MULTIQUIP ESSICK EM-700S User manual

PARTS AND OPERATION MANUAL
PLASTER / MORTAR MIXERS
EM-700S
EM-700P
© COPYRIGHT 2001, MULTIQUIP INC.
Revision #8 (03/17/06)
Go to Discount-Equipment.com to order your parts

Discount-Equipment.com is your online resource for quality parts & equipment.
Florida: 561-964-4949 Outside Florida TOLL FREE: 877-690-3101
Need parts?
Click on this link: http://www.discount-equipment.com/category/5443-parts/ and
choose one of the options to help get the right parts and equipment you are looking
for. Please have the machine model and serial number available in order to help us
get you the correct parts. If you don’t find the part on the website or on one of the
online manuals, please fill out the request form and one of our experienced staff
members will get back to you with a quote for the right part that your machine needs.
We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman,
Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto,
Power Blanket, Nifty Lift, Atlas Copco, Chicago Pneumatic, Allmand, Miller Curber, Skyjack,
Lull, Skytrak, Tsurumi, Husquvarna Target, Stow, Wacker, Sakai, Mi-T-M, Sullair, Basic,
Dynapac, MBW, Weber, Bartell, Bennar Newman, Haulotte, Ditch Runner, Menegotti,
Morrison, Contec, Buddy, Crown, Edco, Wyco, Bomag, Laymor, EZ Trench, Bil-Jax, F.S.
Curtis, Gehl Pavers, Heli, Honda, ICS/PowerGrit, IHI, Partner, Imer, Clipper, MMD, Koshin,
Rice, CH&E, General Equipment ,Amida, Coleman, NAC, Gradall, Square Shooter, Kent,
Stanley, Tamco, Toku, Hatz, Kohler, Robin, Wisconsin, Northrock, Oztec, Toker TK, Rol-Air,
APT, Wylie, Ingersoll Rand / Doosan, Innovatech, Con X, Ammann, Mecalac, Makinex, Smith
Surface Prep,Small Line, Wanco, Yanmar

PAGE 2 — ESSICK EM-700S & 700P — PARTS & OPERATION MANUAL — REV.#8 (03/17/06)
Go to Discount-Equipment.com to order your parts

PAGE 4 — ESSICK EM-700S & 700P — PARTS & OPERATION MANUAL — REV.#8 (03/17/06)
TABLE OF CONTENTS
NOTE: Specification and part number
are subject to change without notice.
Here's How To Get Help.......................................... 3
Table Of Contents ...................................................4
Parts Ordering Procedures ..................................... 5
Rules for Safe Operation & Safety Decals.............. 6
Warranty.................................................................. 7
ESSICK — 700S & 700P
Operations ......................................................... 8-11
Specifications ........................................................ 12
Explanation Of Codes In Remarks Column .......... 14
Suggested Spare Parts......................................... 15
Drum Head and Paddle Shaft Assembly.......... 16-17
Steel Drum (S) .................................................18-19
Polyethylene Drum (P) ..................................... 20-21
Gas Engines, Pulleys & Cab Assembly............ 22-23
Electric Motor & Pulleys ................................... 24-25
Axle & Wheel Group......................................... 26-27
Terms and Conditions Of Sale — Parts ................ 28
Go to Discount-Equipment.com to order your parts

