MSI MS-9641 User manual

i
MS-9641(V1.X)Mainboard
G52-96411x1
9641v1.0-0-Preface.P65 2006/4/28, 午 05:521

ii
CopyrightNotice
The materialinthisdocumentistheintellectual propertyof MICRO-STAR
INTERNATIONAL.Wetakeeverycareinthe preparationof thisdocument, butno
guaranteeisgivenastothecorrectnessofitscontents.Ourproductsareunder
continualimprovementand wereservetherighttomakechangeswithoutnotice.
Trademarks
Alltrademarksarethepropertiesoftheirrespectiveowners.
NVIDIA,theNVIDIAlogo,DualNet, and nForceareregisteredtrademarksortrade-
marksofNVIDIACorporationin theUnitedStatesand/orothercountries.
AMD,Athlon ,Athlon XP,Thoroughbred ,andDuron areregisteredtrade-
marksofAMDCorporation.
Intel®andPentium®areregisteredtrademarksofIntelCorporation.
PS/2and OS®/2areregisteredtrademarksofInternationalBusiness Machines
Corporation.
Windows®95/98/2000/NT/XPareregisteredtrademarksofMicrosoftCorporation.
Netware®isaregisteredtrademarkofNovell,Inc.
Award®isaregisteredtrademarkofPhoenixTechnologiesLtd.
AMI®isaregisteredtrademarkofAmericanMegatrendsInc.
RevisionHistory
Revision RevisionHistory Date
V1.0 FirstreleaseforPCB1.X May2006
withIntel 945GM&ICH7R
TechnicalSupport
Ifaproblemariseswithyoursystemandnosolutioncanbeobtainedfromtheuser’s
manual,pleasecontactyourplaceofpurchaseorlocaldistributor.Alternatively,
pleasetrythefollowing helpresourcesforfurtherguidance.
Visit theMSI websiteforFAQ,technical guide,BIOSupdates,driverupdates,
andotherinformation: http://www.msi.com.tw/program/service/faq/
faq/esc_faq_list.php
Contactourtechnical staff at: http://support.msi.com.tw
9641v1.0-0-Preface.P65 2006/4/28, 午 05:522

iii
SafetyInstructions
CAUTION: Dangerofexplosionifbatteryisincorrectlyreplaced.
Replaceonlywiththe sameorequivalenttype recommendedbythe
manufacturer.
1. Alwaysread thesafetyinstructionscarefully.
2. KeepthisUser’sManualforfuturereference.
3. Keepthisequipmentawayfromhumidity.
4. Laythisequipmentonareliableflatsurfacebeforesetting itup.
5. Theopeningsontheenclosureareforairconvectionhenceprotectstheequip-
ment fromoverheating.DONOTCOVERTHEOPENINGS.
6. Makesurethevoltageofthe powersourceandadjustproperly110/220Vbe-
foreconnectingtheequipmenttothepowerinlet.
7. Placethe powercordsuchawaythatpeoplecannotstepon it. Donotplace
anythingoverthepowercord.
8. AlwaysUnplug thePowerCordbeforeinsertinganyadd-oncardormodule.
9. All cautionsand warningsontheequipmentshouldbenoted.
10. Neverpouranyliquidintotheopeningthatcoulddamage orcauseelectrical
shock.
11. If anyof thefollowing situationsarises, gettheequipmentcheckedbyaservice
personnel:
†Thepowercordorplugisdamaged.
†Liquid haspenetratedintotheequipment.
†Theequipmenthasbeen exposedtomoisture.
†Theequipmenthasnotworkwelloryoucannotgetitworkaccording to
User’sManual.
†Theequipmenthasdroppedand damaged.
†Theequipmenthasobvioussign of breakage.
12.DONOTLEAVETHISEQUIPMENTINANENVIRONMENTUNCONDITIONED,STOR-
AGETEMPERATUREABOVE600C(1400F),IT MAYDAMAGETHEEQUIPMENT.
9641v1.0-0-Preface.P65 2006/4/28, 午 05:523

