesforfurtherguidance.
VisittheMSIwebsiteforFAQ, technicalguide, BIOSupdates, driverupdates,
andotherinformation: http://global.msi.com.tw/index.php?
func=service
Contactourtechnicalstaff at: http://ocss.msi.com.tw
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

iii
SafetyInstructions
CAUTION: Dangerofexplosionifbattery isincorrectlyreplaced.
Replaceonlywiththesameorequivalenttyperecommendedbythe
manufacturer.
1. Alwaysreadthe safetyinstructionscarefully.
2. KeepthisUser’sManualforfuturereference.
3. Keep thisequipmentawayfromhumidity.
4. Laythisequipmenton areliableflatsurfacebeforesettingitup.
5. Theopeningsontheenclosureareforairconvectionhenceprotectstheequip-
mentfromoverheating.DONOTCOVERTHEOPENINGS.
6. Makesurethevoltage ofthepowersourceandadjustproperly110/220Vbe-
foreconnecting theequipmenttothepowerinlet.
7. Placethepowercordsuchawaythatpeoplecannotstep on it.Donotplace
anythingoverthe powercord.
8. AlwaysUnplugthePowerCordbeforeinserting anyadd-oncardormodule.
9. Allcautionsandwarningson the equipment should benoted.
10.Neverpouranyliquidintothe openingthatcoulddamageorcauseelectrical
shock.
11. Ifanyofthefollowingsituationsarises,get theequipmentchecked byservice
personnel:
†Thepowercordorplug isdamaged.
†Liquidhaspenetrated intotheequipment.
†Theequipment hasbeen exposedtomoisture.
†Theequipmentdoesnotworkwelloryou cannotgetit workaccordingto
User’sManual.
†Theequipmenthasdroppedand damaged.
†Theequipment hasobvioussign of breakage.
12.DONOTLEAVETHISEQUIPMENTINANENVIRONMENTUNCONDITIONED,STOR-
AGETEMPERATUREABOVE600 C(1400F), ITMAYDAMAGETHEEQUIPMENT.
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

iv
FCC-BRadioFrequencyInterferenceStatement
Thisequipmenthasbeen
testedandfoundtocomply
withthe limitsforaClass B
digitaldevice,pursuanttoPart
15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotection
againstharmfulinterferenceinaresidentialinstallation. Thisequipmentgenerates,
usesandcanradiateradio frequency energyand, ifnot installedand usedin accor-
dancewiththeinstructions,maycauseharmful interferencetoradio communications.
However,thereisnoguaranteethatinterferencewill notoccurinaparticular
installation.Ifthisequipmentdoescauseharmful interferencetoradio ortelevision
reception, whichcanbedeterminedbyturning theequipmentoff and on, theuseris
encouraged totrytocorrect theinterferencebyoneormoreofthe measureslisted
below. †Reorientorrelocatethereceivingantenna.
†Increasetheseparation between theequipmentandreceiver.
†Connectthe equipmentintoan outletonacircuitdifferentfromthat to
whichthereceiverisconnected.
†Consult thedealeroranexperiencedradio/televisiontechnician forhelp.
Notice1
Thechangesormodificationsnotexpresslyapprovedbythe partyresponsible for
compliancecouldvoidtheuser’sauthoritytooperatetheequipment.
Notice2
ShieldedinterfacecablesandA.C.powercord,if any,must beused in orderto
complywiththeemissionlimits.
VOIRLANOTICED’ INSTALLATIONAVANTDERACCORDERAURESEAU.
Micro-StarInternational
MS-7314
ThisdevicecomplieswithPart15oftheFCCRules.Operationissubject tothe
followingtwo conditions:
(1)thisdevicemaynotcauseharmfulinterference,and
(2)thisdevicemustacceptanyinterferencereceived,includinginterferencethat
maycauseundesiredoperation.
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

v
WEEE (WasteElectricaland ElectronicEquipment) Statement
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