PAGE 6 — ESSICK EM-700S & 700P — PARTS & OPERATION MANUAL — REV.#8 (03/17/06)
RULES FOR SAFE OPERATION & SAFETY DECALS
The safety instruction decal is P/N EM948501
SAFETY INSTRUCTIONS
1. Do not operate or service this machine before reading the operating and maintenance manual.
2. Keep all inexperienced and/or unauthorized people away from equipment at all times.
3. Do not operate this equipment unless all guards and safety devices are attached and in place.
4. Keep this equipment in safe operating condition at all times.
5. Caution must be exercised while servicing this equipment.
Rotating and moving parts can cause injury if contacted.
6. Stop engine and allow to cool before adding fuel or oil.
7. Stop engine when leaving equipment.
8. Block unit when parking on a slope.
9. Unauthorized equipment modifications will void all warranties.
   Ñ    Ñ , 
■ Do not operate or service this equipment
before reading the operating and
maintenance instructions manual or serious
injury may result.
■ Do not operate this equipment unless all
guards and safety devices are attached and
in place.
■ Stop the engine when leaving the
equipment.
■ Blockthe unit when leavingorwhenusing
on a slope
■ Maintain this equipment in a safe
operating condition at all times.
■ Cautionmustbeexercisedwhileservicing
this equipment. Rotating and moving parts
can cause injury if contacted.
■ Stop the engine before servicing, adding
fuel and oil.
■ When towing, an adequate safety chain
mustbefastenedtotheframe,refertopage9.
■ Keep all inexperienced and unauthorized
peopleawayfrom the equipment at alltimes.
■ Unauthorizedequipment modifications will
voidallwarranties.
■ Check all fasteners periodically for
tightness.Alsocheck towing tonguebolt,lock
nut and wheel lug nuts for wear.
■ Wear safety glasses at all times when
workingaroundmachinery.
■ Stop the engine and disconnect the spark
plug before allowing anybody’s hands in the
mixingdrum.
■ Never pour or spray water over the engine
orelectricmotor.
■ Always stand clear of dump handle when
mixer is in operation. Any binding of material
betweenthe mixer bladesanddrumwillcause
drum and handle to quickly move in the
dischargeposition.
The safety instruction decals shown must be on all Essick Mixers
Caution Decal is:
P/N EM948423
CAUTION!CAUTION!
CAUTION!CAUTION!
CAUTION!
SHUT OFF ENGINE BEFORESHUT OFF ENGINE BEFORE
SHUT OFF ENGINE BEFORESHUT OFF ENGINE BEFORE
SHUT OFF ENGINE BEFORE
PUTTING HANDS IN MIXING DRUMPUTTING HANDS IN MIXING DRUM
PUTTING HANDS IN MIXING DRUMPUTTING HANDS IN MIXING DRUM
PUTTING HANDS IN MIXING DRUM
Go to Discount-Equipment.com to order your parts

ESSICKEM-700S & 700P— PARTS &OPERATION MANUAL— REV. #8(03/17/08) — PAGE7
WARRANTY
Thereare nowarranties,expressorimplied,madebyMultiquip
Inc. hereunder on Products manufactured or distributed by it
exceptthewarrantyagainstdefectsinmaterialandworkmanship
on new Products to the original purchaser, as hereinafter set
forth.
Multiquip Inc. warrants Products manufactured by it to be free
from defects in material and workmanship under normal and
properuseandservicing for the periods specified onthebottom
ofthis page.Warrantyontheenginessupplied with theProducts
islimitedto the warrantyextendedbythe engine manufacturer.
MultiquipInc.’soleobligationunderthiswarrantyislimitedtothe
replacement or repair, at its Carson, California facility, or such
authorized facility, of only such part or parts thereof as shall
appeartoMultiquip Inc.upon inspection atsuchfacility, tohave
beendefectiveinmaterial and workmanship.
Astatement givingmodelandserial numberoftheProduct, date
ofsale to originalpurchaserand date anddescription of failure
shallaccompanyall parts.
Anypart orparts determinedbyMultiquipInc.tobedefectivewill
bereplacedfreeof charge,F.O.B.Carson,California.Returned
parts subject to warranty must be shipped prepaid to Multiquip
Inc.within30daysfromthedatethedefectivepartorparts were
removed.Thiswarrantydoesnotapply toanypartor partswhich
havebeen subject toabuseor unauthorized repairs
WarrantywithrespecttoProducts,componentsandaccessories
not manufactured by Multiquip Inc. is limited to the warranty
extendedbythemanufacturerofthoseitems.
There are no warranties, express or implied, in addition to the
above except as may be provided in writing by Multiquip Inc.
MULTIQUIPINC.SHALLNOT BELIABLEFORANYSPECIAL,
INDIRECTORCONSEQUENTIALDAMAGES.
THEFOREGOINGWARRANTIESAREINPLACEANDINLIEU
OF ALL WARRANTIES OF MERCHANTABILITY AND
FITNESS AND SETS FORTHTHE ENTIRE OBLIGATION OF
MULTIQUIP INC.
To avoid misrepresentations with respect to Products sold
hereunder, the Dealer agrees that no warranties, or other
operatingguarantiesonanyProductscoveredbythisAgreement
shallbe made in excessofthose made byMultiquipInc.
Multiquip Inc.Warranty Periods:
EM-700.......................... 12 months
Go to Discount-Equipment.com to order your parts