iv
FCC-BRadio Frequency Interference Statement
Thisequipmenthasbeen
tested and found tocomply
withthe limitsforaClassB
digitaldevice,pursuanttoPart
15of the FCCRules.Theselimitsaredesignedtoprovidereasonable protection
againstharmful interferenceinaresidentialinstallation.Thisequipmentgenerates,
usesand canradiateradiofrequencyenergyand,ifnotinstalledand used in accor-
dancewiththeinstructions,maycauseharmful interferencetoradiocommunications.
However,thereisno guarantee thatinterferencewill notoccurin aparticular
installation.Ifthisequipmentdoescauseharmful interferencetoradioortelevision
reception,whichcanbedeterminedbyturning theequipmentoff and on,the useris
encouragedtotrytocorrecttheinterferencebyone ormoreof themeasureslisted
below.
†Reorientorrelocatethereceiving antenna.
†Increasetheseparationbetweentheequipmentand receiver.
†Connecttheequipmentintoanoutleton acircuitdifferentfromthatto
whichthereceiverisconnected.
†Consultthedealeroranexperiencedradio/televisiontechnicianforhelp.
Notice1
Thechangesormodificationsnotexpresslyapprovedbythepartyresponsible for
compliancecould void theuser’sauthoritytooperatetheequipment.
Notice2
Shieldedinterfacecablesand A.C.powercord,ifany,mustbeusedinorderto
complywiththeemissionlimits.
VOIRLANOTICED’INSTALLATIONAVANTDERACCORDERAURESEAU.
Micro-StarInternational
MS-9641
ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothe
followingtwoconditions:
(1)thisdevicemaynotcauseharmfulinterference,and
(2)thisdevicemustaccept anyinterferencereceived,includinginterferencethat
maycauseundesiredoperation.
9641v1.0-0-Preface.P65 2006/4/28, 午 05:524

v
WEEE (WasteElectricaland ElectronicEquipment) Statement
9641v1.0-0-Preface.P65 2006/4/28, 午 05:525

vi
9641v1.0-0-Preface.P65 2006/4/28, 午 05:526

vii
9641v1.0-0-Preface.P65 2006/4/28, 午 05:527

viii
CONTENTS
FCC-B RadioFrequencyInterferenceStatement..........................................................ii
CopyrightNotice..............................................................................................................iii
TechnicalSupport..........................................................................................................iv
SafetyInstructions.........................................................................................................iv
WEEEStatement..............................................................................................................v
Chapter1.GettingStarted....................................................................................1-1
MainboardSpecifications...................................................................................1-2
MainboardLayout................................................................................................1-4
Chapter2.HardwareSetup..................................................................................2-1
Quick ComponentsGuide....................................................................................2-2
CPU(CentralProcessingUnit)............................................................................2-3
CPU&CoolerSetInstallation......................................................................2-4
Memory.................................................................................................................2-6
IntroductiontoDDRIISDRAM......................................................................2-6
DIMMModuleCombination...........................................................................2-6
InstallingDDRII Modules...............................................................................2-7
PowerSupply......................................................................................................2-8
ATX24-PinPowerConnector:ATX1.........................................................2-8
ATX12VPowerConnector:JPW0............................................................2-8
ImportantNotificationaboutPowerIssue..................................................2-9
BackPanel..........................................................................................................2-10
Connectors........................................................................................................2-12
HardDisk Connector: IDEB0.....................................................................2-12
ChassisIntrusionSwitchConnector:JCI1..............................................2-12
CompactFlashCardSlot:CF0..................................................................2-12
Serial ATAII Connectors:SATA1~SATA4.................................................2-13
FanPowerConnectors:CPUFAN0,SYSFAN1,PWRFAN0.....................2-14
FrontPanelConnectors:JFP1..................................................................2-14
FrontUSBConnectors:F_USB2..............................................................2-15
FWH/LPCDebugging Pin Header:JLPC1.................................................2-16
SerialPortConnector:COM0....................................................................2-16
PowerSelect: J5.......................................................................................2-16
TV-OutConnector:JTV0...........................................................................2-17
I2CBusConnector:SM_BUS...................................................................2-18
LAN_LED....................................................................................................2-18
LAN_BYPASSLED:J3.............................................................................2-18
Jumpers..............................................................................................................2-23
9641v1.0-0-Preface.P65 2006/4/28, 午 05:528

ix
ClearCMOSJumper: CLR_CMOS0..........................................................2-23
JCF_SEL&JCFV_SEL..............................................................................2-24
Slots....................................................................................................................2-25
Golden Finger.............................................................................................2-25
PCI(PeripheralComponent Interconnect)Slots......................................2-27
9641v1.0-0-Preface.P65 2006/4/28, 午 05:529

1-1
Getting Started
Getting Started
Chapter1
Thankyouforchoosing theMS-9641 v1.xMicro-ATX
mainboard.Themainboardisbasedon Intel 945GM
and Intel ICH7R chipset foroptimal systemefficiency.
Designedtofittheadvanced Intel CoreDuo/Core
Solo Series processor,themainboarddeliversahigh
performanceandprofessionaldesktopplatformsolution.