vi
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

vii
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

viii
CONTENTS
CopyrightNotice....................................................................................................ii
Trademarks............................................................................................................ii
Revision History....................................................................................................ii
TechnicalSupport.................................................................................................ii
SafetyInstructions................................................................................................iii
FCC-BRadioFrequency InterferenceStatement...................................................iv
WEEE (WasteElectricaland ElectronicEquipment)Statement................................v
Chapter 1.Getting Started.............................................................................1-1
MainboardSpecifications.............................................................................1-2
MainboardLayout........................................................................................1-4
PackingChecklist.........................................................................................1-5
Chapter2.HardwareSetup............................................................................2-1
QuickComponentsGuide.............................................................................2-2
Memory.......................................................................................................2-3
PowerSupply..............................................................................................2-7
BackPanel.................................................................................................2-10
Connectors................................................................................................2-12
Jumper......................................................................................................2-17
Slot............................................................................................................2-18
Chapter3BIOSSetup......................................................................................3-1
EnteringSetup.............................................................................................3-2
TheMainMenu.............................................................................................3-4
StandardCMOSFeatures............................................................................3-6
AdvancedBIOSFeatures............................................................................3-9
IntegratedPeripherals................................................................................3-12
PowerManagementSetup.........................................................................3-14
H/WMonitor...............................................................................................3-17
BIOSSettingPassword..............................................................................3-18
CellMenu...................................................................................................3-19
LoadFail-Safe/ OptimizedDefaults............................................................3-22
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

1-1
GettingStarted
Getting Started
Chapter1
ThankyouforchoosingtheWind Board(MS-7314 v1.
X)Micro-ATXmainboard.The WindBoardisbasedon
Intel brandnewAtomCPUand 945GC+ICH7 chipsets
foroptimalsystemefficiency.TheWind Boarddelivers
ahigh performanceand professionaldesktopplatform
solution.
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

MS-7314Mainboard
1-2
Mainboard Specifications
ProcessorSupport
-Intel ATomseriesCeleron230processorintheLGA437package
SupportedFSB
-533MHz
Chipset
-NorthBridge:Intel 945GCchipset
-SouthBridge:Intel ICH7chipset
Memory Support
-2DDR2DIMMssupportDDR2533/ 667 SDRAM(240pin/ 1.8V)
-Onlysupportstoinstallonedouble-side(2GBmax)memory
module,ortoinstalltwosingle-sidememorymodules(1GBmax
perDIMM)
(Formoreinformationoncompatiblecomponents, pleasevisit
http://global.msi.com.tw/index.php?func=testreport)
LAN
-SupportsPCIELAN10/100FastEthernet byRealtek8101E
Audio
-Chipintegrated byRealtek ALC888
-Flexible5.1-channelaudiowithjacksensing
-CompliantwithAzalia1.0Spec
IDE
-1IDEportbyIntel ICH7
-SupportsUltraDMA66/100mode
-SupportsPIO, BusMasteroperationmode
SATA
-2SATAII portsbyICH7
-Supportsstorageand datatransfersatupto3Gb/s
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

1-3
GettingStarted
Connectors
Back panel
-1PS/2mouseport
-1PS/2keyboardport
-1Parallelport
-1Serialport
-1VGAport
-4USB 2.0Ports
-1LANjack
-3flexibleaudiojacks
On-BoardPinheaders/Connectors
-2USB 2.0pinheaders
-1chassisintrusionconnector
-1frontaudiopinheader
-1Serialportpinheader
Slots
-1PCIslot,support 3.3V/ 5VPCI busInterface
FormFactor
-Mirco-ATX(19.5cmX17.0cm)
Mounting
-4mountingholes
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

MS-7314Mainboard
1-4
WindBoard
(MS-7314v1.X)Micro-ATXMainboard
MainboardLayout
PCI 1
JAUD1
ALC888
RTL8101E
Intel
ICH7
I
D
E
1
A
T
X
1
D
I
M
M
1
D
I
M
M
2
J
F
P
1
J
F
P
2
SYS_
F
A
N
2
JUSB2
JUSB1
JBAT1
SATA1
SATA2
J
C
I
1
J
P
W
1
JCOM
1
BATT
+
Top:LAN jack
Bottom:USBports
USBports
Top : mouse
Bottom:
keyboard
Top:
Parallel Port
Bottom:
COMport
VGAport
T:
M:
B:
Line-In
Line-Out
Mic
Intel
945GC
Intel
Diamondville
CPU
SYS_FAN1
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