PAGE 8 — ESSICK EM-700S & 700P — PARTS & OPERATION MANUAL — REV.#8 (03/17/06)
EM-700S & 700P — OPERATIONS
GENERAL
The Essick EM-700 and EM-900 Series plaster and mortar
mixersarequalitymixersthathave a batch capacity of 2.5 and
3.5bagsrespectively.Withpropercare,theywillgivecontinuous
serviceyear-after-year.
GASOLINE ENGINE CARE
For care and operation of the gasoline engine, refer to the
enginemanufacturer’soperatinginstructionsfurnishedwith the
engine. We recommend draining and refilling the engine
crankcase at least every thirty hours of operation. Check the
engine oil level daily.
ELECTRIC MOTOR CARE
For lubrication care and operation of the electricmotor, referto
yourelectric motorinstructionbookletfurnishedwiththemotor.
Protect the electric motor from dust as much as possible and
keep ventilating openings clean. Do not spray water on the
electricmotor.
Refertothefollowingchart.For recommend plug sizes.
CONTROLS
KILL SWITCH: (Gasoline Engine Only) Located onthe sideof
theenginecover.
ENGINETHROTTLE AND CHOKE CONTROLS: Pleaserefer
totheengineownersmanualforspecificinstructions.Theelectric
motor switch ( electric motor only) located on the motor — is
usedtostart and stopthe mixer.
DUMP LATCH:To dump the tub, grasp the dump handle and
liftthedumplatch,thenrotatethetubtodischargethemix.After,
discharge,returnthetub to the vertical mixing position.
CLUTCH
The paddle shaft and mixing blades are engaged and
disengaged by tightening and loosening the drive belts with a
spring loaded idler pulley. To engage the clutch, rotate the
lever locates at the front of the mixer counterclockwise. The
spring maintains the correct belt tension. To disengage the
clutch, rotate the lever clockwise against the lever stop. The
engine base is slotted to adjust for belt wear and to bring the
idlerpulley into operatingrange.
CAUTION: Stop the engine before allowing anybody to put
their hands in the mixing drum.
WHEELBEARINGS
After every 3 months of operation, remove the hub dust cap
andinspect the wheelbearings.Onceayear,orwhen required,
disassemble the wheel hubs remove the old grease and
repackthe bearings forcinggreasebetween rollers, coneand
cage with a good grade of high speed wheel bearing grease
(never use grease heavier than 265 A.S.T.M.penetration“No.
2.”) Fillthewheel hub with greaseto the insidediameterof the
outer races and also fill the hub grease cap.Reassemble the
hub and mount the wheel.Then tighten the adjusting nut, at
thesame time turn thewheelin both directions,untilthere is a
slight bind to be sure all the bearing surfaces are in contact.
Thenback-offtheadjustingnut1/6 to 1/4 turn or to the nearest
locking hole or sufficiently to allow the wheel to rotate freely
withinlimitsof.001"to.010"endplay.Lockthenutatthisposition.
Installthe cotter pin anddustcap, and tighten allhardware.
ROTOM Ø1TLOV511 007ME Ø1TLOV032 009ME
ESROH REWOP
PACLIATGIP /AMEN KCISSE YDOBNNOC /AMEN KCISSE PACLIATGIP /AMEN KCISSE YDOBNNOC /AMEN KCISSE
PH3&½1 545049/P03-5L645049/R03-5L055049/P51-6L155049/R51-6L
Go to Discount-Equipment.com to order your parts

