MULTIQUIP GLOBUG Series Guide

OPERATION AND PARTS MANUAL
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
GLOBUG SERIES
MODEL GBC
SERIAL NO. G2300001 AND ABOVE
CART TYPE LIGHTING SYSTEM
Revision #2 (10/07/19)
Go to Discount-Equipment.com to order your parts

Discount-Equipment.com is your online resource for quality parts & equipment.
Florida: 561-964-4949 Outside Florida TOLL FREE: 877-690-3101
Need parts?
Click on this link: http://www.discount-equipment.com/category/5443-parts/ and
choose one of the options to help get the right parts and equipment you are looking
for. Please have the machine model and serial number available in order to help us
get you the correct parts. If you don’t find the part on the website or on one of the
online manuals, please fill out the request form and one of our experienced staff
members will get back to you with a quote for the right part that your machine needs.
We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman,
Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto,
Power Blanket, Nifty Lift, Atlas Copco, Chicago Pneumatic, Allmand, Miller Curber, Skyjack,
Lull, Skytrak, Tsurumi, Husquvarna Target, Stow, Wacker, Sakai, Mi-T-M, Sullair, Basic,
Dynapac, MBW, Weber, Bartell, Bennar Newman, Haulotte, Ditch Runner, Menegotti,
Morrison, Contec, Buddy, Crown, Edco, Wyco, Bomag, Laymor, EZ Trench, Bil-Jax, F.S.
Curtis, Gehl Pavers, Heli, Honda, ICS/PowerGrit, IHI, Partner, Imer, Clipper, MMD, Koshin,
Rice, CH&E, General Equipment ,Amida, Coleman, NAC, Gradall, Square Shooter, Kent,
Stanley, Tamco, Toku, Hatz, Kohler, Robin, Wisconsin, Northrock, Oztec, Toker TK, Rol-Air,
APT, Wylie, Ingersoll Rand / Doosan, Innovatech, Con X, Ammann, Mecalac, Makinex, Smith
Surface Prep,Small Line, Wanco, Yanmar

GBC LIGHTING SYSTEM • OPERATION AND PARTS MANUAL —REV. #2 (10/07/19) — PAGE 3
FUEL CHEMICAL WARNING
Gasoline engine exhaust and some of
its constituents are known to cause
cancer,birth defects and other
reproductive harm.
Go to Discount-Equipment.com to order your parts

PAGE 4 — GBC LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #2 (10/07/19)
TABLE OF CONTENTS
GBC Lighting System
Fuel Chemical Warning ........................................... 3
Table of Contents..................................................... 4
Safety Information ............................................... 5–9
Specifications ........................................................ 10
Dimensions............................................................ 11
Footcandle Plot...................................................... 12
General Information............................................... 13
Components .................................................... 14–15
Setup ............................................................... 16–17
Operation......................................................... 18–21
Maintenance.................................................... 22–27
Wiring Diagram...................................................... 28
Explanation of Code in Remarks Column.............. 30
Suggested Spare Parts ......................................... 31
Component Drawings
Nameplate and Decals .................................... 32–33
Balloon and Lamp Assembly........................... 34–35
Mast Assembly ................................................ 36–37
Base Assembly................................................ 38–39
Outrigger Assembly......................................... 40–41
NOTICE
Specifications and part numbers are subject to change
without notice.
Go to Discount-Equipment.com to order your parts

GBC LIGHTING SYSTEM • OPERATION AND PARTS MANUAL —REV. #2 (10/07/19) — PAGE 5
SAFETY INFORMATION
Do not operate or service the equipment before reading
the entire manual. Safety precautions should be followed
at all times when operating this equipment.
Failure to read and understand the safety
messages and operating instructions could
result in injury to yourself and others.
SAFETY MESSAGES
The four safety messages shown below will inform you
about potential hazards that could injure you or others.The
safety messages specifically address the level of exposure
to the operator and are preceded by one of four words:
DANGER, WARNING, CAUTION
or NOTICE.
SAFETY SYMBOLS
DANGER
Indicates a hazardous situation which, if not avoided,
WILL result in DEATH or SERIOUS INJURY.
WARNING
Indicates a hazardous situation which, if not avoided,
COULD result in DEATH or SERIOUS INJURY.
CAUTION
Indicates a hazardous situation which, if not avoided,
COULD result in MINOR or MODERATE INJURY.
NOTICE
Addresses practices not related to personal injury.
Potential hazards associated with the operation of this
equipment will be referenced with hazard symbols which
may appear throughout this manual in conjunction with
safety messages.
Go to Discount-Equipment.com to order your parts

PAGE 6 — GBC LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #2 (10/07/19)
SAFETY INFORMATION
GENERAL SAFETY
CAUTION

NEVER operate this equipment without proper protective
clothing, shatterproof glasses, respiratory protection,
hearing protection, steel-toed boots and other protective
devices required by the job or city and state regulations.