MS-9641Mainboard
1-2
ProcessorSupport
-Intel CoreDuo/CoreSoloSeriesprocessorsinthe478 Micro
FC-PGApackage.
-Supports3/4pinCPUFanPin-HeaderwithFanSpeedControl.
-SupportsIntelCoreDuoTechnology.
SupportedFSB
-533/667MHz
Chipset
-NorthBridge:Intel 945GMchipset
-SouthBridge: Intel ICH7Rchipset
MemorySupport
-DDRII 533/667SDRAM(2GBMax)
-2DDRIIDIMMs(240pin/1.8V)
LAN
-Supports6PCI ExpresssGBLanbyIntel82573L
-SupportsEthernetbypassfunctionwithProgramming Relay(4ports)
IDE
-1IDEportbyICH7R(44-pinconnector)
-SupportsUltraDMA66/100mode
SATA
-4SATAIIportsbyICH7R
-SupportsfourSATAII devices
-Supportsstorageanddatatransfersatup to300MB/s
CF
-Supports1CompactFlashconnector
MainboardSpecifications
Connectors
Backpannel
-6xRJ45 GigabitLANports
-2USB2.0ports
-1serialport
On-BoardPinheaders
-1COM0pinheader
-1USB 2.0pinheader
Slots
-1PCI slot
FormFactor
-Micro-ATX (24.3cmX22.7cm)

1-3
Getting Started
Mounting
-8mounting holes
Accessory
-CPURetentionModule
-CPUCooler

MS-9641Mainboard
1-4
MainboardLayout
MS-9641 Series v1.XMicro-ATXMainboard
PCI0
J3
CLR_CMOS0
JTV0
PCIEX4&PCIBuson Edge
J2
F_USB2
JCF_SEL
SATA2
SATA1
SATA3
JLPC1
JCFV_SEL
SATA4
MH4 IDEB0
CPUFAN0
JPW0
SYSFAN1
CPUKeepoutzone
AUXFAN0
ATX1
COM0
DIMM1
DIMM0
J0
Winbond
W83627EHG
JFP1
BATT
+
BIOS
COM1
JLAN5
JLAN4
JLAN3
JLAN2
JLAN1
JLAN0
JUSB0
JVGA0
Intel
945GM
Intel
ICH7R
LANLED
J5
SMBus

2-1
HardwareSetup
HardwareSetup
Chapter2
Thischapterprovidesyou withtheinformation about
hardwaresetupprocedures.Whiledoingthe installation,
becarefulinholdingthecomponentsandfollowthe
installationprocedures.Forsomecomponents,ifyou
install inthewrong orientation,thecomponentswillnot
workproperly.
Useagroundedwrist strapbeforehandlingcomputer
components.Staticelectricitymaydamagethe
components.

MS-9641Mainboard
2-2
Quick ComponentsGuide
CPU,
p.2-3
DIMM0/1,
p.2-6
AUXFAN0,
p.2-14
SM_BUS,
p.2-18
JPW0,
p.2-9
ATX1,p.2-8
BackPanel,
p.2-10
PCI0,
p.2-24
F_USB2,
p.2-15
JFP1,
p.2-14
SATA1~4,
p.2-13
IDEB0,
p.2-12
CLR_CMOS0,
p.2-20
JCOM0,
p.2-16 SYSFAN1,
p.2-14
CPUFAN0,
p.2-14
JLPC1,
p.2-16
CF0,p.2-12
JTV0,
p.2-17
J3,
p.2-18
LAN_LED,
p.2-18
J5,p.2-16
JCFV_SEL,
p.2-21
JCF_SEL,
p.2-21
GoldenFinger,
p.2-22

2-3
HardwareSetup
CPU(CentralProcessingUnit)
The mainboardsupports Intel CoreDuo/CoreSolo processorin the478
pinpackage.ThemainboardusesaCPUsocketcalledmPGA478foreasyCPU
installation. Whenyouareinstalling theCPU, make suretheCPUhas aheatsink
andacoolingfanattachedonthetoptopreventoverheating.
Important
1.OverheatingwillseriouslydamagetheCPUandsystem.Alwaysmake
surethecoolingfancanworkproperlytoprotecttheCPUfromoverheating.
2.Makesurethatyouapplyan evenlayerofheatsinkpaste(orthermal tape)
between theCPUand the heatsinktoenhanceheatdissipation.
3.Whilereplacing the CPU,always turnoff the ATXpowersupplyorunplug
thepowersupply spowercordfromthe grounded outletfirst toensurethe
safetyofCPU.