ESSICKEM-700S & 700P— PARTS &OPERATION MANUAL— REV. #8(03/17/08) — PAGE9
EM-700S & 700P — OPERATIONS
PADDLE SHAFT BEARING
The paddle shaft in the Essick Mixer rotates in sealed ball
bearings requiring no additional lubrication.
BEARING BRACKET
Greasethebearingbracket every month.
COUNTERSHAFT
The countershaft rotates on two self-aligned pillow block
bearings.Greasetheseevery40hoursusing grade #1 Lithium
Basegrease.
GEAR ALIGNMENT
The countershaft and driven pinion are mounted on a slotted
base.To align gears, loosen pillow block mounting bolts and
movethemuntil the necessaryalignment hasbeenmade.
GEAR LUBRICATION
The surface of the pinion and the bull gear should be very
lightly greased every 250 hours.
IMPORTANT! AVOID OVER-GREASING.
EXCESS GREASE WILL ACCUMULATE
CONTAMINATES AND CAUSE
PREMATUREWEAR.
IMPORTANT — DRUM HEAD SEAL CARE
Oneachendofthemixingdrumisadrumhead containing self
adjusting paddle shaft seals.These seals consist of packing
rings, split glands and spring actuated adjusters. A properly
maintained seal prevents material from working around the
paddle shaft, causing excessive wear. The following is a
suggested procedure of maintenance for protection of the
paddleshaft and bearings:
A. Keep the drum head clean of plaster built up, so the spring
adjusterswill be free towork.
B.Replace withonenewringofpackingandwaterproofgrease
whensplitglandorpressureplateisabout tobottomout against
theendof the drum.
New Packing
When the old packing is to be completely replaced, coat shaft
and packing generously with a good grade of waterproof
grease and insert packing rings. Tighten the two spring
adjuster nuts on each end until the spring is compressed to
1¾inchesor the top oftheadjustingnutis even with thetopof
thedrumhead.
Also, whenever the paddle shaft is removed, new waterproof
greaseshouldbe packed around the ballbearingsinthe drum
heads before reinstalling the shaft.Fill the cavity completely.
DRUM GRILL
The drum opening is covered by a steel grill that is hinged for
easy cleaning. This grill should be closed at all times when
mixer is in use. Do not remove the grill or grill opening bar.
Keep the grill clean by washing it down daily.
CAUTION: Stop the engine before allowing anybody to put
Go to Discount-Equipment.com to order your parts