NEVER operate this equipment when not
feeling well due to fatigue, illness or when
under medication.

NEVER operate this equipment under the influence of
drugs or alcohol.

ALWAYS check the equipment for loosened threads or
bolts before starting.

DO NOT use the equipment for any purpose other than
its intended purposes or applications.
NOTICE

This equipment should only be operated by trained and
qualified personnel 18 years of age and older.

Whenever necessary, replace nameplate, operation and
safety decals when they become difficult read.

Manufacturer does not assume responsibility for any
accident due to equipment modifications. Unauthorized
equipment modification will void all warranties.
NEVER
use accessories or attachments that are not
recommended by Multiquip for this equipment. Damage
to the equipment and/or injury to user may result.
ALWAYS know the location of the nearest
fire extinguisher.
ALWAYS know the location of the nearest
first aid kit.
ALWAYS know the location of the nearest phone or
keep
a phone on the job site.
Also, know the phone numbers
of the nearest ambulance, doctor and
fire department.
This information will be invaluable in the case of an
emergency.
Go to Discount-Equipment.com to order your parts

GBC LIGHTING SYSTEM • OPERATION AND PARTS MANUAL —REV. #2 (10/07/19) — PAGE 7
SAFETY INFORMATION
LIGHTING SYSTEM SAFETY
WARNING

NEVER disconnect any emergency or safety devices.
These devices are intended for operator safety.
Disconnection of these devices can cause severe injury,
bodily harm or even death. Disconnection of any of
these devices will void all warranties.
CAUTION

NEVER attempt service on a running machine.
NOTICE

To prevent the lighting system from overturning, NEVER
use in winds that exceed 22 mph (10 m/s).

The lighting system should only be used in temperatures
between 23° to 104°F (-5° to 40° C). Failure to comply
with these operating parameters could cause the lamp
to malfunction and shorten the ballast life.

ALWAYS keep the lighting system in proper running
condition.

Fix damage to lighting system and replace any broken
parts immediately.

ALWAYS store equipment properly when it is not being
used. Equipment should be stored in a clean, dry location
out of the reach of children and unauthorized personnel.
LAMP SAFETY
WARNING
NEVER
attempt to replace lamp with the power on.
Always unplug the power cord from the generator or
power source when changing the lamp.
ALWAYS allow a sufficient amount of time for the lamp to
cool
before changing. The possibility exists of severe burns.
CAUTION
NEVER
use force when installing the lamp.Excessive force
could cause the lamp to break, causing bodily harm.
NOTICE
NEVER
leave any grease or oil residue on lamp surface
when replacing or removing lamp. This can create hot
spots, reducing the service life of the lamp.
ALWAYS make sure lamp surface is clean and dry.
ALWAYS
replace with MQ recommended type lamp. See
parts section of this manual.
If applicable, ALWAYS
make sure the lamp guard is
installed correctly. NEVER deform the lamp guard.
NEVER
unplug the lamp’s AC power cable during
operation.
ALWAYS have a trained technician
to install and
remove lamp or replace any damaged fixture wiring.
Go to Discount-Equipment.com to order your parts

PAGE 8 — GBC LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #2 (10/07/19)
SAFETY INFORMATION
BALLOON SAFETY
WARNING

To prevent serious burns, NEVER touch
or unzip the balloon envelope when the
lamp is on.
CAUTION

ALWAYS keep the balloon away from sharp objects and
excessive amounts of heat.
NOTICE

To prevent balloon deformation, NEVER use lighting
system in strong winds.

DO NOT place the balloon inside its protective cover
until the lamp has had a sufficient amount of time to cool
down. This will prevent the balloon’s nylon cover from
being burned (touching the lamp surface).

ALWAYS place the balloon inside its protective cover
after each use. This will prolong the life of the balloon
material, keeping it protected from harsh environmental
elements.

Replace balloon immediately if damaged. A damaged
balloon will not inflate properly, and may become more
damaged by touching the hot lamp surface.