MS-9641Mainboard
2-4
5. Liftup theleversonbothsides.
1. LoosethescrewontheCPUsocketwithatankscrewdriverinclockwise
direction.
2. PlacetheCPUon top of thesocket.Makesuretoalign thegoldarrowonthe
CPUwiththearrowkeyonthesocket.
CPU&Cooler SetInstallation
4. Onthefront endoftheCPUsocket isa
lockingmechanismdesignedintothe
formofascrew.Makesurethatyou
actuateordeactuatethismechanism
withascrewdriverbeforeand after
installing the CPU. 3. Pushthe CPUdownuntilits
pinssecurelyfitintothe
socket.

2-5
HardwareSetup
5. Mountthe coolerset (fan&heatsink
bundled)on topoftheCPUandfit it
intotheretentionmechanism.
6. Securetheleverstolockthecooler
set.
7. Connectthe fan powercablefrom
themountedfantothe3-pin fan
powerconnectoron theboard.

MS-9641Mainboard
2-6
Themainboardprovides2slotsfor240-pin DDRIIDIMM,whichsupportsthe
memorysizeupto2GB.SinceDDRII modulesarenotinterchangeablewithDDR1and
theDDRIIstandardisnotbackwardcompatible,youshouldalwaysinstallDDRII
memorymodulein theDDRIIslot(DIMM0~DIMM1).Otherwise,you arenotabletoboot
up yoursystemand yourmainboardmightbe damaged.
DIMM1
DIMM0
Memory
IntroductiontoDDRII SDRAM
DDRIIisanewtechnologyof memorymodule,anditsspeed isthe toplimit of
currentDDR1technology.DDRII usesa1.8Vsupplyforcoreand I/Ovoltage,com-
paredto2.5VforDDR1,andrequires28%lesspowerthanDDR1chips.DDRIItruly
isthe futureof memory,butwillrequiresomechangesasthetechnologyisnot
backwardlycompatibleand onlymotherboardsspecificallydesigned forDDRIImemory
willbeabletosupportthesechips.
DDRIIincorporatesnewfeaturesatthe chiplevel that giveitbettersignal
integrity,therebyenabling higherclockspeeds.
DDRII moduleshave240 pins,versus184 pinsonaDDR1module,and the
lengthofDDRIImodule is5.25”.DDRIImoduleshavesmallerandtighterspaced pins.
The heightofDDRIImodulesvaries,buttheywill typicallybelessthan1.3”in height.
DIMM ModuleCombination
InstallatleastoneDIMM module ontheslots. EachDIMMslot supportsup toa
maximumsizeof1GB.Userscan install eithersingle-ordouble-sidedmodulesto
meettheirownneeds.Pleasenotethat eachDIMMcanworkrespectivelyfor
single-channelDDRII, buttherearesomeruleswhileusing dual-channel
DDRII. Usersmayinstall memorymodulesof differenttypeand densityondifferent-
channel DDR DIMMs.However,the samesize,typeand densitymemorymodules
arenecessarywhileusing dual-channelDDR, orinstabilitymayhappen. Pleaserefer
tothefollowingtablefordetailed dual-channelDDR.Othercombinationnotlisted
belowwill functionassingle-channel DDR.

2-7
HardwareSetup
Volt Notch
DIMM1
(Bank2&3) S/D128MB~1GB
MaximumSystem MemorySupported128MB~2GB
DIMM0
(Bank0&1) S/D128MB~1GB
S: SingleSide D:DoubleSide
SlotMemoryModuleTotalMemory
InstallingDDRII Modules
1. The DDRIIDIMMhasonlyonenotchonthe centerofmodule.The Module will
onlyfitin therightorientation.
2. Insertthe DIMMmemorymoduleverticallyintotheDIMMslot.Thenpushitin
until thegoldenfingeronthememorymodule isdeeplyinsertedinthesocket.
3. Theplasticclip ateachsideof theDIMM slotwill automaticallyclose.
Important
Youcanbarelysee the goldenfingerifthe moduleisproperlyinsertedinthe
socket.