PAGE 10 — ESSICK EM-700S & 700P — PARTS & OPERATION MANUAL — REV.#8 (03/17/06)
BOLT & NUT
DRAWBAR
STEP 1
CONNECTORLINK
FRAME ANGLE
FRAME GUSSET
INSERT CHAINTHROUGH
THE HOLE
DRAWBAR
BOTTOM CONNECTORLINK
REMOVE EXCESS
CHAIN(SLACK)
STEP 3
STEP 2
EM-700S & 700P — OPERATIONS
theirhands in the mixingdrum.
TOWING — Before towing, check with local and state
laws for proper compliance.
The tow bar and chain must be properly attached to the mixer
and towing vehicle prior to towing. Refer to the following
installationinstruction:
Step 1. InserttheDrawBarintothemainframe.Secure,utilizing
the¾" bolt(grade5)andnylocknut.Tightento100 footpounds.
Step 2. Installthechainthroughtheholelocatedbetweenthe
frame gusset and frame angle. Loop the chain together and
placeunderthe DrawBar.Secure with connector link.
Step 3. Extend the chain along the length of the Draw Bar,
remove excess chain (slack) and secure to bottom connector
link. Secure the chain to the towing vehicle, using the
connector link.
NOTE: Itiscriticalthatthelengthofchainbeproperlyadjusted
to prevent the Draw Bar and front mixer stand from
droppingtothe ground (contact)intheeventtheDraw
Bar becomes disconnected from the towing vehicle.
DRAWBAR
VEHICLE
CONNECTORLINK
BALL HITCH COUPLER
1. Check vehicle hitch, ball, and couplerfor signs ofwear or
damage. Replace any parts that are worn or damaged
beforetowing.
2. Use onlythe2"ball diameterasindicatedonyourcoupler.
Use of any other ball diameter will create an extremely
dangerousconditionwhichcanresultinseparationofthe
coupler and ball or ball failure.
3. Be sure the coupler is secured to the hitch ball and the
locklever is downtight and locked.
Rechecktightnessagain after towing about50miles.
4. Check that trailer safety chainsareproperlyconnected.
DANGER If housing is deformed,
replace complete coupler.
USE ONLY GENUINE
FULTON REPAIR KITS.
DANGER BEFORETOWING
RECOMMENDEDMAINTENANCE
1. Smear ball socket and clamp face with chassis grease.
Periodically oil pivot points and solutions surfaces of
couplerwithSAE30wt.motoroil.
2. When parking or storing yourtrailer.Keep the coupler off
the ground so dirt will not build up in the ball socket.
SAFETY CHAIN .........................................P/N13363
CONNECTOR LINK ...................................P/N 01004
Go to Discount-Equipment.com to order your parts

ESSICKEM-700S & 700P — PARTS& OPERATION MANUAL— REV. #8(03/17/08) — PAGE11
2) POLYETHYLENE DRUM MIXERS
Thepoly blade shouldcomeascloseas possibletothesurface
without touching. If material builds up on the drum, you may
use a rubber mallet to dislodge the material without adverse
effect to the drum.
IMPORTANT NOTICE
EPOXY COMPATIBILITY — There are some expoxies and
other chemicals used in certain applications that are not
compatible with polyethylene tubs.
Since Whiteman Industries cannot control the end user’s
application of this product, we will not assume responsibility
for the resulting damages when exposed to incompatible
chemicals.
CLEANING — BLADE ADJUSTMENTS
Alwaysdisconnectthesparkplugwirebeforecleaningtheinside
ofthedrum.
Neverpour or spray wateroverthe gasoline engine orelectric
motor.
For consistent performance, long life and high quality mixing,
thoroughly clean the mixer inside and out at the end of each
day’soperation.To preventlumpsof driedmortar fromforming
andcontamination of futurebatches, do not allowa buildup of
materials to form on the blades or anywhere inside the drum.
Thefollowing is the recommendedwiper blade adjustments:
1) STEEL DRUM MIXERS
SIDE SCRAPERSIDE SCRAPER
SIDE SCRAPERSIDE SCRAPER
SIDE SCRAPER
END SCRAPEREND SCRAPER
END SCRAPEREND SCRAPER
END SCRAPER
EM-700S & 700P — OPERATIONS
Go to Discount-Equipment.com to order your parts

