Whiteman Mixers
Plaster/Mortar and Concrete models

Whiteman Plaster/Mortar Mixers
For the professional contractor!
Whiteman mixers have the features, quality, and
engineering excellence preferred by the contractor and
the equipment rental industry. Our heavy-duty mixers are
reliable, easy to maintain and are available in a full range
of sizes and engine configurations for most any application.
Choose from steel or EasyClean™ polyethylene drums.
Whatever your selection, Whiteman sets the standard.
Available in 7-, 9-, and 12-cubic foot capacities, with
your choice of power and drum materials.
Model WM90S
(9 cu. ft., Steel drum)
Rugged 14-gauge steel
engine covers with punched
ventilation openings for
increased cooling and added
strength.
EasyClean™ polyethylene drums.
(Steel drums also available.)
High-strength cast
iron paddle arms with
wiper blades for a clean,
uniform mix.
Heavy-duty safety grate
with built-in bag cutter.
Durable paddle shaft of 1.#/4" square
hardened steel. Double-sealed
bearings.
Heavy-duty removable
tow tongue made of
tough schedule 80 steel.
Available with loop coupler,
2" ball coupler or pin-type
coupler.
Solid 1.%/8" solid axle with large
B78x13" tires for smooth towing.
Drum lock allows positive
“mix” and “tow” positions.
Forklift pocket
Model WM90P
(9 cu. ft., Poly drum)
7- and 9-cu.ft. • Steel or Poly Drums

Heavy-Duty Features
7- and 9-cu.ft. • Steel or Poly Drums
Less vibration. Engine is
mounted solid to base,
minimizing vibration.
The engine sits level
— important when
checking oil.
Innovative seal system.
Double-sealed bearings
with greasable shaft seals.
Specially designed seep
hole protects bearings and
warns when seal needs
replacement.
Built to last. Heavy duty safety grid
with auto-open safety bar. Built-in bag
cutter. High strength cast iron paddle
arms with rubber blades provide a
clean, uniform mix.
Wider dump shoot for faster, easier
pours.
Convenient, easy operating
engine engagement lever.
Thick tubular steel
reinforced frame resists
damage, provides superior
strength and proper
dumping clearance.
Double V-belt/gear drive. Idler wheel
provides easy, positive engagement.
Allows larger, heavier mixes. Cast-steel
pulleys increase durability.
*Excludes model WM63

Hydraulic Drive Mixers
12-cu.ft. Plaster/Mortar Mixers • Steel or Poly Drums
Setting the standard for innovation and dependability!
Hydraulic drive...
■ Mixes larger, heavier loads — ideal for high
production requirements and lower slump mixes.
■ Hydraulic dump system — allows high production
with minimal operator fatigue.
■ Greatly reduced maintenance — no mechanical
gears or clutches.
■ Built-in hydraulic safety relief system — immediately
disengages itself in case an object becomes wedged
in the drum. Automatically resets when problem is
corrected.
EasyClean™ polyethylene drums.
(Steel drums also available.)
Rugged 14 gauge steel engine
cover with punched pressed
ventilation openings for increased
cooling and added strength.
High-strength cast-iron paddle
arms with wiper blades for a clean,
uniform mix.
Heavy-duty safety grate
with built-in bag cutter.
Durable paddle
shaft of 1.#/4" square
hardened steel. Double-
sealed bearings with
eight spring loaded
greaseable shaft seals.
Heavy-duty removable
tow tongue made of
tough schedule 80 steel.
Available with loop coupler, 2" ball
coupler or pin-type coupler.
Solid 1.%/8" square axle
with large B78x13" tires for
smooth towing. Suspension
springs standard — less
bounce, less sway.
Model WM120PHD (12 cu. ft.) — hydraulic drive,
hydraulic dump, EasyClean drum — available
with steel drum
Dual controls
— mixing blades
and optional
hydraulic dump.

Multiquip Concrete Mixers
4-, 6- and 9-cu.ft. • Steel or Poly Drums
The ultimate in heavy-duty concrete
mixers.
Available in 4-, 6- and 9-cubic foot capacities, with your
choice of power and drum materials.*
Rugged 14-gauge steel
engine covers with punched
ventilation openings for
increased cooling and added
strength.
Easy loading drum — wider and lower.
Steel or EasyClean
polyethylene drums.*
Multi-position
dump latch.
Oversized dump
wheel — easier to
discharge material.
Available with loop coupler,
2" ball coupler or pin-type
coupler.
Heavy-duty retractable
tow tongue made of
tough schedule 80 steel.
Axle springs for less
bounce, less sway.**
Large B78x13" tires for
smooth towing to your job.
Model MC94S (9 cu. ft.)
* 4-cubic foot models available with steel drums only.
** Axle springs not available on 4-cubic foot models.
Heavy-duty one-
piece cast iron ring
gear for longer life.
Model MC94P
(9 cu. ft.)
EasyClean models feature polyethylene drums.