1-5
GettingStarted
Packing Checklist
*Thepicturesareforreferenceonlyand mayvary fromthepackingcontentsof the
product youpurchased.
PowerCable
User’sGuide
andQuick Guide
MSImotherboard MSIDriver/UtilityCD
IDECable
BackIOShield
SATACable
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

2-1
HardwareSetup
HardwareSetup
Chapter2
Thischapterprovidesyouwiththeinformationabout
hardwaresetup procedures.Whiledoing theinstallation,
becarefulinholdingthe componentsandfollowthe
installationprocedures.Forsomecomponents, if you
install inthewrong orientation,thecomponentswill not
workproperly.
Useagrounded wriststrapbeforehandlingcomputer
components.Staticelectricitymaydamagethe
components.
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

MS-7314Mainboard
2-2
Quick ComponentsGuide
DDR2DIMMs,
p.2-3
ATX1,
p.2-7
SATA,
p.2-13
JUSB1~2,
p.2-16
JAUD1,
p.2-14 PCI,
p.2-18
BackPanel,
p.2-10
JPW1, p.2-7
SYS_FAN2,
p.2-13
IDE1,
p.2-12
JBAT1,
p.2-17
JCOM1,
p.2-14
JFP1,
p.2-15
JFP2,
p.2-15
JCI1,
p.2-15
SYS_FAN1,
p.2-13
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

2-3
HardwareSetup
Memory
TheseDIMM slotsareusedforinstalling memory modules.
Formoreinformationoncompatiblecomponents,pleasevisit http://global.msi.com.
tw/index.php?func=testreport
DDR2
240-pin,1.8V
64x2=128 pin56x2=112 pin
Installing MemoryModules
1.Thememory modulehasonlyone notchonthecenterandwill onlyfit intheright
orientation.
2.Insert thememorymoduleverticallyintotheDIMMslot.Thenpushit in until the
goldenfingeronthememory moduleisdeeplyinsertedintheDIMMslot. Theplastic
clipateachsideoftheDIMM slot will automaticallyclosewhenthememory module
isproperlyseated.
3.Manuallycheck if the memory modulehasbeenlockedin placebytheDIMM slot
clipsat the sides.
Important
Youcanbarelysee the golden fingerifthememory moduleisproperlyinserted
in theDIMMslot.
Volt Notch
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

MS-7314Mainboard
2-4
Important
-DDR2 memory modulesarenotinterchangeable withDDRand theDDR2
standardisnotbackwardscompatible.Youshouldalways installDDR2
memorymodulesintheDDR2DIMMslots.
-Toenablesuccessful systemboot-up,always insertthememory modules
intothe DIMM1first.
-Duetothe chipsetspecification,the mainboardwill onlysupportstoinstall one
double-side (2GBmax)memorymodule,ortoinstall twosingle-side memory
modules(1GBmaxperDIMM).
CompatibleDDR2 533 memorylist
Pleaserefertothefollowinglist tofindtheavailableDDR2memorymodules.
Vendor Model Size
HYNIX HYMP532U646-C4(HYNIXHY5PS121621 F-C4) 256MB
Kingston KVR533D2N4/256 (ELPIDA) 256MB
SEC M378T3253FG0-CD5DS(SECK4T56083F-GCD5) 256MB
SEC M378T3253FG0-CD5(SECK4T56083QF-GCD5) 256MB
Aeneon AET660UD00-370A98X 512MB
AENEON AET660UD00-370B97X(AENEONAET93R370B) 512MB
Elixir M2U51264TU88A2B-37B(ElixirN2TU51280AE-37B) 512MB
Hynix HYMP564U64P8-C4(HynixHY5PS12821FP-C4) 512MB
Kingmax KLBC28F-A8KB4[EGES](KingmaxKKEA88B4IAUG-37DA) 512MB
Micron MT4HTF6464AY-53EE1(MicronD9HNV) 512MB
UMAX 53014051-7100(UMAXU2S12D30TP-5C) 512MB
Aeneon AET760UD00-370A98X(AeneonAET93F370A) 1GB
AENEON AET760UD00-370B97X(AENEONAET93R370B) 1GB
KINGSTON KVR533D2N4/1G (HynixHY5PS12821CFP-Y5) 1GB
Micron MT8HTF12864AY-53EA1(MicronD9DMT) 1GB
Micron
MT8HTF12864AY-53EE1(MicronD9HNH)
1GB
TakeMS TMS1GB264C081-534AP(TakeMSMS18T51280-3.7) 1GB
UMAX 53016033-7100(UMAXU2S12D30TP-5C) 1GB
KINGSTON KVR533D2N4/2G (ELPIDAE1108AB-6E-E) 2GB
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