PAGE 12 — ESSICK EM-700S & 700P — PARTS & OPERATION MANUAL — REV.#8 (03/17/06)
EM-700S & 700P — SPECIFICATIONS
EM-700S SPECIFICATIONS
MODEL U.S.(inch) METRIC
CAPACITY ....................................................7 CUBIC FEET ....................................................... 198 LITERS
BAG CAPACITY .............................................1½ - 2½ ............................................................ 1½ - 2½
WEIGHT (appROX.)......................................792 LBS. ............................................................. 357 KG.
L XW XH ..................................................71 X50 X56 IN. .................................................. 180 X127 X142 CM.
LENGTH W/TOW BAR ......................................98 IN. ................................................................. 248 CM.
HEIGHT W/DUMP HANDLE ................................73 IN. ................................................................. 185 CM.
DISCHARGE HEIGHT.......................................21 IN. ................................................................. 53 CM.
DRIVE .........................................................V-BELT TO GEAR ..................................................... —
DUMP ACTION ..............................................MANUAL ............................................................... —
EM-700P SPECIFICATIONS
MODEL U.S.(inch) METRIC
CAPACITY ....................................................7 CUBIC FEET ....................................................... 198 LITERS
BAG CAPACITY .............................................1½ - 2½ ............................................................ 1½ - 2½
WEIGHT (APPROX.).......................................691 LBS. ............................................................. 357 KG.
L XW XH ..................................................71 X50 X56 IN. .................................................. 180 X127 X142 CM.
LENGTH W/TOW BAR ......................................98 IN. ................................................................. 248 CM.
HEIGHT W/DUMP HANDLE ................................73 IN. ................................................................. 185 CM.
DISCHARGE HEIGHT.......................................21 IN. ................................................................. 53 CM.
DRIVE .........................................................V-BELT TO GEAR ..................................................... —
DUMP ACTION.............................................MANUAL .............................................................. —
NOTE: In accordance with our established policy of constant improvement, we reserve the right to amend these specifications at anytime without notice.
Go to Discount-Equipment.com to order your parts

ESSICKEM-700S & 700P — PARTS& OPERATION MANUAL— REV. #8(03/17/08) — PAGE13
NOTE PAGE
Go to Discount-Equipment.com to order your parts

PAGE 14 — ESSICK EM-700S & 700P — PARTS & OPERATION MANUAL — REV.#8 (03/17/06)
EXPLANATION OF CODE IN REMARKS COLUMN
How to read the marks and remarks used in this parts book.
Section 1: Items Found In the “Remarks”Column
Serial Numbers-Where indicated, this indicates a serial
number range (inclusive) where a particular part is used.
Model Number-Where indicated, this shows that the
corresponding part is utilized only with this specific model
number or model number variant.
Section 2: Items Found In the“Remarks”Column
SerialNumbers-Whereindicated,thisindicatesa serial number
range(inclusive) where aparticularpart is used.
Model Number-Where indicated, this shows that the
correspondingpartisutilizedonlywiththisspecificmodelnumber
ormodelnumber variant.
Section 3: Items Found In the“Items Number”Column
Allpartswithsame symbol in the number column,*,#,+, %, or
■
,belongto the same assembly orkit.
Note: If more than one of the same reference number is listed,
thelast one listed indicatesnewest(or latest) part available.
NOTE
If more than one of the same reference number is
listed,the last onelistedindicatesnewest(orlatest)
partavailable.
NOTE
The contents of this catalog are
subjecttochangewithout notice
.
Go to Discount-Equipment.com to order your parts

ESSICKEM-700S & 700P — PARTS& OPERATION MANUAL— REV. #8(03/17/08) — PAGE15
EM-700S & 700P — SUGGESTED SPARE PARTS
EM-700S/P
1 to 4 Units
Qty.P/N Description
3 .........EM505834........... V-BELT
3 .........EM507846........... V-BELT,w/ELECTRICMOTOR
6 .........491010 ................ LATCHASSY
3 .........EM203010........... BLADE KIT STEEL DRUM
3 .........EM204624........... BLADE KIT POLY DRUM
12 .......EM200301........... PACKINGRING
4 .........EM200794........... SPRING
4 .........EM200286........... SPECIAL BOLT
1 .........3351.................... PINIONGEAR
EM-700S/P
5+ Units
Qty.P/N Description
5 .........EM505834........ V-BELT
5 .........EM507846........ V-BELT,w/ELECTRICMOTOR
10 .......491010 ............. LATCHASSY
5 .........EM203010........ BLADE KIT (700S) STEEL DRUM
5 .........EM204624........ BLADE KIT (700P) POLY DRUM
24 .......EM200301........ PACKINGRING
8 .........EM200794........ SPRING
8 .........EM200286........ SPECIALBOLT
2 .........EM902153........ BEARING
1 .........EM940734........ SWITCH, ON/OFF
1 .........509171 ............. DUMP HANDLE,POLYDRUM
2 .........3351................. DRIVEN PINON GEAR
1 .........EM201537........ DUMP HANDLE, STEEL DRUM
2 .........3065................. SEAL,AXLE
2 .........3469................. DUST CAP, AXLE
2 .........EM903049........ BEARING CONE UPTO S/N9896000
2 .........EM903113........ BEARING CONE STARTINGS/N 2080000
2 .........EM903012........ BEARING CUP
NOTE
Part numbers on this Suggested
Spare Parts List may supercede/
replace the P/N shown in the text
pages of this book.
Go to Discount-Equipment.com to order your parts