Multiquip EasyClean™Mixers
6- and 9-cu.ft. Concrete Mixers
EasyClean makes all the difference...
...but not with an EasyClean
mixer! A few taps with a
rubber mallet and the dried
concrete falls right out!
In all standard steel drum
mixers, this dried concrete
could be a nightmare to
clean out...
BEFORE
BEFORE AFTER AFTER
Model WM120PH (12 cu. ft.)
Model MC94P (9 cu. ft.)
Our in nova t i v e E a s y Cl ea n mi xe r s
incorporate polyethylene drums to put an
end to clean up problems.
If a load of material is allowed to dry in a
steel-drum mixer, removing that material may
take several hours — and more often than
not, drums can be dented or damaged in the
process.
Our tough polyethylene drums can be cleaned
in minutes. A tap with a rubber mallet does the
job — without dents, rust or cracks!

Mix-N-Go Concrete Mixers
The economical choice for small jobs.
The Mix-N-Go Concrete Mixer can mix up to three cubic
feet of material, making it ideal for homeowners and small
contractors.
Available with either a steel or polyethylene drum, the Mix-
N-Go is ideal for small footings and bases, binding block
and concrete patching. It is available with a gasoline engine
or electric motor for operator convenience. It can also be
used as a wheelbarrow to transport concrete, debris and
other material around the job site.
When the job is complete, the compact Mix-N-Go fits neatly
into the trunk of a car.
■Replaceable blades bolted to the drum.
■Choice of steel or polyethylene drums.
■Engine options — Gasoline or ¾ HP, 115 single-phase
UL- and CSA-approved electric motor.*
■Job site convenience — can use standard household
power.
■Mixer stand allows drum to rotate 360 degrees.
■New on/off switch protection — water-resistant and
dust proof.
■Pneumatic tires.
www.multiquip.com
Mix-N-Go Concrete Mixers — Specifications
Water-resistant,
dust-proof on/off
switch
Strong ¾ HP
brushless motor,
UL and CSA
approved
Gearbox; gears
immersed in oil for
long trouble-free
life
Model Drum
Construction
Max. Mixing
Capacity* Engine** Height in. (mm)
Width
in. (mm)
Length
in. (mm)
Stand
Weight
lb. (kg)
Dry
Weight
lb. (kg)
MC3SEA Steel 3.0 cu. ft. ¾ HP, 115V, 1ø
Electric Motor
34
(863.6)
23..%/8
(584.2)
48..!/2
(1219.2)
35
(15.9)
138
(62.6)
MC3PEA Polyethylene 3.0 cu. ft. ¾ HP, 115V, 1ø
Electric Motor
34
(863.6)
23..%/8
(584.2)
48..!/2
(1219.2)
35
(15.9)
138
(62.6)
MC3SBA Steel 3.0 cu. ft. Briggs & Stratton
148cc
34
(863.6)
23..%/8
(584.2)
48..!/2
(1219.2)
35
(15.9)
132
(59.9)
MC3PBA Polyethylene 3.0 cu. ft. Briggs & Stratton
148cc
34
(863.6)
23..%/8
(584.2)
48..!/2
(1219.2)
35
(15.9)
132
(59.9)
* Actual mix capacity may vary depending on aggregate size and mix design.
** Engine power ratings are calculated by the individual engine manufacturer and the rating method may vary among engine manufacturers. Multiquip Inc. and its subsidiary
companies makes no claim, representation or warranty as to the power rating of the engine on this equipment and disclaims any responsibility or liability of any kind
whatsoever with respect to the accuracy of the engine power rating. Users are advised to consult the engine manufacturer’s owners manual and its website for specific
information regarding the engine power rating.