DO NOT use excessive force when zipping and unzipping
the balloon. Be gentle with the zipper mechanism. If the
zipper is broken, the balloon will become unusable.
GENERATOR SAFETY
If using a generator to power lighting system,
refer to applicable generator manual safety
information section.
ELECTRICAL SAFETY
DANGER

Lighting system is equipped with a ground pin on the
power plug. For your protection, ALWAYS
complete the
grounding path. NEVER
insert the AC power plug into a
2-prong receptacle to operate lighting system.
When applying power to the lighting system,
ALWAYS
connect the AC power plug to a 3-prong receptacle that
is grounded. The possibility exists of
electrical shock,
electrocution and even death
if the lighting system is
not grounded.
NEVER operate lighting system or
handle any electrical equipment while
standing in water, while barefoot, while
hands are wet or in the rain.A dangerous
electrical shock could occur, causing
severe bodily harm or even death.
ALWAYS make sure the area above
the lighting system is open and clear
of overhead power lines and other
obstructions. Contact with overhead
power lines or other obstructions could
result in equipment damage, electrical
shock, electrocution and even death.
Power Cord/Cable Safety
DANGER
NEVER let power cords or cables lay in water.
NEVER use damaged or worn
cables or cords. Inspect
for cuts in the insulation
NEVER grab or touch a live power
cord or cable with wet hands. The
possibility exists of electrical shock,
electrocution or death.

Make sure power cables are securely connected.
Incorrect connections may cause electrical shock
and
damage to the lighting system.
NOTICE
ALWAYS
make certain that proper power or extension
cord has been selected for the job. See Cable Selection
Chart in this manual.
Go to Discount-Equipment.com to order your parts

GBC LIGHTING SYSTEM • OPERATION AND PARTS MANUAL —REV. #2 (10/07/19) — PAGE 9
SAFETY INFORMATION
LOADING AND UNLOADING
Cart Type - With Lifiting Hook
If lighting system is equipped with a transport lifting hook,
refer to the following safety information.
CAUTION

Before lifting, make sure that lighting system parts are
not damaged and screws are not loosened or lost.

ALWAYS make sure crane or lifting device has been
properly secured to lifting hook of the equipment.

NEVER lift the equipment while lighting system is
running.

Make sure the mast is completely lowered before lifting
the lighting system.

Use adequate lifting cable (wire or rope) of sufficient
strength.

Use one point suspension hook and lift straight upwards.

Never allow any person or animal to stand underneath the
equipment while lifting.

DO NOT lift machine to unnecessary heights.
ACCIRCUIT
BREAKER
120/240V
30A
120V
30A 20A
20A
0N
OFF
IDLE
CONTROL
OPERATION
SWITCH
ON
OFF
FULLPOWER
SWITCH
120V
120V/240V
120
V
OFF
21A
LIFTING
HANGER
LIFTING
SCHACKLE
GENERATOR
LIFTING BALE
FORK LIFT
ALIGNMENT
ARROWS
(4 PLACES)
LIFTING
HOOK
Cart Type - No Lifiting Hook
If lighting system is not equipped with a transport lifting
hook and the mast is removable, refer to the following
safety information.

Before lifting, make sure that the mast and lamp are
removed as described in the manual.

The cart can be safely lifted by two persons to the
transport vehicle.
TRANSPORTING SAFETY
NOTICE

When transporting the lighting system, if applicable,
always place in stow position
and place mast in its
carrying case.
ALWAYS
remove balloon/lamp assembly from the mast
when transporting lighting system. This will prevent
damage to the bulb due to vibration.
NEVER
leave the balloon/lamp exposed during transport.
Exposure to excess wind or rain could damage the
balloon’s nylon cover.
ALWAYS
place balloon inside its protective cover during
transport. Be sure the cover is secured tightly around the
balloon/lamp assembly.
Go to Discount-Equipment.com to order your parts