PAGE 16 — ESSICK EM-700S & 700P — PARTS & OPERATION MANUAL — REV.#8 (03/17/06)
EM-700S & 700P — DRUM HEAD AND PADDLE SHAFT ASSY
PADDLE SHAFT ASSEMBLY
TOW END
DRUM HEAD
26
25 27
28
Go to Discount-Equipment.com to order your parts

ESSICKEM-700S & 700P — PARTS& OPERATION MANUAL— REV. #8(03/17/08) — PAGE17
EM-700S & 700P — DRUM HEAD AND PADDLE SHAFT ASSY
DRUM HEAD AND PADDLE SHAFT ASSY
DRUM HEAD PARTS
NO. PART NO. PART NAME QTY.REMARKS
1 EM507274 PADDLE SHAFT 1
2 EM200297 U-BOLT 2
EM968011 NUT HEX ½-13 4
3 EM200292 U-BOLT INSERT 4
4 EM200018 COLLAR 1
5 EM902153 BEARING 2
6 EM507720 DUMPBEARING .................................................................... 2 ................ FROM S/N 98624071
6 500076 DUMPBEARING .................................................................... 2 ................ FROM S/N 9862400TO 9862470
7 EM916019 GREASEZERK ...................................................................... 2 ................ REPLACES491705
8 EM200288 ADJUSTINGPLATE 2
9 EM200286 SPECIAL BOLT 4
10 EM200285 PACKING GLAND HALF 4
11 EM200303 FOLLOWER 2
12 EM200301 PACKING RING 12
13 EM201648 DRUM HEAD .......................................................................... 2 ................ FROM S/N 98624071
13 EM507272 DRUM HEAD .......................................................................... 2 ................ FROM S/N 9862400TO 9862470
14 EM200794 SPRING 4
15 EM200287 ADJUSTING NUT 4
16 EM966048 BOLT 8
PADDLE SHAFT ASSEMBLY
NO. PART NO. PART NAME QTY.REMARKS
16 EM202899 PADDLE ARM-TOWEND 1
17 EM202897 PADDLE ARM-CENTER 1
18 EM202898 PADDLE ARM-ENGINE END 1
19 EM202896 PADDLE ARM-CENTER 1
20*# EM202928 TOPSTEEL BLADE 4
21*EM923638 EM202927 DRUM END STEEL BLADE2
22*EM202929 TOP RUBBER BLADE (STEEL) DRUM ONLY 4
22# EM507497 TOP PLASTIC BLADE (POLY) DRUM ONLY 4
23# EM507496 DRUM END PLASTIC BLADE (POLY) DRUM ONLY 2
23*EM202926 DRUM END RUBBER BLADE (STEEL) DRUM ONLY 2
25 EM963110 BOLT ½-13 X 3-3/4 1
26 EM923638 LOCKWASHER½ 1
27 EM968011 HEX NUT ½-13 1
28 EM507251 SPACER,BULL GEAR 1
EM203010 BLADEKIT, (STEEL)DRUM ONLY ......................................... 1 ................ INCLS w/*AND MTG.& HDWR
EM204624 BLADEKIT, (POLY)DRUMONLY............................................ 1 ................ INCLS w/# AND MTG.& HDWR
EM203029 HARDWAREKIT, (RUBBER/POLYBLADES) .......................... 1 ................ INCLUDED IN BLADE KITS
Go to Discount-Equipment.com to order your parts