© COPYRIGHT 2012, MULTIQUIP INC.
Rev. (06-12_BD)
MULTIQUIP INC.
POST OFFICE BOX 6254
CARSON, CA 90749
310-537-3700 • 800-421-1244
FAX: [phone]
E-MAIL: [e-mail]
www.multiquip.com
Your Multiquip dealer is:
Whiteman Mixers — Specifications
All features and specifications are subject to change without notice.
* Mixer weight shown is an average; exact weight is dependent upon power source. All mixers available with loop coupler,
2" ball coupler or pin-type coupler.
Heavy duty safety chains are included.
Steel Drum Models Polyethylene Drum Models
Model MC44S MC64S MC94S MC64P MC94P
Capacity — cu.ft. (liters) 4 (110) 6 (165) 9 (248) 6 (165) 9 (248)
Capacity — bags !/3 ½ 1 ½ 1
Power Sources**
0.5 HP 1ø 115V
Elect.
3.5 HP Honda
1.5 HP 1ø 115/230V Elect.
4.8 HP Honda
7.9 HP Honda
1.5 HP 1ø 115/230V Elect.
7.9 HP Honda
1.5 HP 1ø 115/230V
Elect.
4.8 HP Honda
7.9 HP Honda
1.5 HP 1ø 115/230V
Elect.
7.9 HP Honda
Average weight* — lbs. (kg) 495 (225) 685 (311) 810 (367) 685 (311) 800 (363)
Length w/tongue x WxH—
in. (cm)
87x51x54
(221x130x137)
102X51X59
(259X130X150) 106x51x63 (269x130x160) 102X51X59
(259X130X150)
106x51x63
(269x130x160)
Discharge height — in.
(cm) 23 (58) 23 (58) 23 (58) 23 (58) 23 (58)
Drum opening — in. (cm) 16 (40) 17 (43) 19.7 (50) 19 (48) 23.7 (60)
Drum depth — in. (cm) 26 (66) 29 (74) 31 (79) 29 (74) 31 (79)
Tires B78x13 B78x13 B78x13 B78x13 B78x13
Drive V-Belt V-Belt V-Belt V-Belt V-Belt
Dump Action Manual Manual Manual Manual Manual
Concrete Mixers — Steel- and Poly-Drum Models
Model WM45H WM63 WM70S WM90S WM120SHD
(Hydraulic)
Capacity — cu.ft. (liters) 4.5 (113) 6.3 (178) 7 (93) 9 (248) 12 (340)
Capacity — bags ½ 1½ to 2 1½ to 2½ 2½ to 3½ 3½ to 4
Power Sources**
1.0 HP 1ø 115/230V
Electric
4.8 HP Honda
1.5 HP 1ø 115/230V
Electric
4.8 HP Honda
7.9 HP Honda
1.5 HP 1ø 115/230V
Electric
4.8 HP Honda
7.9 HP Honda
3 HP 1ø 230V Electric
7.9 HP Honda 11.7 HP Honda
Drum Material Steel Steel Steel Steel Steel
Average weight* — lbs. (kg) 380 (172) 574 (260) 690 (313) 785 (356) 1,010 (454)
Length w/tongue x WxH— in. (cm) 67x28.5x41
(170x65x104)
92.5x28.5x41
(235x65x104)
98x50x56
(248x127x142)
98x50x59
(248x127x150)
82x51x60
(208x130x152)
Height including handle — in. (cm) 60 (152) 54.6 (1384) 73 (185) 77 (196) 75 (191)
Discharge height — in. (cm) 7.5 (19) 18 (46) 21 (53) 21 (53) 17 (43)
Drive V Belt/Gear V Belt/Gear V-Belt V-Belt Hydraulic
Dump Action Manual Manual Manual Manual Hydraulic Dump
Towable No Yes Yes Yes Yes
Plaster/Mortar Mixers — Steel-Drum Models
Model WM70P WM90P WM120PHD (Hydraulic)
Capacity — cu.ft. (liters) 7 (93) 9 (248) 12 (340)
Capacity — bags 1½ to 2½ 2½ to 3½ 3½ to 4
Power Sources**
1.5 HP 1ø 115/230V
Electric
4.8 HP Honda
7.9 HP Honda
3 HP 1ø 230V Electric
7.9 HP Honda 11.7 HP Honda
Drum Material Polyethylene Polyethylene Polyethylene
Average weight* — lbs. (kg) 690 (313) 785 (356) 1,010 (454)
Length w/tongue x WxH— in. (cm) 98x50x56 (248x127x142) 98x50x59 (248x127x150) 82x51x60 (208x130x152)
Height including handle — in. (cm) 73 (185) 77 (196) 75 (191)
Discharge height — in. (cm) 21 (53) 21 (53) 17 (43)
Drive V-Belt V-Belt Hydraulic
Dump Action Manual Manual Hydraulic Dump
Plaster/Mortar Mixers — Poly-Drum Models
** Engine power ratings are calculated by the individual engine manufacturer and the rating method
may vary among engine manufacturers. Multiquip Inc. and its subsidiary companies makes no claim,
representation or warranty as to the power rating of the engine on this equipment and disclaims any
responsibility or liability of any kind whatsoever with respect to the accuracy of the engine power
rating. Users are advised to consult the engine manufacturer’s owners manual and its website for
specific information regarding the engine power rating.
* Actual mix capacity based on 94lb. bag of Portland cement. May vary depending on aggregate size and mix design.
Connect with us on