PAGE 10 — GBC LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #2 (10/07/19)
SPECIFICATIONS
Table 1. Specifications
Model GBC
Input Voltage 90-130, 170-240 VAC
Max. Current 9.3 A @ 120 V
Frequency 50-60 Hz Single-Phase
Lamp Type 1,000 Watt Metal Halide
Total Luminous Flux 99,750 lm
Standard Balloon Diameter 47.2 in (1200 mm)
Light Coverage (360°) 150 ft (45.7 meters)
Lamp Surface Temperature (Longitudinal) 476.6° F (247° C) max
Lamp Surface Temperature (Transversal) 417.2° F (214° C) max
Balloon Dimensions (L x W x H) 47.2 x 47.2 x 28.3 in.
(1200 x 1200 x 720 mm)
Balloon Material Polyester
Balloon Heat-Resisting Temperature 320-356° F (160-180° C)
Internal Balloon Temperature 126° F (52° C)
Balloon Water Resistance 1,500 mm H
2
O
Fan Motor Voltage 24 VDC
Fan Motor Current 1.2 A
Fan Motor Pressure 0.324 kPA (0.047 psi)
Outriggers 3
Mast - Number of Stages 3 (air shock absorbers)
Dimensions (L x W x H)
Upper Working Position
51.2 x 52.2 x 73.6 to 126 in
(1,300 x 1,325 x 1,870 to 3,200 mm)
Dimensions (L x W x H)
Storage
27.6 x 40 x 47.7 in
(700 x 1,023 x 1,212 mm)
Weight 133.4 lb (49.8 kg)
Appropriate Generator 1700 Watts
Go to Discount-Equipment.com to order your parts

GBC LIGHTING SYSTEM • OPERATION AND PARTS MANUAL —REV. #2 (10/07/19) — PAGE 11
DIMENSIONS
A
C
G
D
E
F
B
Table 2. Dimensions
Reference Letter Description Dimension inches (mm)
ACart Width 27.6 (700)
B Cart Length 40.3 (1,023)
C Total Max. Height (with Standard Balloon) 127.3 (3,200)
D Standard Balloon Height 25.6 (650)
E Mast Height (without Balloon) 100.1 (2,543)
F Cart Height 12.2 (310)
G Standard Balloon Diameter 47.2 (1,200)
Figure 1. GBC Dimensions
Go to Discount-Equipment.com to order your parts

PAGE 12 — GBC LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #2 (10/07/19)
FOOTCANDLE PLOT
10
5
2
1
.5
.25
VALUES LISTED AS FOOTCANDLES SCALE: 1GRID=50FT. (15.24 METERS)
Figure 2. Illumination Range
Go to Discount-Equipment.com to order your parts

GBC LIGHTING SYSTEM • OPERATION AND PARTS MANUAL —REV. #2 (10/07/19) — PAGE 13
GENERAL INFORMATION
The Multiquip GBC Lighting System is a general purpose
floodlight tower intended for emergency and remote lighting
needs. It is universally adaptable to all AC power supplies
and accepts 50/60 Hz, 100-240 V.
The GBC uses a single 1,000 watt lamp with pure white
light for maximum illumination with a light coverage of up
to 150 feet. The standard balloon (GBP) that comes with
the GBC provides 360° glarefree illumination. The balloon
is self-inflating and easy to install and inflate in less than
20 seconds.
The GBC has a three-stage mast that extends to a height
of up to 12 feet. It has a steerable cart design for easy
transportation. Three outriggers on the cart ensures great
stabilization.
The GBC can be powered by a variety of Multiquip's series
generators with an output power of 1.7 kW or greater.
If an extension cord is necessary to connect to a power
source, refer to Table 3 to select the proper length.
Table 3. Extension Cord Gauge Selection
Ampere
Rating
Range
Volts Length of Cord in Feet
115V 25 Ft. 50 Ft. 100 Ft. 150 Ft. 200 Ft. 250 Ft. 300 Ft. 400 Ft. 500 Ft.
230V 50 Ft. 100 Ft. 200 Ft. 300 Ft. 400 Ft. 500 Ft. 600 Ft. 800 Ft. 1000 Ft.
0 - 2 18 18 18 16 16 14 14 12 12
2 - 3 18 18 16 14 14 12 12 10 10
3 - 4 18 18 16 14 12 12 10 10 8
4 - 5 18 18 14 12 12 10 10 8 8
5 - 6 18 16 14 12 10 10 8 8 6
6 - 8 18 16 12 10 10 8 6 6 6
8 - 10 18 14 12 10 8 8 6 6 4
10 - 12 16 14 10 8 8 6 6 4 4
12 - 14 16 12 10 8 6 6 6 4 2
14 - 16 16 12 10 8 6 6 4 4 2
16 - 18 14 12 8 8 6 4 422
18 - 20 14 12 8 6 6 4 4 2 2
Go to Discount-Equipment.com to order your parts

PAGE 14 — GBC LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #2 (10/07/19)
COMPONENTS
19
21
22
23
20
14
15
16
17
18 1
2
3
4
5
6
7
8
9
11
10
12
13
Figure 3. GBC Components
Go to Discount-Equipment.com to order your parts