PAGE 18 — ESSICK EM-700S & 700P — PARTS & OPERATION MANUAL — REV.#8 (03/17/06)
EM-700S — STEEL DRUM
STEEL DRUM
110 111
108
109
Go to Discount-Equipment.com to order your parts

ESSICKEM-700S & 700P — PARTS& OPERATION MANUAL— REV. #8(03/17/08) — PAGE19
EM-700S — STEEL DRUM
STEELDRUM
NO. PART NO. PART NAME QTY.REMARKS
100*EM201537 DUMP HANDLE 1
101 EPC-1 TOWINGTONGUE (P.EYE) ................................... 1..............NOLONGERAVAILABLE
101 EBC-1
TOWINGTONGUE (PIN HOL E) ............................. 1 .............. CONTACTDISCOUNT-EQUIPMENT.
101 HBC-1
TOWINGTONGUE (BALL HIT CH) ......................... 1 .............. CONTACTDISCOUNT-EQUIPMENT.
102 EM963580 CAPSCREW .......................................................... 1..............REPLACES 505067
103 EM969038 LOCK NUT ............................................................. 1 ..............REPLACES505069
104*EM203333 DRUMGRILL 1
105*EM507271 GRILL OPEN BAR 1
106+EM507767 DRUM ASSY (STEEL) ............................................ 1..............INCLS. ITEMSw/*
EM507768 DRUM & SHAFT ASSY.(COMPLETE) (STEEL) ..... 1 ..............INCLS.ITEMS w/+AND DRUM HEAD &
PADDLESHAFTASSY
108 EM506309 MAIN FRAME 1
109 507264 CLUTCH LEVER 1
110 EM507421 DUMP LATCH 1
111 EM507835 CLEVISPIN 1
❑ 13363 SAFETY CHAIN 1
❑ 01004 5/16"CONNECTOR LINK 2
❑ ILLUSTRATED ON PAGE 10
Go to Discount-Equipment.com to order your parts

PAGE 20 — ESSICK EM-700S & 700P — PARTS & OPERATION MANUAL — REV.#8 (03/17/06)
124
125
126
127
124
125
EM-700P — POLYETHYLENE DRUM
POLYETHYLENE
DRUM
122 123
128 129
Go to Discount-Equipment.com to order your parts

ESSICKEM-700S & 700P — PARTS& OPERATION MANUAL— REV. #8(03/17/08) — PAGE21
EM-700P — POLYETHYLENE DRUM
POLYETHYLENEDRUM
MODEL EM-700P
NO. PART NO. PART NAME QTY.REMARKS
115*EM506311 PLASTIC DRUMW/OGRATES 1
116 EM507414 SUPPORT REAR 1
117*504534 STATIONARYGRATE 1
118*504535 MOVEABLEGRATE 1
119*507493 GRATE OPEN BAR 1
120*509171 DUMP HANDLE 1
121 EM507413 DRUM SUPPORT 1
EM509603 DRUM & SHAFT ASSY (COMPLETE) (POLY) ........................ 1 ..................... INCLS ITEMS w/* AND HEAD
END & PADDLE SHAFT ASSY
122 EM963610 HHCS 3/8" NC X ¼" G-5 ........................................................ 7 ..................... REPLACES 492376
123 EM969013 LOCK NUT 3/8" NC................................................................ 7 ..................... REPLACES 492583
124 504987 FHCS ¼" NC X 1" G-5 8
125 EM969079 LOCK NUT ¼" NC.................................................................. 8 ..................... REPLACES EM492581
126 505196 3/8 X 1½" HHCS 8
127 505066 3/8" LOCKNUT 8
128 492392 ½" X 1 NC G-5 BOLT 3
129 492584 ½" LOCK NUT 3
Go to Discount-Equipment.com to order your parts