2-5
HardwareSetup
CompatibleDDR2 667 memorylist
Pleaserefertothefollowinglist tofindtheavailableDDR2memorymodules.
Vendor Model Size
Micron MT4HTF3264AY-667D3(MICROND9GMG) 256MB
SEC M378T3253FZ3-CE6(SECK4T56083QF-ZCE6) 256MB
ADATA ADQPE1908 (ADATAAD29608A8A-3EG) 512MB
AENEON AET660UD00-30DB97X(AENEONAET93R30DB) 512MB
Apacer 78.91G92.9K5(ApacerAM4B5708JQJS7E) 512MB
Geil GX21GB5300LDC 512MB
HYNIX HYMP564U64CP8-Y5(HYNIXHY5PS12821CFP-Y5) 512MB
KINGMAXKLCC28F-A8KB5[FGES](KINGMAXKKEA88B4LAUG-29DX) 512MB
KINGMAX KLCC28F-A8KI5[EGES] (KINGMAXKKA8FEIBF-HJK-30A) 512MB
Micron MT4HTF6464AY-667E1(MicronD9HNZ) 512MB
Nanya
NT512T64U88B0BY-3C(NanyaNT5TU64M8BE-3C)
512MB
OCI 04751208CX5S1G (Infinity64M8PC5300) 512MB
OCZ OCZ2667512 (OCZX42P120840G-3) 512MB
ProMOS V916764K24QBFW-F5(ProMOSV59C1512804QBF3) 512MB
PSC
AL6E8E63B-6EA1T(PSCA3R12E3GEF-G6EA)
512MB
Qimonda HYS64T6400EU-3S-B2(QimondaHYB18T512800B2F3S) 512MB
SEC
M378T6553CZ3-CE6(SECK4T51083QC-ZCE6)
512MB
ADATA ADQPE1A16 (ADATAAD29608A8A-3EG) 1GB
AENEON AET760UD00-30DB97X(AENEONAET93R30DB) 1GB
Apacer 78.01G9O.9K5(ApacerAM4B5808CQJS7E) 1GB
Bufaullo
D2U667C-1GMDJ(MicronD9GNH)
1GB
CORSAIR VALUESELECTVS1GB667D2(CORSAIR64M8CFEG) 1GB
Crucial BL12864AA663.16FD4 1GB
Geil
GX22GB5300LDC
1GB
HYNIX HYMP112U64CP8-Y5(HYNIXHY5PS1G831CFP-Y5) 1GB
HYNIX HYMP512U64CP8-Y5(HYNIXHY5PA12821CFP-Y5) 1GB
KINGBOX UP1GD2667PS(KINGBOXULD264082200P-4) 1GB
KINGMAX
KLCD48F-A8KB5[FHES] (KINGMAXKKEA88B4LAUG-29DX)
1GB
KINGMAX KLCD48F-A8KI5[EHES] (KINGMAXKKA8FEIBF-HJK-30A) 1GB
KINGSTON KVR667D2N5/1G(HYNIXHY5PS12821CFP-Y5) 1GB
Micron
MT8HTF12864AY-667E1(MICROND9HNL)
1GB
NANYA NT1GT64U88B0JY-3C(NANYANT5TU128M8BJ-3C) 1GB
OCI 04701G16CX5S1G (Infinity64M8PC5300) 1GB
ProMOS V916765K24QBFW-F5(ProMOSV59C1512804QBF3) 1GB
PSC
AL7E8E63B-6EA1T(PSCA3R12E3GEF-G6EA)
1GB
Qimonda HYS64T128020EU-3S-B2(QimondaHYB18T512800B2F3S) 1GB
SEC M378T2863DZS-CE6(SECK4T1G084QD-ZCE6) 1GB
SEC
M378T2953CZ3-CE6(SECK4T51083QC-ZCE6)
1GB
Supertalent T667UB1GC(SECK4T51083QE-ZCE6) 1GB
TakeMS TMS1GB264C081-665QI (TakeMSMS18T51280-3) 1GB
UMAX D46701GP3-63BJU(UMAXU2S12D30TP-6E) 1GB
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