GBC LIGHTING SYSTEM • OPERATION AND PARTS MANUAL —REV. #2 (10/07/19) — PAGE 15
COMPONENTS
Figure 3 shows the location of the controls and components
for the GBC Lighting System.The functions of each control
is described below:
1. Balloon Cover — Stores balloon when GBC is not in
use. Allow a sufficient amount of time for the lamp to
cool down before storing balloon. Possibility exists of
balloon getting burned.
2. Balloon — Made of heat resistant polyester, with a
diameter of 47.2 inches (1,200 mm). Balloon is self-
inflating and inflates in less than 20 seconds.
3. Velcro — Used to easily attach optional message strip
to the balloon.
4. Buckle — Used to hold the balloon together when
storing inside the cover.
5. AC Power Cable — Connects to the AC power source.
6. Cart — Holds the generator and can be steered easily
to transport GBC to different locations.
7. Locking Clamps — To secure the generator to the
cart platform, place clamps around the pipe frame of
the generator. Tighten securely to prevent movement.
8. Tire — The GBC uses four pneumatic tires for easy
maneuverability.
9. Brake Pad — When the brake pedal is pressed, this
pad will strike and hold the rear tires in place.
10. Strap Slots — Allows suitcase generators to be
strapped to cart securely.
11. Outriggers — Provides stability to the GBC. When
raising the mast, outriggers should always be deployed.
12. Counter Weight — Locks the outriggers in place when
they are deployed or stowed.
13. Brake Pedal — Step on this pedal and pull back
T-handle to apply the brakes. To release the brakes,
press down and hold brake pedal again then release.
14. T-Handle — Moves the GBC in either forward or
reverse direction by pulling back or pushing forward.
The T-handle also allows the cart to be steered left or
right.
15. Mast — This mast is comprised of three separate
stages. The mast can be raised in excess of 8 feet
(without balloon).
16. Mast Bolt — Loosen to raise mast and tighten to keep
the mast in place when raised to the desired height.
17. Message Strip (OPTIONAL) — A 12 x 43 inch
message strip (Part No. GBBALD1) may be attached
to the balloon. The message strip can be purchased
separately.
18. Zipper — Zips up balloon to completely close it when
lamp is in place.
19. Lamp Holder — Holds lamp in place. Lamp is screwed
into socket.
20. Lamp/Balloon Bolt — Used to tighten mast when
attached to the lamp/balloon assembly.
21. Fan Motor (Blower) — Inflates the balloon as soon
as power is applied to the GBC.
22. Lamp — 1000 watt metal halide bulb with pure white
light for maximum illumination.
23. Lamp Guard — Protects the lamp from being hit by
objects and balloon material from touching lamp.
WARNING
When raising the mast, always be on the lookout for
overhead obstructions.
Go to Discount-Equipment.com to order your parts

PAGE 16 — GBC LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #2 (10/07/19)
SETUP
1. Set the GBC cart on a firm level surface where there
is enough space around the cart for the outriggers to
be deployed.
2. Insert the T-handle into the handle holder on the cart.
Tighten with the wing bolt. See Figure 4.
Figure 4. T-Handle Installation
3. Insert the mast into the mast holder and secure with
lever as shown in Figure 5.
Figure 5. Inserting the Mast Into Holder
4. If desired, attach an optional extension pole to the top
of the mast as shown in Figure 6.
Figure 6. Extension Pole Attachment
T-HANDLE
HANDLE
HOLDER
WING
BOLT
WASHER
MAST
LEVER
HOLDER
EXTENSION
POLE
BOLT
5. Insert the balloon assembly into the mast. Tighten the
T-bolt securely. See Figure 7.
Figure 7. Installing the Balloon
6. Unsnap the three buttons on the bottom of the balloon
cover and unzip the cover. See Figure 8.
Figure 8. Unzipping Balloon Cover
7. Fold the balloon cover into itself and zip it up. See
Figure 9.
Figure 9. Folding Balloon Cover
T-BOLT
MAST
BALLOON
PROTECTIVE
COVER
ZIPPER
BUTTON
FOLD PROTECTIVE
COVER INTO ITSELF
BALLOON
FULLY
EXPOSED
ZIPPER
Go to Discount-Equipment.com to order your parts