MS-7314Mainboard
2-6
Vendor Model Size
AENEON AET860UD00-30DB08X(AENEONAET03F30DB) 2GB
Apacer 78.A1G9O.9K4(ApacerAM4B5808CQJS7E) 2GB
BuffaloSelect D2U667C-2GMEJ(Micron D9HNL) 2GB
CORSAIR VALUESELECTVS2GB667D2(MicroD9HNL) 2GB
Crucial CT25664AA667.16FA(MicronD9FTB) 2GB
HYNIX HYMP125U64CP8-Y5(HYNIXHY5PS1G831CFP-Y5) 2GB
Micron MT16HTF25664AY-667E1(MicronD9HNL) 2GB
NANYA NT2GT64U8HB0JY-3C(NANYANT5TU128M8BJ-3C) 2GB
Qimonda HYS64T256020EU-3S-B(QimondaHYB18T1G800BF-3S) 2GB
Qimonda
HYS64T256020EU-3S-C2(QimondaHYB18T1G800C2F-3S)
2GB
Supertalent T667UB2G/S(SECK4T1G084QD-ZCE6) 2GB
TakeMS TMS2GB264D081-665UY(ELPIDAE1108AB-6E-E) 2GB
UMAX D46702GP0-73BCU (UMAXU2S24D30TP-6E) 2GB
Hynix HYMP564U72CP8-Y5(HynixHY5PS12821CFP-Y5)ECC 512MB/ECC
Hynix HYMP512U72CP8-Y5(HynixHY5PS12821CFP-Y5)ECC 1GB/ ECC
Kingston KVR667D2E5/1G (HynixHY5PS12821BFP-Y5)ECC 1GB/ ECC
Important
1.Formoreinformation oncompatible components,pleasevisithttp://global.
msi.com.tw/index.php?func=testreport.
2.Due tothe CPUlimitation, theinstalled 667 MHzmemorywillbedroppedto
533MHzforsystemstability.
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

2-7
HardwareSetup
Power Supply
ATX20-Pin Power Connector:ATX1
Thisconnectorallowsyoutoconnect toanATXpowersupply.Toconnect totheATX
powersupply,makesurethe plugofthe powersupplyisinserted in the proper
orientationand thepinsarealigned.Then pushdownthepowersupplyfirmlyintothe
connector.
ATX4-pinPower Connector:JPW1
Thispowerconnectorisusedtoprovidepowertothe CPU.
PIN SIGNAL
1GND
2 GND
312V
4 12V
PinDefinition
JPW1
PIN SIGNAL
11 3.3V
12 -12V
13 GND
14 PS_ON
15 GND
16 GND
17 GND
18 -5V
19 5V
20 5V
PIN SIGNAL
1 3.3V
2 3.3V
3GND
45V
5GND
65V
7GND
8PW_OK
9 5V_SB
10 12V
ATX1PinDefinition
ATX1
10
1
20
11
1
34
2
Important
Makesurethat all the connectorsareconnected toproperATXpowersupplies
toensurestable operation ofthemainboard.
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com