GBC LIGHTING SYSTEM • OPERATION AND PARTS MANUAL —REV. #2 (10/07/19) — PAGE 17
SETUP
8. Secure the power cable by hooking it to the eyelet on
the bottom of the balloon as shown in Figure 10.
Figure 10. Securing Cable with Hook
9. Release the buckle on the belt holding the balloon
together. See Figure 11.
Figure 11. Releasing Buckle
CABLE HOOK
BUCKLE
Go to Discount-Equipment.com to order your parts

PAGE 18 — GBC LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #2 (10/07/19)
OPERATION
APPLYING PARKING BRAKE
1. Step on the brake pedal while pulling on the T-handle
until the brake pedal is all the way down. See Figure 12.
Figure 12. Applying Brake
RELEASING PARKING BRAKE
1. Step on the brake pedal, hold then release. See Figure
13.This will disengage the braking mechanism and will
allow the GBC to be moved.
Figure 13. Releasing Brake
BRAKE
BRAKE
RELEASE
DEPLOYING OUTRIGGER
1. Pull up the counterweight that holds the outrigger
in place and pull the outrigger all the way out. See
Figure 14.
Figure 14. Deploying Outrigger
2. Pull the outrigger down until it touches the ground. Pull
down counterweight to lock the outrigger in place. See
Figure 15.
Figure 15. Locking Deployed Outrigger
OUTRIGGER
COUNTERWEIGHT
PULL OUTRIGGER
TO GROUND
PULL DOWN
COUNTERWEIGHT
Go to Discount-Equipment.com to order your parts

GBC LIGHTING SYSTEM • OPERATION AND PARTS MANUAL —REV. #2 (10/07/19) — PAGE 19
OPERATION
STOWING OUTRIGGER
1. Pull up the counterweight to unlock the outrigger and
pull up outrigger. See Figure 16.
Figure 16. Stowing Outrigger
2. Push in outrigger until it is all the way in and pull down
counterweight to lock it in place. See Figure 17.
Figure 17. Locking Stowed Outrigger
PULL UP
OUTRIGGER
PULL UP
COUNTERWEIGHT
PUSH IN
OUTRIGGER
PUSH IN
OUTRIGGER
RAISING THE MAST
1. Raise the second mast to the desired height and tighten
the T-bolt securely. See Figure 18.
Figure 18. Raising the Second Mast
2. To raise the mast higher, raise the third mast until the
lock/release tab pops out. The tab will automatically
rest on the second mast. See Figure 19.
Figure 19. Raising the Third Mast
DANGER
ALWAYS make sure the area above
the lighting system is open and clear
of overhead power lines and other
obstructions. Contact with overhead
power lines or other obstructions could
result in equipment damage, electrical
shock, electrocution and even death.
CAUTION
When raising or lowering the mast, keep hands and
fingers clear of the mast sections to prevent hand and
fingers from getting pinched.
T-BOLT
SECOND
MAST
THIRD
MAST LOCK/
RELEASE
TAB
Go to Discount-Equipment.com to order your parts

PAGE 20 — GBC LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #2 (10/07/19)
LOWERING THE MAST
1. Loosen the T-bolt holding the second mast and push
mast all the way down. Tighten T-bolt securely. See
Figure 20.
Figure 20. Lowering Second Mast
2. Push the lock/release tab on the third mast to release
it and lower third mast. See Figure 21.
Figure 21. Lowering Third Mast
APPLYING POWER
1. Before applying power, make sure that the Power
ON/OFF switch (Figure 22) is in the OFF position.
Figure 22. ON/OFF Switch
T-BOLT
SECOND
MAST
THIRD
MAST
LOCK/
RELEASE
TAB
01
POWER
ON/OFF
SWITCH
OPERATION
2. Connect the AC power cable to the 120 VAC receptacle
on the generator used. See Figure 23.
Figure 23. Connecting to Power Source
3. Start the generator as indicated in the generator
manual.
4. Turn on the Power ON/OFF switch (Figure 22). The
balloon will start to inflate and the lamp will turn on.
DIMMING THE LAMP
1. Slightly unzip the bottom of the balloon to gain access
to the dimmer switch (Figure 24).
Figure 24. Unzipping Balloon
2. Press the dimmer switch lightly (Figure 25). The LED
will blink.The lamp should dim to about 75% brightness.
Figure 25. Dimmer Switch
20A
120V
120 VAC
RECEPTACLE
POWER
CABLE
TYPICAL
GENERATOR
FRONT PANE
L
ZIPPER
BALLOON
01
DIMMER
SWITCH
Go to Discount-Equipment.com to order your parts
